PCIE AER and hot removal

2017-11-16 2018
版权
版权声明：
本文内容由阿里云实名注册用户自发贡献，版权归原作者所有，阿里云开发者社区不拥有其著作权，亦不承担相应法律责任。具体规则请查看《 阿里云开发者社区用户服务协议》和 《阿里云开发者社区知识产权保护指引》。如果您发现本社区中有涉嫌抄袭的内容，填写 侵权投诉表单进行举报，一经查实，本社区将立刻删除涉嫌侵权内容。
简介：

It is very usefull to disable/enable during our verification of some functions, such as PCIE hotplug, firmware upgrade. We need use AER to maks or enable PCIE errors to stop unexpected reset.


Following script give us an example how to control AER and do hot removal and insertion, please feel free to give your comments:


#!/bin/bash


# Notice: following script is only for SLIC2

#set -n;

#set  -v;

#set  -x;


source ./aer_ctr.sh


# Disable SMI error caused by hot removal/insertion

function disable_smi()

{

    setpci -s 00:05.2 0x19C.w=0xffffffff ;

    setpci -s 00:05.2 0x1a0.w=0xffffffff ;

    setpci -s 00:05.2 0x1a4.w=0xffffffff ;

    setpci -s 00:05.2 0x1a8.w=0xffffffff ;

    setpci -s 00:05.2 0x1c8.w=0xffffffff ;

}


# Enable SMI error caused by hot removal/insertion

function enable_smi()

{

    setpci -s 00:05.2 0x19C.w=0x00000000 ;

    setpci -s 00:05.2 0x1a0.w=0x00000000 ;

    setpci -s 00:05.2 0x1a4.w=0x00000000 ;

    setpci -s 00:05.2 0x1a8.w=0x00000000 ;

}



# disable SP reset on PCIE device event

function disable_sp_reset_on_slicevent()

{

    ipmitool raw 0x30 0x81 0x13 0x10 0x00 0x00 0x00

}



# Power off PCIE card

function poweroff_slic()

{

    ipmitool raw 0x30 0x81 0x13 0x01 0x00 0x00 0x00


    # !!! DON"T REMOVE SLEEP , it is for PCIE DLL ready

sleep 1;

}



# Power on PCIE card 2

function poweron_slic()

{

    ipmitool raw 0x30 0x81 0x13 0x01 0x00 0x01 0x00

    # !!! DON"T REMOVE SLEEP , it is for PCIE DLL ready

sleep 1;

}


# disable SLIC hold in reset status

function disable_slic_holdinreset()

{

    ipmitool raw 0x30 0x81 0x13 0x04 0x00 0x00 0x00

    # !!! DON"T REMOVE SLEEP , it is for PCIE DLL ready

  sleep 1;

}



# The serdes value are only for PCIE card 2

# below function also works as C code, it doesn't set 504.b

function apply_serdes()

{


echo "Before Apply serdes:";

#lspci -xxxxx -s 00:07.0 | tee -a before_070_0819.pci

#lspci -xxxxx -s 00:07.1 | tee -a before_071_0819.pci

  #

#  setpci -s 00:06.7 0x504.b=0x76

   # [CTL] 0xa80 # set serdes table

   # read pci offset: bnd[0~30] to  A80

   # original value is 0x55555555

  #setpci  -s 00:07.0 0xa80.l=0x31810842  # correct one

  setpci  -s 00:07.0 0xa80.l=0x00d10842  # correct one

#  setpci  -s 00:07.0 0xa84.l=0x04

#  setpci  -s 00:07.0 0x438.l=0x2757F


  #setpci  -s 00:07.0 0x3cc.l=0x01d80000

  #setpci  -s 00:07.1 0x3cc.l=0x01d80000

  setpci  -s 00:07.0 0x3cc.l=0x01d80000

  setpci  -s 00:07.1 0x3cc.l=0x01d80000


}



# The serdes value are only for SLIC 2

## good one which follow all steps

function apply_serdes_origin()

{



 # the value of 504.b is always 0x76

  setpci -s 00:06.7 0x504.b=0x76

   # [CTL] 0xa80 # set serdes table

   # read pci offset: bnd[0~30] to  A80

   # original value is 0x55555555

  setpci  -s 00:07.0 0xa80.l=0x00


  #[cursor 0] 0x3cc  s.Cursorbnd0/1

  # original both 0x00 0x00

  setpci  -s 00:07.0 0xa80.l=0x00




  #[cursor 1] 0x3cc  s.Cursorbnd2/3

  # original both 0x00 0x00

  #lspci  -s 00:07.1 0xa80.l=0xd80000

  setpci  -s 00:07.0 0xa80.l=0x0000   # according to the C code, write 00:07.0 also



