本文要讲解，在CRM应用之外，不具有CRM context的情况下，如何连接到CRM，获得CRM的相关数据。如果你有耐心的话，也可以仔细研究一下SDK中Sample: Simplified Connection Quick Start using Microsoft Dynamics CRM 2011 and Microsoft Dynamics CRM Online。

CRM 2011提供了一个Assembly microsoft.xrm.client.dll，如果从客户端连接CRM的话，可以使用该Assembly中的OrganizationService类。我在本文中以一个控制台程序来演示如何连接到CRM 2011。首先程序需要使用到的引用如下图。有关CRM的引用都可以在sdk的bin文件夹中找到。

Program.cs的代码为：

using System;
using Microsoft.Xrm.Client.Services;
using Microsoft.Xrm.Client;
using Microsoft.Crm.Sdk.Messages;
using System.ServiceModel;
using System.Configuration;
using Microsoft.Xrm.Sdk;
using Microsoft.Xrm.Sdk.Query;

namespace ConsoleApplication3
{
    public class SimplifiedConnection
    {
        #region Class Level Members

        private OrganizationService _orgService;

        #endregion Class Level Members

        public void Run(String connectionString, bool promptforDelete)
        {
            try
            {
                // Establish a connection to the organization web service using CrmConnection.
                Microsoft.Xrm.Client.CrmConnection connection = CrmConnection.Parse(connectionString);

                // Obtain an organization service proxy.
                // The using statement assures that the service proxy will be properly disposed.
                using (_orgService = new OrganizationService(connection))
                {
                    // Obtain information about the logged on user from the web service.
                    Guid userid = ((WhoAmIResponse)_orgService.Execute(new WhoAmIRequest())).UserId;
                    Entity systemUser = _orgService.Retrieve("systemuser", userid,
                        new ColumnSet(new string[] { "firstname", "lastname" }));
                    Console.WriteLine("Logged on user is {0} {1}.",
                        systemUser["firstname"].ToString(), systemUser["lastname"].ToString());
                }
            }

            // Catch any service fault exceptions that Microsoft Dynamics CRM throws.
            catch (FaultException<Microsoft.Xrm.Sdk.OrganizationServiceFault>)
            {
                // You can handle an exception here or pass it back to the calling method.
                throw;
            }
        }

        #region Public Methods



        #endregion Public Methods

        #region Private Methods

        /// <summary>
        /// Gets web service connection information from the app.config file.
        /// If there is more than one available, the user is prompted to select
        /// the desired connection configuration by name.
        /// </summary>
        /// <returns>A string containing web service connection configuration information.</returns>
        private static String GetServiceConfiguration()
        {
            var connection = ConfigurationManager.ConnectionStrings["CrmConnection"];
            return connection.ConnectionString;
        }



        #endregion Private Methods

        #region Main method

        /// <summary>
        /// Standard Main() method used by most SDK samples.
        /// </summary>
        /// <param name="args"></param>
        static public void Main(string[] args)
        {
            try
            {
                // Obtain connection configuration information for the Microsoft Dynamics
                // CRM organization web service.
                String connectionString = GetServiceConfiguration();

                if (connectionString != null)
                {
                    SimplifiedConnection app = new SimplifiedConnection();
                    app.Run(connectionString, true);
                }
            }

            catch (FaultException<Microsoft.Xrm.Sdk.OrganizationServiceFault> ex)
            {
                Console.WriteLine("The application terminated with an error.");
                Console.WriteLine("Timestamp: {0}", ex.Detail.Timestamp);
                Console.WriteLine("Code: {0}", ex.Detail.ErrorCode);
                Console.WriteLine("Message: {0}", ex.Detail.Message);
                Console.WriteLine("Trace: {0}", ex.Detail.TraceText);
                Console.WriteLine("Inner Fault: {0}",
                    null == ex.Detail.InnerFault ? "Has Inner Fault" : "No Inner Fault");
            }
            catch (System.TimeoutException ex)
            {
                Console.WriteLine("The application terminated with an error.");
                Console.WriteLine("Message: {0}", ex.Message);
                Console.WriteLine("Stack Trace: {0}", ex.StackTrace);
                Console.WriteLine("Inner Fault: {0}",
                    null == ex.InnerException.Message ? "Has Inner Fault" : "No Inner Fault");
            }
            catch (System.Exception ex)
            {
                Console.WriteLine("The application terminated with an error.");
                Console.WriteLine(ex.Message);

                // Display the details of the inner exception.
                if (ex.InnerException != null)
                {
                    Console.WriteLine(ex.InnerException.Message);

