HttpClient在多线程环境下踩坑总结
问题现场
在多线程环境下使用HttpClient组件对某个HTTP服务发起请求，运行一段时间之后发现客户端主机CPU利用率呈现出下降趋势，而不是一个稳定的状态。
而且，从程序日志中判断有线程处于夯住的状态，应该是被阻塞了。
CPU使用率逐步下降

问题排查
一开始找不到原因，怀疑是多线程并发导致的死锁问题，但是通过代码审查并未定位到任何可能的多线程并发问题。
甚至开始怀疑是否是因为内存资源不够引起JVM频繁GC到导致业务线程被暂停，但是从GC的日志输出结果看，GC是正常的。
于是，进入一种丈二和尚摸不着头脑头脑的状态，再次Review代码，发现并未设置请求超时时间，于是设置超时控制，发现问题依然存在，彻底懵逼了。
最后，dump线程堆栈和内存堆栈，再对堆栈数据进行分析。从分析结果看，确认是因为Socket连接在读取数据时被阻塞引起线程夯住。搜索“httpclient 超时”关键字，找到各式各样设置HttpClient超时控制的方式，均尝试过但是并未生效。
实际上到后来才知道，HttpCient的超时控制在不同的版本中设置请求超时参数的方式均各不相同，这才导致了我使用了网上看到的方式设置之后并未生效。当然,根本原因还是因为对HttpClient这个组件不熟悉导致的.

问题重现
1.HttpClient版本

<groupId>org.apache.httpcomponents</groupId>
<artifactId>httpclient</artifactId>
<version>4.5.2</version>

2.Java代码

public class HttpClientTest {

private AtomicInteger counter = new AtomicInteger(0);
private String url = "http://www.baidu.com/";

public static void main(String[] args) {
    new HttpClientTest().test();
}

// 执行测试
private void test() {
    int number = 100000; // 总请求数
    int concurrent = 50; // 每次并发请求数
    CountDownLatch countDownLatch = new CountDownLatch(number); // 计数器
    ExecutorService threadPool = Executors.newFixedThreadPool(concurrent); // 线程池
    int concurrentPer = concurrent;
    boolean over = false;
    while(!over) {
        number = number - concurrent;
        if(number <= 0) {
            concurrentPer = number + concurrent;
            over = true;
        }

        // 线程池批量提交
        for(int i = 0; i < concurrentPer; i++) {
            threadPool.execute(new Runnable() {
                @Override
                public void run() {
                    try {
                        request(url);
                        Thread.sleep(100);
                    } catch (IOException | InterruptedException e) {
                        e.printStackTrace();
                    } finally {
                        countDownLatch.countDown();
                    }
                }
            });
        }
    }
    try {
        countDownLatch.await();
        threadPool.shutdown();
    } catch (InterruptedException e) {
        e.printStackTrace();
    }
}

// 访问指定地址
private void request(String url) throws IOException {
    HttpGet httpGet = new HttpGet(url);
    commnicate(httpGet);
}

// 负责底层通信处理
private void commnicate(HttpRequestBase request) throws IOException {
    ResponseHandler<String> responseHandler = new ResponseHandler<String>() {
        @Override
        public String handleResponse(HttpResponse response) throws ClientProtocolException, IOException {
            return EntityUtils.toString(response.getEntity());
        }
    };

    HttpClient client = HttpClients.createDefault();
    String body = client.execute(request, responseHandler); // 线程可能会在这里被阻塞
    System.out.println(String.format("body size: %s, counter: %s", body.length(), counter.incrementAndGet()));
}

}
运行上述代码一段时间后很容易可以重现出问题,如下为运行控制台信息:
HttpClient重现报错

并且线程全部夯住,进程无法正常结束.

