淘东电商项目（24） -获取验证码功能

/**
 * description: 图形验证码工具类
 * create by: YangLinWei
 * create time: 2020/3/6 4:18 下午
 */
public class RandomValidateCodeUtil {
  public static final String RANDOMCODEKEY = "RANDOMVALIDATECODEKEY";// 放到session中的key
  private String randString = "0123456789";// 随机产生只有数字的字符串 private String
  // private String randString = "ABCDEFGHIJKLMNOPQRSTUVWXYZ";//随机产生只有字母的字符串
  // private String randString =
  // "0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZ";//随机产生数字与字母组合的字符串
  private int width = 95;// 图片宽
  private int height = 25;// 图片高
  private int lineSize = 40;// 干扰线数量
  private int stringNum = 4;// 随机产生字符数量
  private static final Logger logger = LoggerFactory.getLogger(RandomValidateCodeUtil.class);
  private Random random = new Random();
  /**
   * 获得字体
   */
  private Font getFont() {
    return new Font("Fixedsys", Font.CENTER_BASELINE, 18);
  }
  /**
   * 获得颜色
   */
  private Color getRandColor(int fc, int bc) {
    if (fc > 255)
      fc = 255;
    if (bc > 255)
      bc = 255;
    int r = fc + random.nextInt(bc - fc - 16);
    int g = fc + random.nextInt(bc - fc - 14);
    int b = fc + random.nextInt(bc - fc - 18);
    return new Color(r, g, b);
  }
  /**
   * 生成随机图片
   */
  public void getRandcode(HttpServletRequest request, HttpServletResponse response) {
    HttpSession session = request.getSession();
    // BufferedImage类是具有缓冲区的Image类,Image类是用于描述图像信息的类
    BufferedImage image = new BufferedImage(width, height, BufferedImage.TYPE_INT_BGR);
    Graphics g = image.getGraphics();// 产生Image对象的Graphics对象,改对象可以在图像上进行各种绘制操作
    g.fillRect(0, 0, width, height);// 图片大小
    g.setFont(new Font("Times New Roman", Font.ROMAN_BASELINE, 18));// 字体大小
    g.setColor(getRandColor(110, 133));// 字体颜色
    // 绘制干扰线
    for (int i = 0; i <= lineSize; i++) {
      drowLine(g);
    }
    // 绘制随机字符
    String randomString = "";
    for (int i = 1; i <= stringNum; i++) {
      randomString = drowString(g, randomString, i);
    }
    logger.info(randomString);
    // 将生成的随机字符串保存到session中
    session.removeAttribute(RANDOMCODEKEY);
    session.setAttribute(RANDOMCODEKEY, randomString);
    g.dispose();
    try {
      // 将内存中的图片通过流动形式输出到客户端
      ImageIO.write(image, "JPEG", response.getOutputStream());
    } catch (Exception e) {
      logger.error("将内存中的图片通过流动形式输出到客户端失败>>>>   ", e);
    }
  }
  /**
   * 绘制字符串
   */
  private String drowString(Graphics g, String randomString, int i) {
    g.setFont(getFont());
    g.setColor(new Color(random.nextInt(101), random.nextInt(111), random.nextInt(121)));
    String rand = String.valueOf(getRandomString(random.nextInt(randString.length())));
    randomString += rand;
    g.translate(random.nextInt(3), random.nextInt(3));
    g.drawString(rand, 13 * i, 16);
    return randomString;
  }
  /**
   * 绘制干扰线
   */
  private void drowLine(Graphics g) {
    int x = random.nextInt(width);
    int y = random.nextInt(height);
    int xl = random.nextInt(13);
    int yl = random.nextInt(15);
    g.drawLine(x, y, x + xl, y + yl);
  }
  /**
   * 获取随机的字符
   */
  public String getRandomString(int num) {
    return String.valueOf(randString.charAt(num));
  }
  public static Boolean checkVerify(String verifiCode, HttpSession httpSession) {
    if (StringUtils.isEmpty(verifiCode)) {
      return false;
    }
    String random = (String) httpSession.getAttribute("RANDOMVALIDATECODEKEY");
    if (StringUtils.isEmpty(random)) {
      return false;
    }
    if (!random.equals(verifiCode)) {
      return false;
    }
    return true;
  }
}

@Controller
public class VerifyController {
  /**
   * 生成验证码
   */
  @RequestMapping(value = "/getVerify")
  public void getVerify(HttpServletRequest request, HttpServletResponse response) {
    try {
      response.setContentType("image/jpeg");// 设置相应类型,告诉浏览器输出的内容为图片
      response.setHeader("Pragma", "No-cache");// 设置响应头信息，告诉浏览器不要缓存此内容
      response.setHeader("Cache-Control", "no-cache");
      response.setDateHeader("Expire", 0);
      RandomValidateCodeUtil randomValidateCode = new RandomValidateCodeUtil();
      randomValidateCode.getRandcode(request, response);// 输出验证码图片方法
    } catch (Exception e) {
    }
  }
}

@SpringBootApplication(exclude = {DataSourceAutoConfiguration.class,
        DataSourceTransactionManagerAutoConfiguration.class, HibernateJpaAutoConfiguration.class})
public class AppPortalWeb {
    public static void main(String[] args) {
        SpringApplication.run(AppPortalWeb.class, args);
    }
}

<div class="layui-input-block getCode" style="margin-top: 12px;">
    <input type="text" name="graphicCode"
           value="${(registerVo.graphicCode)!''}" placeholder="请输入验证码" class="layui-input">
    <img alt="" src="getVerify" onclick="getVerify(this);"
         style="border: 1px solid #e2e2e2; font-size: 18px; height: 46px; margin-top: -69px; width: 44%; background-color: #e8d6c0; margin-left: 167px;">
</div>

<script>
   //获取验证码
   function getVerify(obj) {
       obj.src = "getVerify?" + Math.random();
   }
</script>
