前言
本文基于内核版本4.1.15分析，随着内核版本升级，部分数据结构会发生变化，但是整体流程没有发生变化。
先附上读写eMMC大体经过，目的在于了解过程，具体细节不作过多分析。
一、文件系统缓存层
_submit_bh (fs/buffer.c)
文件系统层的处理最终会调用到_submit_bh函数，在这里完成将buffer_head描述的数据转换成bio描述（block I/O），传到general block layer，所以对于general block layer接收到的就是一个初始化好的bio，里面描述了需要读写数据的信息。
struct buffer_head { unsigned long b_state; /* */ struct buffer_head *b_this_page;/* circular list of page's buffers */ struct page *b_page; /* the page this bh is mapped to */ sector_t b_blocknr; /* start block number */ size_t b_size; /* size of mapping */ char *b_data; /* pointer to data within the page */ struct block_device *b_bdev; bh_end_io_t *b_end_io; /* I/O completion */ void *b_private; /* reserved for b_end_io */ struct list_head b_assoc_buffers; /* associated with another mapping */ struct address_space *b_assoc_map; /* mapping this buffer is associated with */ atomic_t b_count; /* users using this buffer_head */};
int _submit_bh(int rw, struct buffer_head *bh, unsigned long bio_flags) { struct bio *bio; int ret = 0; ···············省略······················ /* * Only clear out a write error when rewriting */ if (test_set_buffer_req(bh) && (rw & WRITE)) clear_buffer_write_io_error(bh); /* * from here on down, it's all bio -- do the initial mapping, * submit_bio -> generic_make_request may further map this bio around */ bio = bio_alloc(GFP_NOIO, 1); bio->bi_iter.bi_sector = bh->b_blocknr * (bh->b_size >> 9); bio->bi_bdev = bh->b_bdev; bio->bi_io_vec[0].bv_page = bh->b_page; bio->bi_io_vec[0].bv_len = bh->b_size; bio->bi_io_vec[0].bv_offset = bh_offset(bh); bio->bi_vcnt = 1; bio->bi_iter.bi_size = bh->b_size; bio->bi_end_io = end_bio_bh_io_sync; bio->bi_private = bh; bio->bi_flags |= bio_flags; /* Take care of bh's that straddle the end of the device */ guard_bio_eod(rw, bio); if (buffer_meta(bh)) rw |= REQ_META; if (buffer_prio(bh)) rw |= REQ_PRIO; bio_get(bio); submit_bio(rw, bio);//提交bio,进入通用块层 if (bio_flagged(bio, BIO_EOPNOTSUPP)) ret = -EOPNOTSUPP; bio_put(bio); return ret; }
二、general block layer
submit_bio (block/blk-core.c)
该函数主要判断读还是写，然后调用generic_make_request，将bio加入请求队列中。
内核希望一次只有一个make_request_fn是活动的，否则使用堆叠设备的堆栈可能是一个问题。因此，使用current->bio_list保存由make_request_fn函数提交的请求列表。Current ->bio_list也用作一个标志，表示generic_make_request当前是否在这个任务中是活动的。如果它是NULL，那么没有活动的make_request。如果它是非null，那么make_request是活动的，并且应该在尾部添加新的请求。
void generic_make_request(struct bio *bio) { struct bio_list bio_list_on_stack; if (!generic_make_request_checks(bio)) return; if (current->bio_list) { bio_list_add(current->bio_list, bio); return; } /* following loop may be a bit non-obvious, and so deserves some * explanation. * Before entering the loop, bio->bi_next is NULL (as all callers * ensure that) so we have a list with a single bio. * We pretend that we have just taken it off a longer list, so * we assign bio_list to a pointer to the bio_list_on_stack, * thus initialising the bio_list of new bios to be * added. ->make_request() may indeed add some more