查看端口状态存在大量请求处于建立连接状态(ESTABLISHED):

netstat -anpt

tcp 0 0 172.17.7.81:56408 180.118.128.179:56033 ESTABLISHED 3766/java
tcp 0 0 172.17.7.81:57644 115.202.238.177:27016 ESTABLISHED 3847/java
tcp 0 0 172.17.7.81:36616 117.57.21.0:25719 ESTABLISHED 3766/java
tcp 0 0 172.17.7.81:59944 112.245.197.118:57220 ESTABLISHED 3847/java
tcp 0 0 172.17.7.81:48722 218.5.215.10:40835 ESTABLISHED 4007/java
tcp 0 0 172.17.7.81:52734 115.194.17.14:45210 ESTABLISHED 4007/java
tcp 0 0 172.17.7.81:60586 59.32.37.129:16637 ESTABLISHED 3686/java
tcp 0 0 172.17.7.81:36776 222.89.86.109:21667 ESTABLISHED 3766/java
tcp 0 0 172.17.7.81:51690 60.161.249.162:59039 ESTABLISHED 3927/java
tcp 0 0 172.17.7.81:42226 58.218.200.59:80 TIME_WAIT -
tcp 0 0 172.17.7.81:56566 117.70.47.194:40879 ESTABLISHED 3686/java
tcp 0 0 172.17.7.81:43266 182.120.202.204:45893 ESTABLISHED 3766/java
tcp 0 0 172.17.7.81:55630 60.169.223.16:21280 ESTABLISHED 3927/java
tcp 0 0 172.17.7.81:54922 60.168.81.26:25464 ESTABLISHED 3927/java
tcp 0 0 172.17.7.81:53352 112.252.97.83:53584 ESTABLISHED 3847/java
tcp 0 0 172.17.7.81:52684 113.121.242.43:14447 ESTABLISHED 3927/java
tcp 0 0 172.17.7.81:54750 113.121.241.168:45173 ESTABLISHED 3686/java
tcp 0 0 172.17.7.81:41510 113.105.202.106:47288 ESTABLISHED 4007/java
tcp 0 0 172.17.7.81:38804 121.232.148.62:57938 ESTABLISHED 3847/java
tcp 0 0 172.17.7.81:41468 113.105.202.106:47288 ESTABLISHED 3927/java
tcp 0 0 172.17.7.81:45444 123.163.81.185:22012 ESTABLISHED 3766/java
tcp 0 0 172.17.7.81:54810 113.121.241.168:45173 ESTABLISHED 4007/java
tcp 0 0 172.17.7.81:51542 175.153.23.147:20766 ESTABLISHED 3927/java
tcp 0 0 172.17.7.81:45644 218.5.215.10:40835 ESTABLISHED 4007/java
tcp 0 0 172.17.7.81:35730 116.53.197.198:30042 ESTABLISHED 3766/java
tcp 0 0 172.17.7.81:54738 113.121.241.168:45173 ESTABLISHED 3686/java
tcp 0 0 172.17.7.81:60600 59.32.37.129:16637 ESTABLISHED 3686/java
tcp 0 0 172.17.7.81:54862 113.121.241.168:45173 ESTABLISHED 4007/java
tcp 0 0 172.17.7.81:40980 115.225.153.215:17292 ESTABLISHED 3686/java
tcp 0 0 172.17.7.81:54166 123.149.162.129:18269 ESTABLISHED 3766/java
tcp 0 0 172.17.7.81:60712 120.35.190.184:33054 ESTABLISHED 3766/java
tcp 0 0 172.17.7.81:55802 106.42.211.65:59547 ESTABLISHED 3766/java
同时,分析线程堆栈信息(jstack -F -l pid > thread_stack.log)可以看到如下信息:

