CentOS7下利用cobbler部署CentOS

简介:

1)安装epel源和cobbler

1
2
3
4
5
6
7
8
9
10
[root@cobbler ~] # yum -y install http://mirrors.163.com/centos/7/extras/x86_64/Packages/epel-release-7-9.noarch.rpm
[root@cobbler ~] # yum install cobbler cobbler-web dhcp tftp-server pykickstart httpd xinetd -y
[root@cobbler ~] # systemctl start xinetd.service
[root@cobbler ~] # systemctl enable xinetd.service
[root@cobbler ~] # systemctl start httpd
[root@cobbler ~] # systemctl enable httpd
Created  symlink  from  /etc/systemd/system/multi-user .target.wants /httpd .service to  /usr/lib/systemd/system/httpd .service.
[root@cobbler ~] # systemctl start cobblerd.service
[root@cobbler ~] # systemctl enable cobblerd.service
Created  symlink  from  /etc/systemd/system/multi-user .target.wants /cobblerd .service to  /usr/lib/systemd/system/cobblerd .service.

2)配置cobbler

1
2
3
4
5
6
7
8
9
10
11
12
检查cobbler:
[root@cobbler ~] # cobbler check
The following are potential configuration items that you may want to fix:
1 : The  'server'  field  in  /etc/cobbler/settings  must be  set  to something other than localhost, or kickstarting features will not work.  This should be a resolvable  hostname  or IP  for  the boot server as reachable by all machines that will use it.
2 : For PXE to be functional, the  'next_server'  field  in  /etc/cobbler/settings  must be  set  to something other than 127.0.0.1, and should match the IP of the boot server on the PXE network.
3 : change  'disable'  to  'no'  in  /etc/xinetd .d /tftp
4 : some network boot-loaders are missing from  /var/lib/cobbler/loaders , you may run  'cobbler get-loaders'  to download them, or,  if  you only want to handle x86 /x86_64  netbooting, you may ensure that you have installed a *recent* version of the syslinux package installed and can ignore this message entirely.  Files  in  this directory, should you want to support all architectures, should include pxelinux.0, menu.c32, elilo.efi, and yaboot. The  'cobbler get-loaders'  command  is the easiest way to resolve these requirements.
5 :  enable  and start rsyncd.service with systemctl
6 : debmirror package is not installed, it will be required to manage debian deployments and repositories
7 : The default password used by the sample templates  for  newly installed machines (default_password_crypted  in  /etc/cobbler/settings ) is still  set  to  'cobbler'  and should be changed, try:  "openssl passwd -1 -salt 'random-phrase-here' 'your-password-here'"  to generate new one
8 : fencing tools were not found, and are required to use the (optional) power management features.  install  cman or fence-agents to use them
Restart cobblerd and  then  run  'cobbler sync'  to apply changes.

修改cobbler的配置文件:

1
2
3
4
5
6
7
[root@cobbler ~] # vim /etc/cobbler/settings
# if you do not set this correctly, this will be manifested in TFTP open timeouts.
将“next_server: 127.0.0.1”修改为“next_server: 10.10.10.222”
将“server: 127.0.0.1”修改为“server: 10.10.10.222”
# set to 1 to enable Cobbler's DHCP management features.
# the choice of DHCP management engine is in /etc/cobbler/modules.conf
将“manage_dhcp: 0”修改为“manage_dhcp: 1”

修改cobbler默认的密码:

1
2
3
4
5
6
将“default_password_crypted:  "$1$mF86/UHC$WvcIcX2t6crBz2onWxyac." ”修改为“default_password_crypted:  "$1$wanwan$K9lP0CajD0pbFaxI0if84/"
随机生成一个密码:
[root@cobbler ~] # openssl passwd -1 -salt 'wanwan' 'redhat12345'
$1$wanwan$K9lP0CajD0pbFaxI0if84/
[root@cobbler ~] # vim /etc/xinetd.d/tftp
将“disable                 =  yes ”修改为“disable                 = no”

重启rsync服务:

1
2
3
[root@cobbler ~] # systemctl start rsyncd.service
[root@cobbler ~] # systemctl enable rsyncd.service
Created  symlink  from  /etc/systemd/system/multi-user .target.wants /rsyncd .service to  /usr/lib/systemd/system/rsyncd .service.

