一文读懂 | 如何快速部署 OceanBase 开源版

yum install -y yum-utils
yum-config-manager --add-repo https://mirrors.aliyun.com/oceanbase/OceanBase.repo
yum -y install ob-deploy oceanbase obclient

[root@obce00 ~]# useradd admin
[root@obce00 ~]# rpm -ivh rpm/*
准备中...                          ################################# [100%]
正在升级/安装...
   1:oceanbase-ce-libs-3.1.0-1.el7    ################################# [ 33%]
   2:oceanbase-ce-3.1.0-1.el7         ################################# [ 67%]
   3:obproxy-3.1.0-1.el7              ################################# [100%]
[root@obce00 ~]# rpm -ql oceanbase-ce-3.1.0-1.el7.x86_64
/home/admin/oceanbase
/home/admin/oceanbase/bin
/home/admin/oceanbase/bin/import_time_zone_info.py
/home/admin/oceanbase/bin/observer
/home/admin/oceanbase/etc
/home/admin/oceanbase/etc/timezone_V1.log
[root@obce00 ~]# rpm -ql obproxy-3.1.0-1.el7
/home/admin/obproxy-3.1.0/bin
/home/admin/obproxy-3.1.0/bin/obproxy
/home/admin/obproxy-3.1.0/bin/obproxyd.sh

vim /etc/sysctl.conf
net.core.somaxconn = 2048
net.core.netdev_max_backlog = 10000
net.core.rmem_default = 16777216
net.core.wmem_default = 16777216
net.core.rmem_max = 16777216
net.core.wmem_max = 16777216
net.ipv4.ip_local_port_range = 3500 65535
net.ipv4.ip_forward = 0
net.ipv4.conf.default.rp_filter = 1
net.ipv4.conf.default.accept_source_route = 0
net.ipv4.tcp_syncookies = 0
net.ipv4.tcp_rmem = 4096 87380 16777216
net.ipv4.tcp_wmem = 4096 65536 16777216
net.ipv4.tcp_max_syn_backlog = 16384
net.ipv4.tcp_fin_timeout = 15
net.ipv4.tcp_max_syn_backlog = 16384
net.ipv4.tcp_tw_reuse = 1
net.ipv4.tcp_tw_recycle = 1
net.ipv4.tcp_slow_start_after_idle=0
vm.swappiness = 0
vm.min_free_kbytes = 2097152
vm.max_map_count=655360
fs.aio-max-nr=1048576

sysctl -p

vi /etc/security/limits.conf
* soft nofile 655360
* hard nofile 655360
* soft nproc 655360
* hard nproc 655360
* soft core unlimited
* hard core unlimited
* soft stack unlimited
* hard stack unlimited

ulimit -a

systemctl status firewalld

systemctl disable firewalld
systemctl stop firewalld
systemctl status firewalld

vi /etc/selinux/config
# This file controls the state of SELinux on the system.
# SELINUX= can take one of these three values:
#     enforcing - SELinux security policy is enforced.
#     permissive - SELinux prints warnings instead of enforcing.
#     disabled - No SELinux policy is loaded.
SELINUX=disabled

setenforce 0

[admin@obce00 obd]$ sudo rpm -ivh ob-deploy-1.1.0-1.el8.x86_64.rpm

rpm -ql `rpm -qa|grep ob-deploy`

[admin@obce00 ~]$ tree ~/.obd -L 1
/home/admin/.obd
├── cluster
├── log
├── mirror
├── obd.conf
├── plugins
├── repository
└── version
5 directories, 2 files

/bin/rm -rf ~/.obd/mirror/remote/OceanBase.repo

obd mirror clone /tmp/obd/*.rpm

obd mirror list local

yum install -y yum-utils
yum-config-manager --add-repo https://mirrors.aliyun.com/oceanbase/OceanBase.repo
yum install -y ob-deploy

# lvm 分盘
pvcreate /dev/vdb
vgcreate obvg /dev/vdb
lvcreate -L 20G obvg -n lvredo
lvcreate -l 100%FREE obvg -n lvdata
# 格式化文件系统
mkfs.ext4 /dev/obvg/lvdata
mkfs.ext4 /dev/obvg/lvredo
# 修改 mount 参数文件
vim /etc/fstab
/dev/obvg/lvredo          /redo              ext4            defaults,noatime,nodiratime,nodelalloc,barrier=0        0 0
/dev/obvg/lvdata             /data         ext4            defaults,noatime,nodiratime,nodelalloc,barrier=0        0 0
# 挂载文件系统
mkdir -p /data /redo
vim /etc/fstab
mount /data
mount /redo
chown -R admin.admin /data /redo
# 检查
df -h
输出：
文件系统                 容量  已用  可用 已用% 挂载点
/dev/mapper/obvg-lvdata   59G   53M   56G    1% /data
/dev/mapper/obvg-lvredo   20G   45M   19G    1% /redo

