Data Processing with SMACK: Spark,
Mesos, Akka, Cassandra, and Kafka
This article introduces the
SMACK (Spark, Mesos, Akka, Cassandra, and Kafka) stack and
illustrates how you can use it to build scalable data processing platforms
While the SMACK stack is really concise and consists of only several
components, it is possible to implement different system designs within it
which list not only purely batch or stream processing, but also contain more
complex Lambda and Kappa architectures as well.
What is the SMACK stack?
First, let’s talk a little bit
about what SMACK is. Here’s a quick rundown of the technologies that are
included in it:

Spark - a
fast and general engine for distributed large-scale data processing.
Mesos - a
cluster resource management system that provides efficient resource isolation
and sharing across distributed applications.
Akka - a
toolkit and runtime for building highly concurrent, distributed, and resilient
message-driven applications on the JVM.
• Cassandra
- a distributed highly available database designed to handle large amounts of
data across multiple datacenters.
• Kafka
- a high-throughput, low-latency distributed messaging system/commit log
designed for handling real-time data feeds.
Storage layer:
Cassandra
Although not in alphabetical order, first let’s
start with the C in SMACK. Cassandra is well
known for its high-availability and high-throughput
characteristics and is able to handle enormous write loads and survive cluster
nodes failures. In terms of CAP theorem, Cassandra provides
tunable consistency/availability for operations.

What
is most interesting here is that when it comes to data processing, Cassandra
is linearly scalable (increased loads could be addressed by just adding more
nodes to a cluster) and it provides cross-datacenter replication (XDCR)
capabilities. Actually XDCR provides not only data replication but a set of use
cases, including:
<bullet
point - Start>
•
Geo-distributed datacenters handling data specific for the region or located
closer to customers.
•
Data migration across datacenters: recovery after failures or moving data to a
new datacenter.
• Separate
operational and analytics workloads.
<bullet
point - End>
However,
all these features come for their own price and with Cassandra this
price is its data model. This could be thought of just as a nested sorted map
distributed across cluster nodes by partition key and entries sorted/grouped by
clustering columns. An example is provided below:

To
get specific data in some range, the full key must be specified and no range
clauses allowed except for the last column in the list. This constraint is
introduced to limit multiple scans for different ranges which may produce
random access to disks and lower down the performance. This means that the data
model should be carefully designed against read queries to limit the amount of
reads/scans which leads to lesser flexibility when it comes to support of new
queries.
But
what if one has some tables that need to be joined somehow with another tables?
Let's consider the next case: calculate total views per campaign for a given
month for all campaigns.

With
a given model, the only way to achieve this goal is to read all campaigns, read
all events, sum the properties (with matched campaign IDs) and assign them to
campaigns. It can be really challenging to implement such applications because
the amount of data stored in Casandra may be huge and exceed the memory
capacity. Therefore, such sort of data should be processed in a distributed
manner and Spark perfectly fits this type of use cases.
Processing layer:
Spark

The
main abstraction Spark operates with is RDD (Resilient
Distributed Dataset, a distributed collection of elements) and the workflow
consists of four main phases:
<bullet
points - start>
•
RDD operations (transformations and actions) form DAG (Direct Acyclic Graph).
•
DAG is split into stages of tasks which are then submitted to the cluster
manager.
•
Stages combine tasks which don't require shuffling/repartitioning.
•
Tasks run on workers and results then return to the client.
<bullet
points - end>
Here's
how one can solve the above problem with Spark and Cassandra:

Interaction
with Cassandra is performed via Spark-Cassandra-connector, which
makes the whole process easy and straightforward. There's one more interesting
option to work with NoSQL stores and that’s SparkSQL, which
translates SQL statements into a series of RDD operations.

With
several lines of code it's possible to implement naive Lambda design which
of course could be much more sophisticated, but this example shows just how
easy this can be achieved.
Almost MapReduce:
bringing processing closer to data
Spark-Cassandra
connector is
data-locality aware and reads the data from the closest node in a cluster, thus
minimizing the amount of data transferred over the network. To fully facilitate
Spark-C* connector data locality awareness, Spark workers should
be collocated with Cassandra nodes.

