CORS 几种解决方案

简介: CORS背后的基本思想是使用自定义的HTTP头部允许浏览器和服务器相互了解对方,从而决定请求或响应成功与否. Access-Control-Allow-Origin:指定授权访问的域 Access-Control-Allow-Methods:授权请求的方法(GET, POST, PUT, DELETE,OPTIONS等) 一:简单的自定义CORSFilter / Interceptor 适合设置单一的(或全部)授权访问域,所有配置都是固定的,特简单。
+关注继续查看

CORS背后的基本思想是使用自定义的HTTP头部允许浏览器和服务器相互了解对方,从而决定请求或响应成功与否.

Access-Control-Allow-Origin:指定授权访问的域
Access-Control-Allow-Methods:授权请求的方法(GET, POST, PUT, DELETE,OPTIONS等)

一:简单的自定义CORSFilter / Interceptor

适合设置单一的(或全部)授权访问域,所有配置都是固定的,特简单。也没根据请求的类型做不同的处理

在web.xml 中添加filter

<filter>
    <filter-name>cros</filter-name>
    <filter-class>cn.ifengkou.test.filter.CORSFilter</filter-class>
</filter>
<filter-mapping>
    <filter-name>cros</filter-name>
    <url-pattern>/*</url-pattern>
</filter-mapping>

新增CORSFilter 类

@Component
public class CORSFilter extends OncePerRequestFilter {
    @Override
    protected void doFilterInternal(HttpServletRequest request, HttpServletResponse response, FilterChain filterChain) throws ServletException, IOException {
        response.addHeader("Access-Control-Allow-Origin", "*");
        response.addHeader("Access-Control-Allow-Methods", "GET, POST, PUT, DELETE");
        response.addHeader("Access-Control-Allow-Headers", "Content-Type");
        response.addHeader("Access-Control-Max-Age", "1800");//30 min
        filterChain.doFilter(request, response);
    }
}

Access-Control-Allow-Origin只能配置 或者一个域名*
比如配置了192.168.56.130,那么只有192.168.56.130 能拿到数据,否则全部报403异常

response.addHeader("Access-Control-Allow-Origin", "http://192.168.56.130");

二:Nginx 配置支持Ajax跨域

这里是一个nginx启用COSR的参考配置:来源

#
# Wide-open CORS config for nginx
#
location / {
     if ($request_method = 'OPTIONS') {
        add_header 'Access-Control-Allow-Origin' '*';
        add_header 'Access-Control-Allow-Methods' 'GET, POST, OPTIONS';
        #
        # Custom headers and headers various browsers *should* be OK with but aren't
        #
        add_header 'Access-Control-Allow-Headers' 'DNT,X-CustomHeader,Keep-Alive,User-Agent,X-Requested-With,If-Modified-Since,Cache-Control,Content-Type';
        #
        # Tell client that this pre-flight info is valid for 20 days
        #
        add_header 'Access-Control-Max-Age' 1728000;
        add_header 'Content-Type' 'text/plain charset=UTF-8';
        add_header 'Content-Length' 0;
        return 204;
     }
     if ($request_method = 'POST') {
        add_header 'Access-Control-Allow-Origin' '*';
        add_header 'Access-Control-Allow-Methods' 'GET, POST, OPTIONS';
        add_header 'Access-Control-Allow-Headers' 'DNT,X-CustomHeader,Keep-Alive,User-Agent,X-Requested-With,If-Modified-Since,Cache-Control,Content-Type';
     }
     if ($request_method = 'GET') {
        add_header 'Access-Control-Allow-Origin' '*';
        add_header 'Access-Control-Allow-Methods' 'GET, POST, OPTIONS';
        add_header 'Access-Control-Allow-Headers' 'DNT,X-CustomHeader,Keep-Alive,User-Agent,X-Requested-With,If-Modified-Since,Cache-Control,Content-Type';
     }
}

