ECS集群部署大数据环境

简介: 大数据
+关注继续查看


本参考文档使用4节点机器集群进行部署,操作用户为root

·部署Hadoop环境


一、机器初始化

1,绑定机器的网卡和硬盘(此步骤只针对未绑定网卡和硬盘的erdma机器,大部分机器开出来网卡和硬盘是绑定的)

查看如图即为绑定成功。



申请到ecs机器后,需绑定机器的网卡和硬盘。具体步骤如下:

绑定与解绑 rdma 网卡脚本:

bind() {
    echo $1 > /sys/bus/pci/drivers/iohub_sriov/unbind
    echo $1 > /sys/bus/pci/drivers/virtio-pci/bind
}
ubind() {
    echo $1 > /sys/bus/pci/drivers/virtio-pci/unbind
    echo $1 > /sys/bus/pci/drivers/iohub_sriov/bind
}
main() {
    local op=$1
    local bdf=$2
    if [ $bdf == "all" ]; then
    for i in `xdragon-bdf net all`
    do
        eval $op $i
    done
    else
        eval $op $bdf
    fi
}
main $@

绑定与解绑 硬盘 脚本:

bind() {
    echo $1 > /sys/bus/pci/drivers/iohub_sriov/unbind
    echo $1 > /sys/bus/pci/drivers/virtio-pci/bind
}
ubind() {
    echo $1 > /sys/bus/pci/drivers/virtio-pci/unbind
    echo $1 > /sys/bus/pci/drivers/iohub_sriov/bind
}
main() {
    local op=$1
    local bdf=$2
    if [ $bdf == "all" ]; then
    for i in `xdragon-bdf blk  all`
    do
        eval $op $i
    done
    else
        eval $op $bdf
    fi
}

main $@

分别登录机器,保存脚本后执行 bash ./<name> bind all ,对网卡及硬盘进行绑定。

硬盘绑定后进行初始化及挂载操作:

#初始化

mkfs -t ext4 /dev/vdb
mkfs.ext4 /dev/vdc
mkfs.ext4 /dev/vdd
mkfs.ext4 /dev/vde
mkfs.ext4 /dev/vdf
mkfs.ext4 /dev/vdg
mkfs.ext4 /dev/vdh
mkfs.ext4 /dev/vdi
mkfs.ext4 /dev/vdj
mkfs.ext4 /dev/vdk


#挂载

mount /dev/vdb /mnt/disk1
mount /dev/vdc /mnt/disk2
mount /dev/vdd /mnt/disk3
mount /dev/vde /mnt/disk4
mount /dev/vdf /mnt/disk5
mount /dev/vdg /mnt/disk6
mount /dev/vdh /mnt/disk7
mount /dev/vdi /mnt/disk8
mount /dev/vdj /mnt/disk9
mount /dev/vdj /mnt/disk10





2,配置集群间互信

①每台节点配置/etc/hosts文件


各节点ssh-keygen生成RSA密钥和公钥

ssh-keygen -q -t rsa  -N "" -f  ~/.ssh/id_rsa

将所有的公钥文件汇总到一个总的授权key文件中

ssh 192.168.70.210 cat ~/.ssh/id_rsa.pub >> ~/.ssh/authorized_keys

ssh 192.168.70.213 cat ~/.ssh/id_rsa.pub >> ~/.ssh/authorized_keys

ssh 192.168.70.202 cat ~/.ssh/id_rsa.pub >> ~/.ssh/authorized_keys

ssh 192.168.70.201 cat ~/.ssh/id_rsa.pub >> ~/.ssh/authorized_keys

④ 将该总授权key文件分发至其他各个机器中

scp ~/.ssh/authorized_keys 192.168.70.213:~/.ssh/

scp ~/.ssh/authorized_keys 192.168.70.202:~/.ssh/

scp ~/.ssh/authorized_keys 192.168.70.201:~/.ssh/

3,下载相关资源包

下载hadoop,jdk,spark安装包到/opt 路径下,本文以hadoop-2.7.7、spark-2.4.4及jdk1.8.0_291为例


下载Hadoop:   wget https://archive.apache.org/dist/hadoop/common/hadoop-2.7.7/hadoop-2.7.7.tar.gz

