Elastic-Job-Lite和Elastic-Job-Cloud提供统一作业接口，开发者仅需作业接口做自己的实现，再进行不同的配置以及部署即可完成一个分布式的Job。
Java配置启动
- 首先引入maven依赖
<dependency> <groupId>com.dangdang</groupId> <artifactId>elastic-job-lite-core</artifactId> <version>2.1.5</version> </dependency> 复制代码
- 接着实现统一作业接口进行业务操作
@Slf4j public class MyElasticJob implements SimpleJob { @Override public void execute(ShardingContext context) { switch (context.getShardingItem()) { case 0: log.info("0000"); break; case 1: log.info("1111"); break; case 2: log.info("2222"); break; } } } 复制代码
- 对作业进行配置工作
// 作业的基本配置内容 private static LiteJobConfiguration createJobConfiguration() { // 定义作业核心配置 JobCoreConfiguration simpleCoreConfig = JobCoreConfiguration.newBuilder("demoSimpleJob", "0/15 * * * * ?", 10).build(); // 定义SIMPLE类型配置 SimpleJobConfiguration simpleJobConfig = new SimpleJobConfiguration(simpleCoreConfig, MyElasticJob.class.getCanonicalName()); // 定义Lite作业根配置 return LiteJobConfiguration.newBuilder(simpleJobConfig).build(); } // zookeeper注册中心配置 private static CoordinatorRegistryCenter createRegistryCenter() { CoordinatorRegistryCenter regCenter = new ZookeeperRegistryCenter(new ZookeeperConfiguration("zk_host:2181", "elastic-job-demo")); regCenter.init(); return regCenter; } 复制代码
- 启动运行作业
public class JavaMain { public static void main(String[] args) { new JobScheduler(createRegistryCenter(), createJobConfiguration()).init(); } } 复制代码
通过控制台打印输出的内容，可以发现Demo编写运行成功，恭喜你！
[IMFO]2020-07-30 14:39:15,227--main--[org quartz.impl.StaschedulerFactory] Quartz scheduler'demoSimpleJb’initialized from an externally provided properties instance [I1FO]2020-07-3014:39:15,227--main-- [orgquartz.impl.StdSchedulerFactory] Quartz scheduler version: 2.2.1 [I1FO ]2020-07-30 14:39:15,512 --main-- [org quartz.core.QuartzScheduler] Scheduler demoSimpleJob_$_NOI_CLUSTERED started [I1FO ]2020-07-30 14:39:31,027 --inner-job-demoSimpleJob-1- [example.MyElasticJob] 0000 [INFO ]2020-07-30 14:39:31,027 --inner-job-demoSimpleJob-2- [example.MyElasticJob] 1111 [I1FO]2020-07-30 14:39:31,028 --inner-job-demoSimpleJob-3- [example.MyElasticJob] 2222 [INFO ]2020-07-30 14:39:45,387 --inner-job-demoSimpleJob-3- [example.MyElasticJob] 0000 [INFO]2020-07-30 14:39:45,387 --inner-job-demoSimpleJob-4- [example.MyElasticJob] 1111 [INFO]2020-07-30 14:39:45,387 --inner-job-demoSimpleJob-5- [example.MyElasticJob] 2222 [I1FO]2020-07-30 14:40:00,511 --inner-job-demoSimpleJob-6- example MvElasticTob] 0000 [INF0]2020-07-3014:40:00.511--inner-job-demoSimpleJob-4--[example.MvElasticJob] 1111 [IMF012020-07-3014:40:00.512--inner-iob-demoSimpleJob-6--[example.MvFlasticJob] 2222
[zk:localhost:2181(CONNECTED)2] ls / elastic-iob-lite-springboot,log dir event notification isr change notification, zookeeper, admin, consumers cluster, config，latest producer_id block, brokers, controller epoch] Telastic-job-lite-springboot，log_dir_event_notification,isr_change_notification, zookeeper, admin elastic-job-demo-quick-demo consume erscluster, config,latest_producer id block, brokers, controller epoch] zk:localhost:2181(CONNECTED)3] ls / Telastic-job-lite-springboot, log dir event notification,dd-job, isr change notification, zookeeper, admin,elastic-job-demo-quick-demo consumerscluster,config,latest producer id block, brokes税ohtralledepoth区 zk:localhost:2181(CONNECTED)4]