  # re-training, set bit, sleep , then clear the re-trian bit

  #[PR ]   0x3E   link control bit



  ##  check link -status [A2]

}


# do PCIE retraning by set the bridge control register

function retrain()

{


    #exp=83;


# step 0.0: display original link status reg

# let exp=exp+0x40;


# step 1: clear the linkBandwidth management bit

#setpci -s 00:03.0 0xa2.b=0xff;


#lspci -xxxxx -s 00:03.0 | tee -a  gdrootp2_0.lspci

# step 1.2: use link bridge contrl to reset the link bit

setpci -s 00:03.0 0x3e.w=0x0053;

#sleep 1

usleep 500000

#lspci -xxxxx -s 00:03.0 | tee -a  gdrootp2_1.lspci

setpci -s 00:03.0 0x3e.w=0x0013;

#sleep 1

usleep 500000

#lspci -xxxxx -s 00:03.0 | tee -a  gdrootp2_3.lspci


# step 1.5: save original link status reg

temp=`lspci -xxx -s 00:03.0 | grep "a0:" `;

     exp=`echo $temp | awk '{print $4}'`;

echo "Notice!!!! current link status is : $exp";

# let exp=exp+0x40;


# step 2: set the link train bit of control reg

    # for root port 2 (slot 2)

    # original 0x40

#setpci -s 00:03.0 0xa0.b=0x60;

#lspci -xxx -s 00:03.0 | grep "a0:"


    # wait until link staus is ready



# step 3: check and wait until finish link training

#    status=`lspci -xxx -s 00:03.0 | grep "a0:" | awk '{print $4}'`;

#

#    while [ $exp -ne $status ]

#    do

#

# echo "Current Link Status is $status" | tee -a lspci.log;

#        sleep 1;

#        status=`lspci -xxx -s 00:03.0 | grep a0: | awk '{print $4}' `

#    done

    #setpci -s 1f:00.0 0xbc.b=0x6;

    #setpci -s 1f:00.1 0xbc.b=0x6;

    #setpci -s 1f:00.2 0xbc.b=0x6;

    #setpci -s 1f:00.3 0xbc.b=0x6;

}


# test shows it doesn't matter whether it is set or not

function restore_bar()

{



echo "restore_bar";

}


# test shows it doesn't matter whether it is set or not

function restore_cmd()

{

echo "restore_cmd";

}


function unhide_regs()

{

# original value

# b0: c0 00 20 01 ce 00 20 01 c0 00 24 01 ec 00 20 01

# c0: e0 08 48 00 e0 0f 48 00 e0 0f 04 00 e0 05 00 00

#

    setpci -s 7f:10.7 0xb0.l=0x00;

    setpci -s 7f:10.7 0xb4.l=0x00;

    setpci -s 7f:10.7 0xb8.l=0x00;

    setpci -s 7f:10.7 0xbc.l=0x00;

    setpci -s 7f:10.7 0xc0.l=0x00;

    setpci -s 7f:10.7 0xc4.l=0x00;

    setpci -s 7f:10.7 0xc8.l=0x00;

    setpci -s 7f:10.7 0xcc.l=0x00;


    setpci -s ff:10.7 0xb0.l=0x00;

    setpci -s ff:10.7 0xb4.l=0x00;

    setpci -s ff:10.7 0xb8.l=0x00;

    setpci -s ff:10.7 0xbc.l=0x00;

    setpci -s ff:10.7 0xc0.l=0x00;

    setpci -s ff:10.7 0xc4.l=0x00;

    setpci -s ff:10.7 0xc8.l=0x00;

    setpci -s ff:10.7 0xcc.l=0x00;


    #echo "After unhide regs:" | tee -a lspci.log

    #lspci -vvvv -t | tee -a lspci.log


}



function hide_regs1()