下载cobbler相关的包:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
[root@cobbler ~] # cobbler get-loaders
task started: 2017-03-20_110931_get_loaders
task started ( id =Download Bootloader Content,  time =Mon Mar 20 11:09:31 2017)
downloading https: //cobbler .github.io /loaders/README  to  /var/lib/cobbler/loaders/README
downloading https: //cobbler .github.io /loaders/COPYING .elilo to  /var/lib/cobbler/loaders/COPYING .elilo
downloading https: //cobbler .github.io /loaders/COPYING .yaboot to  /var/lib/cobbler/loaders/COPYING .yaboot
downloading https: //cobbler .github.io /loaders/COPYING .syslinux to  /var/lib/cobbler/loaders/COPYING .syslinux
downloading https: //cobbler .github.io /loaders/elilo-3 .8-ia64.efi to  /var/lib/cobbler/loaders/elilo-ia64 .efi
downloading https: //cobbler .github.io /loaders/yaboot-1 .3.17 to  /var/lib/cobbler/loaders/yaboot
downloading https: //cobbler .github.io /loaders/pxelinux .0-3.86 to  /var/lib/cobbler/loaders/pxelinux .0
downloading https: //cobbler .github.io /loaders/menu .c32-3.86 to  /var/lib/cobbler/loaders/menu .c32
downloading https: //cobbler .github.io /loaders/grub-0 .97-x86.efi to  /var/lib/cobbler/loaders/grub-x86 .efi
downloading https: //cobbler .github.io /loaders/grub-0 .97-x86_64.efi to  /var/lib/cobbler/loaders/grub-x86_64 .efi
*** TASK COMPLETE ***
[root@cobbler ~] # systemctl restart cobblerd.service
[root@cobbler ~] # cobbler check
The following are potential configuration items that you may want to fix:
1 : debmirror package is not installed, it will be required to manage debian deployments and repositories
2 : fencing tools were not found, and are required to use the (optional) power management features.  install  cman or fence-agents to use them
[root@cobbler ~] # cd /etc/cobbler/
[root@cobbler cobbler] # ls
auth.conf       dhcp.template           ldap            power           rsync .template       users .conf     zone_templates
cheetah_macros  dnsmasq.template        modules.conf    pxe            secondary.template   users .digest
cobbler_bash    import_rsync_whitelist  mongodb.conf    reporting      settings            version
completions     iso                     named.template   rsync .exclude  tftpd.template      zone.template

3)配置服务

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
[root@cobbler cobbler] # vim dhcp.template
subnet 10.10.10.0 netmask 255.255.255.0 {
      option routers             10.10.10.2;
      option domain-name-servers 10.10.10.2;
      option subnet-mask         255.255.255.0;
      range dynamic-bootp        10.10.10.100 10.10.10.200;
      default-lease- time          21600;
      max-lease- time              43200;
      next-server                $next_server;
      class  "pxeclients"  {
           match  if  substring (option vendor-class-identifier, 0, 9) =  "PXEClient" ;
           if  option pxe-system- type  = 00:02 {
                   filename  "ia64/elilo.efi" ;
           else  if  option pxe-system- type  = 00:06 {
                   filename  "grub/grub-x86.efi" ;
           else  if  option pxe-system- type  = 00:07 {
                   filename  "grub/grub-x86_64.efi" ;
           else  {
                   filename  "pxelinux.0" ;
           }
      }
}
备注:主要修改网段、DNS、网关等信息
[root@cobbler cobbler] # cobbler sync
通过cobbler管理的dhcp的配置文件
[root@cobbler cobbler] # egrep -v '^#|^$' /etc/dhcp/dhcpd.conf
ddns-update-style interim;
allow booting;
allow bootp;
ignore client-updates;
set  vendorclass = option vendor-class-identifier;
option pxe-system- type  code 93 = unsigned integer 16;
subnet 10.10.10.0 netmask 255.255.255.0 {
      option routers             10.10.10.2;
      option domain-name-servers 10.10.10.2;
      option subnet-mask         255.255.255.0;
      range dynamic-bootp        10.10.10.100 10.10.10.200;
      default-lease- time          21600;
      max-lease- time              43200;
      next-server                10.10.10.222;
      class  "pxeclients"  {
           match  if  substring (option vendor-class-identifier, 0, 9) =  "PXEClient" ;
           if  option pxe-system- type  = 00:02 {
                   filename  "ia64/elilo.efi" ;
           else  if  option pxe-system- type  = 00:06 {
                   filename  "grub/grub-x86.efi" ;
           else  if  option pxe-system- type  = 00:07 {
                   filename  "grub/grub-x86_64.efi" ;
           else  {
                   filename  "pxelinux.0" ;
           }
      }
}
group {
}

