原文: WPF如何实现一款类似360安全卫士界面的程序？(共享源码!)

　　以前学习Windows Form编程的时候，总感觉自己做的界面很丑，看到360安全卫士、迅雷等软件的UI设计都非常美观，心里总是憧憬着要是自己能实现这样的UI效果该多好！！！另一个困扰我的问题是，这个UI皮肤是如何用技术实现的呢？！虽然好多年过去了，但心里的憧憬和疑惑一直没有消失，而且越来越强烈。在日常的工作和学习中，自己在网上也经常留意类似的技术或者文章。最近在学习WPF的过程中，看到网上也有仿360和仿迅雷UI设计的资源，通过对资源的学习和自己的动手实践，终于实现了下面的仿360安全卫士界面：

由于项目文件比较多，这里罗列出核心的过程和代码：

1、VS解决方案结构：

WpfPageTransitions是一个WPF类库，实现UI页面切换动画效果，支持多种动画，可以通过TransitionType属性进行设置，其原理是定义了多个切换动画类型的Storyboard,程序根据配置的TransitionType去执行匹配的Storyboard动画（分出入动画，xxxxxxIn和xxxxxxOut)。360UI是一个WPF 桌面应用程序，styles文件夹下存放了定义的按钮样式、菜单项样式、页签样式等样式和需要的所有UI切图资源。pages文件夹下存放切换的详细子页面。

（备注：图片资源和部分文件来自互联网，特别感谢KXFang360项目提供的360整套配图和布局文件）

2、页面切换控件核心代码：

  1 <UserControl x:Class="WpfPageTransitions.PageTransition"
  2              xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
  3              xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
  4              xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
  5              xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
  6              xmlns:local="clr-namespace:WpfPageTransitions"
  7              mc:Ignorable="d"
  8              d:DesignHeight="300" d:DesignWidth="300">
  9     <UserControl.Resources>
 10
 11         <Style TargetType="{x:Type ContentPresenter}">
 12             <Setter Property="LayoutTransform">
 13                 <Setter.Value>
 14                     <ScaleTransform />
 15                 </Setter.Value>
 16             </Setter>
 17         </Style>
 18
 19         <local:CenterConverter x:Key="centerConverter"/>
 20
 21         <!-- Slide and Fade -->
 22         <Storyboard x:Key="SlideAndFadeIn" >
 23             <ThicknessAnimation Duration="0:0:.75" Storyboard.TargetProperty="Margin" From="500,0,-500,0" To="0" DecelerationRatio=".9" />
 24             <DoubleAnimation Duration="0:0:.25" Storyboard.TargetProperty="Opacity" From="0" To="1" />
 25         </Storyboard>
 26
 27         <Storyboard x:Key="SlideAndFadeOut">
 28             <ThicknessAnimation Duration="0:0:.5" Storyboard.TargetProperty="Margin" To="-500,0,500,0" AccelerationRatio=".9"/>
 29             <DoubleAnimation Duration="0:0:.5" Storyboard.TargetProperty="Opacity" To="0" />
 30         </Storyboard>
 31
 32         <!-- Fade -->
 33         <Storyboard x:Key="FadeIn" >
 34             <DoubleAnimation Duration="0:0:.25" Storyboard.TargetProperty="Opacity" From="0" To="1" />
 35         </Storyboard>
 36
 37         <Storyboard x:Key="FadeOut">
 38             <DoubleAnimation Duration="0:0:.5" Storyboard.TargetProperty="Opacity" To="0" />
 39         </Storyboard>
 40
 41         <!-- Slide -->
 42         <Storyboard x:Key="SlideIn" >
 43             <ThicknessAnimation Duration="0:0:.75" Storyboard.TargetProperty="Margin" From="500,0,-500,0" To="0" DecelerationRatio=".9" />
 44         </Storyboard>
 45
 46         <Storyboard x:Key="SlideOut">
 47             <ThicknessAnimation Duration="0:0:.5" Storyboard.TargetProperty="Margin" To="-500,0,500,0" AccelerationRatio=".9"/>
 48         </Storyboard>
 49
 50         <!-- Grow -->
 51         <Storyboard x:Key="GrowIn" >
 52             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleX)" From="0" To="1" Duration="0:0:.75" DecelerationRatio=".9" />
 53             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleY)" From="0" To="1" Duration="0:0:.75" DecelerationRatio=".9" />
 54         </Storyboard>
 55
 56         <Storyboard x:Key="GrowOut">
 57             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleX)" To="0" Duration="0:0:.75" AccelerationRatio=".9" />
 58             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleY)" To="0" Duration="0:0:.75" AccelerationRatio=".9" />
 59         </Storyboard>
 60
 61         <!-- Grow and Fade -->
 62         <Storyboard x:Key="GrowAndFadeIn" >
 63             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleX)" From="0" To="1" Duration="0:0:.75" DecelerationRatio=".9" />
 64             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleY)" From="0" To="1" Duration="0:0:.75" DecelerationRatio=".9" />
 65             <DoubleAnimation Duration="0:0:.25" Storyboard.TargetProperty="Opacity" From="0" To="1" />