[admin@obce00 ~]$ cat obce-single.yaml
## Only need to configure when remote login is required
# user:
#   username: your username
#   password: your password if need
#   key_file: your ssh-key file path if need
#   port: your ssh port, default 22
#   timeout: ssh connection timeout (second), default 30
oceanbase-ce:
  servers:
    # Please don't use hostname, only IP can be supported
    - 172.20.249.50
  global:
    #  The working directory for OceanBase Database. OceanBase Database is started under this directory. This is a required field.
    home_path: /home/admin/oceanbase-ce
    # The directory for data storage. The default value is $home_path/store.
    data_dir: /data
    # The directory for clog, ilog, and slog. The default value is the same as the data_dir value.
    redo_dir: /redo
    # Please set devname as the network adaptor's name whose ip is  in the setting of severs.
    # if set severs as "127.0.0.1", please set devname as "lo"
    # if current ip is 192.168.1.10, and the ip's network adaptor's name is "eth0", please use "eth0"
    devname: eth0
    mysql_port: 2881 # External port for OceanBase Database. The default value is 2881.
    rpc_port: 2882 # Internal port for OceanBase Database. The default value is 2882.
    zone: zone1
    cluster_id: 1
    # please set memory limit to a suitable value which is matching resource.
    memory_limit: 8G # The maximum running memory for an observer
    system_memory: 3G # The reserved system memory. system_memory is reserved for general tenants. The default value is 30G.
    stack_size: 512K
    cpu_count: 16
    cache_wash_threshold: 1G
    __min_full_resource_pool_memory: 268435456
    workers_per_cpu_quota: 10
    schema_history_expire_time: 1d
    # The value of net_thread_count had better be same as cpu's core number.
    net_thread_count: 4
    major_freeze_duty_time: Disable
    minor_freeze_times: 10
    enable_separate_sys_clog: 0
    enable_merge_by_turn: FALSE
    # datafile_disk_percentage: 20 # The percentage of the data_dir space to the total disk space. This value takes effect only when datafile_size is 0. The default value is 90.
    datafile_size: 50G
    syslog_level: WARN # System log level. The default value is INFO.
    enable_syslog_wf: false # Print system logs whose levels are higher than WARNING to a separate log file. The default value is true.
    enable_syslog_recycle: true # Enable auto system log recycling or not. The default value is false.
    max_syslog_file_count: 10 # The maximum number of reserved log files before enabling auto recycling. The default value is 0.
    root_password: bzNvgyhB  # root user password, can be empty

obd cluster deploy obce-single -c obce-single.yaml

obd cluster list

[admin@obce00 ~]$ tree /home/admin/oceanbase-ce/
/home/admin/oceanbase-ce/
├── admin
├── bin
│   └── observer -> /home/admin/.obd/repository/oceanbase-ce/3.1.0/84bd2fe27f8b8243cc57d8a3f68b4c50f94aab80/bin/observer
<......>
├── log
└── store -> /data
[admin@obce00 ~]$ tree /data
/data
├── clog -> /redo/clog
├── ilog -> /redo/ilog
├── slog -> /redo/slog
└── sstable
4 directories, 0 files
[admin@obce00 ~]$ tree /redo
/redo
├── clog
├── ilog
└── slog
3 directories, 0 files

obd cluster start obce-single

[admin@obce00 ~]$ mysql -h 172.20.249.50 -uroot@sys -P2881 -pbzNvgyhB -c -A oceanbase

sudo rpm -ivh /tmp/obd/obclient-2.0.0-2.el8.x86_64.rpm /tmp/obd/libobclient-2.0.0-2.el8.x86_64.rpm
obclient -h 172.20.249.50 -uroot@sys -P2881 -pbzNvgyhB -c -A oceanbase

