# yum install -y openstack-keystone httpd mod_wsgi
# mysql -u root -p -e "CREATE DATABASE keystone "
MariaDB [(none)]> CREATE DATABASE keystone;
Query OK, 1 row affected (0.03 sec)
MariaDB [(none)]> GRANT ALL PRIVILEGES ON keystone.* TO 'keystone'@'localhost' \
IDENTIFIED BY 'zoomtech';
MariaDB [(none)]> GRANT ALL PRIVILEGES ON keystone.* TO 'keystone'@'%' \
-> IDENTIFIED BY 'zoomtech';
Query OK, 0 rows affected (0.01 sec)
MariaDB [(none)]> exit
Bye
[root@controller1 ~]# mysql -uroot -p -e "CREATE DATABASE keystone"
[root@controller1 ~]# mysql -uroot -p -e "GRANT ALL PRIVILEGES ON keystone.* TO 'keystone'@'%' IDENTIFIED BY 'zoomtech'"
[root@controller1 ~]# mysql -uroot -p -e "GRANT ALL PRIVILEGES ON keystone.* TO 'keystone'@'localhost' IDENTIFIED BY 'zoomtech'"
[root@controller1 ~]# openssl rand -hex 10
d68d8a32a75bdbfdb004
配置/etc/keystone/keystone.conf文件
[DEFAULT]
verbose = true
admin_token = 745faaa51f7c62f8a2a7
public_bind_host = 192.168.17.132
admin_bind_host = 192.168.17.132
bind_host = controller1
[database]
connection = mysql+pymysql://keystone:zoomtech@demo.open-stack.cn/keystone
[token]
provider = keystone.token.providers.uuid.Provider
dirver = keystone.token.persistence.backends.memcach.Token
caching = true
token = keystone.auth.plugins.token.Token
[revoke]
driver = keystone.contrib.revoke.backends.sql.Revoke
[identity]
driver = sql
#driver = keystone.identity.backends.sql.identity
[catalog]
driver = sql
#driver = keystone.catalog.backends.sql.Catalog
[memcache]
servers = controller1:11211,controller2:11211,controller3:11211
[root@controller1 ~]# openstack-config --set /etc/keystone/keystone.conf DEFAULT admin_token d68d8a32a75bdbfdb004
[root@controller1 ~]# openstack-config --set /etc/keystone/keystone.conf database connection mysql+pymysql://keystone:zoomtech@demo.open-stack.cn/keystone
[root@controller1 ~]# openstack-config --set /etc/keystone/keystone.conf token provider fernet
[root@controller1 ~]# openstack-config --set /etc/keystone/keystone.conf memcache servers controller1:11211,controller2:11211,controller3:11211
[root@controller1 ~]# scp /etc/keystone/keystone.conf controller2:/etc/keystone/
keystone.conf 100% 72KB 71.9KB/s 00:00
[root@controller1 ~]# scp /etc/keystone/keystone.conf controller3:/etc/keystone/
[root@controller2 ~]# vim /etc/keystone/keystone.conf
admin_token = 745faaa51f7c62f8a2a7
public_bind_host = 192.168.17.151
bind_host = controller2
admin_bind_host = 192.168.17.151
[root@controller3 ~]# vim /etc/keystone/keystone.conf
[default]
public_bind_host = 192.168.17.138
bind_host = controller3
admin_bind_host = 192.168.17.138
确认权限
[root@controller1 ~]# ll /etc/keystone/keystone.conf
-rw-r----- 1 root keystone 73642 Feb 21 15:42 /etc/keystone/keystone.conf
[root@controller1 ~]# chown root:keystone /etc/keystone/keystone.conf
[root@controller1 ~]# chmod 640 /etc/keystone/keystone.conf
同步Keystone数据库
[root@controller1 ~]# su -s /bin/sh -c "keystone-manage db_sync" keystone
初始化Fernet keys
[root@controller1 ~]# keystone-manage fernet_setup --keystone-user keystone --keystone-group keystone
配置Apache Http服务
1、三个节点配置 /etc/httpd/conf/httpd.conf
[root@controller1 ~] # vim /etc/httpd/conf/httpd.conf
ServerName controller1
Listen 8080
[root@controller2 ~]# vim /etc/httpd/conf/httpd.conf
ServerName controller2
Listen 8080
[root@controller3 ~]# vim /etc/httpd/conf/httpd.conf
ServerName controller3
Listen 8080
2、[root@controller1 ~]# vim /etc/httpd/conf.d/wsgi-keystone.conf
