react-grapesjs——开源代码学习与修改(初出茅庐)(一)

简介: react-grapesjs——开源代码学习与修改(初出茅庐)

⭐前言

大家好,我是yma16,本文分享关于react-grapesjs——源码学习。

该系列往期文章:

react搭建在线编辑html的站点——引入grapes实现在线拖拉拽编辑html

结果演示:

https://yongma16.xyz/react-mjml/

⭐grapesjs初始化过程

源码:https://github.com/GrapesJS/grapesjs

目录结构

运行源码

💖 渲染大体流程

💖 Editor对象 创建
  1. new Editor进入 Editor对象
  2. class Editor implements IBaseModule 执行构造函数 constructor
constructor(config: EditorConfig = {}, opts: any = {}) {
    this.config = {
      ...defaults,
      ...config,
      pStylePrefix: config.stylePrefix ?? defaults.stylePrefix,
    };
    this.em = new EditorModel(this.config);
    this.$ = opts.$;
    this.em.init(this);
    this.editor = this.em;
  }
💖 EditorModel 对象创建
  1. class EditorModel extends Model 执行构造函数
constructor(conf: EditorConfig = {}) {
   super();
   this._config = conf;
   const { config } = this;
   this.set('Config', conf);
   this.set('modules', []);
   this.set('toLoad', []);
   this.set('storables', []);
   this.set('selected', new Selected());
   this.set('dmode', config.dragMode);
   const { el, log } = config;
   const toLog = log === true ? keys(logs) : isArray(log) ? log : [];
   bindAll(this, 'initBaseColorPicker');
   if (el && config.fromElement) {
     config.components = el.innerHTML;
   }
   this.attrsOrig = el
     ? toArray(el.attributes).reduce((res, next) => {
         res[next.nodeName] = next.nodeValue;
         return res;
       }, {} as Record<string, any>)
     : '';
   // Move components to pages
   if (config.components && !config.pageManager) {
     config.pageManager = { pages: [{ component: config.components }] };
   }
   // Load modules
   deps.forEach(constr => this.loadModule(constr));
   storableDeps.forEach(constr => this.loadStorableModule(constr));
   this.on('change:componentHovered', this.componentHovered, this);
   this.on('change:changesCount', this.updateChanges, this);
   this.on('change:readyLoad change:readyCanvas', this._checkReady, this);
   toLog.forEach(e => this.listenLog(e));
   // Deprecations
   [{ from: 'change:selectedComponent', to: 'component:toggled' }].forEach(event => {
     const eventFrom = event.from;
     const eventTo = event.to;
     this.listenTo(this, eventFrom, (...args) => {
       this.trigger(eventTo, ...args);
       this.logWarning(`The event '${eventFrom}' is deprecated, replace it with '${eventTo}'`);
     });
   });
 }
💖 load modules 加载定义的目录模块Module

deps的类型

const deps: (new (em: EditorModel) => IModule)[] = [
  UtilsModule,
  I18nModule,
  KeymapsModule,
  UndoManagerModule,
  StorageManager,
  DeviceManager,
  ParserModule,
  StyleManager,
  SelectorManager,
  ModalModule,
  CodeManagerModule,
  PanelManager,
  RichTextEditorModule,
  TraitManager,
  LayerManager,
  CanvasModule,
  CommandsModule,
  BlockManager,
];
// Load modules
    deps.forEach(constr => this.loadModule(constr));
💖 StyleManager渲染过程

路径 src/style_manager

构造函数

constructor(em: EditorModel) {
    super(em, 'StyleManager', new Sectors([], { em }), stylesEvents, defaults);
    bindAll(this, '__clearStateTarget');
    const c = this.config;
    const ppfx = c.pStylePrefix;
    if (ppfx) c.stylePrefix = ppfx + c.stylePrefix;
    this.builtIn = new PropertyFactory();
    this.properties = new Properties([], { em, module: this });
    this.sectors = this.all; // TODO check if (module: this) is required
    const model = new Model({ targets: [] });
    this.model = model;
    // Triggers for the selection refresh and properties
    const ev = 'component:toggled component:update:classes change:state change:device frame:resized selector:type';
    this.upAll = debounce(() => this.__upSel(), 0);
    model.listenTo(em, ev, this.upAll as any);
    // Clear state target on any component selection change, without debounce (#4208)
    model.listenTo(em, 'component:toggled', this.__clearStateTarget);
    // Triggers only for properties (avoid selection refresh)
    const upProps = debounce(() => {
      this.__upProps();
      this.__trgCustom();
    }, 0);
    model.listenTo(em, 'styleable:change undo redo', upProps);
    // Triggers only custom event
    const trgCustom = debounce(() => this.__trgCustom(), 0);
    model.listenTo(em, `${evLayerSelect} ${evTarget}`, trgCustom);
    // Other listeners
    model.on('change:lastTarget', () => em.trigger(evTarget, this.getSelected()));
  }


react-grapesjs——开源代码学习与修改(初出茅庐)(二)https://developer.aliyun.com/article/1492697