挂载并导入数据:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
[root@cobbler ~] # mount /dev/cdrom /mnt
mount /dev/sr0  is write-protected, mounting  read -only
[root@cobbler ~] # df -h
Filesystem           Size  Used Avail Use% Mounted on
/dev/mapper/cl-root    50G  9.8G   41G  20% /
devtmpfs             1.9G     0  1.9G   0%  /dev
tmpfs                1.9G  144K  1.9G   1%  /dev/shm
tmpfs                1.9G  9.0M  1.9G   1%  /run
tmpfs                1.9G     0  1.9G   0%  /sys/fs/cgroup
/dev/mapper/cl-home    46G   36M   46G   1%  /home
/dev/sda1            1014M  175M  840M  18%  /boot
tmpfs                378M   12K  378M   1%  /run/user/0
/dev/sr0              4.1G  4.1G     0 100%  /mnt
[root@cobbler ~] # cobbler import --path=/mnt --name=CentOS-7.3 --arch=x86_64
task started: 2017-03-20_113200_import
task started ( id =Media  import time =Mon Mar 20 11:32:00 2017)
Found a candidate signature: breed=redhat, version=rhel6
Found a candidate signature: breed=redhat, version=rhel7
Found a matching signature: breed=redhat, version=rhel7
Adding distros from path  /var/www/cobbler/ks_mirror/CentOS-7 .3-x86_64:
creating new distro: CentOS-7.3-x86_64
trying  symlink /var/www/cobbler/ks_mirror/CentOS-7 .3-x86_64 ->  /var/www/cobbler/links/CentOS-7 .3-x86_64
creating new profile: CentOS-7.3-x86_64
associating repos
checking  for  rsync  repo(s)
checking  for  rhn repo(s)
checking  for  yum repo(s)
starting descent into  /var/www/cobbler/ks_mirror/CentOS-7 .3-x86_64  for  CentOS-7.3-x86_64
processing repo at :  /var/www/cobbler/ks_mirror/CentOS-7 .3-x86_64
need to process repo /comps /var/www/cobbler/ks_mirror/CentOS-7 .3-x86_64
looking  for  /var/www/cobbler/ks_mirror/CentOS-7 .3-x86_64 /repodata/ *comps*.xml
Keeping repodata as-is : /var/www/cobbler/ks_mirror/CentOS-7 .3-x86_64 /repodata
*** TASK COMPLETE ***

说明:cobbler导入的镜像放在:/var/www/cobbler/ks_mirror

1
2
3
4
[root@cobbler ks_mirror] # pwd
/var/www/cobbler/ks_mirror
[root@cobbler ks_mirror] # ls
CentOS-7.3-x86_64  config