bios * through a recursive call to generic_make_request. If it * did, we find a non-NULL value in bio_list and re-enter the loop * from the top. In this case we really did just take the bio * of the top of the list (no pretending) and so remove it from * bio_list, and call into ->make_request() again. */ BUG_ON(bio->bi_next); bio_list_init(&bio_list_on_stack); current->bio_list = &bio_list_on_stack; do { struct request_queue *q = bdev_get_queue(bio->bi_bdev); q->make_request_fn(q, bio); bio = bio_list_pop(current->bio_list); } while (bio); current->bio_list = NULL; /* deactivate */ }
make_request_fn在blk_queue_make_request函数里赋值，指向blk_queue_bio函数，blk_queue_bio函数使用电梯算法对bio尝试合并，然后调用__blk_run_queue运行队列。
随后在__blk_run_queue_uncond中调用q->request_fn(q)，request_fn在blk_init_queue函数中初始化，指向mmc_request_fn函数。而mmc_request_fn通过wake_up_process唤醒了mmc_queue_thread，该函数在mmc_init_queue函数中完成初始化赋值，随后执行mmc_queue_thread，该函数在queue.c（drivers/mmc/card），代表着从此进入了MMC子系统card层。内核4.1以后的某个版本将card层合并到core层去了，所以这里暂且把card层也当成MMC的CORE核心层去看吧。
三、MMC core层
在mmc_queue_thread函数，通过blk_fetch_request从mmc queue中取出请求，然后执行mq->issue_fn下发请求，mq->issue_fn在mmc_blk_alloc_req函数完成初始化，即执行mmc_blk_issue_rq下发请求。
static int mmc_blk_issue_rq(struct mmc_queue *mq, struct request *req) { int ret; struct mmc_blk_data *md = mq->data; struct mmc_card *card = md->queue.card; struct mmc_host *host = card->host; unsigned long flags; unsigned int cmd_flags = req ? req->cmd_flags : 0; if (req && !mq->mqrq_prev->req) /* claim host only for the first request */ mmc_get_card(card); ret = mmc_blk_part_switch(card, md); if (ret) { if (req) { blk_end_request_all(req, -EIO); } ret = 0; goto out; } mq->flags &= ~MMC_QUEUE_NEW_REQUEST; if (cmd_flags & REQ_DISCARD) { /* complete ongoing async transfer before issuing discard */ if (card->host->areq) mmc_blk_issue_rw_rq(mq, NULL); if (req->cmd_flags & REQ_SECURE) ret = mmc_blk_issue_secdiscard_rq(mq, req); else ret = mmc_blk_issue_discard_rq(mq, req); } else if (cmd_flags & REQ_FLUSH) { /* complete ongoing async transfer before issuing flush */ if (card->host->areq) mmc_blk_issue_rw_rq(mq, NULL); ret = mmc_blk_issue_flush(mq, req); } else { if (!req && host->areq) { spin_lock_irqsave(&host->context_info.lock, flags); host->context_info.is_waiting_last_req = true; spin_unlock_irqrestore(&host->context_info.lock, flags); } ret = mmc_blk_issue_rw_rq(mq, req); } out: if ((!req && !(mq->flags & MMC_QUEUE_NEW_REQUEST)) || (cmd_flags & MMC_REQ_SPECIAL_MASK)) /* * Release host when there are no more requests * and after special request(discard, flush) is done. * In case sepecial request, there is no reentry to * the 'mmc_blk_issue_rq' with 'mqrq_prev->req'. */ mmc_put_card(card); return ret; }
暂且仅关注读写请求，通过判断request的成员cmd_flags，执行mmc_blk_issue_rw_rq下发读写请求。
经过一系列的调用，最终都会调到host->ops->request，这个十分重要，调用该函数代表着从MMC的core层进入到host层了，request定义在mmc_host_ops结构体里，host层是与平台紧密相关的，drivers/mmc/host的源文件并不是所有都会编译，所以这里还需结合你的芯片平台。
进入drivers/mmc/host， 可以通过以下方法确认使用的host是哪个。
