简介: 1.Spring实现数据库的读写分离 现在大型的电子商务系统,在数据库层面大都采用读写分离技术,就是一个Master数据库,多个Slave数据库。Master库负责数据更新和实时数据查询,Slave库当然负责非实时数据查询。因为在实际的应用中,数据库都是读多写少(读取数据的频率高,更新数据的频率相对较少),而读取数据通常耗时比较长,占用数据库服务器的CPU较多,从而影响用

1.Spring实现数据库的读写分离

现在大型的电子商务系统,在数据库层面大都采用读写分离技术,就是一个Master数据库,多个Slave数据库。Master库负责数据更新和实时数据查询,Slave库当然负责非实时数据查询。因为在实际的应用中,数据库都是读多写少(读取数据的频率高,更新数据的频率相对较少),而读取数据通常耗时比较长,占用数据库服务器的CPU较多,从而影响用户体验。我们通常的做法就是把查询从主库中抽取出来,采用多个从库,使用负载均衡,减轻每个从库的查询压力。

  采用读写分离技术的目标:有效减轻Master库的压力,又可以把用户查询数据的请求分发到不同的Slave库,从而保证系统的健壮性。我们看下采用读写分离的背景

  随着网站的业务不断扩展,数据不断增加,用户越来越多,数据库的压力也就越来越大,采用传统的方式,比如:数据库或者SQL的优化基本已达不到要求,这个时候可以采用读写分离的策 略来改变现状。

  具体到开发中,如何方便的实现读写分离呢?目前常用的有两种方式:

  1 第一种方式是我们最常用的方式,就是定义2个数据库连接,一个是MasterDataSource,另一个是SlaveDataSource。更新数据时我们读取MasterDataSource,查询数据时我们读取SlaveDataSource。这种方式很简单,我就不赘述了。

  2 第二种方式动态数据源切换,就是在程序运行时,把数据源动态织入到程序中,从而选择读取主库还是从库。主要使用的技术是:annotationspring AOP ,反射。下面会详细的介绍实现方式。

   在介绍实现方式之前,我们先准备一些必要的知识,spring 的AbstractRoutingDataSource 类

     AbstractRoutingDataSource这个类 是spring2.0以后增加的,我们先来看下AbstractRoutingDataSource的定义:

    public abstract class AbstractRoutingDataSource extends AbstractDataSource implements InitializingBean  {}


    AbstractRoutingDataSource继承了AbstractDataSource ,而AbstractDataSource 又是DataSource 的子类。DataSource   是javax.sql 的数据源接口,定义如下:



复制代码
public interface DataSource  extends CommonDataSource,Wrapper {

  /**
   * <p>Attempts to establish a connection with the data source that
   * this <code>DataSource</code> object represents.
   *
   * @return  a connection to the data source
   * @exception SQLException if a database access error occurs
   */
  Connection getConnection() throws SQLException;

  /**
   * <p>Attempts to establish a connection with the data source that
   * this <code>DataSource</code> object represents.
   *
   * @param username the database user on whose behalf the connection is
   *  being made
   * @param password the user's password
   * @return  a connection to the data source
   * @exception SQLException if a database access error occurs
   * @since 1.4
   */
  Connection getConnection(String username, String password)
    throws SQLException;

}
复制代码



  DataSource 接口定义了2个方法,都是获取数据库连接。我们在看下AbstractRoutingDataSource 如何实现了DataSource接口:

复制代码
public Connection getConnection() throws SQLException {
        return determineTargetDataSource().getConnection();
    }

    public Connection getConnection(String username, String password) throws SQLException {
        return determineTargetDataSource().getConnection(username, password);
    }
复制代码



  很显然就是调用自己的determineTargetDataSource()  方法获取到connection。determineTargetDataSource方法定义如下:

复制代码
protected DataSource determineTargetDataSource() {
        Assert.notNull(this.resolvedDataSources, "DataSource router not initialized");
        Object lookupKey = determineCurrentLookupKey();
        DataSource dataSource = this.resolvedDataSources.get(lookupKey);
        if (dataSource == null && (this.lenientFallback || lookupKey == null)) {
            dataSource = this.resolvedDefaultDataSource;
        }
        if (dataSource == null) {
            throw new IllegalStateException("Cannot determine target DataSource for lookup key [" + lookupKey + "]");
        }
        return dataSource;
    }
复制代码



   我们最关心的还是下面2句话:

    Object lookupKey = determineCurrentLookupKey();
        DataSource dataSource = this.resolvedDataSources.get(lookupKey);

    determineCurrentLookupKey方法返回lookupKey,resolvedDataSources方法就是根据lookupKey从Map中获得数据源。resolvedDataSources 和determineCurrentLookupKey定义如下:

  private Map<Object, DataSource> resolvedDataSources;

  protected abstract Object determineCurrentLookupKey()

  看到以上定义,我们是不是有点思路了,resolvedDataSources是Map类型,我们可以把MasterDataSource和SlaveDataSource存到Map中,如下:

    key        value

    master             MasterDataSource

    slave                  SlaveDataSource

  我们在写一个类DynamicDataSource  继承AbstractRoutingDataSource,实现其determineCurrentLookupKey() 方法,该方法返回Map的key,master或slave。