<VirtualHost *:5000>
WSGIDaemonProcess keystone-public processes=5 threads=1 user=keystone group=keystone display-name=%{GROUP}
WSGIProcessGroup keystone-public
WSGIScriptAlias / /usr/bin/keystone-wsgi-public
WSGIApplicationGroup %{GLOBAL}
WSGIPassAuthorization On
ErrorLogFormat "%{cu}t %M"
ErrorLog /var/log/httpd/keystone-error.log
CustomLog /var/log/httpd/keystone-access.log combined
<Directory /usr/bin>
Require all granted
</Directory>
</VirtualHost>
<VirtualHost *:35357>
WSGIDaemonProcess keystone-admin processes=5 threads=1 user=keystone group=keystone display-name=%{GROUP}
WSGIProcessGroup keystone-admin
WSGIScriptAlias / /usr/bin/keystone-wsgi-admin
WSGIApplicationGroup %{GLOBAL}
WSGIPassAuthorization On
ErrorLogFormat "%{cu}t %M"
ErrorLog /var/log/httpd/keystone-error.log
CustomLog /var/log/httpd/keystone-access.log combined
<Directory /usr/bin>
Require all granted
</Directory>
</VirtualHost>
将wsgi-keystone.conf复制到 controller2和controller3
3、启动apache
# systemctl enable httpd.service
# systemctl start httpd.service
[root@controller1 ~]# export OS_TOKEN=d68d8a32a75bdbfdb004
[root@controller1 ~]# export OS_URL=http://demo.open-stack.cn:35357/v3
[root@controller1 ~]# export OS_IDENTITY_API_VERSION=3
创建服务实体和身份认证服务：
[root@controller1 ~]# openstack service create --name keystone --description "OpenStack Identity" identity
+-------------+----------------------------------+
| Field | Value |
+-------------+----------------------------------+
| description | OpenStack Identity |
| enabled | True |
| id | 5fe30200d9464aa384b5ddc1864b0244 |
| name | keystone |
| type | identity |
+-------------+----------------------------------+
error:
Unable to establish connection to http://demo.open-stack.cn:35357/v3/services
创建认证服务的 API 端点：
[root@controller1 ~]# openstack endpoint create --region RegionOne \
identity public http://demo.open-stack.cn:5000/v3
+--------------+-----------------------------------+
| Field | Value |
+--------------+-----------------------------------+
| enabled | True |
| id | 527cfe77e4d64668ae4c5a92f5841607 |
| interface | public |
| region | RegionOne |
| region_id | RegionOne |
| service_id | 5fe30200d9464aa384b5ddc1864b0244 |
| service_name | keystone |
| service_type | identity |
| url | http://demo.open-stack.cn:5000/v3 |
+--------------+-----------------------------------+
[root@controller1 ~]# openstack endpoint create --region RegionOne identity internal http://demo.open-stack.cn:5000/v3
+--------------+-----------------------------------+
| Field | Value |
+--------------+-----------------------------------+
| enabled | True |
| id | 9ecf73dab7c9481b9bb6976be271e93c |
| interface | internal |
| region | RegionOne |
| region_id | RegionOne |
| service_id | 5fe30200d9464aa384b5ddc1864b0244 |
| service_name | keystone |
| service_type | identity |
| url | http://demo.open-stack.cn:5000/v3 |
+--------------+-----------------------------------+
[root@controller1 ~]# openstack endpoint create --region RegionOne identity admin http://demo.open-stack.cn:35357/v3
+--------------+------------------------------------+
| Field | Value |
+--------------+------------------------------------+
| enabled | True |
| id | 4606f3b199a14167a9ebe76a0bda45f3 |
| interface | admin |
| region | RegionOne |
| region_id | RegionOne |
| service_id | 5fe30200d9464aa384b5ddc1864b0244 |
| service_name | keystone |
| service_type | identity |
| url | http://demo.open-stack.cn:35357/v3 |