"pool-1-thread-45" #55 prio=5 os_prio=0 tid=0x00007f78702df000 nid=0x33d5 runnable [0x00007f7830c1d000]
java.lang.Thread.State: RUNNABLE

at java.net.SocketInputStream.socketRead0(Native Method)
at java.net.SocketInputStream.socketRead(SocketInputStream.java:116)
at java.net.SocketInputStream.read(SocketInputStream.java:171)
at java.net.SocketInputStream.read(SocketInputStream.java:141)
at org.apache.http.impl.io.SessionInputBufferImpl.streamRead(SessionInputBufferImpl.java:139)
at org.apache.http.impl.io.SessionInputBufferImpl.fillBuffer(SessionInputBufferImpl.java:155)
at org.apache.http.impl.io.SessionInputBufferImpl.readLine(SessionInputBufferImpl.java:284)
at org.apache.http.impl.conn.DefaultHttpResponseParser.parseHead(DefaultHttpResponseParser.java:140)
at org.apache.http.impl.conn.DefaultHttpResponseParser.parseHead(DefaultHttpResponseParser.java:57)
at org.apache.http.impl.io.AbstractMessageParser.parse(AbstractMessageParser.java:261)
at org.apache.http.impl.DefaultBHttpClientConnection.receiveResponseHeader(DefaultBHttpClientConnection.java:165)
at org.apache.http.impl.conn.CPoolProxy.receiveResponseHeader(CPoolProxy.java:167)
at org.apache.http.protocol.HttpRequestExecutor.doReceiveResponse(HttpRequestExecutor.java:272)
at org.apache.http.protocol.HttpRequestExecutor.execute(HttpRequestExecutor.java:124)
at org.apache.http.impl.execchain.MainClientExec.execute(MainClientExec.java:271)
at org.apache.http.impl.execchain.ProtocolExec.execute(ProtocolExec.java:184)
at org.apache.http.impl.execchain.RetryExec.execute(RetryExec.java:88)
at org.apache.http.impl.execchain.RedirectExec.execute(RedirectExec.java:110)
at org.apache.http.impl.client.InternalHttpClient.doExecute(InternalHttpClient.java:184)
at org.apache.http.impl.client.CloseableHttpClient.execute(CloseableHttpClient.java:71)
at org.apache.http.impl.client.CloseableHttpClient.execute(CloseableHttpClient.java:220)
at org.apache.http.impl.client.CloseableHttpClient.execute(CloseableHttpClient.java:164)
at org.apache.http.impl.client.CloseableHttpClient.execute(CloseableHttpClient.java:139)
at org.chench.extra.HttpClientTest.commnicate(HttpClientTest.java:106) # 线程在这里阻塞
at org.chench.extra.HttpClientTest.request(HttpClientTest.java:93)
at org.chench.extra.HttpClientTest.access$100(HttpClientTest.java:31)
at org.chench.extra.HttpClientTest$1.run(HttpClientTest.java:62)
at java.util.concurrent.ThreadPoolExecutor.runWorker(ThreadPoolExecutor.java:1149)
at java.util.concurrent.ThreadPoolExecutor$Worker.run(ThreadPoolExecutor.java:624)
at java.lang.Thread.run(Thread.java:748)

Locked ownable synchronizers:

- <0x0000000086d50638> (a java.util.concurrent.ThreadPoolExecutor$Worker)

从堆栈日志中可以看到,线程处于RUNNABLE状态,并且阻塞在at org.chench.extra.HttpClientTest.commnicate(HttpClientTest.java:106)处.

解决方案
通过线程堆栈日志分析可以定位到线程夯住是因为HttpClient在执行访问时被阻塞了,结合源代码找到阻塞原因是因为未设置请求超时时间.