                    FaultException<Microsoft.Xrm.Sdk.OrganizationServiceFault> fe = ex.InnerException
                        as FaultException<Microsoft.Xrm.Sdk.OrganizationServiceFault>;
                    if (fe != null)
                    {
                        Console.WriteLine("Timestamp: {0}", fe.Detail.Timestamp);
                        Console.WriteLine("Code: {0}", fe.Detail.ErrorCode);
                        Console.WriteLine("Message: {0}", fe.Detail.Message);
                        Console.WriteLine("Trace: {0}", fe.Detail.TraceText);
                        Console.WriteLine("Inner Fault: {0}",
                            null == fe.Detail.InnerFault ? "Has Inner Fault" : "No Inner Fault");
                    }
                }
            }

            // Additional exceptions to catch: SecurityTokenValidationException, ExpiredSecurityTokenException,
            // SecurityAccessDeniedException, MessageSecurityException, and SecurityNegotiationException.

            finally
            {
                Console.WriteLine("Press <Enter> to exit.");
                Console.ReadLine();
            }
        }
        #endregion Main method
    }
}

上面的程序需要从配置文件读取ConnectionString。一个范例app.config文件如下所示。

<?xml version="1.0"?>
<configuration>
  <connectionStrings>

    <!-- Online using Office 365 -->
    <!-- <add name="CrmConnection"
         connectionString="Url=https://contoso.crm.dynamics.com;
         Username=someone@contoso.onmicrosoft.com;
         Password=password;"/> -->

    <!-- Online using Windows Live ID -->
     <add name="CrmConnection"
         connectionString="Url=https://aaronbabbitt.api.crm4.dynamics.com/XRMServices/2011/Organization.svc;
         Username=username@aaronbabbitt.onmicrosoft.com; Password=password; DeviceID=11hfn41bbqrg580vyvoea05abc;
         DevicePassword=fuqNIlx%e$.l*+ax_#8O4abc;"/>

    <!--On-premises with provided user credentials-->
    <!--<add name="CrmConnection"
         connectionString="Url=http://servername/orgname; Domain=domainname; Username=username;
         Password=password;"/>-->

    <!-- On-premises using Windows integrated security -->
    <!--<add name="CrmConnection"
         connectionString="Url=http://servername/orgname;"/>-->

    <!-- On-Premises (IFD) with claims -->
    <!--<add name="CrmConnection"
         connectionString="Url=https://url.xxx/XRMServices/2011/Organization.svc;
         Username=username@xxx.local; Password=password;"/>-->
  </connectionStrings>
  <startup>
    <supportedRuntime version="v4.0" sku=".NETFramework,Version=v4.0"/>
  </startup>
</configuration>

这段代码完成的事情很简单，就是使用OrganizationService类来执行一个WhoAmIRequest。如果成功就表示控制台成功连接到了CRM。配置文件中一共有5个connection string 的样例。分别用来连接：

（1）使用Office 365 ID 的 CRM Online；

（2）使用Windows Live ID的 CRM Online；

（3） CRM On-Premises；

（4）CRM On-Premises，使用当前Windows integrated security来登录，所以不需要提供用户密码；

（5）使用了IFD的CRM On-Premises。

上面除了（1）我没有进行测试，其他四种CRM都通过了该段代码的测试。在Connection String中，对于CRM Online和IFD On-Premises，URL需要使用Organization Service 的 URL。要查看CRM的Organization Service的URL，可以在Settings –> Customization –> Customizations –> Developer Resources中查看

连接CRM Online的时候，需要DeviceID和DevicePassword。很多人不懂DeviceID是干什么用的。DeviceID的目的就是注册一个设备，使这个设备可以使用Windows Live ID。当你注册了这个设备后，任何用户就都可以使用这个设备了。所以如果这个是一个从未注册过的设备，你首先要注册它。关于如何注册一个设备，可以使用sdk带的deviceregistration工具。具体的命令是DeviceRegistration.exe /operation:Register。命令运行成功后，你就可以拷贝生成的Device ID和Device Password了。

最后再说一下，因为在配置文件中，我们保存了用户登录信息，这样很容易泄露用户名和密码，所以我再说一下如何对配置文件的Connection string进行加密。对配置文件加密可以使用aspnet_regiis.exe工具，Visual Studio自带这个工具。如果没有Visual Studio，.Net中也包含了这个工具。可以在%windows root directory%\Microsoft.NET\%Framework\%version 中找到该工具。首先将app.config另存为文件名为web.config的文件，假如我将该文件保存到我的C:\temp目录中。文件的内容为：