+--------------+------------------------------------+
[root@controller1 ~]# openstack domain create --description "Default Domain" default
+-------------+----------------------------------+
| Field | Value |
+-------------+----------------------------------+
| description | Default Domain |
| enabled | True |
| id | 6fb0271bda4d459ab05a752b7708dee3 |
| name | default |
+-------------+----------------------------------+
[root@controller1 ~]# openstack project create --domain default \
--description "Admin Project" admin
+-------------+----------------------------------+
| Field | Value |
+-------------+----------------------------------+
| description | Admin Project |
| domain_id | 6fb0271bda4d459ab05a752b7708dee3 |
| enabled | True |
| id | b81fade4255149c29aa53b87312f60de |
| is_domain | False |
| name | admin |
| parent_id | 6fb0271bda4d459ab05a752b7708dee3 |
+-------------+----------------------------------+
[root@controller1 ~]# openstack user create --domain default \
--password-prompt admin
User Password:
Repeat User Password:
+-----------+----------------------------------+
| Field | Value |
+-----------+----------------------------------+
| domain_id | 6fb0271bda4d459ab05a752b7708dee3 |
| enabled | True |
| id | e88caafd2c874b6ab4bc23d8b5fbf422 |
| name | admin |
+-----------+----------------------------------+
[root@controller1 ~]# openstack role create admin
+-----------+----------------------------------+
| Field | Value |
+-----------+----------------------------------+
| domain_id | None |
| id | cb618462ef4a4479a7c0b611d3ead7ed |
| name | admin |
+-----------+----------------------------------+
[root@controller1 ~]# openstack role add --project admin --user admin admin
创建Service
[root@controller1 ~]# openstack project create --domain default \
--description "Service Project" service
+-------------+----------------------------------+
| Field | Value |
+-------------+----------------------------------+
| description | Service Project |
| domain_id | 6fb0271bda4d459ab05a752b7708dee3 |
| enabled | True |
| id | b581d85c3bd642d88909f36a1ebb6387 |
| is_domain | False |
| name | service |
| parent_id | 6fb0271bda4d459ab05a752b7708dee3 |
+-------------+----------------------------------+
创建``demo`` 项目：
[root@controller1 ~]# openstack project create --domain default \
--description "Demo Project" demo
+-------------+----------------------------------+
| Field | Value |
+-------------+----------------------------------+
| description | Demo Project |
| domain_id | 6fb0271bda4d459ab05a752b7708dee3 |
| enabled | True |
| id | da951d38bfd24ecc9d7384d3b8760dd6 |
| is_domain | False |
| name | demo |
| parent_id | 6fb0271bda4d459ab05a752b7708dee3 |
+-------------+----------------------------------+
[root@controller1 ~]# openstack user create --domain default \
--password-prompt demo
User Password:
Repeat User Password:
+-----------+----------------------------------+
| Field | Value |
+-----------+----------------------------------+
| domain_id | 6fb0271bda4d459ab05a752b7708dee3 |
| enabled | True |
| id | f113613d853342dba7b9636b571208bf |
| name | demo |
+-----------+----------------------------------+
创建 user 角色：
[root@controller1 ~]# openstack role create user
+-----------+----------------------------------+
| Field | Value |
+-----------+----------------------------------+
| domain_id | None |
| id | 1c0bcc0e6ffe46d7b0366ead1d55908f |
| name | user |
+-----------+----------------------------------+