上述问题本质上是因为HttpClient组件并未设置请求超时控制导致的:虽然连接超时,但是读取失败,导致线程一直被阻塞.
那么,应该如何设置HttpClient的超时时间呢?鉴于HttpClient的官方文档没有明确说明,并且不同版本的HttpClient组件设置超时控制的方式不一致,所以建议直接查看源码.
HttpClient执行访问请求时序图如下:
HttpClient访问请求时序图

顺藤摸瓜,在MainClientExec.java的execute()方法中看到有2处使用了timeout参数,其含义各不相同:
(1)在获取HttpClientConnection对象时需要读取配置参数中的ConnectionRequestTimeout值,该参数用于控制获取连接的超时时间.
timeout参数
(2)获取到HttpClientConnection对象之后读取配置参数中的SocketTimeout值,设置Socket超时时间.
设置Socket超时
显然,这2个timeout参数都需要从RequestConfig对象中获取.
既然找到了使用timeout参数的地方,下一步需要确定该参数是如何设置的.沿着HttpClient的请求时序图路径往回查找,在InternalHttpClient.java类的doExecute()方法中可以很清晰地看到设置了RequestConfig对象参数.

@Override

protected CloseableHttpResponse doExecute(
        final HttpHost target,
        final HttpRequest request,
        final HttpContext context) throws IOException, ClientProtocolException {
    Args.notNull(request, "HTTP request");
    HttpExecutionAware execAware = null;
    if (request instanceof HttpExecutionAware) {
        execAware = (HttpExecutionAware) request;
    }
    try {
        final HttpRequestWrapper wrapper = HttpRequestWrapper.wrap(request, target);
        final HttpClientContext localcontext = HttpClientContext.adapt(
                context != null ? context : new BasicHttpContext());
        // 通过RequestConfig对象配置连接参数
        RequestConfig config = null;
        if (request instanceof Configurable) {
            // 如果在HttpRequest对象中设置了RequestConfig属性,直接使用
            config = ((Configurable) request).getConfig();
        }
        if (config == null) {
            // 如果在HttpRequest对象中未设置RequestConfig对象属性,则获取HttpParams属性构造RequestConfig对象
            final HttpParams params = request.getParams();
            if (params instanceof HttpParamsNames) {
                if (!((HttpParamsNames) params).getNames().isEmpty()) {
                    config = HttpClientParamConfig.getRequestConfig(params);
                }
            } else {
                config = HttpClientParamConfig.getRequestConfig(params);
            }
        }
        if (config != null) {
            // 使用RequestConfig对象配置连接参数
            localcontext.setRequestConfig(config);
        }
        setupContext(localcontext);
        final HttpRoute route = determineRoute(target, wrapper, localcontext);
        return this.execChain.execute(route, wrapper, localcontext, execAware);
    } catch (final HttpException httpException) {
        throw new ClientProtocolException(httpException);
    }
}

(3)HttpClient默认使用的连接池为PoolingHttpClientConnectionManager,在建立连接时(connect()方法)会使用其中的SocketConfig配置参数对Socket进行配置,如下所示:

PoolingHttpClientConnectionManager.java
@Override
public void connect(

    final HttpClientConnection managedConn,
    final HttpRoute route,
    final int connectTimeout,
    final HttpContext context) throws IOException {
Args.notNull(managedConn, "Managed Connection");
Args.notNull(route, "HTTP route");
final ManagedHttpClientConnection conn;
synchronized (managedConn) {
    final CPoolEntry entry = CPoolProxy.getPoolEntry(managedConn);
    conn = entry.getConnection();
}
final HttpHost host;
if (route.getProxyHost() != null) {
    host = route.getProxyHost();
} else {
    host = route.getTargetHost();
}
final InetSocketAddress localAddress = route.getLocalSocketAddress();
SocketConfig socketConfig = this.configData.getSocketConfig(host);
if (socketConfig == null) {
    // 使用配置参数SocketConfig
    socketConfig = this.configData.getDefaultSocketConfig();
}
if (socketConfig == null) {
    socketConfig = SocketConfig.DEFAULT;
}
this.connectionOperator.connect(
        conn, host, localAddress, connectTimeout, socketConfig, context);