由于大部分人都用spring或Spring boot， 所以这2中方式接下来也是要介绍的。
使用Spring配置启动
- 添加如下maven 依赖
<dependency> <groupId>com.dangdang</groupId> <artifactId>elastic-job-lite-spring</artifactId> <version>2.1.5</version> </dependency> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-context</artifactId> </dependency> 复制代码
- 作业的Spring配置 在resource目录下添加文件applicationContext.xml，内容如下
<?xml version="1.0" encoding="UTF-8"?> <beans xmlns="http://www.springframework.org/schema/beans" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:reg="http://www.dangdang.com/schema/ddframe/reg" xmlns:job="http://www.dangdang.com/schema/ddframe/job" xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd http://www.dangdang.com/schema/ddframe/reg http://www.dangdang.com/schema/ddframe/reg/reg.xsd http://www.dangdang.com/schema/ddframe/job http://www.dangdang.com/schema/ddframe/job/job.xsd "> <!--配置作业注册中心 --> <reg:zookeeper id="regCenter" server-lists="192.168.104.102:2181" namespace="dd-job" base-sleep-time-milliseconds="1000" max-sleep-time-milliseconds="3000" max-retries="3"/> <!-- 配置作业--> <job:simple id="demoSimpleSpringJob" class="example.MyElasticJob" registry-center-ref="regCenter" cron="0/10 * * * * ?" sharding-total-count="3" sharding-item-parameters="0=A,1=B,2=C"/> </beans> 复制代码
- 启动作业 程序启动读取Spring配置文件，作业将自动加载。
public class JavaMain { public static void main(String[] args) { new ClassPathXmlApplicationContext("classpath:applicationContext.xml"); } } 复制代码
[IFO ]2020-07-3014:57:32,967--main-- [orgquartz.impl.StaschedulerFactory] Quartz scheduler'demoSimpleSpringJob’initialized from an pyterng 7t provided properties instance [I1FO ]2020-07-30 14:57:32,967--main-- [orgquartz.impl.StdSchedulerFactory] Quartz scheduler version: 2.2.1 [I1FO ]2020-07-3014:57:33,230 --main-- [org.quartz.core.QuartzScheduler]SchedulerdemoSimpleSpringJob_$_NON_CLUSTERED started [IFO]2020-07-3014:57:40,385--inner-job-demoSimpleSpringJob-1--[example.MyElasticJob] 0000 [INFO]2020-07-3014:57:40,385--inner-job-demoSimpleSpringJob-2--[example.MyElasticJob] 1111 [INFO]2020-07-3014:57:40,385--inner-job-demoSimpleSpringJob-3--[example.MyElasticJob] 2222 [INFO]2020-07-30 14:57:50,159 --inner-job-demoSimpleSpringJob-4--[example.MyElasticJob] 0000 [I1FO]2020-07-30 14:57:50,160 --inner-job-demoSimpleSpringJob-5--[example.MyElasticJob] 1111 [I1FO]2020-07-3014:57:50,160--inner-job-demoSimpleSpringJob-6--[example.MyElasticJob] 2222
zk:localhost:2181(CONNECTED) 1] ls / elastic-job-lite-springboot，log_dir_event_notification,isr_change_notification, zookeeper, admin, consumers, cluster, config, latest_p oroducer id block, brokers, controller epoch] zk:localhost:2181(CONNECTED)2] ls / [elastic-job-lite-springboot, log dir event notification,isr change notification, zookeeper,admin, elastic-job-demo-quick-demo, consume erscluster. config,latest producer id block, brokers, controller epoch] Izk:localhost:2181(CONNECTED)3] ls/ 7k:1ncalhnst:2181(CONNECTEn)41 elastic-job-lite-springboot, log dir event notification, dd-job isr change notification, zookeeper, admin，elastic-job-demo-quick-demo consumers,cluster,config,latest_producer_id_block, brokers, con@roiter