## Only need to configure when remote login is required
user:
   username: admin
#   password: your password if need
   key_file: /home/admin/.ssh/id_rsa.pub
   port: your ssh port, default 22
#   timeout: ssh connection timeout (second), default 30
oceanbase-ce:
  servers:
    - name: obce01
      # Please don't use hostname, only IP can be supported
      ip: 172.20.249.53
    - name: obce02
      ip: 172.20.249.55
    - name: obce03
      ip: 172.20.249.56
  global:
    # Please set devname as the network adaptor's name whose ip is  in the setting of severs.
    # if set severs as "127.0.0.1", please set devname as "lo"
    # if current ip is 192.168.1.10, and the ip's network adaptor's name is "eth0", please use "eth0"
    devname: bond0
    cluster_id: 2
    # please set memory limit to a suitable value which is matching resource.
    # memory_limit: 200G # The maximum running memory for an observer
    # system_memory: 30G # The reserved system memory. system_memory is reserved for general tenants. The default value is 30G.
    minor_freeze_times: 100
    minor_warm_up_duration_time: 0
    freeze_trigger_percentage: 40
    enable_merge_by_turn: FALSE
    datafile_disk_percentage: 50 # The percentage of the data_dir space to the total disk space. This value takes effect only when datafile_size is 0. The default value is 90.
    # datafile_size: 500G
    syslog_level: INFO # System log level. The default value is INFO.
    enable_syslog_wf: false # Print system logs whose levels are higher than WARNING to a separate log file. The default value is true.
    enable_syslog_recycle: true # Enable auto system log recycling or not. The default value is false.
    max_syslog_file_count: 50 # The maximum number of reserved log files before enabling auto recycling. The default value is 0.
    # observer cluster name, consistent with obproxy's cluster_name
    appname: obce-3zones
    root_password: 0EI5N08d # root user password, can be empty
    proxyro_password: FAKEPASSWORD02 # proxyro user pasword, consistent with obproxy's observer_sys_password, can be empty
  obce01:
    mysql_port: 2881 # External port for OceanBase Database. The default value is 2881.
    rpc_port: 2882 # Internal port for OceanBase Database. The default value is 2882.
    #  The working directory for OceanBase Database. OceanBase Database is started under this directory. This is a required field.
    home_path: /home/admin/oceanbase-ce
    # The directory for data storage. The default value is $home_path/store.
    data_dir: /data
    # The directory for clog, ilog, and slog. The default value is the same as the data_dir value.
    redo_dir: /redo
    zone: zone1
  obce02:
    mysql_port: 2881 # External port for OceanBase Database. The default value is 2881.
    rpc_port: 2882 # Internal port for OceanBase Database. The default value is 2882.
    #  The working directory for OceanBase Database. OceanBase Database is started under this directory. This is a required field.
    home_path: /home/admin/oceanbase-ce
    # The directory for data storage. The default value is $home_path/store.
    data_dir: /data
    # The directory for clog, ilog, and slog. The default value is the same as the data_dir value.
    redo_dir: /redo
    zone: zone2
  obce03:
    mysql_port: 2881 # External port for OceanBase Database. The default value is 2881.
    rpc_port: 2882 # Internal port for OceanBase Database. The default value is 2882.
    #  The working directory for OceanBase Database. OceanBase Database is started under this directory. This is a required field.
    home_path: /home/admin/oceanbase-ce
    # The directory for data storage. The default value is $home_path/store.
    data_dir: /data
    # The directory for clog, ilog, and slog. The default value is the same as the data_dir value.
    redo_dir: /redo
    zone: zone3
obproxy:
  servers:
    - 172.20.249.53
    - 172.20.249.55
    - 172.20.249.56
  # Set dependent components for the component.
  # When the associated configurations are not done, OBD will automatically get the these configurations from the dependent components.
  depends:
    - oceanbase-ce
  global:
    listen_port: 2883 # External port. The default value is 2883.
    prometheus_listen_port: 2884 # The Prometheus port. The default value is 2884.
    home_path: /home/admin/obproxy
    # oceanbase root server list
    # format: ip:mysql_port;ip:mysql_port
    rs_list: 172.20.249.53:2881;172.20.249.55:2881;172.20.249.56:2881
    enable_cluster_checkout: false
    # observer cluster name, consistent with oceanbase-ce's appname
    cluster_name: obce-3zones
    obproxy_sys_password: FAKEPASSWORD01 # obproxy sys user password, can be empty
    observer_sys_password: FAKEPASSWORD02 # proxyro user pasword, consistent with oceanbase-ce's proxyro_password, can be empty

obclient -h172.20.249.54 -uroot@obmysql#obce-3zones -P2883 -p123456 -c -A test
