Kubernetes容器运行时接口-CRI

本文涉及的产品
容器镜像服务 ACR,镜像仓库100个 不限时长
简介: Kubernetes提供了多种容器开放接口用于对接不同的后端来提供资源,如提供计算资源的容器运行时接口(Container Runtime Interface, CRI),提供网络资源的容器网络接口(Container Network Interface, CNI),提供提供存储资源的容器存储接口(Container Storage Interface, CSI)。

CRI 简介

在 Kubernetes1.5 之前 Docker 作为第一个容器运行时,Kubelet 通过内嵌 dockershim 操作容器API,但随着越来越多的容器运行时的希望加入kubelet,社区开始有人提出通过加入一个client/server接口来抽象容器运行时。在 v1.6.0 后, Kubernetes 开始默认启用 CRI(容器运行时接口),下图是容器运行时在 kubernets 中得作用。


CRI 架构介绍

以下主要介绍Kubernetes1.18版的CRI

CRI 为 kubelet 提供一套抽象的容器调度的接口,CRI 主要承接 kubelet 对容器的操作。CRI 得通信协议是 gRPC,当时主要考虑到性能问题。加入 CRI 后 kubelet 得架构如下图所示。

Kubelet 现在主要包含两个运行时的模块,一个是 dockershim, 一个是 remote。dockershim 是原来的提供Docker的运行时接口(PS: docker果然还是一等公民🤭:)。remote包对应的就是 CRI 接口,采用gRPC,通过 RemoteRuntime 和 CRI RuntimeService相连:

...
// createAndStartFakeRemoteRuntime creates and starts fakeremote.RemoteRuntime.
// It returns the RemoteRuntime, endpoint on success.
// Users should call fakeRuntime.Stop() to cleanup the server.
func createAndStartFakeRemoteRuntime(t *testing.T) (*fakeremote.RemoteRuntime, string) {
    endpoint, err := fakeremote.GenerateEndpoint()
    require.NoError(t, err)

    fakeRuntime := fakeremote.NewFakeRemoteRuntime()
    fakeRuntime.Start(endpoint)

    return fakeRuntime, endpoint
}

func createRemoteRuntimeService(endpoint string, t *testing.T) internalapi.RuntimeService {
    runtimeService, err := NewRemoteRuntimeService(endpoint, defaultConnectionTimeout)
    require.NoError(t, err)

    return runtimeService
}

func TestVersion(t *testing.T) {
    fakeRuntime, endpoint := createAndStartFakeRemoteRuntime(t)
    defer fakeRuntime.Stop()

    r := createRemoteRuntimeService(endpoint, t)
    version, err := r.Version(apitest.FakeVersion)
    assert.NoError(t, err)
    assert.Equal(t, apitest.FakeVersion, version.Version)
    assert.Equal(t, apitest.FakeRuntimeName, version.RuntimeName)
}

CRI 容器运行时的三类行为

CRI 容器运行时主要描述了三种服务的行为 Sandbox、Container、Image:

Sandbox:

// PodSandboxManager contains methods for operating on PodSandboxes. The methods
// are thread-safe.
type PodSandboxManager interface {
    // RunPodSandbox creates and starts a pod-level sandbox. Runtimes should ensure
    // the sandbox is in ready state.
    RunPodSandbox(config *runtimeapi.PodSandboxConfig, runtimeHandler string) (string, error)
    // StopPodSandbox stops the sandbox. If there are any running containers in the
    // sandbox, they should be force terminated.
    StopPodSandbox(podSandboxID string) error
    // RemovePodSandbox removes the sandbox. If there are running containers in the
    // sandbox, they should be forcibly removed.
    RemovePodSandbox(podSandboxID string) error
    // PodSandboxStatus returns the Status of the PodSandbox.
    PodSandboxStatus(podSandboxID string) (*runtimeapi.PodSandboxStatus, error)
    // ListPodSandbox returns a list of Sandbox.
    ListPodSandbox(filter *runtimeapi.PodSandboxFilter) ([]*runtimeapi.PodSandbox, error)
    // PortForward prepares a streaming endpoint to forward ports from a PodSandbox, and returns the address.
    PortForward(*runtimeapi.PortForwardRequest) (*runtimeapi.PortForwardResponse, error)
}