三:支持多域名配置的CORS Filter

因为知道已经有可以用的库可以解决,所以就没重复造轮子了。其实因为懒,看看别人的源码算了。。。

mvnrepository搜索cors-filter,目前也就两个可以用

这两个也都大同小异,因为ebay开源在github上,也有详细的README,那么就以ebay的cors-filter为例

配置

添加依赖包到项目:

<dependency>
    <groupId>org.ebaysf.web</groupId>
    <artifactId>cors-filter</artifactId>
    <version>1.0.1</version>
</dependency>

添加配置(具体配置项,还是见项目的README.md吧)

  <filter>
    <filter-name>CORS Filter</filter-name>
    <filter-class>org.ebaysf.web.cors.CORSFilter</filter-class>
    <init-param>
      <param-name>cors.allowed.origins</param-name>
      <param-value>http://192.168.56.129,http://192.168.56.130</param-value>
    </init-param>
    <init-param>
      <param-name>cors.allowed.methods</param-name>
      <param-value>GET,POST,HEAD,OPTIONS,PUT</param-value>
    </init-param>
    <init-param>
      <param-name>cors.allowed.headers</param-name>
      <param-value>Content-Type,X-Requested-With,accept,Origin,Access-Control-Request-Method,Access-Control-Request-Headers</param-value>
    </init-param>
  </filter>
  <filter-mapping>
    <filter-name>CORS Filter</filter-name>
    <url-pattern>/*</url-pattern>
  </filter-mapping>

源码分析

源码地址:github。但通过IDEA Decompiled 出来的更清晰.....,以下是反编译的

ebaysf的cors-filter 只有一个类CORSFilter。也就是一个拦截器,implements Filter

public final class CORSFilter implements Filter {

通过是实现Filter 的init 方法从配置文件中读取参数:

public void init(FilterConfig filterConfig) throws ServletException {
    this.parseAndStore("*", "GET,POST,HEAD,OPTIONS", "Origin,Accept,X-Requested-With,Content-Type,Access-Control-Request-Method,Access-Control-Request-Headers", "", "true", "1800", "false", "true");
    this.filterConfig = filterConfig;
    this.loggingEnabled = false;
    if(filterConfig != null) {
        String configAllowedOrigins = filterConfig.getInitParameter("cors.allowed.origins");
        String configAllowedHttpMethods = filterConfig.getInitParameter("cors.allowed.methods");
        String configAllowedHttpHeaders = filterConfig.getInitParameter("cors.allowed.headers");
        String configExposedHeaders = filterConfig.getInitParameter("cors.exposed.headers");
        String configSupportsCredentials = filterConfig.getInitParameter("cors.support.credentials");
        String configPreflightMaxAge = filterConfig.getInitParameter("cors.preflight.maxage");
        String configLoggingEnabled = filterConfig.getInitParameter("cors.logging.enabled");
        String configDecorateRequest = filterConfig.getInitParameter("cors.request.decorate");
        this.parseAndStore(configAllowedOrigins, configAllowedHttpMethods, configAllowedHttpHeaders, configExposedHeaders, configSupportsCredentials, configPreflightMaxAge, configLoggingEnabled, configDecorateRequest);
    }
}

parseAndStore 方法,解析参数。以 解析cors.allowed.orgins为例;其他参数同理

    Set e;
    if(allowedOrigins != null) {
        if(allowedOrigins.trim().equals("*")) {
            this.anyOriginAllowed = true;
        } else {
            this.anyOriginAllowed = false;
            e = this.parseStringToSet(allowedOrigins);
            this.allowedOrigins.clear();
            this.allowedOrigins.addAll(e);
        }
    }
//parseStringToSet
//对多域名用点分割,加到HashSet中,再赋给allowedOrigins(Collection<String> allowedOrigins = new HashSet();)
private Set<String> parseStringToSet(String data) {
    String[] splits;
    if(data != null && data.length() > 0) {
        splits = data.split(",");
    } else {
        splits = new String[0];
    }