{


# original value

# b0: c0 00 20 01 ce 00 20 01 c0 00 24 01 ec 00 20 01

# c0: e0 08 48 00 e0 0f 48 00 e0 0f 04 00 e0 05 00 00

#

    setpci -s 7f:10.7 0xb0.l=0xffffffff;

    setpci -s 7f:10.7 0xb4.l=0xffffffff;

    setpci -s 7f:10.7 0xb8.l=0xffffffff;

    setpci -s 7f:10.7 0xbc.l=0xffffffff;

    setpci -s 7f:10.7 0xc0.l=0xffffffff;

    setpci -s 7f:10.7 0xc4.l=0xffffffff;

    setpci -s 7f:10.7 0xc8.l=0xffffffff;

    setpci -s 7f:10.7 0xcc.l=0xffffffff;


    setpci -s ff:10.7 0xb0.l=0xffffffff;

    setpci -s ff:10.7 0xb4.l=0xffffffff;

    setpci -s ff:10.7 0xb8.l=0xffffffff;

    setpci -s ff:10.7 0xbc.l=0xffffffff;

    setpci -s ff:10.7 0xc0.l=0xffffffff;

    setpci -s ff:10.7 0xc4.l=0xffffffff;

    setpci -s ff:10.7 0xc8.l=0xffffffff;

    setpci -s ff:10.7 0xcc.l=0xffffffff;


    echo "After hide regs:" | tee -a lspci.log

    lspci -vvvv -t | tee -a lspci.log

}


function hide_regs()

{


# original value

# b0: c0 00 20 01 ce 00 20 01 c0 00 24 01 ec 00 20 01

# c0: e0 08 48 00 e0 0f 48 00 e0 0f 04 00 e0 05 00 00

#

    setpci -s 7f:10.7 0xb0.b=0xc0;

    setpci -s 7f:10.7 0xb4.b=0xce;

    setpci -s 7f:10.7 0xb8.b=0xc0;

    setpci -s 7f:10.7 0xbc.b=0xec;

    setpci -s 7f:10.7 0xc0.b=0xe0;

    setpci -s 7f:10.7 0xc4.b=0xe0;

    setpci -s 7f:10.7 0xc8.b=0xe0;

    setpci -s 7f:10.7 0xcc.b=0xe0;


    setpci -s ff:10.7 0xb0.b=0xc0;

    setpci -s ff:10.7 0xb4.b=0xce;

    setpci -s ff:10.7 0xb8.b=0xc0;

    setpci -s ff:10.7 0xbc.b=0xec;

    setpci -s ff:10.7 0xc0.b=0xe0;

    setpci -s ff:10.7 0xc4.b=0xe0;

    setpci -s ff:10.7 0xc8.b=0xe0;

    setpci -s ff:10.7 0xcc.b=0xe0;


    #echo "After hide regs:" | tee -a lspci.log

    #lspci -vvvv -t | tee -a lspci.log

}


function unhide_regs_original()

{

# original value

# b0: c0 00 20 01 ce 00 20 01 c0 00 24 01 ec 00 20 01

# c0: e0 08 48 00 e0 0f 48 00 e0 0f 04 00 e0 05 00 00

#

    setpci -s 7f:10.7 0xb0.b=0x00;

    setpci -s 7f:10.7 0xb4.b=0x0e;

    setpci -s 7f:10.7 0xb8.b=0x00;

    setpci -s 7f:10.7 0xbc.b=0x2c;

    #setpci -s 7f:10.7 0xc0.b=0x20;

    #setpci -s 7f:10.7 0xc4.b=0x20;

    #setpci -s 7f:10.7 0xc8.b=0x20;

    #setpci -s 7f:10.7 0xcc.b=0x20;


    setpci -s ff:10.7 0xb0.b=0x00;

    setpci -s ff:10.7 0xb4.b=0x0e;

    setpci -s ff:10.7 0xb8.b=0x00;

    setpci -s ff:10.7 0xbc.b=0x2c;

    #setpci -s ff:10.7 0xc0.b=0x20;

    #setpci -s ff:10.7 0xc4.b=0x20;

    #setpci -s ff:10.7 0xc8.b=0x20;

    #setpci -s ff:10.7 0xcc.b=0x20;


    echo "After unhide regs:" | tee -a lspci.log

    lspci -vvvv -t -A intel-conf1 | tee -a lspci.log


}



function hide_regs_original()

{


# original value

# b0: c0 00 20 01 ce 00 20 01 c0 00 24 01 ec 00 20 01

# c0: e0 08 48 00 e0 0f 48 00 e0 0f 04 00 e0 05 00 00

#

    setpci -s 7f:10.7 0xb0.b=0xc0;

    setpci -s 7f:10.7 0xb4.b=0xce;

    setpci -s 7f:10.7 0xb8.b=0xc0;

    setpci -s 7f:10.7 0xbc.b=0xec;

    #setpci -s 7f:10.7 0xc0.b=0xe0;

