兄弟连区块链教程Fabric1.0源代码分析gRPC（Fabric中注册的gRPC Service）二

　　区块链教程Fabric1.0源代码分析gRPC（Fabric中注册的gRPC Service）二。

1.3、Endorser Service（背书服务）

1.3.1、Endorser Service客户端

type EndorserClient interface {
    ProcessProposal(ctx context.Context, in *SignedProposal, opts ...grpc.CallOption) (*ProposalResponse, error)
}

type endorserClient struct {
    cc *grpc.ClientConn
}

func NewEndorserClient(cc *grpc.ClientConn) EndorserClient {
    return &endorserClient{cc}
}

func (c *endorserClient) ProcessProposal(ctx context.Context, in *SignedProposal, opts ...grpc.CallOption) (*ProposalResponse, error) {
    out := new(ProposalResponse)
    err := grpc.Invoke(ctx, "/protos.Endorser/ProcessProposal", in, out, c.cc, opts...)
    if err != nil {
        return nil, err
    }
    return out, nil
}
//代码在protos/peer/peer.pb.go

1.3.2、Endorser Service服务端

type EndorserServer interface {
    ProcessProposal(context.Context, *SignedProposal) (*ProposalResponse, error)
}

func RegisterEndorserServer(s *grpc.Server, srv EndorserServer) {
    s.RegisterService(&_Endorser_serviceDesc, srv)
}

func _Endorser_ProcessProposal_Handler(srv interface{}, ctx context.Context, dec func(interface{}) error, interceptor grpc.UnaryServerInterceptor) (interface{}, error) {
    in := new(SignedProposal)
    if err := dec(in); err != nil {
        return nil, err
    }
    if interceptor == nil {
        return srv.(EndorserServer).ProcessProposal(ctx, in)
    }
    info := &grpc.UnaryServerInfo{
        Server:     srv,
        FullMethod: "/protos.Endorser/ProcessProposal",
    }
    handler := func(ctx context.Context, req interface{}) (interface{}, error) {
        return srv.(EndorserServer).ProcessProposal(ctx, req.(*SignedProposal))
    }
    return interceptor(ctx, in, info, handler)
}

var _Endorser_serviceDesc = grpc.ServiceDesc{
    ServiceName: "protos.Endorser",
    HandlerType: (*EndorserServer)(nil),
    Methods: []grpc.MethodDesc{
        {
            MethodName: "ProcessProposal",
            Handler:    _Endorser_ProcessProposal_Handler,
        },
    },
    Streams:  []grpc.StreamDesc{},
    Metadata: "peer/peer.proto",
}
//代码在protos/peer/peer.pb.go

1.4、ChaincodeSupport Service（链码支持服务）

1.4.1、ChaincodeSupport Service客户端

type ChaincodeSupportClient interface {
    Register(ctx context.Context, opts ...grpc.CallOption) (ChaincodeSupport_RegisterClient, error)
}

type chaincodeSupportClient struct {
    cc *grpc.ClientConn
}

func NewChaincodeSupportClient(cc *grpc.ClientConn) ChaincodeSupportClient {
    return &chaincodeSupportClient{cc}
}

func (c *chaincodeSupportClient) Register(ctx context.Context, opts ...grpc.CallOption) (ChaincodeSupport_RegisterClient, error) {
    stream, err := grpc.NewClientStream(ctx, &_ChaincodeSupport_serviceDesc.Streams[0], c.cc, "/protos.ChaincodeSupport/Register", opts...)
    if err != nil {
        return nil, err
    }
    x := &chaincodeSupportRegisterClient{stream}
    return x, nil
}
//代码在protos/peer/peer.pb.go

1.4.2、ChaincodeSupport Service服务端

type ChaincodeSupportServer interface {
    Register(ChaincodeSupport_RegisterServer) error
}

func RegisterChaincodeSupportServer(s *grpc.Server, srv ChaincodeSupportServer) {
    s.RegisterService(&_ChaincodeSupport_serviceDesc, srv)
}

func _ChaincodeSupport_Register_Handler(srv interface{}, stream grpc.ServerStream) error {
    return srv.(ChaincodeSupportServer).Register(&chaincodeSupportRegisterServer{stream})
}

var _ChaincodeSupport_serviceDesc = grpc.ServiceDesc{
    ServiceName: "protos.ChaincodeSupport",
    HandlerType: (*ChaincodeSupportServer)(nil),
    Methods:     []grpc.MethodDesc{},
    Streams: []grpc.StreamDesc{
        {
            StreamName:    "Register",
            Handler:       _ChaincodeSupport_Register_Handler,
            ServerStreams: true,
            ClientStreams: true,
        },
    },
    Metadata: "peer/chaincode_shim.proto",
}
//代码在protos/peer/peer.pb.go

