简介： Element登录+注册

1.1 定义

ElementUI是一套基于Vue.js的桌面端组件库，提供了丰富的UI组件和交互功能，旨在帮助开发者快速构建现代化的Web应用程序。它具有以下作用：

提供丰富的UI组件：ElementUI包含了各种常用的UI组件，例如按钮、表单、表格、对话框、菜单等等。这些组件都经过精心设计和开发，可以直接在项目中使用，无需从头编写和样式。

提高开发效率：ElementUI提供了一致的设计语言和交互模式，使得开发者可以快速搭建用户界面。通过组件的封装和预设的样式，开发者能够更加专注于业务逻辑的实现，提高开发效率。

响应式设计：ElementUI的组件都经过响应式的设计，能够自动适应不同屏幕大小和设备类型。这意味着你可以在不同的终端上（如PC、平板、手机）保持一致的用户体验，无需额外的适配工作。

可定制性：ElementUI允许开发者根据自己的需要进行定制和扩展。你可以根据项目的风格和要求，修改组件的样式、主题色等，以满足特定的设计需求。

总之，ElementUI是一个功能强大、易于使用和高度可定制的Vue.js组件库，为开发者提供了构建现代化Web应用程序的工具和资源。它能够加速开发过程，提升用户体验，并且适应不同的设备和屏幕尺寸。

1.3 完成用户注册登录界面搭建

1.3.3 下载js依赖

npm install element-ui -S

1.3.4 创建用户登录注册组件

编写用户登录和注册的Vue组件

<template>
  <div class="login-wrap">
    <el-form class="login-container">
      <h1 class="title">用户登录</h1>
      <el-form-item label="">
        <el-input type="text" v-model="username" placeholder="登录账号" autocomplete="off"></el-input>
      </el-form-item>
      <el-form-item label="">
        <el-input type="password" v-model="password" placeholder="登录密码" autocomplete="off"></el-input>
      </el-form-item>
      <el-form-item>
        <el-button type="primary" style="width:100%;" @click="doSubmit()">提交</el-button>
      </el-form-item>
      <el-row style="text-align: center;margin-top:-10px">
        <el-link type="primary">忘记密码</el-link>
        <el-link type="primary" @click="gotoRegister()">用户注册</el-link>
      </el-row>
    </el-form>
  </div>
</template>
<script>
export default {
  name: 'Login',
  data () {
    return {
      username: '',
      passwprd: ''
    }
  }
  ,methods:{
    gotoRegister(){
      this.$router.push('/register');
    }
  }
}
</script>
<style scoped>
  .login-wrap {
    box-sizing: border-box;
    width: 100%;
    height: 100%;
    padding-top: 10%;
    background-repeat: no-repeat;
    background-position: center right;
    background-size: 100%;
  }
.login-container {
  border-radius: 10px;
  margin: 0px auto;
  width: 350px;
  padding: 30px 35px 15px 35px;
  background: #fff;
  border: 1px solid #eaeaea;
  text-align: left;
  box-shadow: 0 0 20px 2px rgba(0, 0, 0, 0.1);
}
.title {
  margin: 0px auto 40px auto;
  text-align: center;
  color: #505458;
}
</style>

1.3.5 配置路由

import Vue from 'vue'
import Router from 'vue-router'
import HelloWorld from '@/components/HelloWorld'
import login from '@/views/login'
import register from '@/views/register'
Vue.use(Router)
export default new Router({
  routes: [
    {
      path: '/',
      name: 'login',
      component: login
    },
  {
    path: '/register',
    name: 'register',
    component: register
  },
  ]
})