  好了,说了这么多,有点烦了,下面我们看下怎么实现。

   上面已经提到了我们要使用的技术,我们先看下annotation的定义:

@Retention(RetentionPolicy.RUNTIME)
@Target(ElementType.METHOD)
public @interface DataSource {
    String value();
}



    我们还需要实现spring的抽象类AbstractRoutingDataSource,就是实现determineCurrentLookupKey方法:

复制代码
public class DynamicDataSource extends AbstractRoutingDataSource {

    @Override
    protected Object determineCurrentLookupKey() {
        // TODO Auto-generated method stub
        return DynamicDataSourceHolder.getDataSouce();
    }

}


public class DynamicDataSourceHolder {
    public static final ThreadLocal<String> holder = new ThreadLocal<String>();

    public static void putDataSource(String name) {
        holder.set(name);
    }

    public static String getDataSouce() {
        return holder.get();
    }
}
复制代码



    从DynamicDataSource 的定义看出,他返回的是DynamicDataSourceHolder.getDataSouce()值,我们需要在程序运行时调用DynamicDataSourceHolder.putDataSource()方法,对其赋值。下面是我们实现的核心部分,也就是AOP部分,DataSourceAspect定义如下:

复制代码
public class DataSourceAspect {

    public void before(JoinPoint point)
    {
        Object target = point.getTarget();
        String method = point.getSignature().getName();

        Class<?>[] classz = target.getClass().getInterfaces();

        Class<?>[] parameterTypes = ((MethodSignature) point.getSignature())
                .getMethod().getParameterTypes();
        try {
            Method m = classz[0].getMethod(method, parameterTypes);
            if (m != null && m.isAnnotationPresent(DataSource.class)) {
                DataSource data = m
                        .getAnnotation(DataSource.class);
                DynamicDataSourceHolder.putDataSource(data.value());
                System.out.println(data.value());
            }

        } catch (Exception e) {
            // TODO: handle exception
        }
    }
}
复制代码





    为了方便测试,我定义了2个数据库,shop模拟Master库,test模拟Slave库,shop和test的表结构一致,但数据不同,数据库配置如下:

复制代码
<bean id="masterdataSource"
        class="org.springframework.jdbc.datasource.DriverManagerDataSource">
        <property name="driverClassName" value="com.mysql.jdbc.Driver" />
        <property name="url" value="jdbc:mysql://127.0.0.1:3306/shop" />
        <property name="username" value="root" />
        <property name="password" value="yangyanping0615" />
    </bean>

    <bean id="slavedataSource"
        class="org.springframework.jdbc.datasource.DriverManagerDataSource">
        <property name="driverClassName" value="com.mysql.jdbc.Driver" />
        <property name="url" value="jdbc:mysql://127.0.0.1:3306/test" />
        <property name="username" value="root" />
        <property name="password" value="yangyanping0615" />
    </bean>

        <beans:bean id="dataSource" class="com.air.shop.common.db.DynamicDataSource">
        <property name="targetDataSources">
              <map key-type="java.lang.String">
                  <!-- write -->
                 <entry key="master" value-ref="masterdataSource"/>
                 <!-- read -->
                 <entry key="slave" value-ref="slavedataSource"/>
              </map>

        </property>
        <property name="defaultTargetDataSource" ref="masterdataSource"/>
    </beans:bean>

    <bean id="transactionManager"
        class="org.springframework.jdbc.datasource.DataSourceTransactionManager">
        <property name="dataSource" ref="dataSource" />
    </bean>


    <!-- 配置SqlSessionFactoryBean -->
    <bean id="sqlSessionFactory" class="org.mybatis.spring.SqlSessionFactoryBean">
        <property name="dataSource" ref="dataSource" />
        <property name="configLocation" value="classpath:config/mybatis-config.xml" />
    </bean>
复制代码



  在spring的配置中增加aop配置

复制代码
<!-- 配置数据库注解aop -->
    <aop:aspectj-autoproxy></aop:aspectj-autoproxy>
    <beans:bean id="manyDataSourceAspect" class="com.air.shop.proxy.DataSourceAspect" />
    <aop:config>
        <aop:aspect id="c" ref="manyDataSourceAspect">
            <aop:pointcut id="tx" expression="execution(* com.air.shop.mapper.*.*(..))"/>
            <aop:before pointcut-ref="tx" method="before"/>
        </aop:aspect>
    </aop:config>
    <!-- 配置数据库注解aop -->
复制代码



   下面是MyBatis的UserMapper的定义,为了方便测试,登录读取的是Master库,用户列表读取Slave库:

复制代码
public interface UserMapper {
    @DataSource("master")
    public void add(User user);

    @DataSource("master")
    public void update(User user);

    @DataSource("master")
    public void delete(int id);

    @DataSource("slave")
    public User loadbyid(int id);

    @DataSource("master")
    public User loadbyname(String name);

