torch.gather()使用方法

问题分析

在阅读OneIE代码时，突然看到一段代码十分精妙，用来预测BERT等预训练语言模型在使用tokenizer进行分词时，会将一个单词可能分成多个token，如原始句子为"(END VIDEO CLIP)"，正常理解按照空格和字符进行划分为["(", "END", "VIDEO", "CLIP", ")"]，然而BERT的划分结果为["(", "E", "##ND", "VI", "##DE", "##O", "C", "##L", "##IP", ")"]，则每个token对应的长度为token_lens=[1, 2, 3, 3, 1]。所以在经过BERT之后，单词END的表征将变成了两个部分(E,##ND)，所以END的表示便有了歧义，常见的做法有：1、取E和##ND表征的平均值。2、取E来表示END。3、E和##ND表征进行连接，在经过线性变化进行降维。如果还有其他做法可以进行补充。

为什么上述问题要用到torch.gather()函数呢？这个是因为这个函数可以按照给出的索引对原始的tensor进行取值，类似于列表中的索引和切片。

原理分析

先看官方文档，官方文档给出了函数的定义及其相关解析。

红色框中表明了函数根据index的索引进行取值的规则。建议多看几遍！！！dim的取值为多少，就代表

函数存在三个输入参数：

input:表示输入向量
dim:按照该轴进行取值，和常规的函数相同用法
index:需要在输入向量中取值的索引位置

值得注意是，dim的值要小于输入向量input的维度，如果是一个二维的向量，则dim只能取值为0或1，和常规的函数相同使用。函数输出的向量形状和index向量必须一致。index向量中的取值要小于input的形状维度。更加详细的规则如下所示：