二、数据交互

2.1 数据导入

介绍数据导入的概念和步骤

<template>
  <div class="login-wrap">
    <el-form class="login-container">
      <h1 class="title">用户注册</h1>
      <el-form-item label="">
        <el-input type="text" v-model="username" placeholder="注册账号" autocomplete="off"></el-input>
      </el-form-item>
      <el-form-item label="">
        <el-input type="password" v-model="password" placeholder="注册密码" autocomplete="off"></el-input>
      </el-form-item>
      <el-form-item>
        <el-button type="primary" style="width:100%;" @click="doSubmit()">提交</el-button>
      </el-form-item>
      <el-row style="text-align: center;margin-top:-10px">
        <el-link type="primary">忘记密码</el-link>
        <el-link type="primary" @click="gotoLogin()">用户登录</el-link>
      </el-row>
    </el-form>
  </div>
</template>
<script>
export default {
  name: 'Login',
  data () {
   return {
     username: '',
     passwprd: ''
   }
  }
  ,methods:{
    gotoLogin(){
      this.$router.push('/');
    }
  }
}
</script>
<style scoped>
  .login-wrap {
    box-sizing: border-box;
    width: 100%;
    height: 100%;
    padding-top: 10%;
    background-repeat: no-repeat;
    background-position: center right;
    background-size: 100%;
  }
.login-container {
  border-radius: 10px;
  margin: 0px auto;
  width: 350px;
  padding: 30px 35px 15px 35px;
  background: #fff;
  border: 1px solid #eaeaea;
  text-align: left;
  box-shadow: 0 0 20px 2px rgba(0, 0, 0, 0.1);
}
.title {
  margin: 0px auto 40px auto;
  text-align: center;
  color: #505458;
}
</style>

导入ssm项目充当后台

2.3 安装引用相关模块

2.3.1 安装相关模块

下载并安装axios、vue-router等必要的模块

npm i axios -S

npm i vue-axios -S

npm i qs -S

2.3.2 引用相关模块

在Vue项目中引入所需的模块

安装好后即进行模块引用，安装后就在项目中进行引用，添加axios的全局配置，创建一个actio.js，如下：

解释：action.js（针对后台请求接口的封装定义）

对后台请求的地址的封装，URL格式如下： 模块名_实体名_操作

export default {
  'SERVER': 'http://localhost:8080/', //服务器
  'SYSTEM_USER_DOLOGIN': 'user/userLogin', //登陆
  'SYSTEM_USER_DOREG': 'userAction.action', //注册
  'getFullPath': k => { //获得请求的完整地址，用于mockjs测试时使用
    return this.SERVER + this[k];
  }
}

创建http.js，用于vue项目对axios的全局配置，如下：

解释：http.js（针对axios的全局配置）

/**
 * vue项目对axios的全局配置
 */
import axios from 'axios'
import qs from 'qs'
//引入action模块，并添加至axios的类属性urls上
import action from '@/api/action'
axios.urls = action
// axios默认配置
axios.defaults.timeout = 10000; // 超时时间
// axios.defaults.baseURL = 'http://localhost:8080/j2ee15'; // 默认地址
axios.defaults.baseURL = action.SERVER;
//整理数据
// 只适用于 POST,PUT,PATCH，transformRequest` 允许在向服务器发送前，修改请求数据
axios.defaults.transformRequest = function(data) {
  data = qs.stringify(data);
  return data;
};
// 请求拦截器
axios.interceptors.request.use(function(config) {
  return config;
}, function(error) {
  return Promise.reject(error);
});
// 响应拦截器
axios.interceptors.response.use(function(response) {
  return response;
}, function(error) {
  return Promise.reject(error);
});
// // 路由请求拦截
// // http request 拦截器
// axios.interceptors.request.use(
//  config => {
//    //config.data = JSON.stringify(config.data);
//    //config.headers['Content-Type'] = 'application/json;charset=UTF-8';
//    //config.headers['Token'] = 'abcxyz';
//    //判断是否存在ticket，如果存在的话，则每个http header都加上ticket
//    // if (cookie.get("token")) {
//    //  //用户每次操作，都将cookie设置成2小时
//    //  cookie.set("token", cookie.get("token"), 1 / 12)
//    //  cookie.set("name", cookie.get("name"), 1 / 12)
//    //  config.headers.token = cookie.get("token");
//    //  config.headers.name = cookie.get("name");
//    // }
//    return config;
//  },
//  error => {
//    return Promise.reject(error.response);
//  });
// // 路由响应拦截
// // http response 拦截器
// axios.interceptors.response.use(
//  response => {
//    if (response.data.resultCode == "404") {
//      console.log("response.data.resultCode是404")
//      // 返回 错误代码-1 清除ticket信息并跳转到登录页面
//      //      cookie.del("ticket")
//      //      window.location.href='http://login.com'
//      return
//    } else {
//      return response;
//    }
//  },
//  error => {
//    return Promise.reject(error.response) // 返回接口返回的错误信息
//  });
export default axios;