Container:

// ContainerManager contains methods to manipulate containers managed by a
// container runtime. The methods are thread-safe.
type ContainerManager interface {
    // CreateContainer creates a new container in specified PodSandbox.
    CreateContainer(podSandboxID string, config *runtimeapi.ContainerConfig, sandboxConfig *runtimeapi.PodSandboxConfig) (string, error)
    // StartContainer starts the container.
    StartContainer(containerID string) error
    // StopContainer stops a running container with a grace period (i.e., timeout).
    StopContainer(containerID string, timeout int64) error
    // RemoveContainer removes the container.
    RemoveContainer(containerID string) error
    // ListContainers lists all containers by filters.
    ListContainers(filter *runtimeapi.ContainerFilter) ([]*runtimeapi.Container, error)
    // ContainerStatus returns the status of the container.
    ContainerStatus(containerID string) (*runtimeapi.ContainerStatus, error)
    // UpdateContainerResources updates the cgroup resources for the container.
    UpdateContainerResources(containerID string, resources *runtimeapi.LinuxContainerResources) error
    // ExecSync executes a command in the container, and returns the stdout output.
    // If command exits with a non-zero exit code, an error is returned.
    ExecSync(containerID string, cmd []string, timeout time.Duration) (stdout []byte, stderr []byte, err error)
    // Exec prepares a streaming endpoint to execute a command in the container, and returns the address.
    Exec(*runtimeapi.ExecRequest) (*runtimeapi.ExecResponse, error)
    // Attach prepares a streaming endpoint to attach to a running container, and returns the address.
    Attach(req *runtimeapi.AttachRequest) (*runtimeapi.AttachResponse, error)
    // ReopenContainerLog asks runtime to reopen the stdout/stderr log file
    // for the container. If it returns error, new container log file MUST NOT
    // be created.
    ReopenContainerLog(ContainerID string) error
}

Image:

// ImageManagerService interface should be implemented by a container image
// manager.
// The methods should be thread-safe.
type ImageManagerService interface {
    // ListImages lists the existing images.
    ListImages(filter *runtimeapi.ImageFilter) ([]*runtimeapi.Image, error)
    // ImageStatus returns the status of the image.
    ImageStatus(image *runtimeapi.ImageSpec) (*runtimeapi.Image, error)
    // PullImage pulls an image with the authentication config.
    PullImage(image *runtimeapi.ImageSpec, auth *runtimeapi.AuthConfig, podSandboxConfig *runtimeapi.PodSandboxConfig) (string, error)
    // RemoveImage removes the image.
    RemoveImage(image *runtimeapi.ImageSpec) error
    // ImageFsInfo returns information of the filesystem that is used to store images.
    ImageFsInfo() ([]*runtimeapi.FilesystemUsage, error)
}

CRI 容器生命周期操作流程

kubelet创建一个Pod主要可以拆解成:

  1. 调用RunPodSandox创建一个pod沙盒
  2. 调用CreateContainer创建一个容器
  3. 调用StartContainer启动一个容器

CRI Streaming接口

streaming接口主要是用于执行 exec 命令,exec 命令主要用于 attach 容器进行交互,通过流式接口的可以节省资源,提高连接的可靠性。
kubelet 调用 Exec() 接口发给 RuntimeService ,RuntimeService 返回一个 url 给到 apiserver, 让 apiserver 跟 Stream Server 直接建立连接,获取流式数据。 由于绕过了kubelet,因此Stream Server 也提高连接的可靠性
CRI 中 Exec() 接口:

// ContainerManager contains methods to manipulate containers managed by a
// container runtime. The methods are thread-safe.
type ContainerManager interface {
    ...
    // Exec prepares a streaming endpoint to execute a command in the container, and returns the address.
    Exec(*runtimeapi.ExecRequest) (*runtimeapi.ExecResponse, error)
    // Attach prepares a streaming endpoint to attach to a running container, and returns the address.
    Attach(req *runtimeapi.AttachRequest) (*runtimeapi.AttachResponse, error)
    ...
}