    HashSet set = new HashSet();
    if(splits.length > 0) {
        String[] arr$ = splits;
        int len$ = splits.length;

        for(int i$ = 0; i$ < len$; ++i$) {
            String split = arr$[i$];
            set.add(split.trim());
        }
    }

    return set;
}

如何实现 doFilter

public void doFilter(ServletRequest servletRequest, ServletResponse servletResponse, FilterChain filterChain) throws IOException, ServletException {
    if(servletRequest instanceof HttpServletRequest && servletResponse instanceof HttpServletResponse) {
        HttpServletRequest request1 = (HttpServletRequest)servletRequest;
        HttpServletResponse response = (HttpServletResponse)servletResponse;
        //识别request 属于哪种类别
        CORSFilter.CORSRequestType requestType = this.checkRequestType(request1);
        if(this.decorateRequest) {
            decorateCORSProperties(request1, requestType);
        }

        switch(CORSFilter.SyntheticClass_1.$SwitchMap$org$ebaysf$web$cors$CORSFilter$CORSRequestType[requestType.ordinal()]) {
        case 1:
            this.handleSimpleCORS(request1, response, filterChain);
            break;
        case 2:
            this.handleSimpleCORS(request1, response, filterChain);
            break;
        case 3:
            this.handlePreflightCORS(request1, response, filterChain);
            break;
        case 4:
            this.handleNonCORS(request1, response, filterChain);
            break;
        default:
            this.handleInvalidCORS(request1, response, filterChain);
        }

    } else {
        String request = "CORS doesn\'t support non-HTTP request or response.";
        throw new ServletException(request);
    }
}

判断request类别,根据类别进行差异化处理。handleSimpleCORS 处理过程,判断是否设置允许所有origin参数,判断是否符合httpMethods要求,判断此次request的origin(origin = request.getHeader("Origin"))是否在allowedOrigins(origin白名单)内。如果在,就设置response.addHeader("Access-Control-Allow-Origin", origin);这样也就实现了多域名支持。流程图就不画了...

public void handleSimpleCORS(HttpServletRequest request, HttpServletResponse response, FilterChain filterChain) throws IOException, ServletException {
        CORSFilter.CORSRequestType requestType = this.checkRequestType(request);
        String origin;
        if(requestType != CORSFilter.CORSRequestType.SIMPLE && requestType != CORSFilter.CORSRequestType.ACTUAL) {
            origin = "Expects a HttpServletRequest object of type " + CORSFilter.CORSRequestType.SIMPLE + " or " + CORSFilter.CORSRequestType.ACTUAL;
            throw new IllegalArgumentException(origin);
        } else {
            origin = request.getHeader("Origin");
            String method = request.getMethod();
            if(!this.isOriginAllowed(origin)) {
                this.handleInvalidCORS(request, response, filterChain);
            } else if(!this.allowedHttpMethods.contains(method)) {
                this.handleInvalidCORS(request, response, filterChain);
            } else {
                if(this.anyOriginAllowed && !this.supportsCredentials) {
                    response.addHeader("Access-Control-Allow-Origin", "*");
                } else {
                    response.addHeader("Access-Control-Allow-Origin", origin);
                }

                if(this.supportsCredentials) {
                    response.addHeader("Access-Control-Allow-Credentials", "true");
                }

                if(this.exposedHeaders != null && this.exposedHeaders.size() > 0) {
                    String exposedHeadersString = join(this.exposedHeaders, ",");
                    response.addHeader("Access-Control-Expose-Headers", exposedHeadersString);
                }