最后在前端的项目中main.js文件中引入vue-axios 模块，如下：

import axios from '@/api/http'
import VueAxios from 'vue-axios'
Vue.use(VueAxios,axios)

2.4 axios之get请求

使用axios发送GET请求获取数据

<template>
  <div class="login-wrap">
    <el-form class="login-container">
      <h1 class="title">用户登录</h1>
      <el-form-item label="">
        <el-input type="text" v-model="username" placeholder="登录账号" autocomplete="off"></el-input>
      </el-form-item>
      <el-form-item la-0bel="">
        <el-input type="password" v-model="password" placeholder="登录密码" autocomplete="off"></el-input>
      </el-form-item>
      <el-form-item>
        <el-button type="primary" style="width:100%;" @click="doSubmit()">提交</el-button>
      </el-form-item>
      <el-row style="text-align: center;margin-top:-10px">
        <el-link type="primary">忘记密码</el-link>
        <el-link type="primary" @click="gotoRegister()">用户注册</el-link>
      </el-row>
    </el-form>
  </div>
</template>
<script>
  import axios from 'axios'
    import qs from 'qs'
  export default {
    name:'login',
    data () {
      return {
        username:'',
      password:''
      }
    }
  ,methods:{
    gotoRegister(){
      this.$router.push('/register');
    },
    doSubmit(){
      let url=this.axios.urls.SYSTEM_USER_DOLOGIN;
      let params={
        username:this.username,
        password:this.password
      }
     axios.get(url,{params:params}).then(r=>{
        console.log(r);
        if (r.data.success) {
          this.$message({
                    message:r.data.msg,
                    type: 'success'
                  });
        }else{
           this.$message.error(r.data.msg);
        }
       } ).catch(e=>{
       })
    }
  }
  }
</script>
<style scoped>
  .login-wrap {
    box-sizing: border-box;
    width: 100%;
    height: 100%;
    padding-top: 10%;
    /* background-color: #112346; */
    background-repeat: no-repeat;
    background-position: center right;
    background-size: 100%;
  }
  .login-container {
    border-radius: 10px;
    margin: 0px auto;
    width: 350px;
    padding: 30px 35px 15px 35px;
    background: #fff;
    border: 1px solid #eaeaea;
    text-align: left;
    box-shadow: 0 0 20px 2px rgba(0, 0, 0, 0.1);
  }
  .title {
    margin: 0px auto 40px auto;
    text-align: center;
    color: #505458;
  }
</style>

