bthread源码剖析（二）: 工作窃取与TaskGroup的run_main_task()

size_t _steal_seed;
    size_t _steal_offset;
    ContextualStack* _main_stack;
    bthread_t _main_tid;
    WorkStealingQueue<bthread_t> _rq;
    RemoteTaskQueue _remote_rq;

// Push a bthread into the runqueue from another non-worker thread.
    void ready_to_run_remote(bthread_t tid, bool nosignal = false);

TaskGroup* g = tls_task_group;
    if (g) {
        TaskGroup::exchange(&g, bbw->tid);
    } else {
        bbw->control->choose_one_group()->ready_to_run_remote(bbw->tid);
    }

template <bool REMOTE>
int TaskGroup::start_background(bthread_t* __restrict th,
                                const bthread_attr_t* __restrict attr,
                                void * (*fn)(void*),
                                void* __restrict arg) {
...
...
    if (REMOTE) {
        ready_to_run_remote(m->tid, (using_attr.flags & BTHREAD_NOSIGNAL));
    } else {
        ready_to_run(m->tid, (using_attr.flags & BTHREAD_NOSIGNAL));
    }
    return 0;
}

void TaskGroup::run_main_task() {
    ...
    TaskGroup* dummy = this;
    bthread_t tid;
    while (wait_task(&tid)) {
        TaskGroup::sched_to(&dummy, tid);
        DCHECK_EQ(this, dummy);
        DCHECK_EQ(_cur_meta->stack, _main_stack);
        if (_cur_meta->tid != _main_tid) {
            TaskGroup::task_runner(1/*skip remained*/);
        }
        ...
    }
    // Don't forget to add elapse of last wait_task.
    current_task()->stat.cputime_ns += butil::cpuwide_time_ns() - _last_run_ns;
}

bool TaskGroup::wait_task(bthread_t* tid) {
    do {
        if (_last_pl_state.stopped()) {
            return false;
        }
        _pl->wait(_last_pl_state);
        if (steal_task(tid)) {
            return true;
        }
    } while (true);
}

TaskGoup::steal_task()
    bool steal_task(bthread_t* tid) {
        if (_remote_rq.pop(tid)) {
            return true;
        }
        _last_pl_state = _pl->get_state();
        return _control->steal_task(tid, &_steal_seed, _steal_offset);
    }

bool TaskControl::steal_task(bthread_t* tid, size_t* seed, size_t offset) {
    // 1: Acquiring fence is paired with releasing fence in _add_group to
    // avoid accessing uninitialized slot of _groups.
    const size_t ngroup = _ngroup.load(butil::memory_order_acquire/*1*/);
    if (0 == ngroup) {
        return false;
    }
    // NOTE: Don't return inside `for' iteration since we need to update |seed|
    bool stolen = false;
    size_t s = *seed;
    for (size_t i = 0; i < ngroup; ++i, s += offset) {
        TaskGroup* g = _groups[s % ngroup];
        // g is possibly NULL because of concurrent _destroy_group
        if (g) {
            if (g->_rq.steal(tid)) {
                stolen = true;
                break;
            }
            if (g->_remote_rq.pop(tid)) {
                stolen = true;
                break;
            }
        }
    }
    *seed = s;
    return stolen;
}

void TaskGroup::task_runner(intptr_t skip_remained) {
    TaskGroup* g = tls_task_group;
    if (!skip_remained) {
        while (g->_last_context_remained) {
            RemainedFn fn = g->_last_context_remained;
            g->_last_context_remained = NULL;
            fn(g->_last_context_remained_arg);
            g = tls_task_group;
        }
     ...
     }

do {
        // Meta and identifier of the task is persistent in this run.
        TaskMeta* const m = g->_cur_meta;
        ...
        // 执行TM（bthread)中的回调函数
        void* thread_return;
        try {
            thread_return = m->fn(m->arg);
        } catch (ExitException& e) {
            thread_return = e.value();
        }
        // Group is probably changed
        g = tls_task_group;
        // TODO: Save thread_return
        (void)thread_return;
        ... 日志
        // 清理 线程局部变量（下面是原注释)
        // Clean tls variables, must be done before changing version_butex
        // otherwise another thread just joined this thread may not see side
        // effects of destructing tls variables.
        KeyTable* kt = tls_bls.keytable;
        if (kt != NULL) {
            return_keytable(m->attr.keytable_pool, kt);
            // After deletion: tls may be set during deletion.
            tls_bls.keytable = NULL;
            m->local_storage.keytable = NULL; // optional
        }
        // 累加版本号，且版本号不能为0（下面是原注释)
        // Increase the version and wake up all joiners, if resulting version
        // is 0, change it to 1 to make bthread_t never be 0. Any access
        // or join to the bthread after changing version will be rejected.
        // The spinlock is for visibility of TaskGroup::get_attr.
        {
            BAIDU_SCOPED_LOCK(m->version_lock);
            if (0 == ++*m->version_butex) {
                ++*m->version_butex;
            }
        }
        // 唤醒joiner
        butex_wake_except(m->version_butex, 0);
        // _nbthreads减1（注意_nbthreads不是整型）
        g->_control->_nbthreads << -1;
        g->set_remained(TaskGroup::_release_last_context, m);
        // 查找下一个任务，并切换到其对应的运行时上下文
        ending_sched(&g);
    } while (g->_cur_meta->tid != g->_main_tid);