<?xml version="1.0"?>
<configuration>
  <connectionStrings>

    <!-- Online using Windows Live ID -->
    <add name="CrmConnection"
        connectionString="Url=https://aaronbabbitt.api.crm4.dynamics.com/XRMServices/2011/Organization.svc;
         Username=username@aaronbabbitt.onmicrosoft.com; Password=password; DeviceID=11hfn41bbqrg580vyvoea05abc;
         DevicePassword=fuqNIlx%e$.l*+ax_#8O4abc;"/>

  </connectionStrings>
  <startup>
    <supportedRuntime version="v4.0" sku=".NETFramework,Version=v4.0"/>
  </startup>
</configuration>

运行命令 aspnet_regiis -pef "connectionStrings" "C:\temp"，打开web.config文件，发现加密后的内容为：

<?xml version="1.0"?>
<configuration>
  <connectionStrings configProtectionProvider="RsaProtectedConfigurationProvider">
      <EncryptedData Type="http://www.w3.org/2001/04/xmlenc#Element"
          xmlns="http://www.w3.org/2001/04/xmlenc#">
          <EncryptionMethod Algorithm="http://www.w3.org/2001/04/xmlenc#tripledes-cbc" />
          <KeyInfo xmlns="http://www.w3.org/2000/09/xmldsig#">
              <EncryptedKey xmlns="http://www.w3.org/2001/04/xmlenc#">
                  <EncryptionMethod Algorithm="http://www.w3.org/2001/04/xmlenc#rsa-1_5" />
                  <KeyInfo xmlns="http://www.w3.org/2000/09/xmldsig#">
                      <KeyName>Rsa Key</KeyName>
                  </KeyInfo>
                  <CipherData>
                      <CipherValue>ll2Y+mC2QlqQ/xhj4jpTu4IQwYVoXjJ7ZVomJvWTtfo5f1o8N46lEPED5Z8k4RrSoJWlk2CKsmxIW8Y5soBlsckEe8ZAGfAHezynUXI1X3QNXLX7qm6F2A7NPuZxpEjKv1JEWOKpTxwo3MMXZwiKjuw3e/puOqKYsrfqT+wHK1E=</CipherValue>
                  </CipherData>
              </EncryptedKey>
          </KeyInfo>
          <CipherData>
              <CipherValue>1+ugw1BnAfPhQW3AXtWnjn+KjYFdD4xz56ue8RFjATaNw0HbdyoYm4F+R1zKQP7iqWIebD/gNoYNARFiF7BwHtgOO+7nJsSzkH5i6FgkNaJtvIPUMK7dXF9kCbXEB1MGmnSnjgb8AHhvy68k+Ib1HuWeSvlRDzHuLAOWQ4iM6+Impdcoe27Rs02tRs3a/Jy0NPFhUS+Ps0tTsMJQO5uztcjPbmaNx/jOoxHWaUDWpSx7ucaOK1p/Ko4aN29W1y7iCvvi0wFAOXPi1oega5qSXFnyIADekuPRXxM1vNvKHXBuemxslqtNfazTeY/NxkJ/qRYUbPfdxJRk2MaBZtPOS57nqTWxiRGQJtsUliw4Y0x8sfj/wO0/aDD7T/zFVOj9Ayk15bTNQ2Kpu8qM+DpiUkg/I6l0HDDYz1BZlgItGEjykDjgE6QrB6Woq+svAukEt7bbCitdPPSbliE7d1lxw6VktjQ9/3A1</CipherValue>
          </CipherData>
      </EncryptedData>
  </connectionStrings>
  <startup>
    <supportedRuntime version="v4.0" sku=".NETFramework,Version=v4.0"/>
  </startup>
</configuration>

然后你可以将该内容拷贝到你的app.config文件中去。

解密的命令为aspnet_regiis -pef "connectionStrings" "C:\temp"。当然解密与加密必须是在同一电脑上进行的，如果某个恶意用户获取了你加密后的app.config文件，在他自己的电脑上运行该命令是无法解密该文件的。

总结：从CRM外部连接CRM，可以使用上面的CRM“万能”连接程序，基本上各种deployment方式的CRM，都可以使用它来连接。该程序使用了Assembly microsoft.xrm.client.dll中的OrganizationService类。你需要在app.config或web.config中配置connection string。最后基于安全性，要对配置文件的connectionStrings section进行加密。加密可以使用aspnet_regiis 工具。