下载spark :   wget https://archive.apache.org/dist/spark/spark-2.4.4/spark-2.4.4-bin-hadoop2.7.tgz

下载jdk   :   wget https://download.oracle.com/otn/java/jdk/8u301-b09/d3c52aa6bfa54d3ca74e617f18309292/jdk-8u301-linux-x64.tar.gz

下载hive  :    wget https://archive.apache.org/dist/hive/hive-2.3.7/apache-hive-2.3.7-bin.tar.gz

(由于jdk版本众多,此下载链接仅作参考,实际可根据需求自行在官网下载jdk版本。配置jdk也需按照实际下载版本进行配置)


将3个压缩包分发至其余3个节点并解压

scp -r hadoop-2.7.7.tar.gz  jdk-8u291-linux-x64.tar.gz spark-2.4.4-bin-hadoop2.7  iZ8vbi4yik4sloxwhzcmxzZ:/opt

scp -r hadoop-2.7.7.tar.gz  jdk-8u291-linux-x64.tar.gz spark-2.4.4-bin-hadoop2.7  iZ8vb7zxw3jzrodh0htmgiZ:/opt

scp -r hadoop-2.7.7.tar.gz  jdk-8u291-linux-x64.tar.gz spark-2.4.4-bin-hadoop2.7  iZ8vb7zxw3jzrodh0htmgjZ:/opt

二、配置JDK

1,解压jdk压缩包


在/opt路径下解压jdk包。

2,配置环境变量

在/etc/profile中增加:

  export JAVA_HOME=/opt/jdk1.8.0_291/

  export JRE_HOME=/opt/jdk1.8.0_291/jre

  export CLASSPATH=.:$JAVA_HOME/lib:$JRE_HOME/lib:$CLASSPATH

  export PATH=$PATH:$JAVA_HOME/bin:$HADOOP_HOME/bin:$SPARK_HOME/bin:$HIVE_HOME/bin

执行 source /etc/profile 使环境变量生效

三、安装Hadoop

 1.配置core-site.xml文件

📎core-site.xml


·需在各节点中创建此路径

2.配置 hadoop-env.sh文件

📎hadoop-env.sh


export JAVA_HOME环境变量

  3.配置 yarn-env.sh

📎yarn-env.sh

修改JAVA_HOME为本机JAVA_HOME路径


 4.配置hdfs-site.xml

📎hdfs-site.xml


5.配置mapred-site.xml

📎mapred-site.xml


配置yarn管理

6.配置yarn-site.xml

📎yarn-site.xml


7.配置slaves 文件


将主机名添加进slaves文件

hadoop3.0之后slaves文件改名为workers

8.配置hadoop的环境变量

在/etc/profile中增加:

export HADOOP_HOME=/opt/hadoop-2.7.7/

export HADOOP_CONF_DIR=$HADOOP_HOME/etc/hadoop

9.分发至各节点

将/opt/hadoop-2.7.7分发至其余各节点

10.格式化hdfs

主节点执行

hadoop namenode -format

11.开启hadoop

在master节点/opt/hadoop-2.7.7/路径下执行:

sbin/start-dfs.sh

sbin/start-yarn.sh

完成 后执行jps查询,master如下图所示,则配置成功。


四、安装Spark

1.配置环境变量

vi /etc/profile 中加入

export SPARK_HOME=/opt/spark-2.4.4-bin-hadoop2.7

分发/etc/profile文件至其余节点

1.配置slaves 文件

将主机名添加进slaves

vi  /opt/spark-2.4.4-bin-hadoop2.7/conf/slaves


2.配置spark-env.sh

在/opt/spark-2.4.4-bin-hadoop2.7/conf 路径下执行

cp spark-env.sh.template spark-env.sh

在spark-env.sh中增加:

export SPARK_MASTER_HOST=iZ8vbi4yik4sloxwhzcmxuZ

export SPARK_LOCAL_IP=`/sbin/ip addr show eth0 | grep "inet\b" | awk '{print $2}' | cut -d/ -f1`