以官方示例为例，

扩展dim=0将会产生不一样的结果

BERT的token表征分析

回到问题中，部分token在tokenizer时会分成多个表示，我们将以OneIE代码为例进行分析和讲解：

from transformers import BertTokenizer, BertModel
import torch
def token_lens_to_idxs(token_lens):
    """Map token lengths to a word piece index matrix (for torch.gather) and a
    mask tensor.
    For example (only show a sequence instead of a batch):
    token lengths: [1,1,1,3,1]
    =>
    indices: [[0,0,0], [1,0,0], [2,0,0], [3,4,5], [6,0,0]]
    masks: [[1.0, 0.0, 0.0], [1.0, 0.0, 0.0], [1.0, 0.0, 0.0],
            [0.33, 0.33, 0.33], [1.0, 0.0, 0.0]]
    Next, we use torch.gather() to select vectors of word pieces for each token,
    and average them as follows (incomplete code):
    outputs = torch.gather(bert_outputs, 1, indices) * masks
    outputs = bert_outputs.view(batch_size, seq_len, -1, self.bert_dim)
    outputs = bert_outputs.sum(2)
    :param token_lens (list): token lengths. (batch,seq_len)
    :return: a index matrix and a mask tensor.
    """
    max_token_num = max([len(x) for x in token_lens])
    max_token_len = max([max(x) for x in token_lens])
    idxs, masks = [], []
    for seq_token_lens in token_lens:
        seq_idxs, seq_masks = [], []
        offset = 0
        for token_len in seq_token_lens:
            seq_idxs.extend([i + offset for i in range(token_len)
                             ] + [-1] * (max_token_len - token_len))
            seq_masks.extend([1.0 / token_len] * token_len +
                             [0.0] * (max_token_len - token_len))
            offset += token_len
        seq_idxs.extend([-1] * max_token_len *
                        (max_token_num - len(seq_token_lens)))
        seq_masks.extend([0.0] * max_token_len *
                         (max_token_num - len(seq_token_lens)))
        idxs.append(seq_idxs)
        masks.append(seq_masks)
    return idxs, masks, max_token_num, max_token_len
def data_process(datas):
    token_lens = []
    tokens = []
    pieces = []
    sentences = []
    for data in datas:
        token_lens.append(data['token_lens'])
        tokens.append(data['tokens'])
        pieces.append(data['pieces'])
        sentences.append(data['sentence'])
    return token_lens, tokens, pieces, sentences
def get_bert_input(pieces, tokenizer, max_length=24):
    _piece_idxs = []
    _attn_masks = []
    for piece in pieces:
        piece_idxs = tokenizer.encode(piece,
                                      add_special_tokens=True,
                                      max_length=max_length,
                                      truncation=True)
        pad_num = max_length - len(piece_idxs)
        attn_mask = [1] * len(piece_idxs) + [0] * pad_num
        piece_idxs = piece_idxs + [0] * pad_num
        _piece_idxs.append(piece_idxs)
        _attn_masks.append(attn_mask)
    _piece_idxs = torch.LongTensor(_piece_idxs)
    _attn_masks = torch.LongTensor(_attn_masks)
    return _piece_idxs, _attn_masks
data_example = [{"doc_id": "CNN_IP_20030409.1600.02", "sent_id": "CNN_IP_20030409.1600.02-21", "tokens": ["Yet", "until", "this", "war", "is", "fully", "won", ",", "we", "cannot", "be", "overconfident", "in", "our", "position", "."], "pieces": ["Yet", "until", "this", "war", "is", "fully", "won", ",", "we", "cannot", "be", "over", "##con", "##fi", "##dent", "in", "our", "position", "."], "token_lens": [1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 4, 1, 1, 1, 1], "sentence": "Yet until this war is fully won, we cannot be overconfident in our position.", "entity_mentions": [{"id": "CNN_IP_20030409.1600.02-E10-53", "text": "we", "entity_type": "GPE", "mention_type": "PRO", "entity_subtype": "Nation", "start": 8, "end": 9}, {"id": "CNN_IP_20030409.1600.02-E10-54", "text": "our", "entity_type": "GPE", "mention_type": "PRO", "entity_subtype": "Nation", "start": 13, "end": 14}], "relation_mentions": [], "event_mentions": [{"id": "CNN_IP_20030409.1600.02-EV1-1", "event_type": "Conflict:Attack", "trigger": {"text": "war", "start": 3, "end": 4}, "arguments": []}]},
                {"doc_id": "CNN_IP_20030409.1600.02", "sent_id": "CNN_IP_20030409.1600.02-22", "tokens": ["And", "we", "must", "not", "underestimate", "the", "desperation", "of", "whatever", "forces", "remain", "loyal", "to", "the", "dictator", "."], "pieces": ["And", "we", "must", "not", "under", "##est", "##imate", "the", "desperation", "of", "whatever", "forces", "remain", "loyal", "to", "the", "dictator", "."], "token_lens": [1, 1, 1, 1, 3, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1], "sentence": "And we must not underestimate the desperation of whatever forces remain loyal to the dictator.", "entity_mentions": [{"id": "CNN_IP_20030409.1600.02-E10-55", "text": "we", "entity_type": "GPE", "mention_type": "PRO", "entity_subtype": "Nation", "start": 1, "end": 2}, {
                    "id": "CNN_IP_20030409.1600.02-E31-56", "text": "forces", "entity_type": "PER", "mention_type": "NOM", "entity_subtype": "Group", "start": 9, "end": 10}, {"id": "CNN_IP_20030409.1600.02-E12-57", "text": "dictator", "entity_type": "PER", "mention_type": "NOM", "entity_subtype": "Individual", "start": 14, "end": 15}], "relation_mentions": [{"id": "CNN_IP_20030409.1600.02-R17-1", "relation_type": "GEN-AFF", "relation_subtype": "GEN-AFF:Citizen-Resident-Religion-Ethnicity", "arguments": [{"entity_id": "CNN_IP_20030409.1600.02-E31-56", "text": "forces", "role": "Arg-1"}, {"entity_id": "CNN_IP_20030409.1600.02-E12-57", "text": "dictator", "role": "Arg-2"}]}], "event_mentions": []},
                {"doc_id": "CNN_IP_20030409.1600.02", "sent_id": "CNN_IP_20030409.1600.02-23", "tokens": ["(", "END", "VIDEO", "CLIP", ")"], "pieces": ["(", "E", "##ND", "VI", "##DE", "##O", "C", "##L", "##IP", ")"], "token_lens": [
                    1, 2, 3, 3, 1], "sentence": "(END VIDEO CLIP)", "entity_mentions": [], "relation_mentions": [], "event_mentions": []},
                {"doc_id": "CNN_IP_20030409.1600.02", "sent_id": "CNN_IP_20030409.1600.02-18", "tokens": ["(", "BEGIN", "VIDEO", "CLIP", ")"], "pieces": ["(", "B", "##EG", "##IN", "VI", "##DE", "##O", "C", "##L", "##IP", ")"], "token_lens": [1, 3, 3, 3, 1], "sentence": "(BEGIN VIDEO CLIP)", "entity_mentions": [], "relation_mentions": [], "event_mentions": []}]
bert_dim = 1536
batch_size = 1
tokenizer = BertTokenizer.from_pretrained('./bert/bert-base-cased')
# output_hidden_states=True，表示输出bert中间层的结果
bert = BertModel.from_pretrained(
    './bert/bert-base-cased', output_hidden_states=True)
token_lens, tokens, pieces, sentences = data_process(data_example)
piece_idxs, attention_masks = get_bert_input(pieces, tokenizer, 24)
all_bert_outputs = bert(piece_idxs, attention_mask=attention_masks)
bert_outputs = all_bert_outputs[0]
# 取BERT倒数第三层的输出连接，使效果更佳
extra_bert_outputs = all_bert_outputs[2][-3]
bert_outputs = torch.cat([bert_outputs, extra_bert_outputs], dim=2)
# 最为关键多个token融合，并选出最终的bert输出表示
idxs, masks, token_num, token_len = token_lens_to_idxs(token_lens)
# +1 是因为第一个向量是[CLS]，并且将idxs中最小值有-1变化为0，expand是为了进行广播
idxs = piece_idxs.new(idxs).unsqueeze(-1).expand(batch_size, -1, bert_dim) + 1
# 便于后续的矩阵逐元素乘法
masks = bert_outputs.new(masks).unsqueeze(-1)
# 逐元素乘法，因为mask会对多个词token进行平均化，并且将没有分割的token的mask填充置0
bert_outputs = torch.gather(bert_outputs, 1, idxs) * masks
bert_outputs = bert_outputs.view(batch_size, token_num, token_len, bert_dim)
bert_outputs = bert_outputs.sum(2)
print(bert_outputs)