默认kickstart文件存放位置:/var/lib/cobbler/kickstarts/

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
[root@cobbler ~] # cd /var/lib/cobbler/kickstarts/
[root@cobbler kickstarts] # ll
total 52
-rw-r--r-- 1 root root  115 Nov 17 03:09 default.ks
-rw-r--r-- 1 root root   22 Nov 17 03:09 esxi4-ks.cfg
-rw-r--r-- 1 root root   22 Nov 17 03:09 esxi5-ks.cfg
drwxr-xr-x 2 root root   56 Mar 20 10:39 install_profiles
-rw-r--r-- 1 root root 1424 Nov 17 03:09 legacy.ks
-rw-r--r-- 1 root root  292 Nov 17 03:09 pxerescue.ks
-rw-r--r-- 1 root root 2916 Nov 17 03:09 sample_autoyast.xml
-rw-r--r-- 1 root root 1825 Nov 17 03:09 sample_end.ks
-rw-r--r-- 1 root root    0 Nov 17 03:09 sample_esx4.ks
-rw-r--r-- 1 root root  324 Nov 17 03:09 sample_esxi4.ks
-rw-r--r-- 1 root root  386 Nov 17 03:09 sample_esxi5.ks
-rw-r--r-- 1 root root 1784 Nov 17 03:09 sample.ks
-rw-r--r-- 1 root root 3419 Nov 17 03:09 sample_old.seed
-rw-r--r-- 1 root root 5879 Nov 17 03:09 sample.seed
[root@cobbler ~] # cobbler list
distros:
    CentOS-7.3-x86_64
profiles:
    CentOS-7.3-x86_64
systems:
repos:
images:
mgmtclasses:
packages:
files:
[root@cobbler ~] # cobbler profile report
Name                           : CentOS-7.3-x86_64
TFTP Boot Files                : {}
Comment                        :
DHCP Tag                       : default
Distribution                   : CentOS-7.3-x86_64
Enable gPXE?                   : 0
Enable PXE Menu?               : 1
Fetchable Files                : {}
Kernel Options                 : {}
Kernel Options (Post Install)  : {}
Kickstart                      :  /var/lib/cobbler/kickstarts/sample_end .ks
Kickstart Metadata             : {}
Management Classes             : []
Management Parameters          : <<inherit>>
Name Servers                   : []
Name Servers Search Path       : []
Owners                         : [ 'admin' ]
Parent Profile                 :
Internal proxy                 :
Red Hat Management Key         : <<inherit>>
Red Hat Management Server      : <<inherit>>
Repos                          : []
Server Override                : <<inherit>>
Template Files                 : {}
Virt Auto Boot                 : 1
Virt Bridge                    : xenbr0
Virt CPUs                      : 1
Virt Disk Driver Type          : raw
Virt File Size(GB)             : 5
Virt Path                      :
Virt RAM (MB)                  : 512
Virt Type                      : kvm