export SPARK_LOCAL_DIRS=/mnt/data/spark_tmp

export HADOOP_CONF_DIR=$HADOOP_HOME/etc/hadoop/

export SPARK_DAEMON_MEMORY=10g


3.配置spark-defaults.conf

#
# Licensed to the Apache Software Foundation (ASF) under one or more
# contributor license agreements.  See the NOTICE file distributed with
# this work for additional information regarding copyright ownership.
# The ASF licenses this file to You under the Apache License, Version 2.0
# (the "License"); you may not use this file except in compliance with
# the License.  You may obtain a copy of the License at
#
#    http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
#
# Default system properties included when running spark-submit.
# This is useful for setting default environmental settings.
# Example:
# spark.master                     spark://master1:7077
# spark.eventLog.enabled           true
# spark.eventLog.dir               hdfs://namenode:8021/directory
# spark.serializer                 org.apache.spark.serializer.KryoSerializer
# spark.driver.memory              5g
# spark.executor.extraJavaOptions  -XX:+PrintGCDetails -Dkey=value -Dnumbers="one two three"
spark.master yarn
spark.deploy-mode client
#driver
spark.driver.cores 4
spark.driver.memory 10g
spark.driver.maxResultSize 10g
##executor
spark.executor.instances 45
spark.executor.memory 13g
spark.executor.cores 4
#shuffle
spark.task.maxFailures 4
spark.default.parallelism  180
spark.sql.shuffle.partitions 180
spark.shuffle.compress true
spark.shuffle.spill.compress true
#other
spark.task.maxFailures 4
spark.kryoserializer.buffer 640k
spark.memory.storageFraction 0.5
spark.shuffle.file.buffer 32k
spark.kryoserializer.buffer.max 2000m
spark.serializer org.apache.spark.serializer.KryoSerializer
spark.memory.fraction 0.6
spark.network.timeout 3600
spark.sql.broadcastTimeout 3600
spark.locality.wait=0s
#speculation
#spark.speculation=true
#spark.speculation.interval=300s
#spark.speculation.quantile=0.9
#spark.speculation.multiplier=1.5
#aqe
spark.sql.adaptive.enabled true
spark.sql.autoBroadcastJoinThreshold 128m
spark.sql.adaptive.advisoryPartitionSizeInBytes 128MB
spark.sql.adaptive.coalescePartitions.minPartitionNum 1
spark.sql.adaptive.coalescePartitions.initialPartitionNum 180
spark.sql.adaptive.forceApply true
spark.sql.adaptive.coalescePartitions.enabled   true
spark.sql.adaptive.localShuffleReader.enabled   true
spark.sql.adaptive.skewJoin.enabled     true
spark.sql.adaptive.skewJoin.skewedPartitionFactor 5
spark.sql.adaptive.skewJoin.skewedPartitionThresholdInBytes 256m
#DF
#spark.sql.optimizer.dynamicPartitionPruning.enabled  false
#spark.sql.optimizer.dynamicPartitionPruning.reuseBroadcastOnly true
spark.sql.optimizer.dynamicDataPruning.pruningSideThreshold 10GB
#spark.sql.optimizer.dynamicDataPruning.enabled false
#cbo
#spark.sql.statistics.histogram.enabled true
#spark.sql.statistics.histogram.numBins 32
spark.sql.cbo.enabled true
spark.sql.cbo.joinReorder.enabled true
spark.sql.cbo.planStats.enabled  true
spark.sql.cbo.starSchemaDetection true
spark.sql.cbo.joinReorder.card.weight  0.6
spark.sql.cbo.joinReorder.ga.enabled true
spark.sql.autoBroadcastJoinRowThreshold 500000
#log
spark.eventLog.enabled true
spark.eventLog.dir hdfs://master1:9000/sparklogs
spark.eventLog.compress true
log4j.logger.org.apache.storage.ShuffleBlockFetcherIterator TRACE



在hdfs中创建/sparklogs目录

hadoop fs -mkdir /sparklogs

分发/opt/spark-2.4.4-bin-hadoop2.7至其余节点

4.启动spark

在/opt/spark-2.4.4-bin-hadoop2.7路径下执行:

sbin/start-all.sh

jps执行如下图,则启动成功。



五、安装Mysql

1,下载安装包(以8.0.21版本为例)

#下载

wget https://dev.mysql.com/get/Downloads/MySQL-8.0/mysql-8.0.21-linux-glibc2.12-x86_64.tar.xz