The
above image illustrates Spark collocation with Cassandra. It
makes sense to separate your operational (or Write-heavy) cluster from one for
analytics. Here’s why:
<Bullet
Points>
•
Clusters can be scaled independently.
•
Data is replicated by Cassandra, with no extra-work needed.
•
The analytics cluster has different Read/Write load patterns.
•
The analytics cluster could contain additional data (for example, dictionaries)
and processing results.
• Spark
resources impact is limited to only one cluster.
Let's
look at the Spark application deployment options one more time:

As
can be seen above, there are three main options available for the cluster
resource manager:
• Spark
Standalone — Spark (as the master node) and workers are installed and
executed as standalone applications (which obviously introduces some overhead
and supports only static resource allocation per worker).
• YARN
— Works very good if you already have Hadoop.
• Mesos
— From the beginning, Mesos was designed for dynamic allocation of cluster
resources, not only for running Hadoop applications but for handling
heterogeneous workloads.
Mesos architecture
The
M in SMACK stands for the Mesos architecture. A Mesos cluster consists
of master nodes which are responsible for resource offerings and scheduling,
and slave nodes which do the actual heavy lifting in the task execution.

In
HA mode
with multiple master nodes, ZooKeeper is used for leader election and
service discovery. Applications executed on Mesos are called frameworks
and utilize APIs to handle resource offers and submit tasks to Mesos.
Generally the task execution process consists of the following steps:
1. Slave nodes
provide available resources to the master node.
2. The master
node sends resource offers to frameworks.
3. The
scheduler replies with tasks and resources needed per task.
4. The master
node sends tasks to slave nodes.
Bringing Spark, Mesos
and Cassandra together
As
said before Spark workers should be collocated with Cassandra
nodes to enforce data locality awareness, thus lowering the amount of network
traffic and Cassandra cluster load. Here's one of the possible
deployment scenarios on how to achieve this with Mesos:

<Bullet Points>
• Mesos
master nodes and ZooKeepers are collocated.
• Mesos
slave nodes and Cassandra nodes are collocated to enforce better data
locality for Spark.
• Spark
binaries are deployed to all worker nodes and spark-env.sh is configured
with proper master endpoints and executor JAR location.
•
The Spark executor JAR is uploaded to S3/HDFS.
With provided setup,
the Spark job can be submitted to the cluster with simple spark-submit
invocation from any worker nodes having Spark binaries installed and
assembly JAR containing actual job logic uploaded.

There
exist options to run Dockerized Spark, so that there's no need to
distribute binaries to every single cluster node.
Scheduled and
Long-running Task Execution
Every
data processing system sooner or later faces the necessity of running two types
of jobs: scheduled/periodic jobs like periodic batch aggregations and
long-running ones which are the case for stream processing. The main
requirement for both of these types is fault tolerance - jobs must continue
running even in case of cluster nodes failures. Mesos ecosystem comes
with two outstanding frameworks supporting each of this types of jobs.
Marathon is
a framework for fault-tolerant execution of long-running tasks supporting HA
mode with ZooKeeper, able to run Docker and having a nice REST
API. Here's an example of using the shell command to run spark-submit
for simple job configuration:

Chronos has
the same characteristics as Marathon but is designed for running
scheduled jobs and in general it is distributed HA cron supporting
graphs of jobs. Here's an example of S3 compaction job configuration
which is implemented as a simple bashscript:

There are plenty of frameworks already available or under active
development (such as Hadoop, Cassandra, Kafka, Myriad, Storm and Samza) which
are targeted to integrate widely used systems with Mesos
resource management capabilities.
Ingesting the Data
Up
till now we have the storage layer designed, resource management set up and
jobs are configured. The only thing which is not there yet is the data to
process:

