The Ambari management tool for Hadoop offers among other handy tools a comprehensive REST API for cluster administration. Logically a cluster is divided into hosts, services and service components. While the UI might not always has support for all needed scenarios sure the REST API can be used to achieve it. For example moving a master component of a service from one host to another.
In this post we are going to look a little closer at the way the Ambari API can be used to manage Hadoop services. At the end of this post you will find a list of all the currently supported Hadoop services with all the needed master, slave and client components that can be manged and administrated within your HDP stack. Also this posts contains the possible states and state transitions a component might have which could become useful when facing problems like Host config is in invalid state.
The possible states a service component can be in is listed below. To change or get the state of a service component the following API calls can be issued.
|
1
2
3
4
5
6
7
8
|
// Getting the state of the component
curl -k -u admin:admin -H "X-Requested-By:ambari" -i -X GET
http://<HOST>:8080/api/v1/clusters/<CLUSTER_NAME>/hosts/<HOST_FQDN>/host_components/YARN_CLIENT
// Setting the state of the component to INSTALLED
curl -k -u admin:admin -H "X-Requested-By:ambari" -i -X PUT
-d '{"RequestInfo":{"context":"Install YARN_CLIENT"},
"Body":{"HostRoles":{"state":"INSTALLED"}}}'
http://<HOST>:8080/api/v1/clusters/<CLUSTER_NAME>/hosts/<HOST_FQDN>/host_components/YARN_CLIENT
|
Among the need to change the state of a service component a very common issue is the need to actually move one service – most likely a master service – to different host. Users faced with this problems often need to issue the existing API due to a lack of support by the existing UI – at least with older releases of Ambari Web UI. This is an example of moving the OOZIE_SERVER to a new host.
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
|
// Stop the old component by putting it back in state INSTALLED
curl -u admin:admin -H "X-Requested-By:ambari" -i -X PUT
-d '{"RequestInfo": {"context": "Stop Oozie","query":"HostRoles/component_name.in('OOZIE_SERVER')"},
"Body":{"HostRoles": {"state": "INSTALLED"}}}'
http://<HOST>:8080/api/v1/clusters/<CLUSTER_NAME>/hosts
/<OLD_HOST_FQDN>/host_components/OOZIE_SERVER
// Add component to host
curl -u admin:admin -H "X-Requested-By:ambari" -i -X POST -d
http://<HOST>:8080/api/v1/clusters/<CLUSTER_NAME>/hosts
/<NEW_HOST_FQDN>/host_components/OOZIE_SERVER
// Install component by achieving stated INSTALLED
curl -u admin:admin -H "X-Requested-By:ambari" -i -X PUT
-d '{"RequestInfo": {"context": "Install Oozie","query":"HostRoles/component_name.in('OOZIE_SERVER')"},
"Body":{"HostRoles": {"state": "INSTALLED"}}}'
http://<HOST>:8080/api/v1/clusters/<CLUSTER_NAME>/hosts
/<NEW_HOST_FQDN>/host_components/OOZIE_SERVER
// Delete old component
curl -u admin:admin -H "X-Requested-By:ambari" -i -X DELETE
http://<HOST>:8080/api/v1/clusters/<CLUSTER_NAME>/hosts
/<OLD_HOST_FQDN>/host_components/OOZIE_SERVER
// Starting the new component
curl -u admin:admin -H "X-Requested-By:ambari" -i -X PUT
-d '{"RequestInfo": {"context": "Start Oozie","query":"HostRoles/component_name.in('OOZIE_SERVER')"},
"Body":{"HostRoles": {"state": "STARTED"}}}'
http://<HOST>:8080/api/v1/clusters/<CLUSTER_NAME>/hosts
/<NEW_HOST_FQDN>/host_components/OOZIE_SERVER
|
Removing a complete service from the cluster would require all the removal of all it’s components together with the service itself. For example for removing the Knox service we would need to remove the KNOX_GATEWAY component from the cluster, but before let’s get their state:
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
|
// Get service info
curl -u admin:admin -H "X-Requested-by:ambari" -i -k -X GET
http://<HOST>:8080/api/v1/clusters/<CLUSTER_NAME>/services/KNOX/
// Stop component KNOX_GATEWAY
curl -u admin:admin -H "X-Requested-by:ambari" -i -k -X PUT
-d '{"ServiceComponentInfo": {"state": "INSTALLED"}}'
http://<HOST>:8080/api/v1/clusters/<CLUSTER_NAME>/services/KNOX/components/KNOX_GATEWAY
// Stop service KNOX
curl -u admin:admin -H "X-Requested-by:ambari" -i -k -X PUT
-d '{"ServiceInfo": {"state": "INSTALLED"}}'
http://<HOST>:8080/api/v1/clusters/<CLUSTER_NAME>/services/KNOX
// Delete component
curl -u admin:admin -H "X-Requested-by:ambari" -i -k -X DELETE
http://<HOST>:8080/api/v1/clusters/<CLUSTER_NAME>/hosts/<HOST_FQDN>/host_components/KNOX_GATEWAY
// Delete service
curl -u admin:admin -H "X-Requested-by:ambari" -i -k -X DELETE
http://<HOST>:8080/api/v1/clusters/<CLUSTER_NAME>/services/KNOX
|
Possible states of a component:
StateDescription
INITInitial/Clean state.
