三种基本操作 Query(a read‐only fetch), Mutation(a write followed by a fetch), Subscription(订阅，不常用，适合长连接业务)
1. 起步，用express实现最简单的例子
运行一个GraphQL API Server
GraphiQL is a great tool for debugging and inspecting a server, so we recommend running it whenever your application is in development mode.
index.js
const express = require('express');
const graphqlHTTP = require('express-graphql');
const schema = require('./schema');
const app = express();
// 具体选项含义见文档
// https://github.com/graphql/express-graphql
app.use('/graphql', graphqlHTTP({
schema: schema,
graphiql: true,
}));
app.listen(12580);
console.log("please open http://localhost:12580/graphql")
schema.js
const {
GraphQLObjectType,
GraphQLSchema,
GraphQLString,
} = require('graphql');
const Query = new GraphQLObjectType({
name: 'BlogSchema',
description: 'Root of the Blog Schema',
fields: () => ({
echo: {
type: GraphQLString,
description: '回应你输入的内容',
args: {
message: {type: GraphQLString}
},
resolve: function(source, {message}) {
return `hello: ${message}`;
}
},
})
});
const Schema = new GraphQLSchema({
query: Query,
});
module.exports = Schema;
注意点:
上篇讲过GraphQL只是一套规范，目前官方只提供了JS版本，其他PHP，Go等其他语言都是社区实现的。
-
当只有一种操作，并且是query，可以省去query操作名关键字
image.png 可以看到字段和字段参数要指定类型，因为GraphQL是强类型的。
因为指定了参数类型是string，输入时必须要用双引号
注意看调试面板的请求
GraphQL API server运行时，只要构造http请求就可以，传入不同的query参数，也能得到和在GraphiQL同样的结果
2. 查询
2.1 变量
所有声明的变量都必须是标量、枚举型或者输入对象类型。
默认变量
使用默认值
覆盖默认值
类型后面带个感叹号表示参数必填
2.2 别名
2.3 片段
提取公众的部分
上面的查询，将共同的字段：id和name，提取成fragment
2.4 指令
GraphQL内置两个核心指令，@skip 和 @include@skip(if: Boolean) 如果参数为 true，跳过此字段。
? 貌似参数必须要写默认值 ?
3. 修改 Mutation
4. 分页
分页的原理：定义一个Edges类型，包含node和cursor字段，Node保存查询列表内容，Cursor记录分页。以下面的Github例子
5. GitHub GraphQL API
打开 https://developer.github.com/v4/explorer/
先打开右侧的Docs浏览所有Query，发现有个名为search的query
他返回的是个 SearchResultItemConnection!类型，接着点进去
你会发现所有已Connection结尾的类型，其结果都包含pageInfo, edges, nodes
输入下面的内容，这个查询是返回包含"graphql"关键字的前三个仓库，并显示每个仓库的前3个issues的作者，头像信息。
{
search(first: 3, query: "graphql", type: REPOSITORY) {
codeCount
pageInfo {
startCursor
endCursor
hasNextPage
hasPreviousPage
}
edges {
cursor
node {
... on Repository {
nameWithOwner
issues(first: 3) {
nodes {
author {
avatarUrl
login
resourcePath
url
}
title
}
}
}
}
}
}
rateLimit {
cost
limit
nodeCount
resetAt
remaining
}
}
返回的结果类似
{
"data": {
"search": {
"codeCount": 16287,
"pageInfo": {
"startCursor": "Y3Vyc29yOjE=",
"endCursor": "Y3Vyc29yOjM=",
"hasNextPage": true,
"hasPreviousPage": false
},
"edges": [
{
"cursor": "Y3Vyc29yOjE=",
"node": {
"nameWithOwner": "facebook/graphql",
"issues": {
"nodes": [
{
"author": {
"avatarUrl": "https://avatars0.githubusercontent.com/u/540892?v=4",
"login": "raymondfeng",
"resourcePath": "/raymondfeng",
"url": "https://github.com/raymondfeng"
},
"title": "Possibility of collaboration with LoopBack framework?"
},
{
"author": {
"avatarUrl": "https://avatars1.githubusercontent.com/u/825073?v=4",
"login": "luisobo",
"resourcePath": "/luisobo",
"url": "https://github.com/luisobo"
},
"title": "Pagination?"
},
{
"author": {
"avatarUrl": "https://avatars3.githubusercontent.com/u/71047?v=4",
"login": "KyleAMathews",
"resourcePath": "/KyleAMathews",
"url": "https://github.com/KyleAMathews"
},
"title": "Custom Sorting"
}
]
}
}
},
{
"cursor": "Y3Vyc29yOjI=",
"node": {
"nameWithOwner": "graphql-go/graphql",
"issues": {
"nodes": [
{
"author": {
"avatarUrl": "https://avatars0.githubusercontent.com/u/78585?v=4",
"login": "sogko",
"resourcePath": "/sogko",
"url": "https://github.com/sogko"
},
"title": "Suggestion: Improve package discovery"
},
{
"author": {
"avatarUrl": "https://avatars2.githubusercontent.com/u/1064547?v=4",
"login": "ptomasroos",
"resourcePath": "/ptomasroos",
"url": "https://github.com/ptomasroos"
},
"title": "Why not wrap the C lib?"
},
{
"author": {
"avatarUrl": "https://avatars0.githubusercontent.com/u/1000404?v=4",
"login": "chris-ramon",
"resourcePath": "/chris-ramon",
"url": "https://github.com/chris-ramon"
},
"title": "Using graphql-go in other programs throws various errors."
}
]
}
}
},
{
"cursor": "Y3Vyc29yOjM=",
"node": {
"nameWithOwner": "Youshido/GraphQL",
"issues": {
"nodes": [
{
"author": {
"avatarUrl": "https://avatars2.githubusercontent.com/u/2429244?v=4",
"login": "mrbarletta",
"resourcePath": "/mrbarletta",
"url": "https://github.com/mrbarletta"
},
"title": "How to manage a List of Posts"
},
{
"author": {
"avatarUrl": "https://avatars2.githubusercontent.com/u/2429244?v=4",
"login": "mrbarletta",
"resourcePath": "/mrbarletta",
"url": "https://github.com/mrbarletta"
},
"title": "No way to get requested fields of the object inside `resolve`"
},
{
"author": {
"avatarUrl": "https://avatars0.githubusercontent.com/u/971254?v=4",
"login": "larswolff",
"resourcePath": "/larswolff",
"url": "https://github.com/larswolff"
},
"title": "Minor documentation issue?"
}
]
}
}
}
]
},
"rateLimit": {
"cost": 1,
"limit": 5000,
"nodeCount": 12,
"resetAt": "2018-03-31T01:47:34Z",
"remaining": 4995
}
}
}
- 每个node包含一个cursor游标，不是数字，是唯一字符串
- 如果想查下一页，直接修改query search，添加after参数。
search(first: 3, after:"Y3Vyc29yOjM=", query: "graphql", type: REPOSITORY) { - 关于实现原理，参考
最后欢迎 clone 我的仓库, 里面包含了所有例子。