四、MMC host层
sdhci_request函数主要做的事情是判断host_flags，是否设置了SDHCI_AUTO_CMD12和SDHCI_AUTO_CMD23。
因为对于MMC读有两种方式，一种是先发送CMD23设置要读的长度（单位：block）；另一种是开放式读，直到card接收到CMD12才停止读card。所以这里对SDHCI_AUTO_CMD12的判断，目的是避免重复发送CMD12，后面有个地方会提到。
对于SDHCI_AUTO_CMD23的处理，区别就是在于使用mmc_request里的sbc还是cmd，事实上并没什么区别，他们的类型都是struct mmc_command。
static void sdhci_request(struct mmc_host *mmc, struct mmc_request *mrq) { struct sdhci_host *host; int present; unsigned long flags; host = mmc_priv(mmc); sdhci_runtime_pm_get(host); /* Firstly check card presence */ present = sdhci_do_get_cd(host); spin_lock_irqsave(&host->lock, flags); WARN_ON(host->mrq != NULL); #ifndef SDHCI_USE_LEDS_CLASS sdhci_activate_led(host); #endif /* * Ensure we don't send the STOP for non-SET_BLOCK_COUNTED * requests if Auto-CMD12 is enabled. */ if (!mrq->sbc && (host->flags & SDHCI_AUTO_CMD12)) { if (mrq->stop) { mrq->data->stop = NULL; mrq->stop = NULL; } } host->mrq = mrq; if (!present || host->flags & SDHCI_DEVICE_DEAD) { host->mrq->cmd->error = -ENOMEDIUM; tasklet_schedule(&host->finish_tasklet); } else { if (mrq->sbc && !(host->flags & SDHCI_AUTO_CMD23)) sdhci_send_command(host, mrq->sbc); else sdhci_send_command(host, mrq->cmd); } mmiowb(); spin_unlock_irqrestore(&host->lock, flags); }
在sdhci_send_command已经是接近最底层的操作了，大部分是位运算和写寄存器操作。
void sdhci_send_command(struct sdhci_host *host, struct mmc_command *cmd) { int flags; u32 mask; unsigned long timeout; WARN_ON(host->cmd); /* Wait max 10 ms */ timeout = 10; mask = SDHCI_CMD_INHIBIT; if ((cmd->data != NULL) || (cmd->flags & MMC_RSP_BUSY)) mask |= SDHCI_DATA_INHIBIT; /* We shouldn't wait for data inihibit for stop commands, even though they might use busy signaling */ if (host->mrq->data && (cmd == host->mrq->data->stop)) mask &= ~SDHCI_DATA_INHIBIT; while (sdhci_readl(host, SDHCI_PRESENT_STATE) & mask) { if (timeout == 0) { pr_err("%s: Controller never released " "inhibit bit(s).\n", mmc_hostname(host->mmc)); sdhci_dumpregs(host); cmd->error = -EIO; tasklet_schedule(&host->finish_tasklet); return; } timeout--; mdelay(1); } timeout = jiffies; if (!cmd->data && cmd->busy_timeout > 9000) timeout += DIV_ROUND_UP(cmd->busy_timeout, 1000) * HZ + HZ; else timeout += 10 * HZ; mod_timer(&host->timer, timeout); host->cmd = cmd; host->busy_handle = 0; sdhci_prepare_data(host, cmd); sdhci_writel(host, cmd->arg, SDHCI_ARGUMENT); sdhci_set_transfer_mode(host, cmd); if ((cmd->flags & MMC_RSP_136) && (cmd->flags & MMC_RSP_BUSY)) { pr_err("%s: Unsupported response type!\n", mmc_hostname(host->mmc)); cmd->error = -EINVAL; tasklet_schedule(&host->finish_tasklet); return; } if (!(cmd->flags & MMC_RSP_PRESENT)) flags = SDHCI_CMD_RESP_NONE; else if (cmd->flags & MMC_RSP_136) flags = SDHCI_CMD_RESP_LONG; else if (cmd->flags & MMC_RSP_BUSY) flags = SDHCI_CMD_RESP_SHORT_BUSY; else flags = SDHCI_CMD_RESP_SHORT; if (cmd->flags & MMC_RSP_CRC) flags |= SDHCI_CMD_CRC; if (cmd->flags & MMC_RSP_OPCODE) flags |= SDHCI_CMD_INDEX; /* CMD19 is special in that the Data Present Select should be set */ if (cmd->data || cmd->opcode == MMC_SEND_TUNING_BLOCK || cmd->opcode == MMC_SEND_TUNING_BLOCK_HS200) flags |= SDHCI_CMD_DATA; sdhci_writew(host, SDHCI_MAKE_CMD(cmd->opcode, flags), SDHCI_COMMAND); }