作业类型介绍
Elastic-Job提供Simple、Dataflow和Script 3种作业类型。
Simple类型作业
意为简单实现，未经任何封装的类型。需实现SimpleJob接口。该接口仅提供单一方法用于覆盖，此方法将定时执行。与Quartz原生接口相似，但提供了弹性扩缩容和分片等功能。
public class MyElasticJob implements SimpleJob { @Override public void execute(ShardingContext context) { switch (context.getShardingItem()) { case 0: // do something by sharding item 0 break; case 1: // do something by sharding item 1 break; case 2: // do something by sharding item 2 break; // case n: ... } } } 复制代码
Dataflow类型作业
Dataflow类型用于处理数据流，需实现DataflowJob接口。该接口提供2个方法可供覆盖，分别用于抓取(fetchData)和处理(processData)数据。
可通过DataflowJobConfiguration配置是否流式处理。
流式处理数据只有fetchData方法的返回值为null或集合长度为空时，作业才停止抓取，否则作业将一直运行下去； 非流式处理数据则只会在每次作业执行过程中执行一次fetchData方法和processData方法，随即完成本次作业。
如果采用流式作业处理方式，建议processData处理数据后更新其状态，避免fetchData再次抓取到，从而使得作业永不停止。 流式数据处理参照TbSchedule设计，适用于不间歇的数据处理。
public class MyElasticJob implements DataflowJob<Foo> { @Override public List<Foo> fetchData(ShardingContext context) { switch (context.getShardingItem()) { case 0: List<Foo> data = // get data from database by sharding item 0 return data; case 1: List<Foo> data = // get data from database by sharding item 1 return data; case 2: List<Foo> data = // get data from database by sharding item 2 return data; // case n: ... } } @Override public void processData(ShardingContext shardingContext, List<Foo> data) { // process data // ... } } 复制代码
Script类型作业
Script类型作业意为脚本类型作业，支持shell，python，perl等所有类型脚本。只需通过控制台或代码配置scriptCommandLine即可，无需编码。执行脚本路径可包含参数，参数传递完毕后，作业框架会自动追加最后一个参数为作业运行时信息。
#!/bin/bash echo sharding execution context is $* 复制代码
作业运行时会输出
sharding execution context is {“jobName”:“scriptElasticDemoJob”,“shardingTotalCount”:10,“jobParameter”:“”,“shardingItem”:0,“shardingParameter”:“A”} 复制代码
以上方法中的参数shardingContext包含作业配置、片和运行时信息。可通过getShardingTotalCount(), getShardingItem()等方法分别获取分片总数，运行在本作业服务器的分片序列号等。
配置介绍
配置说明
Elastic-Job配置分为3个层级，分别是Core, Type和Root。每个层级使用相似于装饰者模式的方式装配。
Core对应JobCoreConfiguration，用于提供作业核心配置信息，如：作业名称、分片总数、CRON表达式等。
Type对应JobTypeConfiguration，有3个子类分别对应SIMPLE, DATAFLOW和SCRIPT类型作业，提供3种作业需要的不同配置，如：DATAFLOW类型是否流式处理或SCRIPT类型的命令行等。
Root对应JobRootConfiguration，有2个子类分别对应Lite和Cloud部署类型，提供不同部署类型所需的配置，如：Lite类型的是否需要覆盖本地配置或Cloud占用CPU或Memory数量等。
类似如下代码
// 定义作业核心配置 JobCoreConfiguration simpleCoreConfig = JobCoreConfiguration.newBuilder("demoSimpleJob", "0/15 * * * * ?", 10).build(); // 定义SIMPLE类型配置 SimpleJobConfiguration simpleJobConfig = new SimpleJobConfiguration(simpleCoreConfig, SimpleDemoJob.class.getCanonicalName()); // 定义Lite作业根配置 JobRootConfiguration simpleJobRootConfig = LiteJobConfiguration.newBuilder(simpleJobConfig).build(); 复制代码
Spring的配置说明
与Spring容器配合使用作业，可将作业Bean配置为Spring Bean，并在作业中通过依赖注入使用Spring容器管理的数据源等对象。可用placeholder占位符从属性文件中取值。Lite可考虑使用Spring命名空间方式简化配置。