 66         </Storyboard>
 67
 68         <Storyboard x:Key="GrowAndFadeOut">
 69             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleX)" To="0" Duration="0:0:.75" AccelerationRatio=".9" />
 70             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleY)" To="0" Duration="0:0:.75" AccelerationRatio=".9" />
 71             <DoubleAnimation Duration="0:0:.75" Storyboard.TargetProperty="Opacity" To="0" />
 72         </Storyboard>
 73
 74         <!-- Flip -->
 75         <Storyboard x:Key="FlipIn" >
 76             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[1].(SkewTransform.AngleX)" From="-100" To="0" Duration="0:0:.75" DecelerationRatio=".9" />
 77             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[1].(SkewTransform.AngleY)" From="-100" To="0" Duration="0:0:.75" DecelerationRatio=".9" />
 78         </Storyboard>
 79
 80         <Storyboard x:Key="FlipOut">
 81             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[1].(SkewTransform.AngleX)" To="100" Duration="0:0:.75" AccelerationRatio=".9" />
 82             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[1].(SkewTransform.AngleY)" To="100" Duration="0:0:.75" AccelerationRatio=".9" />
 83         </Storyboard>
 84
 85         <!-- Flip and Fade -->
 86         <Storyboard x:Key="FlipAndFadeIn" >
 87             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[1].(SkewTransform.AngleX)" From="-100" To="0" Duration="0:0:.75" DecelerationRatio=".9" />
 88             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[1].(SkewTransform.AngleY)" From="-100" To="0" Duration="0:0:.75" DecelerationRatio=".9" />
 89             <DoubleAnimation Duration="0:0:.25" Storyboard.TargetProperty="Opacity" From="0" To="1" />
 90         </Storyboard>
 91
 92         <Storyboard x:Key="FlipAndFadeOut">
 93             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[1].(SkewTransform.AngleX)" To="100" Duration="0:0:.75" AccelerationRatio=".9" />
 94             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[1].(SkewTransform.AngleY)" To="100" Duration="0:0:.75" AccelerationRatio=".9" />
 95             <DoubleAnimation Duration="0:0:.75" Storyboard.TargetProperty="Opacity" To="0" />
 96         </Storyboard>
 97
 98         <!-- Spin -->
 99         <Storyboard x:Key="SpinIn" >
100             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[2].(RotateTransform.Angle)" From="-360" To="0" Duration="0:0:.75" DecelerationRatio=".9" />
101             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleX)" From="0" To="1" Duration="0:0:.75" DecelerationRatio=".9" />
102             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleY)" From="0" To="1" Duration="0:0:.75" DecelerationRatio=".9" />
103         </Storyboard>
104
105         <Storyboard x:Key="SpinOut">
106             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[2].(RotateTransform.Angle)" To="360" Duration="0:0:.75" AccelerationRatio=".9" />
107             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleX)" To="0" Duration="0:0:.75" AccelerationRatio=".9" />
108             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleY)" To="0" Duration="0:0:.75" AccelerationRatio=".9" />
109         </Storyboard>
110
111         <!-- Spin and Fade -->
112         <Storyboard x:Key="SpinAndFadeIn" >
113             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[2].(RotateTransform.Angle)" From="-360" To="0" Duration="0:0:.75" DecelerationRatio=".9" />
114             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleX)" From="0" To="1" Duration="0:0:.75" DecelerationRatio=".9" />
115             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleY)" From="0" To="1" Duration="0:0:.75" DecelerationRatio=".9" />
116             <DoubleAnimation Duration="0:0:.25" Storyboard.TargetProperty="Opacity" From="0" To="1" />
117         </Storyboard>
118
119         <Storyboard x:Key="SpinAndFadeOut">
120             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[2].(RotateTransform.Angle)" To="360" Duration="0:0:.75" AccelerationRatio=".9" />