CRI proto接口定义

CRI 是一个为kubelet提供的一个广泛的容器运行时的无需编译的接口插件。 CRI 包含了一个 protocol buffers 和 gRPC API。kubernetes1.18的 CRI 代码路径:kubernetes/staging/src/k8s.io/cri-api/
CRI中定义了容器和镜像的服务的接口,因为容器运行时与镜像的生命周期是彼此隔离的,因此需要定义两个服务 RuntimeService 和 ImageService。

RuntimeService的proto接口定义文件

// Runtime service defines the public APIs for remote container runtimes
service RuntimeService {
    // Version returns the runtime name, runtime version, and runtime API version.
    rpc Version(VersionRequest) returns (VersionResponse) {}

    // RunPodSandbox creates and starts a pod-level sandbox. Runtimes must ensure
    // the sandbox is in the ready state on success.
    rpc RunPodSandbox(RunPodSandboxRequest) returns (RunPodSandboxResponse) {}
    // StopPodSandbox stops any running process that is part of the sandbox and
    // reclaims network resources (e.g., IP addresses) allocated to the sandbox.
    // If there are any running containers in the sandbox, they must be forcibly
    // terminated.
    // This call is idempotent, and must not return an error if all relevant
    // resources have already been reclaimed. kubelet will call StopPodSandbox
    // at least once before calling RemovePodSandbox. It will also attempt to
    // reclaim resources eagerly, as soon as a sandbox is not needed. Hence,
    // multiple StopPodSandbox calls are expected.
    rpc StopPodSandbox(StopPodSandboxRequest) returns (StopPodSandboxResponse) {}
    // RemovePodSandbox removes the sandbox. If there are any running containers
    // in the sandbox, they must be forcibly terminated and removed.
    // This call is idempotent, and must not return an error if the sandbox has
    // already been removed.
    rpc RemovePodSandbox(RemovePodSandboxRequest) returns (RemovePodSandboxResponse) {}
    // PodSandboxStatus returns the status of the PodSandbox. If the PodSandbox is not
    // present, returns an error.
    rpc PodSandboxStatus(PodSandboxStatusRequest) returns (PodSandboxStatusResponse) {}
    // ListPodSandbox returns a list of PodSandboxes.
    rpc ListPodSandbox(ListPodSandboxRequest) returns (ListPodSandboxResponse) {}

    // CreateContainer creates a new container in specified PodSandbox
    rpc CreateContainer(CreateContainerRequest) returns (CreateContainerResponse) {}
    // StartContainer starts the container.
    rpc StartContainer(StartContainerRequest) returns (StartContainerResponse) {}
    // StopContainer stops a running container with a grace period (i.e., timeout).
    // This call is idempotent, and must not return an error if the container has
    // already been stopped.
    // TODO: what must the runtime do after the grace period is reached?
    rpc StopContainer(StopContainerRequest) returns (StopContainerResponse) {}
    // RemoveContainer removes the container. If the container is running, the
    // container must be forcibly removed.
    // This call is idempotent, and must not return an error if the container has
    // already been removed.
    rpc RemoveContainer(RemoveContainerRequest) returns (RemoveContainerResponse) {}
    // ListContainers lists all containers by filters.
    rpc ListContainers(ListContainersRequest) returns (ListContainersResponse) {}
    // ContainerStatus returns status of the container. If the container is not
    // present, returns an error.
    rpc ContainerStatus(ContainerStatusRequest) returns (ContainerStatusResponse) {}
    // UpdateContainerResources updates ContainerConfig of the container.
    rpc UpdateContainerResources(UpdateContainerResourcesRequest) returns (UpdateContainerResourcesResponse) {}
    // ReopenContainerLog asks runtime to reopen the stdout/stderr log file
    // for the container. This is often called after the log file has been
    // rotated. If the container is not running, container runtime can choose
    // to either create a new log file and return nil, or return an error.
    // Once it returns error, new container log file MUST NOT be created.
    rpc ReopenContainerLog(ReopenContainerLogRequest) returns (ReopenContainerLogResponse) {}