}
DefaultHttpClientConnectionOperator.java
@Override

public void connect(
        final ManagedHttpClientConnection conn,
        final HttpHost host,
        final InetSocketAddress localAddress,
        final int connectTimeout,
        final SocketConfig socketConfig,
        final HttpContext context) throws IOException {
    final Lookup<ConnectionSocketFactory> registry = getSocketFactoryRegistry(context);
    final ConnectionSocketFactory sf = registry.lookup(host.getSchemeName());
    if (sf == null) {
        throw new UnsupportedSchemeException(host.getSchemeName() +
                " protocol is not supported");
    }
    final InetAddress[] addresses = host.getAddress() != null ?
            new InetAddress[] { host.getAddress() } : this.dnsResolver.resolve(host.getHostName());
    final int port = this.schemePortResolver.resolve(host);
    for (int i = 0; i < addresses.length; i++) {
        final InetAddress address = addresses[i];
        final boolean last = i == addresses.length - 1;

        Socket sock = sf.createSocket(context);
        // 使用socketConfig参数中的超时时间对Socket进行配置
        sock.setSoTimeout(socketConfig.getSoTimeout());
        sock.setReuseAddress(socketConfig.isSoReuseAddress());
        sock.setTcpNoDelay(socketConfig.isTcpNoDelay());
        sock.setKeepAlive(socketConfig.isSoKeepAlive());
        if (socketConfig.getRcvBufSize() > 0) {
            sock.setReceiveBufferSize(socketConfig.getRcvBufSize());
        }
        if (socketConfig.getSndBufSize() > 0) {
            sock.setSendBufferSize(socketConfig.getSndBufSize());
        }

        final int linger = socketConfig.getSoLinger();
        if (linger >= 0) {
            sock.setSoLinger(true, linger);
        }
        conn.bind(sock);

        // ...
    }
}

经过源码解读可以很明确地知道,在HttpClient 4.5.2版本中,设置连接参数有3种方式:
(1)在HttpRequest对象中设置RequestConfig对象属性
(2)在HttpRequest对象中设置HttpParams对象属性.
(3)在连接池对象中设置SocketConfig对象属性

既然找到了根源,下面分别通过这3种方式设置超时参数进行验证.
方式1: 通过RequestConfig对象设置超时参数

int timeOut = 5000;
RequestConfig requestConfig = RequestConfig.custom()

    .setConnectionRequestTimeout(timeOut) // 获取连接超时时间
    .setConnectTimeout(timeOut) // 设置HTTP连接超时时间
    .setSocketTimeout(timeOut) // 设置Socket超时时间
    .build();

request.setConfig(requestConfig);
方式2: 通过HttpParams对象设置超时参数

int timeOut = 5000;
HttpParams params = new BasicHttpParams();
params.setParameter(CoreConnectionPNames.SO_TIMEOUT, timeOut); // 设置Socket超时时间
params.setParameter(CoreConnectionPNames.CONNECTION_TIMEOUT, timeOut); // 设置HTTP连接超时时间
request.setParams(params);
方式3: 通过连接池对象设置超时参数

int timeOut = 5000;
PoolingHttpClientConnectionManager connManager = new PoolingHttpClientConnectionManager();
// 对连接池设置SocketConfig对象
connManager.setDefaultSocketConfig(SocketConfig.custom().setSoTimeout(timeOut).build());
client = HttpClients.custom().setConnectionManager(connManager).build();
通过上述3种方式分别设置超时参数验证,虽然在运行过程中会有报错,但是不会导致线程被阻塞,进程能正常运行结束:
有报错但是不会出现线程夯住

解决问题之后客户端CPU使用率恢复正常:
CPU使用率基本稳定

总结/教训/反思
之所以会遇到这样的问题，还是因为对HttpClient组件不熟悉导致的；另外，在发现问题之后如何快速定位问题，并搜索稳定的解决方案很重要。
HttpClient组件每个版本的API变化都比较大，在使用时一定要彻底清楚当前使用的版本是如何设置超时时间的。而如何确定知道超时时间控制，通过源代码查看最为妥当.
在Java平台使用Http客户端组件，可以有多个选择：
(1)直接使用JDK提供的URL类访问
(2)使用HttpClient组件，有坑，不同版本设置参数的方式变动较大，最好是阅读一下当前使用版本的源码实现，正确设置好超时时间等参数
(3)如果使用了Spring MVC框架，还可以使用Spring MVC提供的RestTemplate组件，底层是使用Netty实现的客户端

