1.前言
书接上回，上篇分享了作者做的基于bulkRNA的细胞分类评估工具CellNet及其更新版PACNet，现在分享的是单细胞数据的细胞分类评估工具singleCellNet，该工具与CellNet是同时期开发的。
singleCellNet：https://github.com/CahanLab/singleCellNet
2.singleCellNet简介
整个框架及思路与bulk的处理大同小异的，且特色还是多物种和多分组，这里作者依旧提供了PBMC的测试数据：
下载R包：
install.packages("devtools") devtools::install_github("pcahan1/singleCellNet") library(singleCellNet)
下载数据：
download.file("https://s3.amazonaws.com/cnobjects/singleCellNet/examples/sampTab_Park_MouseKidney_062118.rda", "sampTab_Park_MouseKidney_062118.rda") download.file("https://s3.amazonaws.com/cnobjects/singleCellNet/examples/expMatrix_Park_MouseKidney_Oct_12_2018.rda", "expMatrix_Park_MouseKidney_Oct_12_2018.rda") download.file("https://s3.amazonaws.com/cnobjects/singleCellNet/examples/expMatrix_TM_Raw_Oct_12_2018.rda", "expMatrix_TM_Raw_Oct_12_2018.rda") download.file("https://s3.amazonaws.com/cnobjects/singleCellNet/examples/sampTab_TM_053018.rda", "sampTab_TM_053018.rda") ## For cross-species analyis: download.file("https://s3.amazonaws.com/cnobjects/singleCellNet/examples/human_mouse_genes_Jul_24_2018.rda", "human_mouse_genes_Jul_24_2018.rda") download.file("https://s3.amazonaws.com/cnobjects/singleCellNet/examples/6k_beadpurfied_raw.rda", "6k_beadpurfied_raw.rda") download.file("https://s3.amazonaws.com/cnobjects/singleCellNet/examples/stDat_beads_mar22.rda", "stDat_beads_mar22.rda") ## To demonstrate how to integrate loom files to SCN download.file("https://s3.amazonaws.com/cnobjects/singleCellNet/examples/pbmc_6k.loom", "pbmc_6k.loom")
3.singleCellNet demo
加载查询数据：
stPark = utils_loadObject("sampTab_Park_MouseKidney_062118.rda") expPark = utils_loadObject("expMatrix_Park_MouseKidney_Oct_12_2018.rda") dim(expPark) # [1] 16272 43745 genesPark = rownames(expPark) rm(expPark) gc()
加载测试数据：
expTMraw = utils_loadObject("expMatrix_TM_Raw_Oct_12_2018.rda") dim(expTMraw) # [1] 23433 24936 stTM = utils_loadObject("sampTab_TM_053018.rda") dim(stTM) # [1] 24936 17 stTM<-droplevels(stTM)
拆分训练集和测试集：
## 交集共有基因 commonGenes = intersect(rownames(expTMraw), genesPark) length(commonGenes) # [1] 13831 expTMraw = expTMraw[commonGenes,] ## 拆分数据 set.seed(100) #can be any random seed number stList = splitCommon(sampTab=stTM, ncells=100, dLevel="newAnn") stTrain = stList[[1]] expTrain = expTMraw[,rownames(stTrain)]
训练分类器：
system.time(class_info<-scn_train(stTrain = stTrain, expTrain = expTrain, nTopGenes = 10, nRand = 70, nTrees = 1000, nTopGenePairs = 25, dLevel = "newAnn", colName_samp = "cell")) # user system elapsed # 476.839 25.809 503.351
提取数据进行分类器评估：
#validate data stTestList = splitCommon(sampTab=stList[[2]], ncells=100, dLevel="newAnn") #normalize validation data so that the assessment is as fair as possible stTest = stTestList[[1]] expTest = expTMraw[commonGenes,rownames(stTest)] #predict classRes_val_all = scn_predict(cnProc=class_info[['cnProc']], expDat=expTest, nrand = 50)
4.评估结果
看一下全部细胞准确度和召回率的结果：
tm_heldoutassessment = assess_comm(ct_scores = classRes_val_all, stTrain = stTrain, stQuery = stTest, dLevelSID = "cell", classTrain = "newAnn", classQuery = "newAnn", nRand = 50) plot_PRs(tm_heldoutassessment)