上述代码就是采用方法一，取E和##ND表征的平均值进行特征融合，如果还是很复杂，可以看以下精简版代码示例就可以看出特征融合的原理，最好自己运行代码查看：

import torch
bert_outputs = torch.rand((1, 12, 8))
idxs = [0, -1, -1, 1, -1, -1, 2, 3, -1, 4, -1, -1]
masks = [1, 0, 0, 1, 0, 0, 0.5, 0.5, 0, 1,  0, 0]
idxs = torch.LongTensor(idxs)
idxs = idxs.unsqueeze(-1).expand(1, -1, 8) + 1
# 便于后续的矩阵逐元素乘法
masks = bert_outputs.new(masks).unsqueeze(-1)
# 逐元素乘法，因为mask会对多个词token进行平均化，并且将没有分割的token的mask填充置0,
# dim=1表示在bert_outputs的seq上进行采样，gather对batch和dimension上维度保持不变，在乘mask则会将多余的清零
print(bert_outputs)
bert_outputs = torch.gather(bert_outputs, 1, idxs)
print(bert_outputs)
bert_outputs=bert_outputs* masks
print(bert_outputs)
bert_outputs = bert_outputs.view(1, 4, 3, 8)
bert_outputs = bert_outputs.sum(2)
print(bert_outputs)