1.5、Gossip Service（Gossip服务）

1.5.1、Gossip Service客户端

type GossipClient interface {
    // GossipStream is the gRPC stream used for sending and receiving messages
    GossipStream(ctx context.Context, opts ...grpc.CallOption) (Gossip_GossipStreamClient, error)
    // Ping is used to probe a remote peer's aliveness
    Ping(ctx context.Context, in *Empty, opts ...grpc.CallOption) (*Empty, error)
}

type gossipClient struct {
    cc *grpc.ClientConn
}

func NewGossipClient(cc *grpc.ClientConn) GossipClient {
    return &gossipClient{cc}
}

func (c *gossipClient) GossipStream(ctx context.Context, opts ...grpc.CallOption) (Gossip_GossipStreamClient, error) {
    stream, err := grpc.NewClientStream(ctx, &_Gossip_serviceDesc.Streams[0], c.cc, "/gossip.Gossip/GossipStream", opts...)
    if err != nil {
        return nil, err
    }
    x := &gossipGossipStreamClient{stream}
    return x, nil
}

type Gossip_GossipStreamClient interface {
    Send(*Envelope) error
    Recv() (*Envelope, error)
    grpc.ClientStream
}

type gossipGossipStreamClient struct {
    grpc.ClientStream
}

func (x *gossipGossipStreamClient) Send(m *Envelope) error {
    return x.ClientStream.SendMsg(m)
}

func (x *gossipGossipStreamClient) Recv() (*Envelope, error) {
    m := new(Envelope)
    if err := x.ClientStream.RecvMsg(m); err != nil {
        return nil, err
    }
    return m, nil
}

func (c *gossipClient) Ping(ctx context.Context, in *Empty, opts ...grpc.CallOption) (*Empty, error) {
    out := new(Empty)
    err := grpc.Invoke(ctx, "/gossip.Gossip/Ping", in, out, c.cc, opts...)
    if err != nil {
        return nil, err
    }
    return out, nil
}
//代码在protos/gossip/message.pb.go

1.5.2、Gossip Serviced服务端

type GossipServer interface {
    // GossipStream is the gRPC stream used for sending and receiving messages
    GossipStream(Gossip_GossipStreamServer) error
    // Ping is used to probe a remote peer's aliveness
    Ping(context.Context, *Empty) (*Empty, error)
}

func RegisterGossipServer(s *grpc.Server, srv GossipServer) {
    s.RegisterService(&_Gossip_serviceDesc, srv)
}

func _Gossip_GossipStream_Handler(srv interface{}, stream grpc.ServerStream) error {
    return srv.(GossipServer).GossipStream(&gossipGossipStreamServer{stream})
}

type Gossip_GossipStreamServer interface {
    Send(*Envelope) error
    Recv() (*Envelope, error)
    grpc.ServerStream
}

type gossipGossipStreamServer struct {
    grpc.ServerStream
}

func (x *gossipGossipStreamServer) Send(m *Envelope) error {
    return x.ServerStream.SendMsg(m)
}

func (x *gossipGossipStreamServer) Recv() (*Envelope, error) {
    m := new(Envelope)
    if err := x.ServerStream.RecvMsg(m); err != nil {
        return nil, err
    }
    return m, nil
}

func _Gossip_Ping_Handler(srv interface{}, ctx context.Context, dec func(interface{}) error, interceptor grpc.UnaryServerInterceptor) (interface{}, error) {
    in := new(Empty)
    if err := dec(in); err != nil {
        return nil, err
    }
    if interceptor == nil {
        return srv.(GossipServer).Ping(ctx, in)
    }
    info := &grpc.UnaryServerInfo{
        Server:     srv,
        FullMethod: "/gossip.Gossip/Ping",
    }
    handler := func(ctx context.Context, req interface{}) (interface{}, error) {
        return srv.(GossipServer).Ping(ctx, req.(*Empty))
    }
    return interceptor(ctx, in, info, handler)
}

var _Gossip_serviceDesc = grpc.ServiceDesc{
    ServiceName: "gossip.Gossip",
    HandlerType: (*GossipServer)(nil),
    Methods: []grpc.MethodDesc{
        {
            MethodName: "Ping",
            Handler:    _Gossip_Ping_Handler,
        },
    },
    Streams: []grpc.StreamDesc{
        {
            StreamName:    "GossipStream",
            Handler:       _Gossip_GossipStream_Handler,
            ServerStreams: true,
            ClientStreams: true,
        },
    },
    Metadata: "gossip/message.proto",
}
//代码在protos/gossip/message.pb.go