后端代码

package com.zking.ssm.controller;
import com.zking.ssm.model.User;
import com.zking.ssm.service.IUserService;
import com.zking.ssm.util.JsonResponseBody;
import com.zking.ssm.util.PageBean;
import com.zking.ssm.vo.UserVo;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Controller;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.ResponseBody;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import java.util.HashMap;
import java.util.List;
import java.util.Map;
import com.zking.ssm.jwt.*;
@Controller
@RequestMapping("/user")
public class UserController {
    @Autowired
    private IUserService userService;
    @RequestMapping("/userLogin")
    @ResponseBody
    public JsonResponseBody<?> userLogin(UserVo userVo, HttpServletResponse response){
        if(userVo.getUsername().equals("admin")&&userVo.getPassword().equals("123")){
            //私有要求claim
//            Map<String,Object> json=new HashMap<String,Object>();
//            json.put("username", userVo.getUsername());
            //生成JWT，并设置到response响应头中
//            String jwt=JwtUtils.createJwt(json, JwtUtils.JWT_WEB_TTL);
//            response.setHeader(JwtUtils.JWT_HEADER_KEY, jwt);
            return new JsonResponseBody<>("用户登陆成功！",true,0,null);
        }else{
            return new JsonResponseBody<>("用户名或密码错误！",false,0,null);
        }
    }
    @RequestMapping("/userRegister")
    @ResponseBody
    public JsonResponseBody<?> Register(User user, HttpServletResponse response) {
        if (user.getUsername() != null && user.getPassword() != null && user != null) {
            int n = userService.insertSelective(user);
            if (n > 0) {
                return new JsonResponseBody<>("注册成功！", true, 0, null);
            }
        }
        return new JsonResponseBody<>("用户名或密码错误！", false, 0, null);
    }
    @RequestMapping("/queryUserPager")
    @ResponseBody
    public JsonResponseBody<List<Map<String,Object>>>
            queryUserPager(UserVo userVo, HttpServletRequest request){
        try {
            PageBean pageBean=new PageBean();
            pageBean.setRequest(request);
            List<Map<String, Object>> users = userService.queryUserPager(userVo, pageBean);
            return new JsonResponseBody<>("OK",true,pageBean.getTotal(),users);
        } catch (Exception e) {
            e.printStackTrace();
            return new JsonResponseBody<>("分页查询用户信息失败！",false,0,null);
        }
    }
}

2.5 axios之post请求

使用axios发送POST请求提交数据

<template>
  <div class="login-wrap">
    <el-form class="login-container">
      <h1 class="title">用户登录</h1>
      <el-form-item label="">
        <el-input type="text" v-model="username" placeholder="登录账号" autocomplete="off"></el-input>
      </el-form-item>
      <el-form-item la-0bel="">
        <el-input type="password" v-model="password" placeholder="登录密码" autocomplete="off"></el-input>
      </el-form-item>
      <el-form-item>
        <el-button type="primary" style="width:100%;" @click="doSubmit()">提交</el-button>
      </el-form-item>
      <el-row style="text-align: center;margin-top:-10px">
        <el-link type="primary">忘记密码</el-link>
        <el-link type="primary" @click="gotoRegister()">用户注册</el-link>
      </el-row>
    </el-form>
  </div>
</template>
<script>
  // import axios from 'axios'
 //    import qs from 'qs'
  export default {
    name:'login',
    data () {
      return {
        username:'',
      password:''
      }
    }
  ,methods:{
    gotoRegister(){
      this.$router.push('/register');
    },
    doSubmit(){
      let url=this.axios.urls.SYSTEM_USER_DOLOGIN;
      let params={
        username:this.username,
        password:this.password
      }
      // axios.get(url,{params:params}).then(r=>{
      //  console.log(r);
      //  if (r.data.success) {
      //    this.$message({
      //              message:r.data.msg,
      //              type: 'success'
      //            });
      //  }else{
      //     this.$message.error(r.data.msg);
      //  }
      // } ).catch(e=>{
      // })
      this.axios.post(url,params).then(r=>{
        console.log(r);
        if (r.data.success) {
          this.$message({
                    message:r.data.msg,
                    type: 'success'
                  });
        }else{
           this.$message.error(r.data.msg);
        }
      } ).catch(e=>{
      })
    }
  }
  }
</script>
<style scoped>
  .login-wrap {
    box-sizing: border-box;
    width: 100%;
    height: 100%;
    padding-top: 10%;
    /* background-color: #112346; */
    background-repeat: no-repeat;
    background-position: center right;
    background-size: 100%;
  }
  .login-container {
    border-radius: 10px;
    margin: 0px auto;
    width: 350px;
    padding: 30px 35px 15px 35px;
    background: #fff;
    border: 1px solid #eaeaea;
    text-align: left;
    box-shadow: 0 0 20px 2px rgba(0, 0, 0, 0.1);
  }
  .title {
    margin: 0px auto 40px auto;
    text-align: center;
    color: #505458;
  }
</style>