    // ExecSync runs a command in a container synchronously.
    rpc ExecSync(ExecSyncRequest) returns (ExecSyncResponse) {}
    // Exec prepares a streaming endpoint to execute a command in the container.
    rpc Exec(ExecRequest) returns (ExecResponse) {}
    // Attach prepares a streaming endpoint to attach to a running container.
    rpc Attach(AttachRequest) returns (AttachResponse) {}
    // PortForward prepares a streaming endpoint to forward ports from a PodSandbox.
    rpc PortForward(PortForwardRequest) returns (PortForwardResponse) {}

    // ContainerStats returns stats of the container. If the container does not
    // exist, the call returns an error.
    rpc ContainerStats(ContainerStatsRequest) returns (ContainerStatsResponse) {}
    // ListContainerStats returns stats of all running containers.
    rpc ListContainerStats(ListContainerStatsRequest) returns (ListContainerStatsResponse) {}

    // UpdateRuntimeConfig updates the runtime configuration based on the given request.
    rpc UpdateRuntimeConfig(UpdateRuntimeConfigRequest) returns (UpdateRuntimeConfigResponse) {}

    // Status returns the status of the runtime.
    rpc Status(StatusRequest) returns (StatusResponse) {}
}

ImageService 的 proto 接口定义文件:

// ImageService defines the public APIs for managing images.
service ImageService {
    // ListImages lists existing images.
    rpc ListImages(ListImagesRequest) returns (ListImagesResponse) {}
    // ImageStatus returns the status of the image. If the image is not
    // present, returns a response with ImageStatusResponse.Image set to
    // nil.
    rpc ImageStatus(ImageStatusRequest) returns (ImageStatusResponse) {}
    // PullImage pulls an image with authentication config.
    rpc PullImage(PullImageRequest) returns (PullImageResponse) {}
    // RemoveImage removes the image.
    // This call is idempotent, and must not return an error if the image has
    // already been removed.
    rpc RemoveImage(RemoveImageRequest) returns (RemoveImageResponse) {}
    // ImageFSInfo returns information of the filesystem that is used to store images.
    rpc ImageFsInfo(ImageFsInfoRequest) returns (ImageFsInfoResponse) {}
}

CRI工具介绍

  • CRI命令工具:crictl,帮助用户和开发者调试容器问题
  • CRI测试工具:critest,用于验证CRI接口的测试工具,验证是否满足Kubelet要求。

crictl 安装:

VERSION="v1.17.0"
wget https://github.com/kubernetes-sigs/cri-tools/releases/download/$VERSION/crictl-$VERSION-linux-amd64.tar.gz
sudo tar zxvf crictl-$VERSION-linux-amd64.tar.gz -C /usr/local/bin
rm -f crictl-$VERSION-linux-amd64.tar.gz

critest 安装:

VERSION="v1.17.0"
wget https://github.com/kubernetes-sigs/cri-tools/releases/download/$VERSION/critest-$VERSION-linux-amd64.tar.gz
sudo tar zxvf critest-$VERSION-linux-amd64.tar.gz -C /usr/local/bin
rm -f critest-$VERSION-linux-amd64.tar.gz