遇到的这个坑本身并不属于技术难点,但是面对这个问题的解决思路值得总结:
(1)程序日志，运行日志非常关键,是定位问题时第一时间需要查看的
(2)代码review，逐行逐行地审查,首先排除可能存在的代码逻辑问题,比如:死锁等
(3)通过jstack命令查看线程堆栈信息: jstack -l -F > stack.log
(4)通过jmap命令查看内存堆栈信息: jmap -dump:live format=b,file=heap.bin
(5)如果结合搜索引擎和上述排查步骤依然未能解决问题,应该第一时间考虑直接阅读组件的源代码实现,特别是使用了开源组件时这可能才是真正解决问题的最佳路径

【参考】
https://blog.csdn.net/u011191463/article/details/78664896 HttpClient超时设置详解
https://my.oschina.net/jywm/blog/1834702 解决httpclient超时设置不生效的问题
https://www.jianshu.com/p/4b3e172c4f2d HttpClient 4.5.2-（四）连接超时的配置
https://www.jianshu.com/p/6a41c95855e3 HttpClient 4.5.2-（五）连接池的配置
https://www.jianshu.com/p/c852cbcf3d68 HttpClient高并发下性能优化-http连接池
https://blog.csdn.net/u011402596/article/details/44619443 HttpClient 多线程处理
https://field-notes.iteye.com/blog/2383759 多线程消费使用HttpClient引发的坑
http://blog.51cto.com/lihao001/1788490 httpclient4.3 导致线程阻塞
https://study121007.iteye.com/blog/2304274 HttpClient4.5.2 连接管理
https://www.jianshu.com/p/c852cbcf3d68 HttpClient高并发下性能优化-http连接池
https://alafqq.iteye.com/blog/2325041 httpclient 多线程执行（网上版本太多了。。。误人子弟）
https://gaozzsoft.iteye.com/blog/2352241 HttpClient 4.5.2版本设置连接超时时间-CloseableHttpClient设置Timeout
https://www.cnblogs.com/softidea/p/6964347.html HttpClient 专题

https://blog.csdn.net/u010634066/article/details/83120122 一场HttpClient调用未关闭流引发的问题
https://www.cnblogs.com/mumuxinfei/p/5066633.html Apache HttpClient使用之阻塞陷阱
https://issues.apache.org/jira/browse/HTTPCLIENT-1584 CloseableHttpClient - SSL Handshake has no Socket Timeout
https://monkeyissexy.github.io/2016/11/11/httpclient_ssl_handshake_socketTimeout_bug/ httpclient ssl handshake socketTimeout bug 分析解决过程
http://geekerwang.com/2017/10/22/%E8%AE%B0%E5%BD%95%E4%B8%80%E6%AC%A1%E5%9D%91%EF%BC%9AsocketRead-hang/ 记录一次坑：socketRead hang
https://www.cnblogs.com/jessezeng/p/7448636.html 解决: httpclient ssl 验证导致死锁问题

作者：2Simple
出处：http://www.cnblogs.com/nuccch/

HttpClient在多线程环境下踩坑总结

netstat -anpt

热门文章

最新文章

相关电子书

相关实验场景

热门

活动广场

任务中心

开发者评测

高校计划

乘风者计划

训练营

阿里云MVP

话题

直播

下载

镜像站

技术资料

插件

HttpClient在多线程环境下踩坑总结

netstat -anpt

热门文章

最新文章

相关电子书

相关实验场景