四、注册

简单介绍用户注册的功能和实现方

<template>
  <div class="register-container">
    <div class="register-card">
      <h2 class="register-title">注册</h2>
      <form @submit.prevent="register" class="register-form">
        <div class="form-group">
          <label for="username" class="register-label">用户名:</label>
          <input type="text" id="username" v-model="username" required class="register-input">
        </div>
        <div class="form-group">
          <label for="password" class="register-label">密码:</label>
          <input type="password" id="paassword" v-model="password" required class="register-input">
        </div>
        <div class="form-group">
          <label for="password" class="register-label">编号:</label>
          <input type="password" id="id" v-model="id" required class="register-input">
        </div>
        <button type="submit" class="register-button">注册</button>
      </form>
      <div class="login-link">
        <span>已有账号？</span>
         <el-link type="primary" @click="gotoLogin()">用户登录</el-link>
      </div>
    </div>
  </div>
</template>
<style>
.register-container {
  display: flex;
  flex-direction: column;
  align-items: center;
  justify-content: center;
  height: 100vh;
  background-color: #f5f5f5;
  box-shadow: 0 2px 4px rgba(0, 0, 0, 0.1);
}
.register-card {
  display: flex;
  flex-direction: column;
  align-items: center;
  background-color: #fff;
  padding: 40px 60px;
  border-radius: 8px;
  box-shadow: 0 2px 4px rgba(0, 0, 0, 0.1);
}
.register-title {
  font-size: 28px;
  color: #333;
  margin-bottom: 30px;
}
.register-form {
  display: flex;
  flex-direction: column;
  align-items: center;
}
.form-group {
  margin-bottom: 20px;
}
.register-label {
  font-size: 16px;
  color: #333;
  margin-bottom: 10px;
}
.register-input {
  padding: 10px;
  border: 1px solid #ccc;
  border-radius: 4px;
  width: 240px;
}
.register-button {
  padding: 12px 24px;
  background-color: #ff6700;
  color: #fff;
  border: none;
  border-radius: 4px;
  cursor: pointer;
  font-size: 16px;
}
.login-link {
  margin-top: 20px;
  display: flex;
  align-items: center;
  font-size: 14px;
}
.login-link span {
  color: #555;
  margin-right: 5px;
}
.login-button {
  color: #007bff;
  text-decoration: none;
}
.register-container {
  background-color: #000;
}
.register-card {
  background-color: #222;
  box-shadow: 0 2px 4px rgba(0, 0, 0, 0.1);
}
.register-title {
  color: #fff;
}
.register-label {
  color: #aaa;
}
.register-input {
  border: 1px solid #aaa;
}
.register-button {
  background-color: #000;
  color: #fff;
}
.login-link span {
  color: #aaa;
}
.login-button {
  color: #007bff;
}
</style>
<script>
export default {
  data() {
    return {
      username: '',
      password: '',
      id:''
    };
  },
  methods: {
    register() {
      let url = this.axios.urls.SYSTEM_USER_DOREG;
      let params = {
        username: this.username,
        password: this.password,
        id:this.id
      }
console.log(url)
        this.axios.post(url, params).then(r => {
          console.log(r)
          if (r.data.success) {
            this.$message({
              type: 'success',
              message: r.data.msg
            });
          }else{
            console.log(r)
            this.$message(r.data.msg)
          }
        }).catch(e => {
        })
    },
    gotoLogin(){
        this.$router.push('/');
    }
  }
};
</script>

后端代码

@RequestMapping("/useregister")
    @ResponseBody
    public JsonResponseBody<?> Register(User user, HttpServletResponse response) {
        if (user.getUsername() != null && user.getPassword() != null && user != null) {
            int n = userService.insertSelective(user);
            if (n > 0) {
                return new JsonResponseBody<>("注册成功！", true, 0, null);
            }
        }
        return new JsonResponseBody<>("用户名或密码错误！", false, 0, null);
    }