INSTALLINGIn the process of installing.
INSTALL_FAILEDInstall failed.
INSTALLEDState when install completed successfully.
STARTINGIn the process of starting.
STARTEDState when start completed successfully.
STOPPINGIn the process of stopping.
UNINSTALLINGIn the process of uninstalling.
UNINSTALLEDState when uninstall completed successfully.
WIPING_OUTIn the process of wiping out the install.
UPGRADINGIn the process of upgrading the deployed bits.
DISABLEDDisabled master’s backup state.
UNKNOWNState could not be determined.
Allowed State transitions of a component:
Desired StateStart State
INSTALLED <-INIT, UNINSTALLED, INSTALLED, INSTALLING, STARTED, INSTALL_FAILED, UPGRADING, STOPPING, UNKNOWN, DISABLED
STARTED <-INSTALLED, STARTING, STARTED
UNINSTALLED <-INSTALLED, UNINSTALLED, UNINSTALLING
INIT <-UNINSTALLED, INIT, WIPING_OUT
DISABLED <-INSTALLED, INSTALL_FAILED, UNKNOWN
Services
A Hadoop cluster contains of multiple services that individually have either master, slave or client components. Below you will find a list of all currently supported components as part of a HDP stack divided in master, slave, or client groups. The cardinality notates the number of components that can exist at the same time in one cluster.
Master Services
NameAmbari Component Name
Service
Cardinality
NameNodeNAMENODEHDFS1-2
Secondary NameNodeSECONDARY_NAMENODEHDFS1
ResourceMangerRESOURCEMANAGERYARN1-2
Application Timeline ServerAPP_TIMELINE_SERVERYARN1
HistoryServerHISTORYSERVERMAPREDUCE2 1
Hive MetastoreHIVE_METASTOREHIVE1-2
HiveServer2HIVE_SERVERHIVE1-2
WebHcat ServerWEBHCAT_SERVERHIVE1
HBase MasterHBASE_MASTERHBASE1+
Spark Job History ServerSPARK_JOBHISTORYSERVERSPARK1
Nimbus ServerNIMBUSSTORM1
Storm REST ServerSTORM_REST_APISTORM1
Storm UISTORM_UI_SERVERSTORM1
DRPC ServerDRPC_SERVERSTORM1
Falcon ServerFALCON_SERVERFALCON1
ZookeeperZOOKEEPER_SERVERZOOKEEPER1+ (odd #)
Kafka BrokerKAFKA_BROKERKAFKA1+
Knox GatewayKNOX_GATEWAYKNOX1+
Ranger Admin ServerRANGER_ADMINRANGER1-3
Ranger User SyncRANGER_USERSYNCRANGER1
Ranger Key Management ServerRANGER_KMS_SERVERRANGER_KMS1+
Oozie ServerOOZIE_SERVEROOZIE1
Ganglia ServerGANGLIA_SERVERGANGLIA1
Nagios ServerNAGIOS_SERVERNAGIOS1
Ambari Metrics ServiceMETRICS_COLLECTORAMS1
Zeppelin ServerZEPPELIN_MASTERSPARK / HIVE1
Slave Services
NameAmbari Component Name
ServiceCardinality
DataNodeDATANODEHDFS1+
Journale Nodes for NameNode HAJOURNALNODEHDFS0+ (odd #)
Zookeeper Failover ServiceZKFCHDFS0+
Secondary NameNodeNFS_GATEWAYHDFS0+
Node ManagerNODEMANAGERYARN1+
HBase RegionServerHBASE_REGIONSERVERHBASE1+
Phoneix Query ServerPHOENIX_QUERY_SERVERHBASE0+
Storm SupervisorSUPERVISORSTORM1+
Ganglia Metrics CollectorGANGLIA_MONITORGANGLIAALL
Ambari Metrics CollectorMETRICS_MONITORAMSALL
Clients
NameAmbari Component Name
ServiceCardinality
HDFS ClientHDFS_CLIENTHDFS1+
YARN ClientYARN_CLIENTYARN1+
MapReduce ClientMAPREDUCE2_CLIENTMAPREDUCE21+
Spark ClientSPARK_CLIENTSPARK1+
Falcon ClientFALCON_CLIENTFALCON1+
HBase ClientHBASE_CLIENTHBASE1+
Hive ClientHIVE_CLIENTHIVE1+
HCat ClientHCATHIVE1+
Mahout ClientMAHOUTMAHOUT0+
Oozie ClientOOZIE_CLIENTOOZIE1+
Sqoop ClientSQOOPSQOOP1+
Zookeeper ClientZOOKEEPER_CLIENTZOOKEEPER1+