121             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleX)" To="0" Duration="0:0:.75" AccelerationRatio=".9" />
122             <DoubleAnimation Storyboard.TargetProperty="(RenderTransform).(TransformGroup.Children)[0].(ScaleTransform.ScaleY)" To="0" Duration="0:0:.75" AccelerationRatio=".9" />
123             <DoubleAnimation Duration="0:0:.75" Storyboard.TargetProperty="Opacity" To="0" />
124         </Storyboard>
125
126     </UserControl.Resources>
127
128     <Grid Name="page">
129
130         <ContentControl Name="contentPresenter" >
131             <ContentControl.RenderTransform>
132                 <TransformGroup>
133                     <ScaleTransform ScaleX="1" ScaleY="1"
134                                     CenterX="{Binding RelativeSource={RelativeSource AncestorType=Grid, Mode=FindAncestor}, Path=ActualWidth, Converter={StaticResource centerConverter}}"
135                                     CenterY="{Binding RelativeSource={RelativeSource AncestorType=Grid, Mode=FindAncestor}, Path=ActualHeight, Converter={StaticResource centerConverter}}" />
136                     <SkewTransform AngleX="0" AngleY="0"
137                                    CenterX="{Binding RelativeSource={RelativeSource AncestorType=Grid, Mode=FindAncestor}, Path=ActualWidth, Converter={StaticResource centerConverter}}"
138                                    CenterY="{Binding RelativeSource={RelativeSource AncestorType=Grid, Mode=FindAncestor}, Path=ActualHeight, Converter={StaticResource centerConverter}}" />
139                     <RotateTransform Angle="0"
140                                      CenterX="{Binding RelativeSource={RelativeSource AncestorType=Grid, Mode=FindAncestor}, Path=ActualWidth, Converter={StaticResource centerConverter}}"
141                                      CenterY="{Binding RelativeSource={RelativeSource AncestorType=Grid, Mode=FindAncestor}, Path=ActualHeight, Converter={StaticResource centerConverter}}" />
142                     <TranslateTransform X="0" Y="0" />
143                 </TransformGroup>
144             </ContentControl.RenderTransform>
145
146         </ContentControl>
147
148     </Grid>
149
150 </UserControl>

  1 using System;
  2 using System.Collections.Generic;
  3 using System.Linq;
  4 using System.Text;
  5 using System.Windows;
  6 using System.Windows.Controls;
  7 using System.Windows.Data;
  8 using System.Windows.Documents;
  9 using System.Windows.Input;
 10 using System.Windows.Media;
 11 using System.Windows.Media.Imaging;
 12 using System.Windows.Navigation;
 13 using System.Windows.Shapes;
 14 using System.Threading.Tasks;
 15 using System.Windows.Media.Animation;
 16
 17 namespace WpfPageTransitions
 18 {
 19     public partial class PageTransition : UserControl
 20     {
 21         Stack<UserControl> pages = new Stack<UserControl>();
 22
 23         public UserControl CurrentPage { get; set; }
 24
 25         public static readonly DependencyProperty TransitionTypeProperty = DependencyProperty.Register("TransitionType",
 26             typeof(PageTransitionType),
 27             typeof(PageTransition), new PropertyMetadata(PageTransitionType.SlideAndFade));
 28
 29         public PageTransitionType TransitionType
 30         {
 31             get
 32             {
 33                 return (PageTransitionType)GetValue(TransitionTypeProperty);
 34             }
 35             set
 36             {
 37                 SetValue(TransitionTypeProperty, value);
 38             }
 39         }
 40
 41         public PageTransition()
 42         {
 43             InitializeComponent();
 44         }
 45
 46         public void ShowPage(UserControl newPage)
 47         {
 48             pages.Push(newPage);
 49             Task.Factory.StartNew(() => ShowNewPage());
 50         }
 51
 52         void ShowNewPage()
 53         {
 54             Dispatcher.Invoke((Action)delegate
 55                 {
 56
 57                     if (contentPresenter.Content != null)
 58                     {
 59                         UserControl oldPage = contentPresenter.Content as UserControl;
 60
 61                         if (oldPage != null)
 62                         {