    @DataSource("slave")
    public List<User> list();
}
复制代码



   好了,运行我们的Eclipse看看效果,输入用户名admin 登录看看效果





  从图中可以看出,登录的用户和用户列表的数据是不同的,也验证了我们的实现,登录读取Master库,用户列表读取Slave库。


2.MyBatis多数据源配置 实现读写分离


首先说明,本文的配置使用的最直接的方式,实际用起来可能会很麻烦。

实际应用中可能存在多种结合的情况,你可以理解本文的含义,不要死板的使用。

多数据源的可能情况

1.主从

通常是MySQL一主多从的情况,本文的例子就是主从的情况,但是只有两个数据源,所以采用直接配置不会太麻烦,但是不利于后续扩展,主要是作为一个例子来说明,实际操作请慎重考虑。

针对这种情况,一个更好的解决方法可以参考(本人没有实际尝试过):

http://blog.csdn.net/lixiucheng005/article/details/17391857

还有一个通过SpringAbstractRoutingDataSource路由接口的方式:

http://blog.csdn.net/xtj332/article/details/43953699

2.分库

当业务独立性强,数据量大的时候的,为了提高并发,可能会对表进行分库,分库后,每一个数据库都需要配置一个数据源。

这种情况可以参考本文,但是需要注意每一个数据库对应的Mapper要在不同的包下方便区分和配置。

另外分库的情况下也会存在主从的情况,如果你的数据库从库过多,就参考上面提供的方法,或者寻找其他方式解决。

Mapper分包

分库的情况下,不同的数据库的Mapper一定放在不同的包下。

主从的情况下,同一个Mapper会同时存在读写的情况,创建两个并不合适,使用同一个即可。但是这种情况下需要注意,Spring对Mapper自动生成的名字是相同的,而且类型也相同,这是就不能直接注入Mapper接口。需要通过SqlSession来解决。

Spring基础配置

applicationContext.xml

<code class="language-xml hljs has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: 'Source Code Pro', monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"><span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">beans</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xmlns</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.springframework.org/schema/beans"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xmlns:xsi</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.w3.org/2001/XMLSchema-instance"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xmlns:context</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.springframework.org/schema/context"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xmlns:aop</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.springframework.org/schema/aop"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xsi:schemaLocation</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd http://www.springframework.org/schema/context http://www.springframework.org/schema/context/spring-context.xsd http://www.springframework.org/schema/aop http://www.springframework.org/schema/aop/spring-aop.xsd"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">context:component-scan</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">base-package</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"com.isea533.mybatis.service"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">context:property-placeholder</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">location</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"classpath:config.properties"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">aop:aspectj-autoproxy</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">import</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">resource</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"spring-datasource-master.xml"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">import</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">resource</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"spring-datasource-slave.xml"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">beans</span>></span></code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right-width: 1px; border-right-style: solid; border-right-color: rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li><li style="box-sizing: border-box; padding: 0px 5px;">16</li><li style="box-sizing: border-box; padding: 0px 5px;">17</li><li style="box-sizing: border-box; padding: 0px 5px;">18</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right-width: 1px; border-right-style: solid; border-right-color: rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li><li style="box-sizing: border-box; padding: 0px 5px;">16</li><li style="box-sizing: border-box; padding: 0px 5px;">17</li><li style="box-sizing: border-box; padding: 0px 5px;">18</li></ul>

