Struts2--Helloworld

简介:

搭建Struts2环境时,我们一般需要做以下几个步骤的工作:

1、找到开发Struts2应用需要使用到的jar文件.
2、创建Web工程
3、在web.xml中加入Struts2 MVC框架启动配置
4、编写Struts2的配置文件

开发Struts2应用依赖的jar文件

大家可以到http://struts.apache.org/download.cgi#struts2014下载struts-2.x.x- all.zip。下载完后解压文件,开发struts2应用需要依赖的jar文件在解压目录的lib文件夹下。不同的应用需要的JAR包是不同的。下面给 出了开发Struts 2程序最少需要的JAR。

struts2-core-2.x.x.jar :Struts 2框架的核心类库

xwork-core-2.x.x.jar :XWork类库,Struts 2在其上构建

ognl-2.6.x.jar :对象图导航语言(Object Graph Navigation Language),struts2框架通过其读写对象的属性

freemarker-2.3.x.jar :Struts 2的UI标签的模板使用FreeMarker编写

commons-logging-1.x.x.jar :ASF出品的日志包,Struts 2框架使用这个日志包来支持Log4J和JDK 1.4+的日志记录。

commons-fileupload-1.2.1.jar :文件上传组件,2.1.6版本后必须加入此文件

以上这些Jar文件拷贝 到Web项目的WEB-INF/lib目录中。

Struts2在web.xml中的启动配置

在struts1.x中, struts框架是通过Servlet启动的。在struts2中,struts框架是通过Filter启动的。在web.xml中的配置如下:

<filter>
    <filter-name>struts2</filter-name>
    <filter-class>org.apache.struts2.dispatcher.ng.filter.StrutsPrepareAndExecuteFilter</filter-class>
</filter>
<filter-mapping>
    <filter-name>struts2</filter-name>
    <url-pattern>/*</url-pattern>
</filter-mapping>

在StrutsPrepareAndExecuteFilter的init()方法中将会读取类路径下默认的配置文件struts.xml完成初始化操作。

注意:struts2读取到struts.xml的内容后,以javabean形式存放在内存中,以后struts2对用户的每次请求处理将使用内存中的数据,而不是每次都读取struts.xml文件

Struts2应用的配置文件

Struts2默认的配置文件为struts.xml ,该文件需要存放在src目录下,该文件的配置模版如下:

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE struts PUBLIC
"-//Apache Software Foundation//DTD Struts Configuration 2.1//EN"
"http://struts.apache.org/dtds/struts-2.1.dtd">
<struts>

</struts>

实战--helloworld

Struts2的每个请求需要实现以下内容:
JSP
Action
struts.xml中Action配置

1、新建项目12.01

2、在默认的配置文件struts.xml 中加入如下配置:

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE struts PUBLIC
    "-//Apache Software Foundation//DTD Struts Configuration 2.3//EN"
    "http://struts.apache.org/dtds/struts-2.3.dtd">
<struts>
    <constant name="struts.devMode" value="true" />
    <package name="Hello_World_Struts2" extends="struts-default">
        <action name="index">
            <result>/index.jsp</result>
        </action>
        <action name="hello" class="com.wuyudong.helloworld.action.HelloWorldAction" method="execute">
            <result name="success">/hello.jsp</result>
        </action>
    </package>
</struts>

在struts2框架中使用包来管理Action,包的作用和java中的类包是非常类似的,它主要用于管理一组业务功能相关的action。在实际应用中,我们应该把一组业务功能相关的Action放在同一个包下。

配置包时必须指定name属性,该name属性值可以任意取名,但必须唯一,他不对应java的类包,如果其他包要继承该包,必须通过该属性进行引 用。包的namespace属性用于定义该包的命名空间,命名空间作为访问该包下Action的路径的一部分,如访问上面例子的Action,访问路径 为:/test/helloworld.action。 namespace属性可以不配置,对本例而言,如果不指定该属性,默认的命名空间为“”(空字符串)。

通常每个包都应该继承struts-default包, 因为Struts2很多核心的功能都是拦截器来实现。如:从请求中把请求参数封装到action、文件上传和数据验证等等都是通过拦截器实现的。 struts-default定义了这些拦截器和Result类型。可以这么说:当包继承了struts-default才能使用struts2提供的核 心功能。 struts-default包是在struts2-core-2.x.x.jar文件中的struts-default.xml中定义。 struts-default.xml也是Struts2默认配置文件。 Struts2每次都会自动加载 struts-default.xml文件。