                filterChain.doFilter(request, response);
            }
        }
    }

为了避免对参数一知半解,就把作者的参数描述表贴上来,通过参数表可以了解下header里面各个参数的作用

param-name description
cors.allowed.origins A list of origins that are allowed to access the resource. A '' can be specified to enable access to resource from any origin. Otherwise, a whitelist of comma separated origins can be provided. Ex: http://www.w3.orghttps://www.apache.orgDefaults: (Any origin is allowed to access the resource).
cors.allowed.methods A comma separated list of HTTP methods that can be used to access the resource, using cross-origin requests. These are the methods which will also be included as part of 'Access-Control-Allow-Methods' header in a pre-flight response. Ex: GET,POST. Defaults: GET,POST,HEAD,OPTIONS
cors.allowed.headers A comma separated list of request headers that can be used when making an actual request. These header will also be returned as part of 'Access-Control-Allow-Headers' header in a pre-flight response. Ex: Origin,Accept. Defaults: Origin,Accept,X-Requested-With,Content-Type,Access-Control-Request-Method,Access-Control-Request-Headers
cors.exposed.headers A comma separated list of headers other than the simple response headers that browsers are allowed to access. These are the headers which will also be included as part of 'Access-Control-Expose-Headers' header in the pre-flight response. Ex: X-CUSTOM-HEADER-PING,X-CUSTOM-HEADER-PONG. Default: None
cors.preflight.maxage The amount of seconds, browser is allowed to cache the result of the pre-flight request. This will be included as part of 'Access-Control-Max-Age' header in the pre-flight response. A negative value will prevent CORS Filter from adding this response header from pre-flight response. Defaults: 1800
cors.support.credentials A flag that indicates whether the resource supports user credentials. This flag is exposed as part of 'Access-Control-Allow-Credentials' header in a pre-flight response. It helps browser determine whether or not an actual request can be made using credentials. Defaults: true
cors.logging.enabled A flag to control logging to container logs. Defaults: false
cors.request.decorate A flag to control if the request should be decorated or not. Defaults: true

测试:

1.服务端准备接口(我的地址是:http://192.168.10.61:8080/api

@RequestMapping(method = RequestMethod.GET,value = "test")
@ResponseBody
public HashMap<String,Object> getArticles(){
    HashMap<String,Object> map = new HashMap<>();
    map.put("result","success");
    return map;
}

2.过滤器配置(web.xml),配置允许访问的域为:http://192.168.56.129,http://www.website2.com

<filter>
    <filter-name>CORS Filter</filter-name>
    <filter-class>org.ebaysf.web.cors.CORSFilter</filter-class>
    <init-param>
      <param-name>cors.allowed.origins</param-name>
      <param-value>http://192.168.56.129,http://www.website2.com</param-value>
    </init-param>
  </filter>
  <filter-mapping>
    <filter-name>CORS Filter</filter-name>
    <url-pattern>/*</url-pattern>
  </filter-mapping>

3.准备测试网页index.html:

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <title>cors test page</title>
    <script src="jquery.min.js"></script>
    <script>
        function loadData(){
            $.ajax({
                url: "http://192.168.10.61:8080/api",
                type:"GET",
                dataType:"json",
                timeout:10000,
                success:function(data){
                    $("#result").append(data.result+"<br />");
                    console.log(data);
                },
                error:function(e){
                    $("#result").append(e.statusText+"<br />");
                }
            });
        }
        $(function(){
            $("#host").append("origin:"+window.location.origin);
        });
    </script>
</head>
<body>
<button onclick="loadData()">onclick</button>
<div id="host"></div>
<div id="result" style="height:200px;width:100%"></div>
</body>
</html>

4.将index.html发布到nginx(nginx后面也有方案)

index.html 不能直接用浏览器打开运行,虽然可以调用Ajax请求,但是域是file:///path/index.html

虚拟机增加一个网卡地址(原机器IP是192.168.56.129)

ifconfig eth0:0 192.168.56.130

建立两个测试网站

cd home
mkdir /website1 #站点目录
mkdir /website2

将index.html 传输到这两个目录

配置nginx,增加两个server节点

# ----server1 ----
server {
    listen       192.168.56.129:80;
    server_name  www.website1.com;
    location / {
        root   /website1;
        index  index.html index.htm;
    }
}
# ----server2 ----
server {
    listen       192.168.56.130:80;
    server_name  www.website2.com;
    location / {
        root   /website2;
        index  index.html index.htm;
    }
}

重启nginx服务

./nginx -s reload

5.修改本地hosts文件

//hosts文件路径:windows系统一般在C:\Windows\System32\drivers\etc
192.168.56.129  www.website1.com
192.168.56.130  www.website2.com

通过增加虚拟网卡 、nginx代理 和 修改hosts文件,我在本地就有4个网站(域)可以进行测试了,分别是:

6.测试

准备:

(chrome)打开4个tab,分别进入到上述四个网站,页面打印了当前origin,通过onclick调用Ajax请求,页面布局如下

预期:

结果:




符合预期!