<?xml version="1.0" encoding="UTF-8"?> <beans xmlns="http://www.springframework.org/schema/beans" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:reg="http://www.dangdang.com/schema/ddframe/reg" xmlns:job="http://www.dangdang.com/schema/ddframe/job" xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd http://www.dangdang.com/schema/ddframe/reg http://www.dangdang.com/schema/ddframe/reg/reg.xsd http://www.dangdang.com/schema/ddframe/job http://www.dangdang.com/schema/ddframe/job/job.xsd "> <!--配置作业注册中心 --> <reg:zookeeper id="regCenter" server-lists="yourhost:2181" namespace="dd-job" base-sleep-time-milliseconds="1000" max-sleep-time-milliseconds="3000" max-retries="3" /> <!-- 配置简单作业--> <job:simple id="simpleElasticJob" class="xxx.MySimpleElasticJob" registry-center-ref="regCenter" cron="0/10 * * * * ?" sharding-total-count="3" sharding-item-parameters="0=A,1=B,2=C" /> <bean id="yourRefJobBeanId" class="xxx.MySimpleRefElasticJob"> <property name="fooService" ref="xxx.FooService"/> </bean> <!-- 配置关联Bean作业--> <job:simple id="simpleRefElasticJob" job-ref="yourRefJobBeanId" registry-center-ref="regCenter" cron="0/10 * * * * ?" sharding-total-count="3" sharding-item-parameters="0=A,1=B,2=C" /> <!-- 配置数据流作业--> <job:dataflow id="throughputDataflow" class="xxx.MyThroughputDataflowElasticJob" registry-center-ref="regCenter" cron="0/10 * * * * ?" sharding-total-count="3" sharding-item-parameters="0=A,1=B,2=C" /> <!-- 配置脚本作业--> <job:script id="scriptElasticJob" registry-center-ref="regCenter" cron="0/10 * * * * ?" sharding-total-count="3" sharding-item-parameters="0=A,1=B,2=C" script-command-line="/your/file/path/demo.sh" /> <!-- 配置带监听的简单作业--> <job:simple id="listenerElasticJob" class="xxx.MySimpleListenerElasticJob" registry-center-ref="regCenter" cron="0/10 * * * * ?" sharding-total-count="3" sharding-item-parameters="0=A,1=B,2=C"> <job:listener class="xx.MySimpleJobListener"/> <job:distributed-listener class="xx.MyOnceSimpleJobListener" started-timeout-milliseconds="1000" completed-timeout-milliseconds="2000" /> </job:simple> <!-- 配置带作业数据库事件追踪的简单作业--> <job:simple id="eventTraceElasticJob" class="xxx.MySimpleListenerElasticJob" registry-center-ref="regCenter" cron="0/10 * * * * ?" sharding-total-count="3" sharding-item-parameters="0=A,1=B,2=C" event-trace-rdb-data-source="yourDataSource"> </job:simple> </beans> 复制代码
Java的配置说明
public final class JavaMain { public static void main(String[] args) { new JobScheduler(createRegistryCenter(), createJobConfiguration()).init(); } private static CoordinatorRegistryCenter createRegistryCenter() { CoordinatorRegistryCenter regCenter = new ZookeeperRegistryCenter( new ZookeeperConfiguration("192.168.104.102:2181", "elastic-job-demo-quick-demo")); regCenter.init(); return regCenter; } private static LiteJobConfiguration createJobConfiguration() { // 定义作业核心配置 JobCoreConfiguration simpleCoreConfig = JobCoreConfiguration.newBuilder("demoSimpleJob", "0/15 * * * * ?", 10).build(); // 定义SIMPLE类型配置 SimpleJobConfiguration simpleJobConfig = new SimpleJobConfiguration(simpleCoreConfig, MyElasticJob.class.getCanonicalName()); // 定义Lite作业根配置 return LiteJobConfiguration.newBuilder(simpleJobConfig).build(); } } 复制代码
详细的规则配置请参考配置手册