 63                             oldPage.Loaded -= newPage_Loaded;
 64
 65                             UnloadPage(oldPage);
 66
 67                         }
 68                     }
 69                     else
 70                     {
 71                         ShowNextPage();
 72                     }
 73
 74                 });
 75         }
 76
 77         void ShowNextPage()
 78         {
 79             UserControl newPage = pages.Pop();
 80
 81             newPage.Loaded += newPage_Loaded;
 82
 83             contentPresenter.Content = newPage;
 84         }
 85
 86         void UnloadPage(UserControl page)
 87         {
 88             Storyboard hidePage = (Resources[string.Format("{0}Out", TransitionType.ToString())] as Storyboard).Clone();
 89
 90             hidePage.Completed += hidePage_Completed;
 91
 92             hidePage.Begin(contentPresenter);
 93         }
 94
 95         void newPage_Loaded(object sender, RoutedEventArgs e)
 96         {
 97             Storyboard showNewPage = Resources[string.Format("{0}In", TransitionType.ToString())] as Storyboard;
 98
 99             showNewPage.Begin(contentPresenter);
100
101             CurrentPage = sender as UserControl;
102         }
103
104         void hidePage_Completed(object sender, EventArgs e)
105         {
106             contentPresenter.Content = null;
107             ShowNextPage();
108         }
109     }
110 }

3、Like360Main核心代码为：

其中AllowsTransparency="True" WindowStyle="None" Background="{x:Null}"的目的是让WPF窗体隐藏默认的边框，这样可以允许用背景图片填充WPF定义窗体外观。在这区间可以自定义关闭、最小化和最大化按钮等。MouseLeftButtonDown="Window_MouseLeftButtonDown" 目的是为了支持窗体拖动。FontFamily="SimSun" TextOptions.TextFormattingMode="Display"的目的是为了解决WPF中文字体显示模糊的问题。

  1 <Window x:Class="_360UI.Like360Main"
  2         xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
  3         xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
  4         Title="Like360Main"  Height="610" Width="860"
  5         FontFamily="SimSun"
  6         AllowsTransparency="True" WindowStyle="None"
  7         xmlns:pageTransitions="clr-namespace:WpfPageTransitions;assembly=WpfPageTransitions"
  8         Background="{x:Null}" MouseLeftButtonDown="Window_MouseLeftButtonDown" TextOptions.TextFormattingMode="Display" >
  9     <Window.Resources>
 10         <LinearGradientBrush x:Key="MyBrush" EndPoint="0.5,1" StartPoint="0.5,0">
 11             <GradientStop Color="#CFFFFFFF"/>
 12             <GradientStop Color="#FF7EBDD8" Offset="1"/>
 13         </LinearGradientBrush>
 14     </Window.Resources>
 15     <Border BorderBrush="Black" BorderThickness="1" CornerRadius="5" Margin="10">
 16         <Border.Effect>
 17             <DropShadowEffect ShadowDepth="0" Opacity="0.8"/>
 18         </Border.Effect>
 19         <Border.Background>
 20             <ImageBrush ImageSource="styles/skin/frame.jpg"/>
 21         </Border.Background>
 22         <Grid>
 23             <Grid.RowDefinitions>
 24                 <RowDefinition Height="25.77"/>
 25                 <RowDefinition Height="83.122"/>
 26                 <RowDefinition/>
 27                 <RowDefinition Height="24.5"/>
 28             </Grid.RowDefinitions>
 29             <!--上标题栏-->
 30             <Label Content="360安全卫士界面" HorizontalAlignment="Left"  Width="171.79" Foreground="#A794E9FF" FontWeight="Bold" TextOptions.TextFormattingMode="Display"/>
 31             <Rectangle Margin="0" Stroke="Black" HorizontalAlignment="Right" Width="151.5" Grid.Row="1" StrokeThickness="0">
 32                 <Rectangle.Fill>
 33                     <ImageBrush ImageSource="styles/skin/logo.png" Stretch="Uniform"/>
 34                 </Rectangle.Fill>
 35             </Rectangle>
 36             <Button Content="x" HorizontalAlignment="Right" Margin="0,0,2.625,8" Style="{DynamicResource SysButtonStyle}" Width="44.315" Name="closeButton" Click="closeButton_Click" />
 37             <Button Content="max" HorizontalAlignment="Right" Margin="0,0,46.94,8" Style="{DynamicResource MaxButtonStyle}" Width="41.5" Name="maxButton" Click="maxButton_Click">
 38                 <Button.Background>
 39                     <ImageBrush ImageSource="styles/skin/Button/MAX.png" Stretch="Uniform"/>