    #setpci -s 7f:10.7 0xc4.b=0xe0;

    #setpci -s 7f:10.7 0xc8.b=0xe0;

    #setpci -s 7f:10.7 0xcc.b=0xe0;


    setpci -s ff:10.7 0xb0.b=0xc0;

    setpci -s ff:10.7 0xb4.b=0xce;

    setpci -s ff:10.7 0xb8.b=0xc0;

    setpci -s ff:10.7 0xbc.b=0xec;

    #setpci -s ff:10.7 0xc0.b=0xe0;

    #setpci -s ff:10.7 0xc4.b=0xe0;

    #setpci -s ff:10.7 0xc8.b=0xe0;

    #setpci -s ff:10.7 0xcc.b=0xe0;


    echo "After hide regs:" | tee -a lspci.log

    lspci -vvvv -t -A intel-conf1 | tee -a lspci.log

}



# to set eeprom, however it doens't matter to verify the process of hot plug even if it is emplty

set_eeprom()

{

echo "Set EEPROM done!";

}


# the main process, notice:

## 1. either disable_aer/enable_aer or disable_smi/enable_smi can be used, but it is not recommended

##    to use like this method: disable_aer/enable_smi or disable_smi/enable_aer.

## 2. This fucntion is only for PCIE card 2 and assume the card is: Broadcom Corporation BCM57840 NetXtreme II 10 Gigabit Ethernet,

##      that means it is a ROckslide (Broadcom q-port 10GbE) card

main3()

{


if [ $1 -eq 1 ]

then

    #disable_smi;

    #enable_aer 00:03.0

    disable_aer 00:03.0

    disable_sp_reset_on_slicevent;

    poweroff_slic;

    # do remove the slic

    echo "after power off slic" | tee -a lspci.log

    #lspci -vvvv -t -A intel-conf1 | tee -a lspci.log


    clear_aer 00:03.0

    #enable_smi

    #enable_aer 00:03.0

    #disable_aer 00:03.0

fi


   #echo "sleep 2s";

   #sleep 2;

   #echo "sleep 2s done";

    # insert the SLIC again

    #echo 1 > /sys/bus/pci/rescan

if [ $1 -eq 0 ]

then


temp=`lspci -xxx -s 00:03.0| grep "a0:"`;

     exp=`echo $temp | awk '{print $4}'`;

echo "Before power on slic: Original link status is : $exp";

    poweron_slic

    disable_slic_holdinreset

    unhide_regs_original;

    unhide_regs

    echo 1 > /sys/bus/pci/rescan

    apply_serdes

    #disable_aer 00:03.0


temp=`lspci -xxx -s 00:03.0| grep "a0:"`;

     exp=`echo $temp | awk '{print $4}'`;

echo "Before retarin: Original link status is : $exp";

    retrain

    #hide_regs_original

    #clear_aer 00:03.0

    #clear_aer 80:02.0

    #clear_aer 00:03.0

    #clear_aer 00:01.0

    #hide_regs

    #echo 1 > /sys/bus/pci/rescan

    #echo 1 > /sys/bus/pci/devices/0000:00:03.0/rescan

    restore_bar;

    restore_cmd;

    enable_aer 00:03.0

    #enable_smi


   # echo "After retrain and rescan" | tee -a lspci.log

   # lspci -vvvv -t -A intel-conf1 | tee -a lspci.log

fi

}





main3 $1;