Assuming
that incoming data will arrive at high rates, the endpoints which will receive
it should meet the following requirements:
<Bullet
Points>
•
Provide high throughput/low latency
• Be
resilient
•
Allow easy scalability
•
Support back pressure
On
second thoughts, back pressure is not a must, but it would be nice to have this
as an option to handle load spikes. Akka perfectly fits the requirements
and basically it was designed to provide this feature set. Here is a quick
run-down of the benefits you can expect to get from Akka:
•
Actor model implementation for JVM
•
Message-based and asynchronous
•
Enforcement of the non-shared mutable state
•
Easily scalable from one process to cluster of machines
•
Actors form hierarchies with parental supervision
•
Not only concurrency framework: akka-http, akka-streams, and akka-persistence
Here's
a simplified example of three actors which handle JSON HttpRequest,
parse it into the domain model case class, and save it to Cassandra:

It
looks like only several lines of code are needed to make everything work, but
while writing raw data (events) to Cassandra with Akka, the
following problems may be caused:
<Bullet Points- Start>
• Cassandra
is still designed for fast serving but not batch processing, so pre-aggregation
of incoming data is needed
•
Computation time of aggregations/rollups will grow with amount of data
•
Actors are not suitable for performing aggregation due to stateless design
model
•
Micro-batches could partially solve the problem
•
Some sort of reliable buffer for raw data is still needed
<Bullet Points- end>
Kafka acts as a
buffer for incoming data
For keeping incoming data with some retention and its further
pre-aggregation/processing, some sort of distributed commit log could be used.
In this case, consumers will read data in batches, process it and store it into
Cassandra
in form of pre-aggregates.

Here's an
example of publishing JSON data through HTTP to Kafka with
akka-http:

Consuming the data:
Spark Streaming
While
Akka still could be used for consuming stream data from Kafka,
having Spark in your ecosystem brings Spark Streaming as an
option to solve the following problems:
<Bullet Points>
• It
supports a variety of data sources
• It
provides at-least-once semantics
•
Exactly-once semantics available with Kafka Direct and idempotent storage

Here's
an example of consuming event stream from Kinesis with Spark
Streaming:

Designing for failure: backups
and patching
Usually
this is the most boring part of any system, but it's really important to
protect data from loss in every possible way when the datacenter is unavailable
or analysis is performed on the datacenter breakdowns.
So
why not store the data in Kafka/Kinesis?

At
the moment of writing this article, Kinesis is the only one solution
that can retain data without backups when all processing results have been
lost. While Kafka supports a long retention period, cost of hardware
ownership should be considered because for example S3 storage is much cheaper
than multiple instances running Kafka and S3 SLA are really good.
Apart
from having backups, the restoring/patching strategies should be designed
upfront and tested so that any problems with data could be quickly fixed. Programmers'
mistakes in aggregation job or duplicated data deletion may break the accuracy
of the computation results. Therefore, it is very important to have the
capability of fixing such errors. One thing to make all these operations easier
is to enforce idempotency in the data model so that multiple repetition of the
same operations produce the same results (for example, SQL update is an
idempotent operation while counter increment is not).
Here
is an example of Spark job which reads S3 backup and loads it into Cassandra:

SMACK: The Big Picture
This
concludes our broad description of SMACK. To allow you to better visualize the
design of a data platform built with SMACK, here’s a visual depiction of
the architecture:

In
the above article we talked about some of the basic functions of using SMACK.
To finish with here is a quick rundown of it’s main advantages:
<Bullet
Points - start>
•
Concise toolbox for wide variety of data processing scenarios
•
Battle-tested and widely used software with large support communities
•
Easy scalability and replication of data while preserving low latencies
•
Unified cluster management for heterogeneous loads
•
Single platform for any kind of applications
•
Implementation platform for different architecture designs (batch, streaming,
Lambda, or Kappa)
•
Really fast time-to-market (for example, for MVP verification)
<Bullet
Points - end>
Thanks
for reading. If anyone has experience developing applications using SMACK. Please
leave some comments.