 40                 </Button.Background>
 41             </Button>
 42             <Button Content="mni" HorizontalAlignment="Right" Margin="0,0,88.441,8" Style="{DynamicResource MaxButtonStyle}" Width="41.5" Name="mniButton" Click="mniButton_Click">
 43                 <Button.Background>
 44                     <ImageBrush ImageSource="styles/skin/Button/MNI.png" Stretch="Uniform"/>
 45                 </Button.Background>
 46             </Button>
 47             <Button x:Name="menuButton" HorizontalAlignment="Right" Margin="0,0,129.942,8" Style="{DynamicResource MButtonStyle}" Width="31.833" Click="menuButton_Click">
 48                 <Button.Background>
 49                     <ImageBrush ImageSource="styles/skin/Button/M.png" Stretch="Uniform"/>
 50                 </Button.Background>
 51             </Button>
 52             <Popup x:Name="Menu" AllowsTransparency="True" Margin="0,-1,0,1" PlacementTarget="{Binding ElementName=menuButton}" StaysOpen="False" PopupAnimation="Scroll">
 53                 <Grid Height="113.667" Width="96" Margin="0" HorizontalAlignment="Left">
 54                     <Border BorderThickness="1" CornerRadius="3" Background="#FFEFEFEF" Margin="3">
 55                         <Border.Effect>
 56                             <DropShadowEffect ShadowDepth="0" Opacity="0.495"/>
 57                         </Border.Effect>
 58                         <StackPanel Margin="0,4">
 59                             <MenuItem Header="设 置" Style="{DynamicResource MenuItemStyle}"/>
 60                             <MenuItem Header="更 新"/>
 61                             <MenuItem Header="关 于"/>
 62                             <MenuItem Header="退 出"/>
 63                         </StackPanel>
 64                     </Border>
 65                 </Grid>
 66             </Popup>
 67             <Rectangle Stroke="Black" StrokeThickness="0" Width="1" Margin="0,0,129.2,10.77" HorizontalAlignment="Right" Height="17">
 68                 <Rectangle.Fill>
 69                     <LinearGradientBrush EndPoint="0.5,1" StartPoint="0.5,0">
 70                         <GradientStop Color="#85000000"/>
 71                         <GradientStop Offset="1" Color="#1A4D4D4D"/>
 72                     </LinearGradientBrush>
 73                 </Rectangle.Fill>
 74             </Rectangle>
 75             <Rectangle Stroke="Black" StrokeThickness="0" Width="1" Margin="0,0,88.2,8.77" HorizontalAlignment="Right" Height="17">
 76                 <Rectangle.Fill>
 77                     <LinearGradientBrush EndPoint="0.5,1" StartPoint="0.5,0">
 78                         <GradientStop Color="#85000000"/>
 79                         <GradientStop Offset="1" Color="#1A4D4D4D"/>
 80                     </LinearGradientBrush>
 81                 </Rectangle.Fill>
 82             </Rectangle>
 83             <Rectangle Stroke="Black" StrokeThickness="0" Width="1" Margin="0,0,46.2,8.77" HorizontalAlignment="Right" Height="17">
 84                 <Rectangle.Fill>
 85                     <LinearGradientBrush EndPoint="0.5,1" StartPoint="0.5,0">
 86                         <GradientStop Color="#85000000"/>
 87                         <GradientStop Offset="1" Color="#1A4D4D4D"/>
 88                     </LinearGradientBrush>
 89                 </Rectangle.Fill>
 90             </Rectangle>
 91             <Rectangle Height="3" Margin="0,0,161.775,0" Stroke="Black" StrokeThickness="0" VerticalAlignment="Top">
 92                 <Rectangle.Fill>
 93                     <LinearGradientBrush EndPoint="0.5,1" StartPoint="0.5,0">
 94                         <GradientStop Color="#61FFFFFF"/>
 95                         <GradientStop Offset="1" Color="#1A4D4D4D"/>
 96                     </LinearGradientBrush>
 97                 </Rectangle.Fill>
 98             </Rectangle>
 99             <!--上导航栏-->
100
101              <TabControl  Name="tab360"   Grid.RowSpan="2" Margin="0" Style="{DynamicResource TabControlStyle}" Grid.Row="1" Background="{x:Null}" SelectionChanged="TabControl_SelectionChanged">
102                     <TabItem Header="电脑体验" Height="83" Margin="5,0,0,0" Width="74" Style="{DynamicResource TabItemStyle}" TextOptions.TextFormattingMode="Display">