参考文献

相关实践学习
深入解析Docker容器化技术
Docker是一个开源的应用容器引擎,让开发者可以打包他们的应用以及依赖包到一个可移植的容器中,然后发布到任何流行的Linux机器上,也可以实现虚拟化,容器是完全使用沙箱机制,相互之间不会有任何接口。Docker是世界领先的软件容器平台。开发人员利用Docker可以消除协作编码时“在我的机器上可正常工作”的问题。运维人员利用Docker可以在隔离容器中并行运行和管理应用,获得更好的计算密度。企业利用Docker可以构建敏捷的软件交付管道,以更快的速度、更高的安全性和可靠的信誉为Linux和Windows Server应用发布新功能。 在本套课程中,我们将全面的讲解Docker技术栈,从环境安装到容器、镜像操作以及生产环境如何部署开发的微服务应用。本课程由黑马程序员提供。     相关的阿里云产品:容器服务 ACK 容器服务 Kubernetes 版(简称 ACK)提供高性能可伸缩的容器应用管理能力,支持企业级容器化应用的全生命周期管理。整合阿里云虚拟化、存储、网络和安全能力,打造云端最佳容器化应用运行环境。 了解产品详情: https://www.aliyun.com/product/kubernetes
目录
相关文章
|
数据可视化 大数据 BI
数据可视化大屏的设计规范和案例参考(使用AxureRP软件设计)
在信息化浪潮中,数据可视化不再仅限于单纯的数据呈现,而是逐渐演变为一种能够直观揭示复杂数据内在关联、趋势变化以及关键洞察的艺术形式。
1116 3
|
安全 NoSQL 关系型数据库
使用cnpm搭建企业内部私有NPM仓库
cnpm是企业内部搭建npm镜像和私有npm仓库的开源方案。它同时解决了现有npm架构的一些问题。
1113 0
使用cnpm搭建企业内部私有NPM仓库
|
人工智能 JSON 自然语言处理
阿里云百炼产品月刊【2025年1月】
本月重点包括新增批量推理功能,支持非高峰时段大规模数据处理,享有5折折扣;工作流应用新增循环节点,增强了流程定义的灵活性;数据管理新增解析设置功能,支持自动识别与转换多种数据格式。此外,还推出了多个新模型,如DeepSeek系列、Wanx2.1系列等,涵盖文本生成、图像生成、视频生成等多个领域。特别是DeepSeek-V3,具有671B参数,擅长长文本、代码、数学等领域;Wanx2.1系列则在视频和图像生成方面表现出色。通义千问系列模型也在性能和功能上进行了显著提升,特别是在语义理解和多语言支持方面。此外,本月还举办了多项AI实训营活动,包括智能体创意开发赛、新春主题创作等。
880 0
|
11月前
|
编译器 C语言 C++
C++入门6——模板(泛型编程、函数模板、类模板)
C++入门6——模板(泛型编程、函数模板、类模板)
178 0
C++入门6——模板(泛型编程、函数模板、类模板)
黑神话:悟空中的音效设计与音乐制作
【8月更文第26天】在《黑神话:悟空》这款游戏中,音效和背景音乐是构建沉浸式游戏体验的重要组成部分。本文将探讨游戏音效和背景音乐的创作过程,以及它们如何增强游戏氛围。
1230 0
|
JSON Kubernetes 算法
什么?修改 JSON 内容居然还有个 JSON PATCH 标准
什么?修改 JSON 内容居然还有个 JSON PATCH 标准
584 0
|
存储 机器学习/深度学习 PyTorch
深入理解GPU内存分配:机器学习工程师的实用指南与实验
给定一个模型架构、数据类型、输入形状和优化器,你能否计算出前向传播和反向传播所需的GPU内存量?
250 0
|
Kubernetes 异构计算 容器
Kubelet之Topology Manager分析
Topology Manager是kubelet的一个组件,在kubernetes 1.16加入,而kubernetes 1.18中该feature变为beta版。本篇文档将分析Topology Manager的具体工作原理。1.为什么需要Topology Manager现代计算机的CPU架构多采用NUMA(Non-Uniform Memory Access,非统一内存)架构。NUMA就是将cpu
4580 0
|
存储 定位技术 C语言
嵌入式开发学习之--点亮LED灯(中)
嵌入式开发学习之--点亮LED灯(中)
嵌入式开发学习之--点亮LED灯(中)
|
消息中间件 Cloud Native Java
【深入浅出SpringCloud原理及实战】「SpringCloud-Alibaba系列」微服务模式搭建系统基础架构实战指南及版本规划踩坑分析
【深入浅出SpringCloud原理及实战】「SpringCloud-Alibaba系列」微服务模式搭建系统基础架构实战指南及版本规划踩坑分析
925 1
【深入浅出SpringCloud原理及实战】「SpringCloud-Alibaba系列」微服务模式搭建系统基础架构实战指南及版本规划踩坑分析