2、Orderer节点中注册的gRPC Service

2.1、AtomicBroadcast Service（广播服务）

2.1.1、AtomicBroadcast Service客户端

type AtomicBroadcastClient interface {
    // broadcast receives a reply of Acknowledgement for each common.Envelope in order, indicating success or type of failure
    Broadcast(ctx context.Context, opts ...grpc.CallOption) (AtomicBroadcast_BroadcastClient, error)
    // deliver first requires an Envelope of type DELIVER_SEEK_INFO with Payload data as a mashaled SeekInfo message, then a stream of block replies is received.
    Deliver(ctx context.Context, opts ...grpc.CallOption) (AtomicBroadcast_DeliverClient, error)
}

type atomicBroadcastClient struct {
    cc *grpc.ClientConn
}

func NewAtomicBroadcastClient(cc *grpc.ClientConn) AtomicBroadcastClient {
    return &atomicBroadcastClient{cc}
}

func (c *atomicBroadcastClient) Broadcast(ctx context.Context, opts ...grpc.CallOption) (AtomicBroadcast_BroadcastClient, error) {
    stream, err := grpc.NewClientStream(ctx, &_AtomicBroadcast_serviceDesc.Streams[0], c.cc, "/orderer.AtomicBroadcast/Broadcast", opts...)
    if err != nil {
        return nil, err
    }
    x := &atomicBroadcastBroadcastClient{stream}
    return x, nil
}

func (c *atomicBroadcastClient) Deliver(ctx context.Context, opts ...grpc.CallOption) (AtomicBroadcast_DeliverClient, error) {
    stream, err := grpc.NewClientStream(ctx, &_AtomicBroadcast_serviceDesc.Streams[1], c.cc, "/orderer.AtomicBroadcast/Deliver", opts...)
    if err != nil {
        return nil, err
    }
    x := &atomicBroadcastDeliverClient{stream}
    return x, nil
}
//代码在protos/orderer/ab.pb.go

2.1.2、AtomicBroadcast Service服务端

type AtomicBroadcastServer interface {
    // broadcast receives a reply of Acknowledgement for each common.Envelope in order, indicating success or type of failure
    Broadcast(AtomicBroadcast_BroadcastServer) error
    // deliver first requires an Envelope of type DELIVER_SEEK_INFO with Payload data as a mashaled SeekInfo message, then a stream of block replies is received.
    Deliver(AtomicBroadcast_DeliverServer) error
}

func RegisterAtomicBroadcastServer(s *grpc.Server, srv AtomicBroadcastServer) {
    s.RegisterService(&_AtomicBroadcast_serviceDesc, srv)
}

func _AtomicBroadcast_Broadcast_Handler(srv interface{}, stream grpc.ServerStream) error {
    return srv.(AtomicBroadcastServer).Broadcast(&atomicBroadcastBroadcastServer{stream})
}

func _AtomicBroadcast_Deliver_Handler(srv interface{}, stream grpc.ServerStream) error {
    return srv.(AtomicBroadcastServer).Deliver(&atomicBroadcastDeliverServer{stream})
}

var _AtomicBroadcast_serviceDesc = grpc.ServiceDesc{
    ServiceName: "orderer.AtomicBroadcast",
    HandlerType: (*AtomicBroadcastServer)(nil),
    Methods:     []grpc.MethodDesc{},
    Streams: []grpc.StreamDesc{
        {
            StreamName:    "Broadcast",
            Handler:       _AtomicBroadcast_Broadcast_Handler,
            ServerStreams: true,
            ClientStreams: true,
        },
        {
            StreamName:    "Deliver",
            Handler:       _AtomicBroadcast_Deliver_Handler,
            ServerStreams: true,
            ClientStreams: true,
        },
    },
    Metadata: "orderer/ab.proto",
}
//代码在protos/orderer/ab.pb.go

感谢关注兄弟连区块链教程分享！
