/用来标记线程池状态（高3位），线程个数（低29位）
//默认是RUNNING状态，线程个数为0
private final AtomicInteger ctl = new AtomicInteger(ctlOf(RUNNING, 0));
//线程个数掩码位数
private static final int COUNT_BITS = Integer.SIZE - 3;
//线程最大个数(低29位)00011111111111111111111111111111
private static final int CAPACITY   = (1 << COUNT_BITS) - 1;

//（高3位）：11100000000000000000000000000000
private static final int RUNNING    = -1 << COUNT_BITS;
//（高3位）：00000000000000000000000000000000
private static final int SHUTDOWN   =  0 << COUNT_BITS;
//（高3位）：00100000000000000000000000000000
private static final int STOP       =  1 << COUNT_BITS;
//（高3位）：01000000000000000000000000000000
private static final int TIDYING    =  2 << COUNT_BITS;
//（高3位）：01100000000000000000000000000000
private static final int TERMINATED =  3 << COUNT_BITS;
// 获取高三位 运行状态
private static int runStateOf(int c)     { return c & ~CAPACITY; }
//获取低29位 线程个数
private static int workerCountOf(int c)  { return c & CAPACITY; }
//计算ctl新值，线程状态 与 线程个数
private static int ctlOf(int rs, int wc) { return rs | wc; }

    public static ExecutorService newSingleThreadExecutor() {
        return new FinalizableDelegatedExecutorService
            (new ThreadPoolExecutor(1, 1,
                                    0L, TimeUnit.MILLISECONDS,
                                    new LinkedBlockingQueue<Runnable>()));
    }

    /**
     * Lock held on access to workers set and related bookkeeping.
     * While we could use a concurrent set of some sort, it turns out
     * to be generally preferable to use a lock. Among the reasons is
     * that this serializes interruptIdleWorkers, which avoids
     * unnecessary interrupt storms, especially during shutdown.
     * Otherwise exiting threads would concurrently interrupt those
     * that have not yet interrupted. It also simplifies some of the
     * associated statistics bookkeeping of largestPoolSize etc. We
     * also hold mainLock on shutdown and shutdownNow, for the sake of
     * ensuring workers set is stable while separately checking
     * permission to interrupt and actually interrupting.
     */
    private final ReentrantLock mainLock = new ReentrantLock();

/**
     * Checks if a new worker can be added with respect to current
     * pool state and the given bound (either core or maximum). If so,
     * the worker count is adjusted accordingly, and, if possible, a
     * new worker is created and started, running firstTask as its
     * first task. This method returns false if the pool is stopped or
     * eligible to shut down. It also returns false if the thread
     * factory fails to create a thread when asked.  If the thread
     * creation fails, either due to the thread factory returning
     * null, or due to an exception (typically OutOfMemoryError in
     * Thread.start()), we roll back cleanly.
     *
     * @param firstTask the task the new thread should run first (or
     * null if none). Workers are created with an initial first task
     * (in method execute()) to bypass queuing when there are fewer
     * than corePoolSize threads (in which case we always start one),
     * or when the queue is full (in which case we must bypass queue).
     * Initially idle threads are usually created via
     * prestartCoreThread or to replace other dying workers.
     *
     * @param core if true use corePoolSize as bound, else
     * maximumPoolSize. (A boolean indicator is used here rather than a
     * value to ensure reads of fresh values after checking other pool
     * state).
     * @return true if successful
     */
    private boolean addWorker(Runnable firstTask, boolean core) {
        retry:
        for (;;) {
            int c = ctl.get();
            int rs = runStateOf(c);
            // Check if queue empty only if necessary.
            // 6 检查队列是否只在必要的时候为空
            if (rs >= SHUTDOWN &&
                ! (rs == SHUTDOWN &&
                   firstTask == null &&
                   ! workQueue.isEmpty()))
                return false;
      // 7 循环CAS增加线程个数
            for (;;) {
                int wc = workerCountOf(c);
                // 7.1 如果线程个数超过限制 则返回false
                if (wc >= CAPACITY ||
                    wc >= (core ? corePoolSize : maximumPoolSize))
                    return false;
                // 7.2 cas增加线程个数，同时只能有1个线程成功
                if (compareAndIncrementWorkerCount(c))
                    break retry;
               // 7.3 cas失败了，则看线程池状态是否变化了，变化则跳到外层循环重试重新获取线程池状态，否者内层循环重新cas。
                c = ctl.get();  // Re-read ctl
                if (runStateOf(c) != rs)
                    continue retry;
                // else CAS failed due to workerCount change; retry inner loop
            }
        }
    // 8 到这里，说明CAS成功了
        boolean workerStarted = false;
        boolean workerAdded = false;
        Worker w = null;
        try {
          // 8.1 创建Worker
           w = new Worker(firstTask);
            final Thread t = w.thread;
            if (t != null) {
              // 8.2 加独占锁，为了workers同步，因为可能多个线程调用了线程池的execute方法。
                final ReentrantLock mainLock = this.mainLock;
                mainLock.lock();
                try {
                    // Recheck while holding lock.
                    // Back out on ThreadFactory failure or if
                    // shut down before lock acquired.
                    //8.3 重新检查线程池的状态，避免在获取锁前调用了shutdown接口
                    int rs = runStateOf(ctl.get());
                    if (rs < SHUTDOWN ||
                        (rs == SHUTDOWN && firstTask == null)) {
                        if (t.isAlive()) // precheck that t is startable
                            throw new IllegalThreadStateException();
                        // 8.4 添加任务
                        workers.add(w);
                        int s = workers.size();
                        if (s > largestPoolSize)
                            largestPoolSize = s;
                        workerAdded = true;
                    }
                } finally {
                    mainLock.unlock();
                }
                // 8.5 添加成功，则启动线程
                if (workerAdded) {
                    t.start();
                    workerStarted = true;
                }
            }
        } finally {
            if (! workerStarted)
                addWorkerFailed(w);
        }
        return workerStarted;
    }
