puppet连载15:搭建zabbix服务端、客户端

本文涉及的产品
云数据库 RDS MySQL,集群系列 2核4GB
推荐场景:
搭建个人博客
RDS MySQL Serverless 基础系列,0.5-2RCU 50GB
云数据库 RDS MySQL,高可用系列 2核4GB
简介: zabbix的安装需要先安装mysql.服务端/puppet/soft建vi zabbix35server.sh 文件,内容:!/bin/bashresult=netstat -tnlup|grep 3306;if [ "$result" !=...

zabbix的安装需要先安装mysql.

服务端/puppet/soft建vi zabbix35server.sh 文件,内容:

!/bin/bash

result=netstat -tnlup|grep 3306;

if [ "$result" != "0" ];then
service mysqld start
fi

mysql -uroot -pxmrbi3967968@ -e "create database zabbix character set utf8;"
mysql -uroot -pxmrbi3967968@ -e "grant all privileges on zabbix.* to 'zabbix'@'localhost' identified by 'zabbix';"
mysql -uroot -pxmrbi3967968@ -e "flush privileges;"

cd /usr/share/doc/zabbix-server-mysql-4.0.0
gunzip create.sql.gz
mysql -uroot -pxmrbi3967968@ zabbix</usr/share/doc/zabbix-server-mysql-4.0.0/create.sql

firewall-cmd --add-port=10051/tcp --permanent
firewall-cmd --reload

sed -i "s#;date.timezone =#date.timezone = Asia/Shanghai#g" /etc/php.ini
sed -i "s#post_max_size = 8M#post_max_size = 16M#g" /etc/php.ini
sed -i "s#max_execution_time = 30#max_execution_time = 300#g" /etc/php.ini
sed -i "s#max_input_time = 60#max_input_time = 300#g" /etc/php.ini
sed -i "s#;always_populate_raw_post_data = -1#always_populate_raw_post_data = -1#g" /etc/php.ini

service mysqld restart
chmod 777 /data/mysql

保存退出


mkdir -p /etc/puppet/modules/linuxzabbix/{manifests,templates,files}

建zabbix_server配置文件:

vi /etc/puppet/modules/linuxzabbix/templates/zabbix_server.conf.erb
LogFile=/var/log/zabbix/zabbix_server.log
LogFileSize=0
PidFile=/var/run/zabbix/zabbix_server.pid
SocketDir=/var/run/zabbix
DBName=zabbix
DBUser=zabbix
SNMPTrapperFile=/var/log/snmptrap/snmptrap.log
Timeout=4
AlertScriptsPath=/usr/lib/zabbix/alertscripts
ExternalScripts=/usr/lib/zabbix/externalscripts
LogSlowQueries=3000
DBHost=localhost
DBPassword=zabbix
DBSocket=/data/mysql/mysql.sock


客户端配置

vi /etc/puppet/modules/linuxzabbix/templates/zabbix_agentd.conf.erb
LogFile=/var/log/zabbix/zabbix_agentd.log
PidFile=/var/run/zabbix/zabbix_agentd.pid
EnableRemoteCommands=1
LogRemoteCommands=1
Server=<%= zabbix_server %>
Hostname=<%= fqdn %>
ListenIP=<%= ipaddress %>
Include=/etc/zabbix/zabbix_agentd.d/


vi /etc/puppet/modules/linuxzabbix/manifests/init.pp
class linuxzabbix::zabbix35 {
yumrepo { "zabbix":
descr => "zabbix repo",
baseurl => "http://repo.zabbix.com/zabbix/3.5/rhel/7/$basearch/",
gpgcheck => "0",
enabled => "1",
}
user {"zabbix":
uid => "1051",
shell => "/sbin/nologin",
}
}
class linuxzabbix::zabbixserver35 {
require linuxzabbix::zabbix35
exec {"yum fping":
command => "rpm -ivh http://dl.fedoraproject.org/pub/epel/7/x86_64/Packages/f/fping-3.10-4.el7.x86_64.rpm",
path => ["/usr/sbin","/usr/bin","/bin","/sbin",],
before => Package["zabbix-server-mysql"],
unless => "rpm -qa|grep fping",
}
exec {"yum iksemel":
command => "rpm -ivh http://springdale.math.ias.edu/data/puias/unsupported/7/x86_64//iksemel-1.4-6.sdl7.x86_64.rpm",
path => ["/usr/sbin","/usr/bin","/bin","/sbin",],
before => Package["zabbix-server-mysql"],
unless => "rpm -qa|grep iksemel",
}
package {["zabbix-server-mysql","zabbix-web-mysql",]:
ensure =>installed,
require => Yumrepo["zabbix"],
notify => Exec["zabbixsetup"],
}
file {"/data/zabbix35server.sh":
source => "puppet:///soft/zabbix35server.sh",
ensure => present,
}
exec {"zabbixsetup":
command => "bash /data/zabbix35server.sh",
cwd => "/data",
user => root,
provider => shell,
logoutput => true,
require => File["/data/zabbix35server.sh"],
refreshonly => true,
}
file {"zabbix server config":
ensure => present,
mode => 755,owner=> zabbix,group => zabbix,
path => "/etc/zabbix/zabbix_server.conf",
content => template("/etc/puppet/modules/linuxzabbix/templates/zabbix_server.conf.erb"),
notify => Service["zabbix-server"],
}
service {["zabbix-server","httpd",]:
ensure => running,
enable => true,
hasrestart => true,
hasstatus => true,
}
exec {"mysqlsock":
command => "ln -s /data/mysql/mysql.sock /var/lib/mysql/mysql.sock",
path => ["/usr/sbin","/usr/bin","/bin","/sbin",],
unless => "ls /var/lib/mysql/mysql.sock",
}
}

class linuxzabbix::zabbixagent35 {
require linuxzabbix::zabbix35
package {"zabbix-agent":
ensure => "installed",
require => Yumrepo["zabbix"],
notify => Exec["firewall10050"],
}

exec {"firewall10050":
command => "firewall-cmd --add-port=10050/tcp --permanent && firewall-cmd --reload",
path => ["/usr/sbin","/usr/bin","/bin","/sbin"],
refreshonly => true,
}

file {"/etc/zabbix/zabbix_agentd.conf":
ensure => present,
mode => 755,owner => zabbix,group => zabbix,
content => template("/etc/puppet/modules/linuxzabbix/templates/zabbix_agentd.conf.erb"),
notify => Service["zabbix-agent"],
}
service {"zabbix-agent":
ensure => running,
enable => true,
hasrestart => true,
hasstatus => true,
}
}

调用方式

node 'huangat-test' {

include test

include linuxbaseinstall
include linuxoptimize
include linuxjdktomcat::tomcat8036

include linuxclean::yumclean

include linuxnginx::nginx1102
include linuxpercona::perconaxtradbcluster57rpm
$zabbix_server = "api2"
include linuxzabbix::zabbixagent35
include public::externalfacter
}
node 'api2' {
include linuxbaseinstall
include linuxoptimize
include linuxjdktomcat::tomcat8516

include linuxnginx::openresty1136

include linuxpercona::perconaserver57rpm
include linuxzabbix::zabbixserver35
include public::externalfacter
}