查看cobbler profile的帮助:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
[root@cobbler ~] # cobbler profile edit --help
Usage: cobbler [options]
Options:
   -h, --help            show this help message and  exit
   --name=NAME           Name (Ex: F10-i386-webserver)
   --uid=UID
   --owners=OWNERS       Owners (Owners list  for  authz_ownership (space
                         delimited))
   --distro=DISTRO       Distribution (Parent distribution)
   --parent=PARENT       Parent Profile
   -- enable -gpxe=ENABLE_GPXE
                         Enable gPXE? (Use gPXE instead of PXELINUX  for
                         advanced booting options)
   -- enable -menu=ENABLE_MENU
                         Enable PXE Menu? (Show this profile  in  the PXE menu?)
   --kickstart=KICKSTART
                         Kickstart (Path to kickstart template)
   --kopts=KERNEL_OPTIONS
                         Kernel Options (Ex: selinux=permissive)
   --kopts-post=KERNEL_OPTIONS_POST
                         Kernel Options (Post Install) (Ex: clocksource=pit
                         noapic)
   --ksmeta=KS_META      Kickstart Metadata (Ex: dog=fang agent=86)
   --proxy=PROXY         Internal proxy (Internal proxy URL)
   --repos=REPOS         Repos (Repos to auto-assign to this profile)
   --comment=COMMENT     Comment (Free form text description)
   --virt-auto-boot=VIRT_AUTO_BOOT
                         Virt Auto Boot (Auto boot this VM?)
   --virt-cpus=VIRT_CPUS
                         Virt CPUs (integer)
   --virt- file -size=VIRT_FILE_SIZE
                         Virt File Size(GB)
   --virt-disk-driver=VIRT_DISK_DRIVER
                         Virt Disk Driver Type (The on-disk  format  for  the
                         virtualization disk)
   --virt- ram =VIRT_RAM   Virt RAM (MB)
   --depth=DEPTH
   --virt- type =VIRT_TYPE
                         Virt Type (Virtualization technology to use) (valid
                         options: xenpv,xenfv,qemu,kvm,vmware,openvz,SETTINGS:d
                         efault_virt_type)
   --virt-path=VIRT_PATH
                         Virt Path (Ex:  /directory  OR VolGroup00)
   --virt-bridge=VIRT_BRIDGE
                         Virt Bridge
   --dhcp-tag=DHCP_TAG   DHCP Tag (See manpage or leave blank)
   --server=SERVER       Server Override (See manpage or leave blank)
   --ctime=CTIME
   --mtime=MTIME
   --name-servers=NAME_SERVERS
                         Name Servers (space delimited)
   --name-servers-search=NAME_SERVERS_SEARCH
                         Name Servers Search Path (space delimited)
   --mgmt-classes=MGMT_CLASSES
                         Management Classes (For external configuration
                         management)
   --mgmt-parameters=MGMT_PARAMETERS
                         Management Parameters (Parameters  which  will be handed
                         to your management application (Must be valid YAML
                         dictionary))
   --boot-files=BOOT_FILES
                         TFTP Boot Files (Files copied into tftpboot beyond the
                         kernel /initrd )
   --fetchable-files=FETCHABLE_FILES
                         Fetchable Files (Templates  for  tftp or wget /curl )
   --template-files=TEMPLATE_FILES
                         Template Files (File mappings  for  built- in  config
                         management)
   --redhat-management-key=REDHAT_MANAGEMENT_KEY
                         Red Hat Management Key (Registration key  for  RHN,
                         Spacewalk, or Satellite)
   --redhat-management-server=REDHAT_MANAGEMENT_SERVER
                         Red Hat Management Server (Address of Spacewalk or
                         Satellite Server)
   --template-remote-kickstarts=TEMPLATE_REMOTE_KICKSTARTS
   --clobber             allow add to overwrite existing objects
   -- in -place            edit items  in  kopts or ksmeta without clearing the
                         other items

修改kickstart文件:

1
[root@cobbler ~] # cobbler profile edit --name=CentOS-7.3-x86_64 --kickstart=/var/lib/cobbler/kickstarts/CentOS-7.3-x86_64.cfg