文章标签：
JavaScript
开发者
UED
前端开发
匿瘾
目录
相关文章
风吹落叶花飘荡
|
4月前
|
JavaScript 前端开发
Next js：点击登录显示登录表单，点击注册显示注册表单的功能
本文提供了一个Next.js中使用React状态管理实现点击按钮切换显示登录和注册表单的功能示例，包括创建`authform.tsx`组件和在页面组件中引入使用的方法。
风吹落叶花飘荡
97 0
code袁
|
7月前
|
前端开发 中间件 关系型数据库
node注册和登录你真的清楚了吗？
本文档介绍了创建MySQL数据表、安装配置MySQL模块的过程，并详细阐述了用户注册和登录的功能实现。注册功能包括表单数据校验、用户名占用检测、密码加密及用户插入。登录功能涉及密码判断、生成JWT Token以及使用express-jwt中间件进行Token解析。在整个过程中，还封装了一个错误处理函数用于统一响应错误信息。
code袁
50 2
node注册和登录你真的清楚了吗？
爱你三千遍斯塔克
|
6月前
|
前端开发 开发工具 git
大事件项目04-注册和登录两个页面的准备
大事件项目04-注册和登录两个页面的准备
爱你三千遍斯塔克
52 0
zjzaki
|
6月前
|
JSON JavaScript 前端开发
7.spa项目登录+注册(elementUI)
7.spa项目登录+注册(elementUI)
zjzaki
112 0
极客李华
|
7月前
|
SQL 前端开发 JavaScript
包含后端的登录与注册页面
包含后端的登录与注册页面
极客李华
63 0
懒大王o
|
JavaScript 前端开发 Java
Element登录+注册
Element登录+注册
懒大王o
132 0
姿势不太差
|
JavaScript 前端开发 Java
ElementUI之登录与注册
ElementUI之登录与注册
姿势不太差
328 0
Alone秋
|
存储 前端开发 JavaScript
ElementUI之登陆+注册
ElementUI之登陆+注册
Alone秋
160 0
一个大长腿.
|
数据安全/隐私保护
vue3-admin-element框架登录如何修改？
vue3-admin-element框架登录如何修改？
一个大长腿.
2032 0
流光220
|
SQL 前端开发 JavaScript
登录和注册的基本实现，超简单！
登录和注册的基本实现，超简单！
流光220
81 0

热门文章

最新文章

  • 1
    基于区块链的机器学习模型创建方案
  • 2
    性能的极致,Rust的加持,Zed-Dev编辑器快速搭建Python3.10开发环境
  • 3
    首届Global VR Hackathon完结 全球前三甲诞生
  • 4
    我的博客即将入驻“云栖社区”，诚邀技术同仁一同入驻。
  • 5
    iptables
  • 6
    DevExpress 10.2.4系列-ASPxListBox根据列值不同设置不同图标
  • 7
    jquery的load加载js页面到指定div中
  • 8
    分享平时工作中那些给力的shell命令（更新版）
  • 9
    如何在ubuntu下用SVN commit
  • 10
    hdu 1800 Flying to the Mars
  • 1
    《docker高级篇（大厂进阶）：2.DockerFile解析》包括：是什么、DockerFile构建过程解析、DockerFile常用保留字指令、案例、小总结
    115
  • 2
    《Java 人工智能开发：Eclipse 与 IntelliJ IDEA 双雄助力》
    46
  • 3
    《Java 在开源 AI 框架中的中流砥柱角色》
    36
  • 4
    《Java 与大数据框架：AI 数据预处理的强力联盟》
    39
  • 5
    《Java 优化秘籍：计算密集型 AI 任务加速指南》
    35
  • 6
    《Java 与 OpenAI 协同：开启智能编程新范式》
    31
  • 7
    uniapp开发鸿蒙，是前端新出路吗？
    31
  • 8
    鸿蒙(HarmonyOS)原生AI能力之文本识别
    39
  • 9
    鸿蒙开发之PixelMap介绍与实现图片变换
    34
  • 10
    鸿蒙(HarmonyOS)开发之无须申请权限写入图片到相册
    40

    • 相关电子书

    更多
  • 低代码开发师（初级）实战教程
  • 冬季实战营第三期：MySQL数据库进阶实战
  • 阿里巴巴DevOps 最佳实践手册
    • 下一篇
    【案例实战】SpringBoot整合阿里云文件上传OSS
