1.常用命令监控
docker ps
[root@localhost ~]# docker ps CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES 30d9a0e764a3 busybox "sh" 12 seconds ago Up 11 seconds busybox2 0d44a42e10dc busybox "sh" 17 seconds ago Up 15 seconds busybox1
字段含义
container id：容器的ID
images：基于创建的镜像
command：当前运行环境使用的进程
created：创建的时间
status：运行的时间
ports：映射的端口
names：容器的名称
docker top
查看指定容器内的进程
[root@localhost ~]# docker top busybox1 UID PID PPID C STIME TTY TIME CMD root 2335 2314 0 11:16 pts/0 00:00:00 sh
选项
与在Linux中运行的ps选项相同
a 显示现行终端机下的所有进程，包括其他用户的进程。
u 以用户为主的格式来显示进程状况。
x 显示所有进程，不以终端机来区分。
-A 显示所有进程。
-e 此参数的效果和指定"A"参数相同。
-f 显示UID,PPID,C与STIME栏位。
查看详细docker容器进程
[root@localhost ~]# docker top busybox1 aux USER PID %CPU %MEM VSZ RSS TTY STAT START TIME COMMAND root 2335 0.0 0.0 1320 252 pts/0 Ss+ 11:16 0:00 sh
docker stats
动态显示容器的运行进程
查看所有容器的进程信息
[root@localhost ~]# docker stats CONTAINER ID NAME CPU % MEM USAGE / LIMIT MEM % NET I/O BLOCK I/O PIDS 30d9a0e764a3 busybox2 0.00% 56KiB / 3.686GiB 0.00% 648B / 0B 0B / 0B 1 0d44a42e10dc busybox1 0.00% 56KiB / 3.686GiB 0.00% 1.09kB / 0B 1.18MB / 0B 1
查看容器的动态进程
[root@localhost ~]# docker stats busybox1 CONTAINER ID NAME CPU % MEM USAGE / LIMIT MEM % NET I/O BLOCK I/O PIDS 0d44a42e10dc busybox1 0.00% 56KiB / 3.686GiB 0.00% 1.09kB / 0B 1.18MB / 0B 1
字段含义
container id：容器id
name：容器名字
CPU %：CPU使用百分比
MEM USAGE/limit：容器使用的总内存，以及它允许使用的总内存
mem%：内存使用百分比
net I/O：容器通过其网络接口接收和发送的数据量
block I/O：容器从主机上的块设备写入和读取的数据量
pids：容器已经创建的进程或线程的数量
选项
-a：显示所有容器(默认显示正在运行)
--no-stream：禁用流统计，只拉取第一个结果
--no-trunc：不截断输出
2.weave scope
weave scope 的最大的特点就是会自动生成一张docker容器地图，让我们能够直观的理解，监控和控制器。
1.下载
wget https://github.com/weaveworks/scope/releases/download/v1.13.2/scope
2.安装
[root@localhost ~]# chmod +x scope [root@localhost ~]# ./scope launch Unable to find image 'weaveworks/scope:1.13.2' locally 1.13.2: Pulling from weaveworks/scope ba3557a56b15: Pull complete 3ac4c0e9800c: Pull complete d052e74a4dae: Pull complete aacb9bf49f73: Pull complete 06841e6f61a9: Pull complete ee99b95c7732: Pull complete dd0e726a9a15: Pull complete 05cb5f9d0d32: Pull complete e956cf3e716a: Pull complete Digest: sha256:8591bb11d72f784f784ac8414660759d40b7c0d8819011660c1cc94271480a83 Status: Downloaded newer image for weaveworks/scope:1.13.2 458ddccb286a03b96e523e41d149ee102f6007cd55b4be179334675e5e7c311e Scope probe started Weave Scope is listening at the following URL(s): * http://192.168.2.5:4040/
3.访问查询即可
3.Prometheus监控平台
1.部署数据收集器cadvisor
[root@localhost ~]# docker run -v /:/rootfs:ro -v /var/run/:/var/run/:rw -v /sys:/sys:ro -v /var/lib/docker:/var/lib/docker:ro -p 8080:8080 -d --name cadivsor google/cadvisor
访问：http://192.168.2.5:8080/containers/
2.部署Prometheus
[root@localhost ~]# docker run -d -p 9100:9100 \ -v "/proc:/host/proc" \ -v "/sys:/host/sys" \ -v "/:/rootfs" \ --net=host \ prom/node-exporter \ --path.procfs /host/proc \ --path.sysfs /host/sys \ --collector.filesystem.ignored-mount-points "^/(sys|proc|dev|host|etc|rootfs/var/lib/docker/containers|rootfs/var/lib/docker/overlay2|rootfs/run/docker/netns|rootfs/var/lib/docker/devicemapper|rootfs/var/lib/docker/aufs)($$|/)" Unable to find image 'prom/node-exporter:latest' locally latest: Pulling from prom/node-exporter aa2a8d90b84c: Pull complete b45d31ee2d7f: Pull complete b5db1e299295: Pull complete Digest: sha256:f2269e73124dd0f60a7d19a2ce1264d33d08a985aed0ee6b0b89d0be470592cd Status: Downloaded newer image for prom/node-exporter:latest WARNING: Published ports are discarded when using host network mode 795214fa2248b18fee6e6600bb567493db4be265b5c79c9445eb96020aab3578
编写Prometheus监控配置文件
[root@localhost ~]# vi prometheus.yml # my global config global: scrape_interval: 15s # Set the scrape interval to every 15 seconds. Default is every 1 minute. evaluation_interval: 15s # Evaluate rules every 15 seconds. The default is every 1 minute. # scrape_timeout is set to the global default (10s). # Alertmanager configuration alerting: alertmanagers: - static_configs: - targets: # - alertmanager:9093 # Load rules once and periodically evaluate them according to the global 'evaluation_interval'. rule_files: # - "first_rules.yml" # - "second_rules.yml" # A scrape configuration containing exactly one endpoint to scrape: # Here it's Prometheus itself. scrape_configs: # The job name is added as a label `job=<job_name>` to any timeseries scraped from this config. - job_name: 'prometheus' # metrics_path defaults to '/metrics' # scheme defaults to 'http'. static_configs: - targets: ['localhost:9090','localhost:8080','localhost:9100']
主要配置文件内容
static_configs:
- targets: ['localhost:9090','localhost:8080','localhost:9100']
注意：填写你需要监控的cadvisor的IP地址和端口号
3.部署可视化平台Gragana
[root@localhost ~]# docker run -d -i -p 3000:3000 \ -e "GF_SERVER_ROOT_URL=http://grafana.server.name" \ -e "GF_SECURITY_ADMIN_PASSWORD=secret" \ --net=host \ grafana/grafana
4.进入后台控制台
默认用户名和密码
admin
密码：GF_SECURITY_ADMIN_PASSWORD=secret字段内容
注意：如果不指定密码为admin
1.添加Prometheus模块
2.添加docker容器监控模板
docker容器模板：193
Linux主机监控模板：9276
监控结果