这个文件,主要是引入了spring-datasource-master.xmlspring-datasource-slave.xml

spring-datasource-master.xml

<code class="language-xml hljs has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: 'Source Code Pro', monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"><span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">beans</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xmlns</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.springframework.org/schema/beans"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xmlns:xsi</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.w3.org/2001/XMLSchema-instance"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xmlns:tx</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.springframework.org/schema/tx"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xmlns:aop</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.springframework.org/schema/aop"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xsi:schemaLocation</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd http://www.springframework.org/schema/tx http://www.springframework.org/schema/tx/spring-tx.xsd http://www.springframework.org/schema/aop http://www.springframework.org/schema/aop/spring-aop.xsd"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">id</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"dataSourceMaster"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">class</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"com.alibaba.druid.pool.DruidDataSource"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">init-method</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"init"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">destroy-method</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"close"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"driverClassName"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"${master.jdbc.driverClass}"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"url"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"${master.jdbc.url}"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"username"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"${master.jdbc.user}"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"password"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"${master.jdbc.password}"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"filters"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"stat"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"maxActive"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"20"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"initialSize"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"1"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"maxWait"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"60000"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"minIdle"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"1"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"timeBetweenEvictionRunsMillis"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"60000"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"minEvictableIdleTimeMillis"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"300000"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"validationQuery"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"SELECT 'x'"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"testWhileIdle"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"true"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"testOnBorrow"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"false"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"testOnReturn"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"false"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">id</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"sqlSessionFactory1"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">class</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"org.mybatis.spring.SqlSessionFactoryBean"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"dataSource"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">ref</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"dataSourceMaster"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"mapperLocations"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">array</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">value</span>></span>classpath:mapper/*.xml<span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">value</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">array</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">class</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"org.mybatis.spring.mapper.MapperScannerConfigurer"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"basePackage"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"com.isea533.mybatis.mapper"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"sqlSessionFactoryBeanName"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"sqlSessionFactory1"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">id</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"sqlSessionMaster"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">class</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"org.mybatis.spring.SqlSessionTemplate"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">scope</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"prototype"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">constructor-arg</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">index</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"0"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">ref</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"sqlSessionFactory1"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">aop:config</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">aop:pointcut</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">id</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"appService"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">expression</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"execution(* com.isea533.mybatis.service..*Service*.*(..))"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">aop:advisor</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">advice-ref</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"txAdvice1"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">pointcut-ref</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"appService"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">aop:config</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">tx:advice</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">id</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"txAdvice1"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">transaction-manager</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"transactionManager1"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">tx:attributes</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">tx:method</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"select*"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">read-only</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"true"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">tx:method</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"find*"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">read-only</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"true"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">tx:method</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"get*"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">read-only</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"true"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">tx:method</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"*"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">tx:attributes</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">tx:advice</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">id</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"transactionManager1"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">class</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"org.springframework.jdbc.datasource.DataSourceTransactionManager"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"dataSource"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">ref</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"dataSourceMaster"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">beans</span>></span></code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right-width: 