iOS开发中会经常用到文件上传下载的功能，这篇文件将介绍一下使用asp.net webservice实现文件上传下载。

首先，让我们看下文件下载。

这里我们下载cnblogs上的一个zip文件。使用NSURLRequest+NSURLConnection可以很方便的实现这个功能。

同步下载文件：

        NSString *urlAsString =@"http://files.cnblogs.com/zhuqil/UIWebViewDemo.zip";

NSURL    *url = [NSURL URLWithString:urlAsString];

NSURLRequest *request = [NSURLRequest requestWithURL:url];

NSError *error = nil;

NSData   *data = [NSURLConnection sendSynchronousRequest:request

returningResponse:nil

error:&error];
/* 下载的数据 */
if (data != nil){

NSLog(@"下载成功");
if ([data writeToFile:@"UIWebViewDemo.zip" atomically:YES]) {

NSLog(@"保存成功.");

}
else

{

NSLog(@"保存失败.");

}

} else {

NSLog(@"%@", error);

}

异步下载文件：

- (void)viewDidLoad

{

[super viewDidLoad];
//文件地址
    NSString *urlAsString =@"http://files.cnblogs.com/zhuqil/UIWebViewDemo.zip";

NSURL    *url = [NSURL URLWithString:urlAsString];

NSURLRequest *request = [NSURLRequest requestWithURL:url];

NSMutableData *data = [[NSMutableData alloc] init];

self.connectionData = data;

[data release];

NSURLConnection *newConnection = [[NSURLConnection alloc]

initWithRequest:request
delegate:self

startImmediately:YES];

self.connection = newConnection;

[newConnection release];
if (self.connection != nil){

NSLog(@"Successfully created the connection");

} else {

NSLog(@"Could not create the connection");

}

}




- (void) connection:(NSURLConnection *)connection

didFailWithError:(NSError *)error{

NSLog(@"An error happened");

NSLog(@"%@", error);

}
- (void) connection:(NSURLConnection *)connection

didReceiveData:(NSData *)data{

NSLog(@"Received data");

[self.connectionData appendData:data];

}
- (void) connectionDidFinishLoading

:(NSURLConnection *)connection{
/* 下载的数据 */


NSLog(@"下载成功");
if ([self.connectionData writeToFile:@"UIWebViewDemo.zip" atomically:YES]) {

NSLog(@"保存成功.");

}
else

{

NSLog(@"保存失败.");

}

/* do something with the data here */

}
- (void) connection:(NSURLConnection *)connection

didReceiveResponse:(NSURLResponse *)response{

[self.connectionData setLength:0];

}

- (void) viewDidUnload{

[super viewDidUnload];

[self.connection cancel];

self.connection = nil;

self.connectionData = nil;

}

从上面两段代码中可以看到同步与异步下载的区别，大部分时候我们使用异步下载文件。在asp.net webservice中可以将文件的地址返回到iOS系统，iOS系统在去请求下载该文件。

上传文件

我们先使用VB.Net写一个webservice方法，用于接收上传上来的文件数据，代码如下。

    <WebMethod(Description:="上传文件！")> _

Public Function UploadFile() As XmlDocument

        Dim doc As XmlDocument = New XmlDocument()

        Try

            Dim postCollection As HttpFileCollection = Context.Request.Files

            Dim aFile As HttpPostedFile = postCollection("media")

            aFile.SaveAs(Server.MapPath(".") + "/" + Path.GetFileName(aFile.FileName))

            doc.LoadXml("<xml>ok</xml>")

            Return doc

        Catch ex As Exception

            doc.LoadXml("<xml>fail</xml>")

            Return doc

        End Try

    End Function

文件上传接口

定义一个类PicOperation用于处理上传图片：

@interface PicOperation : NSOperation
{

    UIImage *theImage;
}
@property (retain) UIImage *theImage;
@end

//
//  PicOperation.m
//  DownLoading
//
//  Created by skylin zhu on 11-7-30.
//  Copyright 2011年 mysoft. All rights reserved.
//

#import "PicOperation.h"