例子中使用到的com.wuyudong.helloworld.action.HelloWorldAction类如下:

package com.wuyudong.helloworld.action;

import com.opensymphony.xwork2.ActionSupport;
import com.wuyudong.helloworld.model.MessageStore;

public class HelloWorldAction extends ActionSupport {
    private static final long serialVersionUID = -4958566543551999157L;
    private MessageStore msgStore;
    @Override
    public String execute() throws Exception {
        msgStore = new MessageStore("HelloWorld!");
        return SUCCESS;
    }
    public MessageStore getMsgStore() {
        return msgStore;
    }
    public void setMsgStore(MessageStore msgStore) {
        this.msgStore = msgStore;
    }
}

例子中使用到的hello.jsp如下:

<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>
<%@ taglib prefix="s" uri="/struts-tags"%>
<!DOCTYPE html PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN" "http://www.w3.org/TR/html4/loose.dtd">
<html>
<head>
<meta http-equiv="Content-Type" content="text/html; charset=UTF-8">
<title>Hello World!</title>
</head>
<body>
    <h2>
        <s:property value="msgStore.message" />
    </h2>
</body>
</html>

在struts2中,访问struts2中action的URL路径由两部份组 成:包的命名空间+action的名称,例如访问本例子HelloWorldAction的URL路径为:/helloworld (注意:完整路径为:http://localhost:端口/内容路径/helloworld)。另外我们也可以加上.action后缀访问此 Action。

Action名称的搜索顺序

1.获得请求路径的URI,例如url是:http://server/struts2/path1/path2/path3/test.action

2.首先寻找namespace为/path1/path2/path3的package,如果不存在这个package则执行步骤3;如果存在这 个package,则在这个package中寻找名字为test的action,当在该package下寻找不到action 时就会直接跑到默认namaspace的package里面去寻找action(默认的命名空间为空字符串“” ) ,如果在默认namaspace的package里面还寻找不到该action,页面提示找不到action

3.寻找namespace为/path1/path2的package,如果不存在这个package,则转至步骤4;如果存在这个 package,则在这个package中寻找名字为test的action,当在该package中寻找不到action 时就会直接跑到默认namaspace的package里面去找名字为test的action ,在默认namaspace的package里面还寻找不到该action,页面提示找不到action

4.寻找namespace为/path1的package,如果不存在这个package则执行步骤5;如果存在这个package,则在这个 package中寻找名字为test的action,当在该package中寻找不到action 时就会直接跑到默认namaspace的package里面去找名字为test的action ,在默认namaspace的package里面还寻找不到该action,页面提示找不到action

5.寻找namespace为/的package,如果存在这个package,则在这个package中寻找名字为test的action, 当在package中寻找不到action或者不存在这个package时,都会去默认namaspace的package里面寻找action,如果还 是找不到,页面提示找不到action。

Action配置中的各项默认值

创建 Model类MessageStore

package com.wuyudong.helloworld.model;

public class MessageStore {
    private String message;
    public MessageStore(String msg){
        this.setMessage(msg);
    }
    public String getMessage() {
        return message;
    }
    public void setMessage(String message) {
        this.message = message;
    }
}

创建Action类HelloWorldAction,充当Controller

package com.wuyudong.helloworld.action;

import com.opensymphony.xwork2.ActionSupport;
import com.wuyudong.helloworld.model.MessageStore;

public class HelloWorldAction extends ActionSupport {
    private static final long serialVersionUID = -4958566543551999157L;
    private MessageStore msgStore;
    @Override
    public String execute() throws Exception {
        msgStore = new MessageStore("HelloWorld!");
        return SUCCESS;
    }
    public MessageStore getMsgStore() {
        return msgStore;
    }
    public void setMsgStore(MessageStore msgStore) {
        this.msgStore = msgStore;
    }
}

配置web.xml

<?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns="http://java.sun.com/xml/ns/javaee" xmlns:web="http://java.sun.com/xml/ns/javaee/web-app_2_5.xsd" xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd" id="WebApp_ID" version="3.0">
  <display-name>12.01</display-name>
   <welcome-file-list>
    <welcome-file>index.jsp</welcome-file>
  </welcome-file-list>

    <filter>
      <filter-name>struts2</filter-name>
      <filter-class>
         org.apache.struts2.dispatcher.ng.filter.StrutsPrepareAndExecuteFilter
         </filter-class>
    </filter>

    <filter-mapping>
      <filter-name>struts2</filter-name>
       <url-pattern>/*</url-pattern>
    </filter-mapping>
</web-app>

运行后如图所示
