MS CRM 2011 如何向自定义Ribbon按钮传递参数

2017-11-09 1170

版权

本文内容由阿里云实名注册用户自发贡献，版权归原作者所有，阿里云开发者社区不拥有其著作权，亦不承担相应法律责任。具体规则请查看《阿里云开发者社区用户服务协议》和《阿里云开发者社区知识产权保护指引》。如果您发现本社区中有涉嫌抄袭的内容，填写侵权投诉表单进行举报，一经查实，本社区将立刻删除涉嫌侵权内容。

简介：

首先介绍一下，如果你想查看CRM默认的(标准的)Ribbon定义，可以在sdk\resources\exportedribbonxml文件夹中找到对应Entity的xml文件。如果你想查看某个自定义Entity的ribbon定义，或者你已经对某个Entity进行了修改，可以将改Entity的ribbon定义导出到xml文件中，具体的操作可以参见sdk 中Export Ribbon Definitions这一章节。

在本文中，我们对客户(account)的ribbon进行修改。假如我们是一家投资公司，我们要为Connect按钮增加一个子选项To Investment Partner(默认的子选项有两个To Me和To Another)。

我们要在客户的表单上以及grid中对connect ribbon按钮进行修改，然后我们传递几个参数给我们connect按钮的新子选项，包括accountid，object type code，object type name。

首先我们要做的是，新建一个solution，并将account entity添加进来，注意不要添加其他”required components”。接下来我们新建一个Jscript web resource，我们命名它为AccountLibrary.js。js的代码我们一会再添加，现在先保存好solution，并导出来，解压缩后，我们对customizations.xml文件进行修改。

<RibbonDiffXml>
  <CustomActions>
    <CustomAction Id="mycompany.account.form.ConnectToInvestmentPartner.CustomAction" Location="Mscrm.Form.account.AddConnection.Controls._children" Sequence="42">
      <CommandUIDefinition>
        <Button Id="mycompany.account.form.ConnectToInvestmentPartner.Button" Command="mycompany.account.form.ConnectToInvestmentPartner.Command" LabelText="$LocLabels:mycompany.account.form.ConnectToInvestmentPartner.LabelText" ToolTipTitle="$LocLabels:mycompany.account.form.ConnectToInvestmentPartner.LabelText" ToolTipDescription="$LocLabels:mycompany.account.form.ConnectToInvestmentPartner.ToolTip" />
      </CommandUIDefinition>
    </CustomAction>
    <CustomAction Id="mycompany.account.grid.ConnectToInvestmentPartner.CustomAction" Location="Mscrm.HomepageGrid.account.AddConnection.Controls._children" Sequence="46">
      <CommandUIDefinition>
        <Button Id="mycompany.account.homepagegrid.ConnectToInvestmentPartner.Button" Command="mycompany.account.grid.ConnectToInvestmentPartner.Command" LabelText="$LocLabels:mycompany.account.form.ConnectToInvestmentPartner.LabelText" ToolTipTitle="$LocLabels:mycompany.account.form.ConnectToInvestmentPartner.LabelText" ToolTipDescription="$LocLabels:mycompany.account.form.ConnectToInvestmentPartner.ToolTip" />
      </CommandUIDefinition>
    </CustomAction>
    <CustomAction Id="mycompany.account.subgrid.ConnectToInvestmentPartner.CustomAction" Location="Mscrm.SubGrid.account.AddConnection.Controls._children" Sequence="21">
      <CommandUIDefinition>
        <Button Id="mycompany.account.subgrid.ConnectToInvestmentPartner.Button" Command="mycompany.account.grid.ConnectToInvestmentPartner.Command" LabelText="$LocLabels:mycompany.account.form.ConnectToInvestmentPartner.LabelText" ToolTipTitle="$LocLabels:mycompany.account.form.ConnectToInvestmentPartner.LabelText" ToolTipDescription="$LocLabels:mycompany.account.form.ConnectToInvestmentPartner.ToolTip" />
      </CommandUIDefinition>
    </CustomAction>
  </CustomActions>
  <Templates>
    <RibbonTemplates Id="Mscrm.Templates"></RibbonTemplates>
  </Templates>
  <CommandDefinitions>
    <CommandDefinition Id="mycompany.account.form.ConnectToInvestmentPartner.Command">
      <EnableRules>
        <EnableRule Id="Mscrm.Enabled" />
      </EnableRules>
      <DisplayRules />
      <Actions>
        <JavaScriptFunction Library="$webresource:new_AccountLibrary.js" FunctionName="AccountLibrary.AddConnectionToInvestmentPartner">
          <CrmParameter Value="FirstPrimaryItemId" />
          <CrmParameter Value="PrimaryEntityTypeCode" />
          <CrmParameter Value="PrimaryEntityTypeName" />
        </JavaScriptFunction>
      </Actions>
    </CommandDefinition>
    <CommandDefinition Id="mycompany.account.grid.ConnectToInvestmentPartner.Command">
      <EnableRules>
        <EnableRule Id="Mscrm.Enabled" />
      </EnableRules>
      <DisplayRules />
      <Actions>
        <JavaScriptFunction Library="$webresource:new_AccountLibrary.js" FunctionName="AccountLibrary.AddConnectionToInvestmentPartner">
          <CrmParameter Value="FirstSelectedItemId" />
          <CrmParameter Value="SelectedEntityTypeCode" />
          <CrmParameter Value="SelectedEntityTypeName" />
        </JavaScriptFunction>
      </Actions>
    </CommandDefinition>
  </CommandDefinitions>
  <RuleDefinitions>
    <TabDisplayRules />
    <DisplayRules />
    <EnableRules />
  </RuleDefinitions>
  <LocLabels>
    <LocLabel Id="mycompany.account.form.ConnectToInvestmentPartner.LabelText">
      <Titles>
        <Title languagecode="1033" description="To Investment Partner" />
        <Title languagecode="2052" description="投资伙伴" />
      </Titles>
    </LocLabel>
    <LocLabel Id="mycompany.account.form.ConnectToInvestmentPartner.ToolTip">
      <Titles>
        <Title languagecode="1033" description="To Investment Partner" />
        <Title languagecode="2052" description="投资伙伴" />
      </Titles>
    </LocLabel>
  </LocLabels>
</RibbonDiffXml>

我们在三处对account进行了修改：Form，HomepageGrid和SubGrid。

在Form上，我们使用的是以下几个参数:

在HomepageGrid和SubGrid，我们使用的是以下几个参数:

如果想查看完整的参数列表，可以查找SDK中“<CrmParameter> (RibbonDiffXml)”一节。再来看一下Jscript代码，把这段代码拷贝到AccountLibrary.js web resource中去。

if (typeof (AccountLibrary) == "undefined") {
    AccountLibrary = { __namespace: true };
}


AccountLibrary = {
    Name: "AccountLibrary",
    AddConnectionToInvestmentPartner: function (accountid, objecttypecode, objecttypename) {
        try {
            alert("account id = " + accountid);
            alert("objecttypecode = " + objecttypecode);
            alert("objecttypename = " + objecttypename);
        }
        catch (e) {
            alert(AccountLibrary.Name + " AddConnectionToInvestmentPartner Error: " + e.Message);
        }
    }
}