分类热图评分：
#Create a name vector label used later in classification heatmap where the values are cell types/ clusters and names are the sample names nrand = 50 sla = as.vector(stTest$newAnn) names(sla) = as.vector(stTest$cell) slaRand = rep("rand", nrand) names(slaRand) = paste("rand_", 1:nrand, sep='') sla = append(sla, slaRand) #include in the random cells profile created sc_hmClass(classMat = classRes_val_all,grps = sla, max=300, isBig=TRUE)
比例堆积图，这里如果分类效果好，细胞清晰的话理想状态是一行一个颜色，即每一组都是一种细胞类型
plot_attr(classRes=classRes_val_all, sampTab=stTest, nrand=nrand, dLevel="newAnn", sid="cell")
可视化训练数据的平均顶级对基因表达：
gpTab = compareGenePairs(query_exp = expTest, training_exp = expTrain, training_st = stTrain, classCol = "newAnn", sampleCol = "cell", RF_classifier = class_info$cnProc$classifier, numPairs = 20, trainingOnly= TRUE) train = findAvgLabel(gpTab = gpTab, stTrain = stTrain, dLevel = "newAnn") hm_gpa_sel(gpTab, genes = class_info$cnProc$xpairs, grps = train, maxPerGrp = 50)
查询数据及可视化：
expPark = utils_loadObject("expMatrix_Park_MouseKidney_Oct_12_2018.rda") nqRand = 50 system.time(crParkall<-scn_predict(class_info[['cnProc']], expPark, nrand=nqRand)) # user system elapsed # 89.633 5.010 95.041 sgrp = as.vector(stPark$description1) names(sgrp) = as.vector(stPark$sample_name) grpRand =rep("rand", nqRand) names(grpRand) = paste("rand_", 1:nqRand, sep='') sgrp = append(sgrp, grpRand) # heatmap classification result sc_hmClass(crParkall, sgrp, max=5000, isBig=TRUE, cCol=F, font=8)
分类注释分配：
# This classifies a cell with the catgory with the highest classification score or higher than a classification score threshold of your choosing. # The annotation result can be found in a column named category in the query sample table. stPark <- get_cate(classRes = crParkall, sampTab = stPark, dLevel = "description1", sid = "sample_name", nrand = nqRand) sc_violinClass(sampTab = stPark, classRes = crParkall, sid = "sample_name", dLevel = "description1", addRand = nqRand)
分类结果的天际线图，这个解释一下，可以看作是若干个细胞的密度图
library(viridis) stKid2 = addRandToSampTab(crParkall, stPark, "description1", "sample_name") skylineClass(crParkall, "T cell", stKid2, "description1",.25, "sample_name")
5.跨物种的评估
前面步骤是相似的，但是在加载直系同源物表时，将人类基因名称转换为小鼠直系同源物名称，并将分析限制为训练和查询数据之间共有的基因。
oTab = utils_loadObject("human_mouse_genes_Jul_24_2018.rda") dim(oTab) # [1] 16688 3 aa = csRenameOrth(expQuery, expTMraw, oTab) expQueryOrth = aa[['expQuery']] expTrainOrth = aa[['expTrain']]
各细胞类型横向的小提琴图：
sc_violinClass(sampTab = stQuery,classRes = crHS, sid = "sample_name", dLevel = "description", ncol = 12)
还有一个按分类划分的UMAP图：
system.time(umPrep_HS<-prep_umap_class(crHS, stQuery, nrand=nqRand, dLevel="description", sid="sample_name", topPC=5)) # user system elapsed # 25.703 0.740 26.450 plot_umap(umPrep_HS)
6.小结
- 该工具的适用情况没有想象中的这么广，虽说是多物种特点，但一般研究都是分开做的。细胞分大类的时候用不上，细分小类亚型的时候又用不了。属于是附加项吧，但是需要自己构建特征数据集，再去验证评估自己的分类效果，还是有一点绕的。
- 因此小编认为还是bulk的适用更好一些，也不难怪作者对bulk的工具追更新了一版出来