1px; border-right-style: solid; border-right-color: rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li><li style="box-sizing: border-box; padding: 0px 5px;">16</li><li style="box-sizing: border-box; padding: 0px 5px;">17</li><li style="box-sizing: border-box; padding: 0px 5px;">18</li><li style="box-sizing: border-box; padding: 0px 5px;">19</li><li style="box-sizing: border-box; padding: 0px 5px;">20</li><li style="box-sizing: border-box; padding: 0px 5px;">21</li><li style="box-sizing: border-box; padding: 0px 5px;">22</li><li style="box-sizing: border-box; padding: 0px 5px;">23</li><li style="box-sizing: border-box; padding: 0px 5px;">24</li><li style="box-sizing: border-box; padding: 0px 5px;">25</li><li style="box-sizing: border-box; padding: 0px 5px;">26</li><li style="box-sizing: border-box; padding: 0px 5px;">27</li><li style="box-sizing: border-box; padding: 0px 5px;">28</li><li style="box-sizing: border-box; padding: 0px 5px;">29</li><li style="box-sizing: border-box; padding: 0px 5px;">30</li><li style="box-sizing: border-box; padding: 0px 5px;">31</li><li style="box-sizing: border-box; padding: 0px 5px;">32</li><li style="box-sizing: border-box; padding: 0px 5px;">33</li><li style="box-sizing: border-box; padding: 0px 5px;">34</li><li style="box-sizing: border-box; padding: 0px 5px;">35</li><li style="box-sizing: border-box; padding: 0px 5px;">36</li><li style="box-sizing: border-box; padding: 0px 5px;">37</li><li style="box-sizing: border-box; padding: 0px 5px;">38</li><li style="box-sizing: border-box; padding: 0px 5px;">39</li><li style="box-sizing: border-box; padding: 0px 5px;">40</li><li style="box-sizing: border-box; padding: 0px 5px;">41</li><li style="box-sizing: border-box; padding: 0px 5px;">42</li><li style="box-sizing: border-box; padding: 0px 5px;">43</li><li style="box-sizing: border-box; padding: 0px 5px;">44</li><li style="box-sizing: border-box; padding: 0px 5px;">45</li><li style="box-sizing: border-box; padding: 0px 5px;">46</li><li style="box-sizing: border-box; padding: 0px 5px;">47</li><li style="box-sizing: border-box; padding: 0px 5px;">48</li><li style="box-sizing: border-box; padding: 0px 5px;">49</li><li style="box-sizing: border-box; padding: 0px 5px;">50</li><li style="box-sizing: border-box; padding: 0px 5px;">51</li><li style="box-sizing: border-box; padding: 0px 5px;">52</li><li style="box-sizing: border-box; padding: 0px 5px;">53</li><li style="box-sizing: border-box; padding: 0px 5px;">54</li><li style="box-sizing: border-box; padding: 0px 5px;">55</li><li style="box-sizing: border-box; padding: 0px 5px;">56</li><li style="box-sizing: border-box; padding: 0px 5px;">57</li><li style="box-sizing: border-box; padding: 0px 5px;">58</li><li style="box-sizing: border-box; padding: 0px 5px;">59</li><li style="box-sizing: border-box; padding: 0px 5px;">60</li><li style="box-sizing: border-box; padding: 0px 5px;">61</li><li style="box-sizing: border-box; padding: 0px 5px;">62</li><li style="box-sizing: border-box; padding: 0px 5px;">63</li><li style="box-sizing: border-box; padding: 0px 5px;">64</li><li style="box-sizing: border-box; padding: 0px 5px;">65</li><li style="box-sizing: border-box; padding: 0px 5px;">66</li><li style="box-sizing: border-box; padding: 0px 5px;">67</li><li style="box-sizing: border-box; padding: 0px 5px;">68</li><li style="box-sizing: border-box; padding: 0px 5px;">69</li><li style="box-sizing: border-box; padding: 0px 5px;">70</li><li style="box-sizing: border-box; padding: 0px 5px;">71</li><li style="box-sizing: border-box; padding: 0px 5px;">72</li><li style="box-sizing: border-box; padding: 0px 5px;">73</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right-width: 1px; border-right-style: solid; border-right-color: rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li><li style="box-sizing: border-box; padding: 0px 5px;">16</li><li style="box-sizing: border-box; padding: 0px 5px;">17</li><li style="box-sizing: border-box; padding: 0px 5px;">18</li><li style="box-sizing: border-box; padding: 0px 5px;">19</li><li style="box-sizing: border-box; padding: 0px 5px;">20</li><li style="box-sizing: border-box; padding: 0px 5px;">21</li><li style="box-sizing: border-box; padding: 0px 5px;">22</li><li style="box-sizing: border-box; padding: 0px 5px;">23</li><li style="box-sizing: border-box; padding: 0px 5px;">24</li><li style="box-sizing: border-box; padding: 0px 5px;">25</li><li style="box-sizing: border-box; padding: 0px 5px;">26</li><li style="box-sizing: border-box; padding: 0px 5px;">27</li><li style="box-sizing: border-box; padding: 0px 5px;">28</li><li style="box-sizing: border-box; padding: 0px 5px;">29</li><li style="box-sizing: border-box; padding: 0px 5px;">30</li><li style="box-sizing: border-box; padding: 0px 5px;">31</li><li style="box-sizing: border-box; padding: 0px 5px;">32</li><li style="box-sizing: border-box; padding: 0px 5px;">33</li><li style="box-sizing: border-box; padding: 0px 5px;">34</li><li style="box-sizing: border-box; padding: 0px 5px;">35</li><li style="box-sizing: border-box; padding: 0px 5px;">36</li><li style="box-sizing: border-box; padding: 0px 5px;">37</li><li style="box-sizing: border-box; padding: 0px 5px;">38</li><li style="box-sizing: border-box; padding: 0px 5px;">39</li><li style="box-sizing: border-box; padding: 0px 5px;">40</li><li style="box-sizing: border-box; padding: 0px 5px;">41</li><li style="box-sizing: border-box; padding: 0px 5px;">42</li><li style="box-sizing: border-box; padding: 0px 5px;">43</li><li style="box-sizing: border-box; padding: 0px 5px;">44</li><li style="box-sizing: border-box; padding: 0px 5px;">45</li><li style="box-sizing: border-box; padding: 0px 5px;">46</li><li style="box-sizing: border-box; padding: 0px 5px;">47</li><li style="box-sizing: border-box; padding: 0px 5px;">48</li><li style="box-sizing: border-box; padding: 0px 5px;">49</li><li style="box-sizing: border-box; padding: 0px 5px;">50</li><li style="box-sizing: border-box; padding: 0px 5px;">51</li><li style="box-sizing: border-box; padding: 0px 5px;">52</li><li style="box-sizing: border-box; padding: 0px 5px;">53</li><li style="box-sizing: border-box; padding: 0px 5px;">54</li><li style="box-sizing: border-box; padding: 0px 5px;">55</li><li style="box-sizing: border-box; padding: 0px 5px;">56</li><li style="box-sizing: border-box; padding: 0px 5px;">57</li><li style="box-sizing: border-box; padding: 0px 5px;">58</li><li style="box-sizing: border-box; padding: 0px 5px;">59</li><li style="box-sizing: border-box; padding: 0px 5px;">60</li><li style="box-sizing: border-box; padding: 0px 5px;">61</li><li style="box-sizing: border-box; padding: 0px 5px;">62</li><li style="box-sizing: border-box; padding: 0px 5px;">63</li><li style="box-sizing: border-box; padding: 0px 5px;">64</li><li style="box-sizing: border-box; padding: 0px 5px;">65</li><li style="box-sizing: border-box; padding: 0px 5px;">66</li><li style="box-sizing: border-box; padding: 0px 5px;">67</li><li style="box-sizing: border-box; padding: 0px 5px;">68</li><li style="box-sizing: border-box; padding: 0px 5px;">69</li><li style="box-sizing: border-box; padding: 0px 5px;">70</li><li style="box-sizing: border-box; padding: 0px 5px;">71</li><li style="box-sizing: border-box; padding: 0px 5px;">72</li><li style="box-sizing: border-box; padding: 0px 5px;">73</li></ul>

