Qt Creator plugin动手实践（2）自己动手写qt creator插件，实现自定义工具栏按钮

DEFINES += FIRECAT_TOOLBAR_LIBRARY
# firecat_Toolbar files
SOURCES += \
        firecat_toolbarplugin.cpp
HEADERS += \
        firecat_toolbarplugin.h \
        firecat_toolbar_global.h \
        firecat_toolbarconstants.h
# Qt Creator linking
## Either set the IDE_SOURCE_TREE when running qmake,
## or set the QTC_SOURCE environment variable, to override the default setting
#isEmpty(IDE_SOURCE_TREE): IDE_SOURCE_TREE = $$(QTC_SOURCE)#必须注释掉这句话
isEmpty(IDE_SOURCE_TREE): IDE_SOURCE_TREE = "D:/temp/qt-creator-opensource-src-4.8.2"#指向Qt Creator源码路径
## Either set the IDE_BUILD_TREE when running qmake,
## or set the QTC_BUILD environment variable, to override the default setting
#isEmpty(IDE_BUILD_TREE): IDE_BUILD_TREE = $$(QTC_BUILD)#必须注释掉这句话
#isEmpty(IDE_BUILD_TREE): IDE_BUILD_TREE = "D:/temp/build_plugins"#必须注释掉这句话
Debug:isEmpty(IDE_BUILD_TREE): IDE_BUILD_TREE = "D:/temp/build_plugins/debug/"#自定义Debug生成路径
Release:isEmpty(IDE_BUILD_TREE): IDE_BUILD_TREE = "D:/temp/build_plugins/release/"#自定义Release生成路径
## uncomment to build plugin into user config directory
## <localappdata>/plugins/<ideversion>
##    where <localappdata> is e.g.
##    "%LOCALAPPDATA%\QtProject\qtcreator" on Windows Vista and later
##    "$XDG_DATA_HOME/data/QtProject/qtcreator" or "~/.local/share/data/QtProject/qtcreator" on Linux
##    "~/Library/Application Support/QtProject/Qt Creator" on OS X
#USE_USER_DESTDIR = yes #必须注释掉这句话,否则插件会生成在默认的路径,即C:\Users\firecat\AppData\Local\QtProject\QtCreator\plugins\4.8.2
###### If the plugin can be depended upon by other plugins, this code needs to be outsourced to
###### <dirname>_dependencies.pri, where <dirname> is the name of the directory containing the
###### plugin's sources.
QTC_PLUGIN_NAME = firecat_Toolbar
QTC_LIB_DEPENDS += \
    # nothing here at this time
QTC_PLUGIN_DEPENDS += \
    coreplugin
QTC_PLUGIN_RECOMMENDS += \
    # optional plugin dependencies. nothing here at this time
###### End _dependencies.pri contents ######
include($$IDE_SOURCE_TREE/src/qtcreatorplugin.pri)
RESOURCES += \
    res.qrc

bool firecat_ToolbarPlugin::initialize(const QStringList &arguments, QString *errorString)
{
    // Register objects in the plugin manager's object pool
    // Load settings
    // Add actions to menus
    // Connect to other plugins' signals
    // In the initialize function, a plugin can be sure that the plugins it
    // depends on have initialized their members.
    Q_UNUSED(arguments)
    Q_UNUSED(errorString)
    //我们把RunWithoutDeploy这个方法提携到工具栏,方便使用
    const char id1[] = "ProjectExplorer.RunWithoutDeploy";//这个id对应的是Qt Creator源码的const char RUNWITHOUTDEPLOY[]
    QAction *act1 = Core::ActionManager::command(id1)->action();//对应Qt Creator源码的m_runWithoutDeployAction
    if (act1 == NULL)
    {
        return false;
    }
    const Utils::Icon CLASSIC1(":/image/mode_run.png");//32位图片,34*34像素
    const Utils::Icon FLAT1({{":/image/mode_run_mask.png", Utils::Theme::IconsRunToolBarColor}});//8位图片,34*34像素
    const Utils::Icon FLAT_ACTIVE1({{":/image/mode_run_mask.png", Utils::Theme::IconsModeWelcomeActiveColor}});
    act1->setIcon(Utils::Icon::modeIcon(CLASSIC1, FLAT1, FLAT_ACTIVE1));
    //act1->setIcon(Utils::Icon::sideBarIcon(CLASSIC1, FLAT1));
    act1->setVisible(true);
    Core::ModeManager::addAction(act1, 130);
    //我们把DebugWithoutDeploy这个方法提携到工具栏,方便使用
    const char id2[] = "Debugger.DebugWithoutDeploy";
    QAction *act2 = Core::ActionManager::command(id2)->action();//对应Qt Creator源码的m_debugWithoutDeployAction
    if (act2 == NULL)
    {
        return false;
    }
    const Utils::Icon CLASSIC2(":/image/mode_debug.png");
    const Utils::Icon FLAT2({{":/image/mode_debug_mask.png", Utils::Theme::IconsRunToolBarColor}});
    const Utils::Icon FLAT_ACTIVE2({{":/image/mode_debug_mask.png", Utils::Theme::IconsModeWelcomeActiveColor}});
    act2->setIcon(Utils::Icon::modeIcon(CLASSIC2, FLAT2, FLAT_ACTIVE2));
    //act2->setIcon(Utils::Icon::sideBarIcon(CLASSIC2, FLAT2));
    act2->setVisible(true);
    Core::ModeManager::addAction(act2, 120);
    //我们把微软计算器提携到工具栏,方便使用
#if defined(Q_OS_WIN32)
    QAction *act3 = new QAction(tr("calc"), this);
    const Utils::Icon CLASSIC3(":/image/mode_calc.png");
    const Utils::Icon FLAT3({{":/image/mode_calc_mask.png", Utils::Theme::IconsRunToolBarColor}});
    const Utils::Icon FLAT_ACTIVE3({{":/image/mode_calc_mask.png", Utils::Theme::IconsModeWelcomeActiveColor}});
    act3->setIcon(Utils::Icon::modeIcon(CLASSIC3, FLAT3, FLAT_ACTIVE3));
    //act3->setIcon(Utils::Icon::sideBarIcon(CLASSIC3, FLAT3));
    act3->setVisible(true);
    //QStandardPaths::standardLocations(QStandardPaths::DesktopLocation);//Qt自身没有提供System32的路径
    wchar_t szPath[MAX_PATH] ={0};
    GetSystemDirectory(szPath, MAX_PATH);
    QString path = QString::fromWCharArray(szPath);
    connect(act3, &QAction::triggered, this, [=]() {
        QProcess *poc = new QProcess;
        poc->start(path + "\\calc.exe");//即"C:\\Windows\\system32\\calc.exe"
    });
    Core::ModeManager::addAction(act3, 150);
#endif
    // 因为Qt Creator源码有定义位置摆放的优先级
    // Action priorities
    //const int  P_ACTION_RUN            = 100;
    //const int  P_ACTION_BUILDPROJECT   = 80;
    //const int  P_ACTION_DEBUG          = 90; // Priority for the modemanager.
    //ModeManager::addAction(cmd->action(), Constants::P_ACTION_RUN);
    return true;
}

{
    \"Name\" : \"firecat_Toolbar\",
    \"Version\" : \"$$QTCREATOR_VERSION$$VERSION_SUFFIX\",
    \"CompatVersion\" : \"$$QTCREATOR_COMPAT_VERSION\",
    \"Vendor\" : \"firecatStudio\",
    \"Copyright\" : \"firecatStudio\",
    \"License\" : \"\",
    \"Description\" : \"\",
    \"Url\" : \"\",
    $$dependencyList
}