建议使用,除了对域的过滤,还做了其他很多操作,比简单的自定义过滤器考虑得周全,例如

this.handlePreflightCORS(request1, response, filterChain);
this.handleNonCORS(request1, response, filterChain);
this.handleInvalidCORS(request1, response, filterChain);

总结

cors在开发WebService、RESTful API 时经常会遇到,在以前可能直接通过jsonp解决,jsonp怎样怎样就不多说了。 总之,CORS技术规范出来这么久了,如果不考虑IE6 IE7的问题,那么还是积极拥抱CORS吧

上文三种解决方案,通过搜索引擎均能找到,但估计大部分都是用的第一种最简单的无脑的Cors Filter处理,第二种方案是通过nginx配置的,并不适合所有Web应用。第三种,考虑得很周全,而且使用方便,如果不考虑造重复轮子,推荐使用。

本文所用的测试工程代码太简单了,就不放github了,直接下载吧,项目下载地址

断断续续写了好几天,转载请附带原文路径:http://www.cnblogs.com/sloong/p/cors.html

版权声明:本文内容由阿里云实名注册用户自发贡献,版权归原作者所有,阿里云开发者社区不拥有其著作权,亦不承担相应法律责任。具体规则请查看《阿里云开发者社区用户服务协议》和《阿里云开发者社区知识产权保护指引》。如果您发现本社区中有涉嫌抄袭的内容,填写侵权投诉表单进行举报,一经查实,本社区将立刻删除涉嫌侵权内容。

相关文章
CQRS被称为邪教?
CQRS全称Command Query Responsibility Segregation
0 0
AHAS-功能开关 解决方案
功能开关是一个轻量级的动态配置框架,通过功能开关可以动态管理代码中的配置项,根据需求为某个应用开启或关闭部分功能,或设置某个性能指标的阈值。功能开关通常用于设置黑白名单、运行时动态调整日志级别、降级业务功能等场景。
0 0
JS模块化(一):Commonjs
JS模块化(一):Commonjs
0 0
第167天:canvas绘制柱状图
canvas绘制柱状图 1、HTML 1 DOCTYPE html> 2 3 4 5 6 06柱状图面向对象版本 7 8 body { 9 padding: 0; 10 ma...
975 0
CoreOS 入门
本文讲的是CoreOS 入门【编者的话】本文是一篇 CoreOS 入门文章。分别介绍了 CoreOS 的三个主要组件——配置和服务发现、应用程序管理和调度以及应用程序,对一些概念进行了解释,并初步介绍了一些 CoreOS 的高阶组件供读者探索。
5009 0
CNN
 分类:   30.Machine L & Deep Learning(11)  目录(?)[-]                通俗理解卷积神经网络cs231n与5月dl班课程笔记 前言 人工神经网络 1 神经元...
1259 0
Cmd IIS 重启
将下面三行代码拷到txt文件中,修改txt文档的后缀为bat,双击即可执行,实现iis重启功能。 @echo off iisreset /restart pause 复杂版本的iis重启 @echo off title 是否重启IIS? echo 是否重启IIS? :select set /p restart=请输入您的选择(Y/N
965 0
Cmd IIS 重启
将下面三行代码拷到txt文件中,修改txt文档的后缀为bat,双击即可执行,实现iis重启功能。 @echo off iisreset /restart pause 复杂版本的iis重启 @echo off title 是否重启IIS? echo 是否重启IIS? :select set /p restart=请输入您的选择(Y/N
645 0
文章
问答
文章排行榜
最热
最新
相关电子书
更多
低代码开发师(初级)实战教程
立即下载
阿里巴巴DevOps 最佳实践手册
立即下载
冬季实战营第三期:MySQL数据库进阶实战
立即下载