修改内核参数:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
[root@cobbler ~] # cobbler profile edit --name=CentOS-7.3-x86_64 --kopts='net.ifnames=0 biosdevname=0'
[root@cobbler ~] # cobbler profile report
Name                           : CentOS-7.3-x86_64
TFTP Boot Files                : {}
Comment                        :
DHCP Tag                       : default
Distribution                   : CentOS-7.3-x86_64
Enable gPXE?                   : 0
Enable PXE Menu?               : 1
Fetchable Files                : {}
Kernel Options                 : { 'biosdevname' '0' 'net.ifnames' '0' }
Kernel Options (Post Install)  : {}
Kickstart                      :  /var/lib/cobbler/kickstarts/CentOS-7 .3-x86_64.cfg
Kickstart Metadata             : {}
Management Classes             : []
Management Parameters          : <<inherit>>
Name Servers                   : []
Name Servers Search Path       : []
Owners                         : [ 'admin' ]
Parent Profile                 :
Internal proxy                 :
Red Hat Management Key         : <<inherit>>
Red Hat Management Server      : <<inherit>>
Repos                          : []
Server Override                : <<inherit>>
Template Files                 : {}
Virt Auto Boot                 : 1
Virt Bridge                    : xenbr0
Virt CPUs                      : 1
Virt Disk Driver Type          : raw
Virt File Size(GB)             : 5
Virt Path                      :
Virt RAM (MB)                  : 512
Virt Type                      : kvm
[root@cobbler ~] # cobbler sync
task started: 2017-03-20_135014_sync
task started ( id =Sync,  time =Mon Mar 20 13:50:14 2017)
running pre- sync  triggers
cleaning trees
removing:  /var/www/cobbler/images/CentOS-7 .3-x86_64
removing:  /var/lib/tftpboot/pxelinux .cfg /default
removing:  /var/lib/tftpboot/grub/images
removing:  /var/lib/tftpboot/grub/grub-x86 .efi
removing:  /var/lib/tftpboot/grub/grub-x86_64 .efi
removing:  /var/lib/tftpboot/grub/efidefault
removing:  /var/lib/tftpboot/images/CentOS-7 .3-x86_64
removing:  /var/lib/tftpboot/s390x/profile_list
copying bootloaders
trying hardlink  /var/lib/cobbler/loaders/pxelinux .0 ->  /var/lib/tftpboot/pxelinux .0
copying:  /var/lib/cobbler/loaders/pxelinux .0 ->  /var/lib/tftpboot/pxelinux .0
trying hardlink  /var/lib/cobbler/loaders/menu .c32 ->  /var/lib/tftpboot/menu .c32
copying:  /var/lib/cobbler/loaders/menu .c32 ->  /var/lib/tftpboot/menu .c32
trying hardlink  /var/lib/cobbler/loaders/grub-x86 .efi ->  /var/lib/tftpboot/grub/grub-x86 .efi
trying hardlink  /var/lib/cobbler/loaders/grub-x86_64 .efi ->  /var/lib/tftpboot/grub/grub-x86_64 .efi
copying distros to tftpboot
copying files  for  distro: CentOS-7.3-x86_64
trying hardlink  /var/www/cobbler/ks_mirror/CentOS-7 .3-x86_64 /images/pxeboot/vmlinuz  ->  /var/lib/tftpboot/images/CentOS-7 .3-x86_64 /vmlinuz
trying hardlink  /var/www/cobbler/ks_mirror/CentOS-7 .3-x86_64 /images/pxeboot/initrd .img ->  /var/lib/tftpboot/images/CentOS-7 .3-x86_64 /initrd .img
copying images
generating PXE configuration files
generating PXE menu structure
copying files  for  distro: CentOS-7.3-x86_64
trying hardlink  /var/www/cobbler/ks_mirror/CentOS-7 .3-x86_64 /images/pxeboot/vmlinuz  ->  /var/www/cobbler/images/CentOS-7 .3-x86_64 /vmlinuz
trying hardlink  /var/www/cobbler/ks_mirror/CentOS-7 .3-x86_64 /images/pxeboot/initrd .img ->  /var/www/cobbler/images/CentOS-7 .3-x86_64 /initrd .img
Writing template files  for  CentOS-7.3-x86_64
rendering DHCP files
generating  /etc/dhcp/dhcpd .conf
rendering TFTPD files
generating  /etc/xinetd .d /tftp
processing boot_files  for  distro: CentOS-7.3-x86_64
cleaning link caches
running post- sync  triggers
running python triggers from  /var/lib/cobbler/triggers/sync/post/ *
running python trigger cobbler.modules.sync_post_restart_services
running: dhcpd -t -q
received on stdout:
received on stderr:
running: service dhcpd restart
received on stdout:
received on stderr: Redirecting to  /bin/systemctl  restart  dhcpd.service
running shell triggers from  /var/lib/cobbler/triggers/sync/post/ *
running python triggers from  /var/lib/cobbler/triggers/change/ *
running python trigger cobbler.modules.scm_track
running shell triggers from  /var/lib/cobbler/triggers/change/ *
*** TASK COMPLETE ***

客户端设置从网卡启动:


安装完的CentOS6:


cobbler的图形化管理界面(默认用户名cobbler,默认密码cobbler):






补充下,如果重启cobbler后发现dhcpd服务不能正常使用,很有可能是因为没设置自动启动

1
2
  [root@cobbler ~] # systemctl start dhcpd.service
  [root@cobbler ~] # systemctl enable dhcpd.serviceCreated symlink from /etc/systemd/system/multi-user.target.wants/dhcpd.service to /usr/lib/systemd/system/dhcpd.service.