#解压

tar -xf mysql-8.0.21-linux-glibc2.12-x86_64.tar.xz


2,设置mysql目录

#将解压的文件移动到/usr/local下,并重命名为mysql

  mv mysql-8.0.21-linux-glibc2.12-x86_64 /usr/local/mysql

3.创建data文件夹,并授权

cd /usr/local/mysql/

# 创建文件夹

mkdir data

# 给文件夹授权

chown -R root:root /usr/local/mysql

chmod -R 755  /usr/local/mysql

4,初始化数据库

/usr/local/mysql/bin/mysqld --initialize --user=root --basedir=/usr/local/mysql --datadir=/usr/local/mysql/data


5.配置my.cnf

cd /usr/local/mysql/support-files/
touch my-default.cnf
chmod 777 my-default.cnf
cp /usr/local/mysql/support-files/my-default.cnf /etc/my.cnf
vi /etc/my.cnf
#my.cnf中添加:
---------------------------------------------------------------------------------------------------------------------------------------------
# Remove leading # and set to the amount of RAM for the most important data
# cache in MySQL. Start at 70% of total RAM for dedicated server, else 10%.
# innodb_buffer_pool_size = 128M
# Remove leading # to turn on a very important data integrity option: logging
# changes to the binary log between backups.
# log_bin
# These are commonly set, remove the # and set as required.
[mysqld]
basedir = /usr/local/mysql
datadir = /usr/local/mysql/data
socket = /tmp/mysql.sock
#socket =/var/lib/mysql/mysql.socket
log-error = /usr/local/mysql/data/error.log
pid-file = /usr/local/mysql/data/mysql.pid
user = root
tmpdir = /tmp
port = 3306
#skip-grant-tables
#lower_case_table_names = 1
# server_id = .....
# socket = .....
#lower_case_table_names = 1
max_allowed_packet=32M
default-authentication-plugin = mysql_native_password
#lower_case_file_system = on
#lower_case_table_names = 1
log_bin_trust_function_creators = ON
# Remove leading # to set options mainly useful for reporting servers.
# The server defaults are faster for transactions and fast SELECTs.
# Adjust sizes as needed, experiment to find the optimal values.
# join_buffer_size = 128M
# sort_buffer_size = 2M
# read_rnd_buffer_size = 2M
sql_mode=NO_ENGINE_SUBSTITUTION,STRICT_TRANS_TABLES


6.设置开机自启

cd /usr/local/mysql/support-files

cp mysql.server /etc/init.d/mysql

chmod +x /etc/init.d/mysql

7. 注册服务并检测

#注册

chkconfig --add mysql

#检测

chkconfig --list mysql


###UBUNTU
echo 'deb http://archive.ubuntu.com/ubuntu/ trusty main universe restricted multiverse' >>/etc/apt/sources.list
sudo apt-get update
sudo apt-get install sysv-rc-conf
sysv-rc-conf --list





8. 配置/etc/ld.so.conf

vim /etc/ld.so.conf

# 添加如下内容:

/usr/local/mysql/lib

9. 配置环境变量

vim /etc/profile

# 添加如下内容:

# MYSQL ENVIRONMENT

export PATH=$PATH:/usr/local/mysql/bin:/usr/local/mysql/lib


source /etc/profile


10.启动mysql

service mysql start


11.登录mysql

mysql -uroot -p

使用临时密码登录,修改root用户密码,设置root远程登录

#报错:Your password does not satisfy the current policy requirements

#可设置弱口令(mysql8.0)

set global validate_password.policy=0;

set global validate_password.length=1;

之后再修改密码


mysql> alter user user() identified by "123456";
Query OK, 0 rows affected (0.01 sec)
mysql> ALTER user 'root'@'localhost' IDENTIFIED BY '123456';
Query OK, 0 rows affected (0.00 sec)
mysql> use mysql;
Reading table information for completion of table and column names
You can turn off this feature to get a quicker startup with -A
Database changed
mysql> update user set host = '%' where user = 'root';
Query OK, 1 row affected (0.00 sec)
Rows matched: 1  Changed: 1  Warnings: 0
mysql> FLUSH PRIVILEGES;
Query OK, 0 rows affected (0.00 sec)
用户授权
grant all privileges on  *.* to 'hive'@'%';