103                     <TabItem.Background>
104                         <ImageBrush ImageSource="styles/skin/ico/ico_Examine.png"/>
105                     </TabItem.Background>
106                     <Grid Margin="0" Background="{DynamicResource MyBrush}">
107                         <Grid.ColumnDefinitions>
108                             <ColumnDefinition Width="0.052*"/>
109                             <ColumnDefinition Width="0.9*"/>
110                             <ColumnDefinition Width="0.048*"/>
111                         </Grid.ColumnDefinitions>
112                         <Grid.RowDefinitions>
113                             <RowDefinition Height="40.73"/>
114                             <RowDefinition Height="56.667"/>
115                             <RowDefinition Height="338.833"/>
116                             <RowDefinition Height="26.9999999999997"/>
117                         </Grid.RowDefinitions>
118
119                         <!--详细-->
120                         <Label Content="电脑体检" HorizontalAlignment="Left" Margin="0" Width="94.25" Height="36" FontSize="14.667" FontWeight="Bold" Grid.Column="0" Grid.Row="0" Grid.ColumnSpan="2" />
121                         <pageTransitions:PageTransition Name="pTransitionControl_1" Margin="0" TransitionType="SlideAndFade" Grid.Column="0" Grid.Row="1" Grid.ColumnSpan="3" Grid.RowSpan="2"/>
122
123                     </Grid>
124                 </TabItem>
125                 <TabItem Header="查杀木马" Height="83" Margin="80,0,0,0" Width="74" Style="{DynamicResource TabItemStyle}">
126                     <TabItem.Background>
127                         <ImageBrush ImageSource="styles/skin/ico/ico_dsmain.png"/>
128                     </TabItem.Background>
129                     <Grid Margin="0" Background="{DynamicResource MyBrush}">
130                         <Grid.ColumnDefinitions>
131                             <ColumnDefinition Width="0.052*"/>
132                             <ColumnDefinition Width="0.9*"/>
133                             <ColumnDefinition Width="0.048*"/>
134                         </Grid.ColumnDefinitions>
135                         <Grid.RowDefinitions>
136                             <RowDefinition Height="40.73"/>
137                             <RowDefinition Height="56.667"/>
138                             <RowDefinition Height="338.833"/>
139                             <RowDefinition Height="26.9999999999997"/>
140                         </Grid.RowDefinitions>
141                         <!--详细-->
142                         <Label Content="查杀木马" HorizontalAlignment="Left" Margin="0" Width="94.25" Height="36" FontSize="14.667" FontWeight="Bold" Grid.Column="0" Grid.Row="0" Grid.ColumnSpan="2" />
143                         <pageTransitions:PageTransition Name="pTransitionControl_2" Margin="0" TransitionType="SlideAndFade" Grid.Column="0" Grid.Row="1" Grid.ColumnSpan="3" Grid.RowSpan="2"/>
144
145                     </Grid>
146                 </TabItem>
147                 <TabItem Header="清理插件" Height="83" Margin="155,0,0,0" Width="74" Style="{DynamicResource TabItemStyle}">
148                     <TabItem.Background>
149                         <ImageBrush ImageSource="styles/skin/ico/ico_PluginCleaner.png"/>
150                     </TabItem.Background>
151                     <Grid Margin="0" Background="{DynamicResource MyBrush}">
152                         <Grid.ColumnDefinitions>
153                             <ColumnDefinition Width="0.052*"/>
154                             <ColumnDefinition Width="0.9*"/>
155                             <ColumnDefinition Width="0.048*"/>
156                         </Grid.ColumnDefinitions>
157                         <Grid.RowDefinitions>
158                             <RowDefinition Height="40.73"/>
159                             <RowDefinition Height="56.667"/>
160                             <RowDefinition Height="338.833"/>
161                             <RowDefinition Height="26.9999999999997"/>
162                         </Grid.RowDefinitions>