spring-datasource-slave.xml

master区别不大,主要是id名字和数据源配置有区别。

<code class="language-xml hljs has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: 'Source Code Pro', monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"><span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">beans</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xmlns</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.springframework.org/schema/beans"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xmlns:xsi</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.w3.org/2001/XMLSchema-instance"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xmlns:tx</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.springframework.org/schema/tx"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xmlns:aop</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.springframework.org/schema/aop"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">xsi:schemaLocation</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd http://www.springframework.org/schema/tx http://www.springframework.org/schema/tx/spring-tx.xsd http://www.springframework.org/schema/aop http://www.springframework.org/schema/aop/spring-aop.xsd"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">id</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"dataSourceSlave"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">class</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"com.alibaba.druid.pool.DruidDataSource"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">init-method</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"init"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">destroy-method</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"close"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"driverClassName"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"${slave.jdbc.driverClass}"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"url"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"${slave.jdbc.url}"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"username"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"${slave.jdbc.user}"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"password"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"${slave.jdbc.password}"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"filters"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"stat"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"maxActive"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"20"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"initialSize"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"1"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"maxWait"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"60000"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"minIdle"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"1"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"timeBetweenEvictionRunsMillis"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"60000"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"minEvictableIdleTimeMillis"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"300000"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"validationQuery"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"SELECT 'x'"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"testWhileIdle"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"true"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"testOnBorrow"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"false"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"testOnReturn"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"false"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">id</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"sqlSessionFactory2"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">class</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"org.mybatis.spring.SqlSessionFactoryBean"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"dataSource"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">ref</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"dataSourceSlave"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"mapperLocations"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">array</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">value</span>></span>classpath:mapper/*.xml<span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">value</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">array</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">class</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"org.mybatis.spring.mapper.MapperScannerConfigurer"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"basePackage"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"com.isea533.mybatis.mapper"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"sqlSessionFactoryBeanName"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"sqlSessionFactory2"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">id</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"sqlSessionSlave"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">class</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"org.mybatis.spring.SqlSessionTemplate"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">scope</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"prototype"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">constructor-arg</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">index</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"0"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">ref</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"sqlSessionFactory2"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">aop:config</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">aop:pointcut</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">id</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"appService"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">expression</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"execution(* com.isea533.mybatis.service..*Service*.*(..))"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">aop:advisor</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">advice-ref</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"txAdvice2"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">pointcut-ref</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"appService"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">aop:config</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">tx:advice</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">id</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"txAdvice2"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">transaction-manager</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"transactionManager2"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">tx:attributes</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">tx:method</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"*"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">read-only</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"true"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">tx:attributes</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">tx:advice</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">id</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"transactionManager2"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">class</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"org.springframework.jdbc.datasource.DataSourceTransactionManager"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"dataSource"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">ref</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"dataSourceSlave"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">beans</span>></span></code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right-width: 