本文转自 冰冻vs西瓜 51CTO博客,原文链接:http://blog.51cto.com/molewan/1908475,如需转载请自行联系原作者
目录
相关文章
|
1月前
|
分布式计算 关系型数据库 MySQL
Sqoop【部署 01】CentOS Linux release 7.5 安装配置 sqoop-1.4.7 解决警告并验证(附Sqoop1+Sqoop2最新版安装包+MySQL驱动包资源)
【2月更文挑战第8天】Sqoop CentOS Linux release 7.5 安装配置 sqoop-1.4.7 解决警告并验证(附Sqoop1+Sqoop2最新版安装包+MySQL驱动包资源)
100 1
|
11天前
|
JavaScript Linux 数据安全/隐私保护
如何在CentOS7部署Wiki.js知识库并实现分享好友公网远程使用【内网穿透】
如何在CentOS7部署Wiki.js知识库并实现分享好友公网远程使用【内网穿透】
|
17天前
|
存储 Linux Shell
centos 部署docker容器 安装 、基本使用方法(一)
centos 部署docker容器 安装 、基本使用方法(一)
32 0
|
17天前
|
分布式计算 Hadoop Java
centos 部署Hadoop-3.0-高性能集群(一)安装
centos 部署Hadoop-3.0-高性能集群(一)安装
17 0
|
28天前
|
Linux Shell 开发工具
CentOS8中Docker安装及部署
CentOS8中Docker安装及部署
77 0
|
1月前
|
存储 监控 Linux
Flume【部署 02】Flume监控工具Ganglia的安装与配置(CentOS 7.5 在线安装系统监控工具Ganglia + 权限问题处理 + Flume接入监控配置 + 图例说明)
【2月更文挑战第17天】Flume【部署 02】Flume监控工具Ganglia的安装与配置(CentOS 7.5 在线安装系统监控工具Ganglia + 权限问题处理 + Flume接入监控配置 + 图例说明)
29 1
Flume【部署 02】Flume监控工具Ganglia的安装与配置(CentOS 7.5 在线安装系统监控工具Ganglia + 权限问题处理 + Flume接入监控配置 + 图例说明)
|
2月前
|
关系型数据库 MySQL Linux
Azkaban【部署 02】CentOS release 7.5安装配置azkaban-3.70.0安装阶段(含已编译的10个安装文件:可直接进行安装)
【2月更文挑战第5天】CentOS release 7.5安装配置azkaban-3.70.0安装阶段(含已编译的10个安装文件:可直接进行安装)
48 7
|
Linux 网络安全 开发工具
centos7部署l2tp ipsec
1、查询操作系统版本 #cat /etc/redhat-release CentOS Linux release 7.5.1804 (Core) 2、查询系统是否支持ppp,返回yes代表通过。 #modprobe ppp-compress-18 && echo yes 3、查询系统是否开启了tun,返回File descriptor in bad state代表通过。
7665 0
|
1月前
|
Linux 网络安全 数据安全/隐私保护
如何在 VM 虚拟机中安装 CentOS Linux 9 操作系统保姆级教程(附链接)
如何在 VM 虚拟机中安装 CentOS Linux 9 操作系统保姆级教程(附链接)
170 0
|
1月前
|
存储 JavaScript Linux
Linux环境下安装nmp(Centos环境)保姆级教学 一步到位
Linux环境下安装nmp(Centos环境)保姆级教学 一步到位

热门文章

最新文章