五、中断处理
mmc在注册中断是使用的中断标志是IRQF_SHARED，所以内核并不判断究竟是共享中断线上的哪个设备产生了中断，它会循环执行所有该中断线上注册的中断处理函数（即irqaction->handler函数）。因此irqaction->handler（即sdhci_irq）函数有责任识别出是否是自己的硬件设备产生了中断，然后再执行该中断处理函数。通常是通过读取该硬件设备提供的中断flag标志位进行判断。
可以看到当中断发生时，handler函数sdhci_irq首先对mmc controller中断寄存器读取，判断自己的设备是否发生了中断。
sdhci_irq主要做了三件事，清中断标志，判断是命令中断还是数据中断，这里是中断的上半部。以发生数据中断时分析，调用sdhci_data_irq处理。
static irqreturn_t sdhci_irq(int irq, void *dev_id) { irqreturn_t result = IRQ_NONE; struct sdhci_host *host = dev_id; u32 intmask, mask, unexpected = 0; int max_loops = 16; int cardint = 0; spin_lock(&host->lock); if (host->runtime_suspended && !sdhci_sdio_irq_enabled(host)) { spin_unlock(&host->lock); return IRQ_NONE; } intmask = sdhci_readl(host, SDHCI_INT_STATUS); if (!intmask || intmask == 0xffffffff) { result = IRQ_NONE; goto out; } do { /* Clear selected interrupts. */ mask = intmask & (SDHCI_INT_CMD_MASK | SDHCI_INT_DATA_MASK | SDHCI_INT_BUS_POWER); sdhci_writel(host, mask, SDHCI_INT_STATUS); DBG("*** %s got interrupt: 0x%08x\n", mmc_hostname(host->mmc), intmask); if (intmask & (SDHCI_INT_CARD_INSERT | SDHCI_INT_CARD_REMOVE)) { u32 present = sdhci_readl(host, SDHCI_PRESENT_STATE) & SDHCI_CARD_PRESENT; /* * There is a observation on i.mx esdhc. INSERT * bit will be immediately set again when it gets * cleared, if a card is inserted. We have to mask * the irq to prevent interrupt storm which will * freeze the system. And the REMOVE gets the * same situation. * * More testing are needed here to ensure it works * for other platforms though. */ host->ier &= ~(SDHCI_INT_CARD_INSERT | SDHCI_INT_CARD_REMOVE); host->ier |= present ? SDHCI_INT_CARD_REMOVE : SDHCI_INT_CARD_INSERT; sdhci_writel(host, host->ier, SDHCI_INT_ENABLE); sdhci_writel(host, host->ier, SDHCI_SIGNAL_ENABLE); sdhci_writel(host, intmask & (SDHCI_INT_CARD_INSERT | SDHCI_INT_CARD_REMOVE), SDHCI_INT_STATUS); host->thread_isr |= intmask & (SDHCI_INT_CARD_INSERT | SDHCI_INT_CARD_REMOVE); result = IRQ_WAKE_THREAD; } if (intmask & SDHCI_INT_CMD_MASK) sdhci_cmd_irq(host, intmask & SDHCI_INT_CMD_MASK, &intmask); if (intmask & SDHCI_INT_DATA_MASK) sdhci_data_irq(host, intmask & SDHCI_INT_DATA_MASK); if (intmask & SDHCI_INT_BUS_POWER) pr_err("%s: Card is consuming too much power!\n", mmc_hostname(host->mmc)); if (intmask & SDHCI_INT_RETUNE) mmc_retune_needed(host->mmc); if (intmask & SDHCI_INT_CARD_INT) { if (host->mmc->caps2 & MMC_CAP2_SDIO_IRQ_NOTHREAD) { sdhci_enable_sdio_irq_nolock(host, false); host->thread_isr |= SDHCI_INT_CARD_INT; result = IRQ_WAKE_THREAD; } else { cardint = 1; } } intmask &= ~(SDHCI_INT_CARD_INSERT | SDHCI_INT_CARD_REMOVE | SDHCI_INT_CMD_MASK | SDHCI_INT_DATA_MASK | SDHCI_INT_ERROR | SDHCI_INT_BUS_POWER | SDHCI_INT_CARD_INT); if (intmask) { unexpected |= intmask; sdhci_writel(host, intmask, SDHCI_INT_STATUS); } if (result == IRQ_NONE) result = IRQ_HANDLED; intmask = sdhci_readl(host, SDHCI_INT_STATUS); } while (intmask && --max_loops); out: spin_unlock(&host->lock); if (unexpected) { pr_err("%s: Unexpected interrupt 0x%08x.