六、安装Hive

以hive-2.3.7为例

1.将压缩包解压至/opt下


2. 配置环境变量

vim /etc/profile

#hive

export HIVE_HOME=/opt/apache-hive-2.3.7-bin

3. 配置hive-site.xml

vim /opt/apache-hive-2.3.7-bin/conf/hive-site.xml

📎hive-site.xml

4.拷贝mysql的驱动程序

#下载mysql-connector-java-8.0.21.zip

https://dev.mysql.com/downloads/file/?id=496589

将下载的mysql-connector-java-8.0.21.zip解压后拷贝至/opt/apache-hive-2.3.7-bin/lib下


5.hive初始化

执行

schematool -dbType mysql -initSchema


[报错]


[解决]

一,java.lang.NoSuchMethodError

原因:1.系统找不到相关jar包

2.同一类型的 jar 包有不同版本存在,系统无法决定使用哪一个

二,com.google.common.base.Preconditions.checkArgument

根据百度可知,该类来自于guava.jar

三,查看该jar包在hadoop和hive中的版本信息

hadoop-3.2.1(路径:/opt/hadoop-3.2.1/share/hadoop/common/lib)中该jar包为 guava-27.0-jre.jar


hive-2.3.6(路径:hive/lib)中该jar包为guava-14.0.1.jar


四,解决方案

删除hive中低版本的guava-14.0.1.jar包,将hadoop中的guava-27.0-jre.jar复制到hive的lib目录下即可

[报错]


[解决]

修改hive-site.xml配置

<configuration>
    <property>
        <name>javax.jdo.option.ConnectionUserName</name>
        <value>root</value>
    </property>
    <property>
        <name>javax.jdo.option.ConnectionPassword</name>
        <value>root</value>
    </property>
   <property>
        <name>javax.jdo.option.ConnectionURL</name>
        <value>jdbc:mysql://localhost:3306/hive?createDatabaseIfNotExist=true</value>
    </property>
  <property>
        <name>javax.jdo.option.ConnectionDriverName</name>
        <value>com.mysql.cj.jdbc.Driver</value>
    </property>
 <property>
    <name>datanucleus.schema.autoCreateAll</name>
    <value>true</value>
  </property>
  <property>
                <name>hive.metastore.schema.verification</name>
                <value>false</value>
        </property>
</configuration>



6.在mysql增加hive用户

mysql> create user 'hive'@'localhost' identified by '123456';
Query OK, 0 rows affected (0.00 sec)
mysql> grant all privileges on *.* to 'hive'@'localhost';
Query OK, 0 rows affected (0.00 sec)
mysql> create user 'hive'@'%' identified by '123456';
Query OK, 0 rows affected (0.00 sec)
mysql> grant all privileges on *.* to 'hive'@'%';
Query OK, 0 rows affected (0.00 sec)
mysql> flush privileges;
Query OK, 0 rows affected (0.00 sec)

7.启动hive

执行

hive





版权声明:本文内容由阿里云实名注册用户自发贡献,版权归原作者所有,阿里云开发者社区不拥有其著作权,亦不承担相应法律责任。具体规则请查看《阿里云开发者社区用户服务协议》和《阿里云开发者社区知识产权保护指引》。如果您发现本社区中有涉嫌抄袭的内容,填写侵权投诉表单进行举报,一经查实,本社区将立刻删除涉嫌侵权内容。

相关文章
ECS搭建hadoop大数据环境有感
本人大四,正在忙毕业设计,想着需要一台云服务器,就凭借自己的学生身份申领了阿里云,本文记载我的感想。
200 0
大数据环境下该如何优雅地设计数据分层
发个牢骚,搞大数据的也得建设数据仓库吧。而且不管是传统行业还是现在的互联网公司,都需要对数据仓库有一定的重视,而不是谈一句自己是搞大数据的就很厉害了。数据仓库更多代表的是一种对数据的管理和使用的方式,它是一整套包括了etl、调度、建模在内的完整的理论体系。
38707 0
+关注
28
文章
15
问答
文章排行榜
最热
最新
相关电子书
更多
低代码开发师(初级)实战教程
立即下载
阿里巴巴DevOps 最佳实践手册
立即下载
冬季实战营第三期:MySQL数据库进阶实战
立即下载