#define NOTIFY_AND_LEAVE(X) {[self cleanup:X]; return;}
#define DATA(X) [X dataUsingEncoding:NSUTF8StringEncoding]

// Posting constants
#define IMAGE_CONTENT @"Content-Disposition: form-data; name=\"%@\"; filename=\"image.jpg\"\r\nContent-Type: image/jpeg\r\n\r\n"
#define STRING_CONTENT @"Content-Disposition: form-data; name=\"%@\"\r\n\r\n"
#define MULTIPART @"multipart/form-data; boundary=------------0x0x0x0x0x0x0x0x"

@implementation PicOperation

@synthesize theImage;

//创建postdata

- (NSData*)generateFormDataFromPostDictionary:(NSDictionary*)dict
{

    id boundary = @"------------0x0x0x0x0x0x0x0x";

    NSArray* keys = [dict allKeys];

    NSMutableData* result = [NSMutableData data];

    for (int i = 0; i < [keys count]; i++)

    {

        id value = [dict valueForKey: [keys objectAtIndex:i]];

        [result appendData:[[NSString stringWithFormat:@"--%@\r\n", boundary] dataUsingEncoding:NSUTF8StringEncoding]];

        if ([value isKindOfClass:[NSData class]])

        {

            // handle image data

            NSString *formstring = [NSString stringWithFormat:IMAGE_CONTENT, [keys objectAtIndex:i]];

            [result appendData: DATA(formstring)];

            [result appendData:value];

        }

        else

        {

            // all non-image fields assumed to be strings

            NSString *formstring = [NSString stringWithFormat:STRING_CONTENT, [keys objectAtIndex:i]];

            [result appendData: DATA(formstring)];

            [result appendData:DATA(value)];

        }

        NSString *formstring = @"\r\n";

        [result appendData:DATA(formstring)];

    }

    NSString *formstring =[NSString stringWithFormat:@"--%@--\r\n", boundary];

    [result appendData:DATA(formstring)];

    return result;
}
//上传图片

- (NSString *) UpLoading
{

    if (!self.theImage)

        NOTIFY_AND_LEAVE(@"Please set image before uploading.");

    NSMutableDictionary* post_dict = [[NSMutableDictionary alloc] init];

    [post_dict setObject:@"Posted from iPhone" forKey:@"message"];

    [post_dict setObject:UIImageJPEGRepresentation(self.theImage, 0.75f) forKey:@"media"];

    NSData *postData = [self generateFormDataFromPostDictionary:post_dict];

    [post_dict release];

    NSString *baseurl = @"http://10.5.23.121:7878/WorkflowService.asmx/UploadFile";

    NSURL *url = [NSURL URLWithString:baseurl];

    NSMutableURLRequest *urlRequest = [NSMutableURLRequest requestWithURL:url];

    if (!urlRequest) NOTIFY_AND_LEAVE(@"Error creating the URL Request");

    [urlRequest setHTTPMethod: @"POST"];

    [urlRequest setValue:MULTIPART forHTTPHeaderField: @"Content-Type"];

    [urlRequest setHTTPBody:postData];

    // Submit & retrieve results

    NSError *error;

    NSURLResponse *response;

    NSLog(@"Contacting TwitPic....");

    NSData* result = [NSURLConnection sendSynchronousRequest:urlRequest returningResponse:&response error:&error];

    if (!result)

    {

        [self cleanup:[NSString stringWithFormat:@"Submission error: %@", [error localizedDescription]]];

        return;

    }

    // Return results

    NSString *outstring = [[[NSString alloc] initWithData:result encoding:NSUTF8StringEncoding] autorelease];

    return outstring;
}
@end

这里我主要定义了两个方法，一个是generateFormDataFromPostDictionary用于创建post form data，一个是UpLoading供调用的类上传图片，这个类需要一个UIimage的对象。

类定义好了，上传图片就非常方便了，看下面代码：

PicOperation *pic = [[PicOperation alloc] init];

pic.theImage=[UIImage imageNamed:@"meinv4.jpg"];;

NSString *result = [pic UpLoading];

NSLog(result);