\n", mmc_hostname(host->mmc), unexpected); sdhci_dumpregs(host); } if (cardint && host->mmc->sdio_irqs) mmc_signal_sdio_irq(host->mmc); return result; }
sdhci_data_irq
当上半部完成时，调用sdhci_finish_data(host)，随后执行tasklet_schedule(&host->finish_tasklet)，待处理器调度执行mmc的tasklet。
static void sdhci_data_irq(struct sdhci_host *host, u32 intmask) { ··············省略················· if (intmask & SDHCI_INT_DATA_END) { if (host->cmd) { /* * Data managed to finish before the * command completed. Make sure we do * things in the proper order. */ host->data_early = 1; } else { sdhci_finish_data(host); } } } }
sdhci_tasklet_finish
该函数在sdhci_add_host初始化，当中断下半部任务完成后，也就是mmc驱动程序完成了一个请求的处理，随后执行mmc_request_done。
static void sdhci_tasklet_finish(unsigned long param) { struct sdhci_host *host; unsigned long flags; struct mmc_request *mrq; host = (struct sdhci_host*)param; spin_lock_irqsave(&host->lock, flags); /* * If this tasklet gets rescheduled while running, it will * be run again afterwards but without any active request. */ if (!host->mrq) { spin_unlock_irqrestore(&host->lock, flags); return; } del_timer(&host->timer); mrq = host->mrq; /* * The controller needs a reset of internal state machines * upon error conditions. */ if (!(host->flags & SDHCI_DEVICE_DEAD) && ((mrq->cmd && mrq->cmd->error) || (mrq->sbc && mrq->sbc->error) || (mrq->data && ((mrq->data->error && !mrq->data->stop) || (mrq->data->stop && mrq->data->stop->error))) || (host->quirks & SDHCI_QUIRK_RESET_AFTER_REQUEST))) { /* Some controllers need this kick or reset won't work here */ if (host->quirks & SDHCI_QUIRK_CLOCK_BEFORE_RESET) /* This is to force an update */ host->ops->set_clock(host, host->clock); /* Spec says we should do both at the same time, but Ricoh controllers do not like that. */ sdhci_do_reset(host, SDHCI_RESET_CMD); sdhci_do_reset(host, SDHCI_RESET_DATA); } host->mrq = NULL; host->cmd = NULL; host->data = NULL; #ifndef SDHCI_USE_LEDS_CLASS sdhci_deactivate_led(host); #endif mmiowb(); spin_unlock_irqrestore(&host->lock, flags); mmc_request_done(host->mmc, mrq); sdhci_runtime_pm_put(host); }
wake_up_interruptible
最后通过mrq->done，即mmc_wait_data_done（在__mmc_start_data_req函数赋值），唤醒mmc上下文，作为回调传递给主控制器驱动程序到此完成一个闭环。
static void mmc_wait_data_done(struct mmc_request *mrq) { struct mmc_context_info *context_info = &mrq->host->context_info; context_info->is_done_rcv = true; wake_up_interruptible(&context_info->wait); }
六 总结
忽略掉大部分细节，提炼出主要流程，用一张图概括MMC读写的大概流程。
还有很多很多细节无法全部展示，只能身处那个情景才能分析，对于MMC驱动，内核已经实现，做产品的更多的关注host层以及card的初始化（由于篇幅过长，本文暂未介绍）。
对于mmc controller，对于做产品的来说其实是一个黑盒，eMMC内部也是有firmware去控制的，更多的细节eMMC或者SD卡厂商才知道。但是厂商也是根据JEDEC标准去设计的，他们的芯片手册类似但更简洁。