1px; border-right-style: solid; border-right-color: rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li><li style="box-sizing: border-box; padding: 0px 5px;">16</li><li style="box-sizing: border-box; padding: 0px 5px;">17</li><li style="box-sizing: border-box; padding: 0px 5px;">18</li><li style="box-sizing: border-box; padding: 0px 5px;">19</li><li style="box-sizing: border-box; padding: 0px 5px;">20</li><li style="box-sizing: border-box; padding: 0px 5px;">21</li><li style="box-sizing: border-box; padding: 0px 5px;">22</li><li style="box-sizing: border-box; padding: 0px 5px;">23</li><li style="box-sizing: border-box; padding: 0px 5px;">24</li><li style="box-sizing: border-box; padding: 0px 5px;">25</li><li style="box-sizing: border-box; padding: 0px 5px;">26</li><li style="box-sizing: border-box; padding: 0px 5px;">27</li><li style="box-sizing: border-box; padding: 0px 5px;">28</li><li style="box-sizing: border-box; padding: 0px 5px;">29</li><li style="box-sizing: border-box; padding: 0px 5px;">30</li><li style="box-sizing: border-box; padding: 0px 5px;">31</li><li style="box-sizing: border-box; padding: 0px 5px;">32</li><li style="box-sizing: border-box; padding: 0px 5px;">33</li><li style="box-sizing: border-box; padding: 0px 5px;">34</li><li style="box-sizing: border-box; padding: 0px 5px;">35</li><li style="box-sizing: border-box; padding: 0px 5px;">36</li><li style="box-sizing: border-box; padding: 0px 5px;">37</li><li style="box-sizing: border-box; padding: 0px 5px;">38</li><li style="box-sizing: border-box; padding: 0px 5px;">39</li><li style="box-sizing: border-box; padding: 0px 5px;">40</li><li style="box-sizing: border-box; padding: 0px 5px;">41</li><li style="box-sizing: border-box; padding: 0px 5px;">42</li><li style="box-sizing: border-box; padding: 0px 5px;">43</li><li style="box-sizing: border-box; padding: 0px 5px;">44</li><li style="box-sizing: border-box; padding: 0px 5px;">45</li><li style="box-sizing: border-box; padding: 0px 5px;">46</li><li style="box-sizing: border-box; padding: 0px 5px;">47</li><li style="box-sizing: border-box; padding: 0px 5px;">48</li><li style="box-sizing: border-box; padding: 0px 5px;">49</li><li style="box-sizing: border-box; padding: 0px 5px;">50</li><li style="box-sizing: border-box; padding: 0px 5px;">51</li><li style="box-sizing: border-box; padding: 0px 5px;">52</li><li style="box-sizing: border-box; padding: 0px 5px;">53</li><li style="box-sizing: border-box; padding: 0px 5px;">54</li><li style="box-sizing: border-box; padding: 0px 5px;">55</li><li style="box-sizing: border-box; padding: 0px 5px;">56</li><li style="box-sizing: border-box; padding: 0px 5px;">57</li><li style="box-sizing: border-box; padding: 0px 5px;">58</li><li style="box-sizing: border-box; padding: 0px 5px;">59</li><li style="box-sizing: border-box; padding: 0px 5px;">60</li><li style="box-sizing: border-box; padding: 0px 5px;">61</li><li style="box-sizing: border-box; padding: 0px 5px;">62</li><li style="box-sizing: border-box; padding: 0px 5px;">63</li><li style="box-sizing: border-box; padding: 0px 5px;">64</li><li style="box-sizing: border-box; padding: 0px 5px;">65</li><li style="box-sizing: border-box; padding: 0px 5px;">66</li><li style="box-sizing: border-box; padding: 0px 5px;">67</li><li style="box-sizing: border-box; padding: 0px 5px;">68</li><li style="box-sizing: border-box; padding: 0px 5px;">69</li><li style="box-sizing: border-box; padding: 0px 5px;">70</li><li style="box-sizing: border-box; padding: 0px 5px;">71</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right-width: 1px; border-right-style: solid; border-right-color: rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li><li style="box-sizing: border-box; padding: 0px 5px;">16</li><li style="box-sizing: border-box; padding: 0px 5px;">17</li><li style="box-sizing: border-box; padding: 0px 5px;">18</li><li style="box-sizing: border-box; padding: 0px 5px;">19</li><li style="box-sizing: border-box; padding: 0px 5px;">20</li><li style="box-sizing: border-box; padding: 0px 5px;">21</li><li style="box-sizing: border-box; padding: 0px 5px;">22</li><li style="box-sizing: border-box; padding: 0px 5px;">23</li><li style="box-sizing: border-box; padding: 0px 5px;">24</li><li style="box-sizing: border-box; padding: 0px 5px;">25</li><li style="box-sizing: border-box; padding: 0px 5px;">26</li><li style="box-sizing: border-box; padding: 0px 5px;">27</li><li style="box-sizing: border-box; padding: 0px 5px;">28</li><li style="box-sizing: border-box; padding: 0px 5px;">29</li><li style="box-sizing: border-box; padding: 0px 5px;">30</li><li style="box-sizing: border-box; padding: 0px 5px;">31</li><li style="box-sizing: border-box; padding: 0px 5px;">32</li><li style="box-sizing: border-box; padding: 0px 5px;">33</li><li style="box-sizing: border-box; padding: 0px 5px;">34</li><li style="box-sizing: border-box; padding: 0px 5px;">35</li><li style="box-sizing: border-box; padding: 0px 5px;">36</li><li style="box-sizing: border-box; padding: 0px 5px;">37</li><li style="box-sizing: border-box; padding: 0px 5px;">38</li><li style="box-sizing: border-box; padding: 0px 5px;">39</li><li style="box-sizing: border-box; padding: 0px 5px;">40</li><li style="box-sizing: border-box; padding: 0px 5px;">41</li><li style="box-sizing: border-box; padding: 0px 5px;">42</li><li style="box-sizing: border-box; padding: 0px 5px;">43</li><li style="box-sizing: border-box; padding: 0px 5px;">44</li><li style="box-sizing: border-box; padding: 0px 5px;">45</li><li style="box-sizing: border-box; padding: 0px 5px;">46</li><li style="box-sizing: border-box; padding: 0px 5px;">47</li><li style="box-sizing: border-box; padding: 0px 5px;">48</li><li style="box-sizing: border-box; padding: 0px 5px;">49</li><li style="box-sizing: border-box; padding: 0px 5px;">50</li><li style="box-sizing: border-box; padding: 0px 5px;">51</li><li style="box-sizing: border-box; padding: 0px 5px;">52</li><li style="box-sizing: border-box; padding: 0px 5px;">53</li><li style="box-sizing: border-box; padding: 0px 5px;">54</li><li style="box-sizing: border-box; padding: 0px 5px;">55</li><li style="box-sizing: border-box; padding: 0px 5px;">56</li><li style="box-sizing: border-box; padding: 0px 5px;">57</li><li style="box-sizing: border-box; padding: 0px 5px;">58</li><li style="box-sizing: border-box; padding: 0px 5px;">59</li><li style="box-sizing: border-box; padding: 0px 5px;">60</li><li style="box-sizing: border-box; padding: 0px 5px;">61</li><li style="box-sizing: border-box; padding: 0px 5px;">62</li><li style="box-sizing: border-box; padding: 0px 5px;">63</li><li style="box-sizing: border-box; padding: 0px 5px;">64</li><li style="box-sizing: border-box; padding: 0px 5px;">65</li><li style="box-sizing: border-box; padding: 0px 5px;">66</li><li style="box-sizing: border-box; padding: 0px 5px;">67</li><li style="box-sizing: border-box; padding: 0px 5px;">68</li><li style="box-sizing: border-box; padding: 0px 5px;">69</li><li style="box-sizing: border-box; padding: 0px 5px;">70</li><li style="box-sizing: border-box; padding: 0px 5px;">71</li></ul>