[root@controller1 ~]# openstack role add --project demo --user demo user
编辑 /etc/keystone/keystone-paste.ini 文件，从``[pipeline:public_api]``，[pipeline:admin_api]``和``[pipeline:api_v3]``部分删除``admin_token_auth
[root@controller1 ~]# vim /etc/keystone/keystone-paste.ini
[root@controller1 ~]#
[root@controller1 ~]# unset OS_TOKEN OS_URL
[root@controller1 ~]# openstack --os-auth-url http://demo.open-stack.cn:35357/v3 --os-project-domain-name default --os-user-domain-name default --os-project-name admin --os-username admin token issue
Password:
+------------+----------------------------------+
| Field | Value |
+------------+----------------------------------+
| expires | 2017-02-22T06:28:10.845869Z |
| id | cff141923edc40d69ead04bcde8f01c4 |
| project_id | b81fade4255149c29aa53b87312f60de |
| user_id | e88caafd2c874b6ab4bc23d8b5fbf422 |
+------------+----------------------------------+
[root@controller1 ~]# vim admin-openrc.sh
export OS_PROJECT_DOMAIN_NAME=default
export OS_USER_DOMAIN_NAME=default
export OS_PROJECT_NAME=admin
export OS_USERNAME=admin
export OS_PASSWORD=zoomtech
export OS_AUTH_URL=http://demo.open-stack.cn:35357/v3
export OS_IDENTITY_API_VERSION=3
export OS_IMAGE_API_VERSION=2
[root@controller1 ~]# source admin-openrc.sh
[root@controller1 ~]# openstack token issue
+------------+----------------------------------+
| Field | Value |
+------------+----------------------------------+
| expires | 2017-02-22T06:30:45.484675Z |
| id | de745b965ce2466a904f18ce0a187279 |
| project_id | b81fade4255149c29aa53b87312f60de |
| user_id | e88caafd2c874b6ab4bc23d8b5fbf422 |
+------------+----------------------------------+
[root@controller1 ~]# openstack service list
+----------------------------------+----------+----------+
| ID | Name | Type |
+----------------------------------+----------+----------+
| 5fe30200d9464aa384b5ddc1864b0244 | keystone | identity |
+----------------------------------+----------+----------+
在 Controller2上验证Keystone
[root@controller2 ~]# source admin-openrc.sh
[root@controller2 ~]# openstack token issue
+------------+----------------------------------+
| Field | Value |
+------------+----------------------------------+
| expires | 2017-02-22T06:31:51.487910Z |
| id | e2ffc4461c604107ac9ba7386d493a09 |
| project_id | b81fade4255149c29aa53b87312f60de |
| user_id | e88caafd2c874b6ab4bc23d8b5fbf422 |
+------------+----------------------------------+
[root@controller2 ~]# openstack service list
+----------------------------------+----------+----------+
| ID | Name | Type |
+----------------------------------+----------+----------+
| 5fe30200d9464aa384b5ddc1864b0244 | keystone | identity |
+----------------------------------+----------+----------+
在 Controller2上验证Keystone
[root@controller3 ~]# source admin-openrc.sh
[root@controller3 ~]# openstack token issue
+------------+----------------------------------+
| Field | Value |
+------------+----------------------------------+
| expires | 2017-02-22T06:32:19.618061Z |
| id | 3db2b1cec73d48b496ac8845e0842bea |
| project_id | b81fade4255149c29aa53b87312f60de |
| user_id | e88caafd2c874b6ab4bc23d8b5fbf422 |
+------------+----------------------------------+
[root@controller3 ~]# openstack service list
+----------------------------------+----------+----------+
| ID | Name | Type |
+----------------------------------+----------+----------+
| 5fe30200d9464aa384b5ddc1864b0244 | keystone | identity |
+----------------------------------+----------+----------+