## usage as below:  ###

#main3 0 ## hot insertion

#main3 1 ## hot removal






















本文转自存储之厨51CTO博客，原文链接：http://blog.51cto.com/xiamachao/1844984 ，如需转载请自行联系原作者


文章标签：
Perl
Shell
存储
技术小甜
目录
相关文章
INSVAST
|
3月前
|
算法 数据挖掘 数据处理
文献解读-Sentieon DNAscope LongRead – A highly Accurate, Fast, and Efficient Pipeline for Germline Variant Calling from PacBio HiFi reads
PacBio® HiFi 测序是第一种提供经济、高精度长读数测序的技术，其平均读数长度超过 10kb，平均碱基准确率达到 99.8% 。在该研究中，研究者介绍了一种准确、高效的 DNAscope LongRead 管道，用于从 PacBio® HiFi 读数中调用胚系变异。DNAscope LongRead 是对 Sentieon 的 DNAscope 工具的修改和扩展，该工具曾获美国食品药品管理局（FDA）精密变异调用奖。
INSVAST
34 2
文献解读-Sentieon DNAscope LongRead – A highly Accurate, Fast, and Efficient Pipeline for Germline Variant Calling from PacBio HiFi reads
INSVAST
|
4月前
|
算法 数据挖掘
文献解读-Consistency and reproducibility of large panel next-generation sequencing: Multi-laboratory assessment of somatic mutation detection on reference materials with mismatch repair and proofreading deficiency
Consistency and reproducibility of large panel next-generation sequencing: Multi-laboratory assessment of somatic mutation detection on reference materials with mismatch repair and proofreading deficiency，大panel二代测序的一致性和重复性：对具有错配修复和校对缺陷的参考物质进行体细胞突变检测的多实验室评估
INSVAST
35 6
文献解读-Consistency and reproducibility of large panel next-generation sequencing: Multi-laboratory assessment of somatic mutation detection on reference materials with mismatch repair and proofreading deficiency
auqbllxiu
|
固态存储
《In Pursuit of Optimal Storage PerformanceHardwareSoftware Co-Design with Dual-Mode SSD》电子版地址
In Pursuit of Optimal Storage Performance:Hardware/Software Co-Design with Dual-Mode SSD
auqbllxiu
84 0
《In Pursuit of Optimal Storage PerformanceHardwareSoftware Co-Design with Dual-Mode SSD》电子版地址
MangoPapa
|
数据安全/隐私保护
PCIe ARI (Alternative Routing-ID Interpretation)介绍
PCIe ARI (Alternative Routing-ID Interpretation)介绍
MangoPapa
2040 0
PCIe ARI (Alternative Routing-ID Interpretation)介绍
科技小能手
libvirt 问题：CPU topology doesn't match maximum vcpu
科技小能手
3049 0
Lux_Sun
Data Structures and Algorithms (English) - 7-11 Saving James Bond - Hard Version（30 分）
Data Structures and Algorithms (English) - 7-11 Saving James Bond - Hard Version（30 分）
Lux_Sun
183 0
Lux_Sun
PAT (Advanced Level) Practice - 1096 Consecutive Factors（20 分）
PAT (Advanced Level) Practice - 1096 Consecutive Factors（20 分）
Lux_Sun
149 0
玄学酱
26.2. PERC H700 Integrated - Raid Card
玄学酱
1197 0
嗯哼9925
|
存储 监控 安全
【译】Virtual-Machine-based Intrusion Detection on File-aware Block Level Storage
嗯哼9925
1567 0
科技探索者
Differences between RDM Virtual and Physical Mode
科技探索者
1272 0

热门文章

最新文章

  • 1
    多中心容灾实践：如何实现真正的异地多活？
  • 2
    Canal 数据同步（应用场景） | 学习笔记
  • 3
    你用过的网站前端优化的技术有哪些？
  • 4
    Confluence 6 那些文件需要备份
  • 5
    解决LR-Controller场景下1个用户运行出错
  • 6
    [IOS]本地化
  • 7
    Visual Studio Extensions for SharePoint Services, Really Cool !
  • 8
    基于链表编写“猫吃老鼠”
  • 9
    证码识别--type1
  • 10
    2012年我的关键词
  • 1
    「全网最细 + 实战源码案例」设计模式——外观模式
    97
  • 2
    《迈向绿色智能：探寻人工智能硬件可持续发展之路》
    39
  • 3
    《光存储与3D存储：开启人工智能硬件存储新时代》
    26
  • 4
    《解锁AI潜能：深度挖掘工程数据宝藏》
    37
  • 5
    《深度解析：VAEs如何重塑数据生成与重建格局》
    35
  • 6
    《AI 造梦：解锁虚拟场景与角色逼真丰富密码》
    28
  • 7
    jQuery+Slick插件实现游戏人物轮播展示切换源码
    23
  • 8
    网安入门之MySQL后端基础
    33
  • 9
    【03】优雅草央千澈详解关于APP签名以及分发-上架完整流程-第三篇安卓APP上架华为商店后面的步骤-华为应用商店相对比较麻烦一些-华为商店安卓上架
    32
  • 10
    OpenHands：能自主检索外部知识的 AI 编程工具，自动执行命令、网页浏览和生成代码等操作
    63

    • 相关电子书

    更多
  • Separating hot-cold data into heterogeneous storage based on layered compaction
  • Simplify Distributed Rate-Limiting in Overlay Cloud Network with FDRL
  • Changing the Way Viacom Looks at Video Performance
    • 下一篇
    DataWorks智能交互式数据开发与分析之旅