这里需要注意<tx:method name="*" read-only="true"/>是只读的。如果不是从库,可以按主库进行配置。

在下面代码中:

<code class="language-xml hljs has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: 'Source Code Pro', monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"><span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">class</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"org.mybatis.spring.mapper.MapperScannerConfigurer"</span>></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"basePackage"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"com.isea533.mybatis.mapper"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"><<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">property</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">name</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"sqlSessionFactoryBeanName"</span> <span class="hljs-attribute" style="box-sizing: border-box; color: rgb(102, 0, 102);">value</span>=<span class="hljs-value" style="box-sizing: border-box; color: rgb(0, 136, 0);">"sqlSessionFactory2"</span>/></span> <span class="hljs-tag" style="color: rgb(0, 102, 102); box-sizing: border-box;"></<span class="hljs-title" style="box-sizing: border-box; color: rgb(0, 0, 136);">bean</span>></span></code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right-width: 1px; border-right-style: solid; border-right-color: rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right-width: 1px; border-right-style: solid; border-right-color: rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li></ul>

必须通过sqlSessionFactoryBeanName来指定不同的sqlSessionFactory

config.properties

<code class="language-properties hljs avrasm has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: 'Source Code Pro', monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;"># 数据库配置 - Master</span> master<span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.jdbc</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.driverClass</span> = <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">com</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.mysql</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.jdbc</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.Driver</span> master<span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.jdbc</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.url</span> = jdbc:mysql://<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">192.168</span><span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">.1</span><span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">.11</span>:<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">3306</span>/test master<span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.jdbc</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.user</span> = root master<span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.jdbc</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.password</span> = jj <span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;"># - Slave</span> slave<span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.jdbc</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.driverClass</span> = <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">com</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.mysql</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.jdbc</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.Driver</span> slave<span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.jdbc</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.url</span> = jdbc:mysql://<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">192.168</span><span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">.1</span><span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">.22</span>:<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">3306</span>/test slave<span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.jdbc</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.user</span> = root slave<span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.jdbc</span><span class="hljs-preprocessor" style="color: rgb(68, 68, 68); box-sizing: border-box;">.password</span> = jj</code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right-width: 1px; border-right-style: solid; border-right-color: rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right-width: 1px; border-right-style: solid; border-right-color: rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li></ul>

使用Mapper

这里是针对主从的情况进行设置的,两个配置扫描的Mapper是一样的,所以没法直接注入,需要通过下面的麻烦方式注入。

<code class="language-java hljs has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: 'Source Code Pro', monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"><span class="hljs-annotation" style="color: rgb(155, 133, 157); box-sizing: border-box;">@Service</span> <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">public</span> <span class="hljs-class" style="box-sizing: border-box;"><span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">class</span> <span class="hljs-title" style="box-sizing: border-box; color: rgb(102, 0, 102);">DemoService</span> {</span> <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">private</span> CountryMapper writeMapper; <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">private</span> CountryMapper readMapper; <span class="hljs-annotation" style="color: rgb(155, 133, 157); box-sizing: border-box;">@Resource</span>(name = <span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"sqlSessionMaster"</span>) <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">public</span> <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">void</span> <span class="hljs-title" style="box-sizing: border-box;">setWriteMapper</span>(SqlSession sqlSession) { <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">this</span>.writeMapper = sqlSession.getMapper(CountryMapper.class); } <span class="hljs-annotation" style="color: rgb(155, 133, 157); box-sizing: border-box;">@Resource</span>(name = <span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"sqlSessionSlave"</span>) <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">public</span> <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">void</span> <span class="hljs-title" style="box-sizing: border-box;">setReadMapper</span>(SqlSession sqlSession) { <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">this</span>.readMapper = sqlSession.getMapper(CountryMapper.class); } <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">public</span> <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">int</span> <span class="hljs-title" style="box-sizing: border-box;">save</span>(Country country){ <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">return</span> writeMapper.insert(country); } <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">public</span> List<Country> <span class="hljs-title" style="box-sizing: border-box;">selectPage</span>(<span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">int</span> pageNum, <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">int</span> pageSize) { PageHelper.startPage(pageNum, pageSize); <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">return</span> readMapper.select(<span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">null</span>); } }</code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right-width: 1px; border-right-style: solid; border-right-color: rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li><li style="box-sizing: border-box; padding: 0px 5px;">16</li><li style="box-sizing: border-box; padding: 0px 5px;">17</li><li style="box-sizing: border-box; padding: 0px 5px;">18</li><li style="box-sizing: border-box; padding: 0px 5px;">19</li><li style="box-sizing: border-box; padding: 0px 5px;">20</li><li style="box-sizing: border-box; padding: 0px 5px;">21</li><li style="box-sizing: border-box; padding: 0px 5px;">22</li><li style="box-sizing: border-box; padding: 0px 5px;">23</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right-width: 1px; border-right-style: solid; border-right-color: rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li><li style="box-sizing: border-box; padding: 0px 5px;">16</li><li style="box-sizing: border-box; padding: 0px 5px;">17</li><li style="box-sizing: border-box; padding: 0px 5px;">18</li><li style="box-sizing: border-box; padding: 0px 5px;">19</li><li style="box-sizing: border-box; padding: 0px 5px;">20</li><li style="box-sizing: border-box; padding: 0px 5px;">21</li><li style="box-sizing: border-box; padding: 0px 5px;">22</li><li style="box-sizing: border-box; padding: 0px 5px;">23</li></ul>

因为sqlSession能通过name区分开,所以这里从sqlSession获取Mapper

另外如果需要考虑在同一个事务中写读的时候,需要使用相同的writeMapper,这样在读的时候,才能获取事务中的最新数据。

以上是主从的情况。

在分库的情况时,由于不同Mapper在不同的包下,所以可以直接使用@Resource或者@Autowired注入Mapper,不需要通过sqlSession获取。