163                         <!--详细-->
164                         <Label Content="清理插件" HorizontalAlignment="Left" Margin="0" Width="94.25" Height="36" FontSize="14.667" FontWeight="Bold" Grid.Column="0" Grid.Row="0" Grid.ColumnSpan="2" />
165                         <pageTransitions:PageTransition Name="pTransitionControl_3" Margin="0" TransitionType="SlideAndFade" Grid.Column="0" Grid.Row="1" Grid.ColumnSpan="3" Grid.RowSpan="2"/>
166
167                     </Grid>
168                 </TabItem>
169                 <TabItem Header="修复漏洞" Height="83" Margin="230,0,0,0" Width="74" Style="{DynamicResource TabItemStyle}">
170                     <TabItem.Background>
171                         <ImageBrush ImageSource="styles/skin/ico/ico_VulRepair.png"/>
172                     </TabItem.Background>
173                     <Grid Background="{DynamicResource MyBrush}"/>
174                 </TabItem>
175                 <TabItem Header="清理垃圾" Height="83" Margin="305,0,0,0" Width="74" Style="{DynamicResource TabItemStyle}">
176                     <TabItem.Background>
177                         <ImageBrush ImageSource="styles/skin/ico/ico_RubbishCleaner.png"/>
178                     </TabItem.Background>
179                     <Grid Background="{DynamicResource MyBrush}"/>
180                 </TabItem>
181                 <TabItem Header="清理痕迹" Height="83" Margin="380,0,0,0" Width="74" Style="{DynamicResource TabItemStyle}">
182                     <TabItem.Background>
183                         <ImageBrush ImageSource="styles/skin/ico/ico_TraceCleaner.png"/>
184                     </TabItem.Background>
185                     <Grid Background="{DynamicResource MyBrush}"/>
186                 </TabItem>
187                 <TabItem Header="系统修复" Height="83" Margin="455,0,0,0" Width="74" Style="{DynamicResource TabItemStyle}">
188                     <TabItem.Background>
189                         <ImageBrush ImageSource="styles/skin/ico/ico_SysRepair.png"/>
190                     </TabItem.Background>
191                     <Grid Background="{DynamicResource MyBrush}"/>
192                 </TabItem>
193                 <TabItem Header="功能大全" Height="83" Margin="530,0,0,0" Width="74" Style="{DynamicResource TabItemStyle}">
194                     <TabItem.Background>
195                         <ImageBrush ImageSource="styles/skin/ico/ico_AdvTools.png"/>
196                     </TabItem.Background>
197                     <Grid Background="{DynamicResource MyBrush}"/>
198                 </TabItem>
199                 <TabItem Header="软件管家" Height="83" Margin="605,0,0,0" Width="74" Style="{DynamicResource TabItemStyle}">
200                     <TabItem.Background>
201                         <ImageBrush ImageSource="styles/skin/ico/ico_softmgr.png"/>
202                     </TabItem.Background>
203                     <Grid Background="{DynamicResource MyBrush}"/>
204                 </TabItem>
205             </TabControl>
206
207             <!--导航详细-->
208             <!--下状态栏-->
209             <Label Content="欢迎使用仿360系统"  Margin="0" Grid.Row="3" Foreground="#A794E9FF" FontWeight="Bold" BorderThickness="0" BorderBrush="White" HorizontalAlignment="Left" Width="147.5" TextOptions.TextFormattingMode="Display" />
210             <Label Content="已连接网络" Margin="0" Grid.Row="3" Foreground="#A794E9FF" FontWeight="Bold" BorderThickness="0" BorderBrush="White" HorizontalAlignment="Right" Width="80" TextOptions.TextFormattingMode="Display" />
211         </Grid>
212     </Border>
213 </Window>

 1 using System;
 2 using System.Collections.Generic;  3 using System.Linq;  4 using System.Text;  5 using System.Threading.Tasks;  6 using System.Windows;  7 using System.Windows.Controls;  8 using System.Windows.Data;  9 using System.Windows.Documents; 10 using System.Windows.Input; 11 using System.Windows.Media; 12 using System.Windows.Media.Imaging; 13 using System.Windows.Shapes; 14 15 namespace _360UI 16 { 17 /// <summary> 18 /// Like360Main.xaml 的交互逻辑 19 /// </summary> 20 public partial class Like360Main : Window 21  { 22 public Like360Main() 23  { 24  InitializeComponent(); 25  } 26 27 private void closeButton_Click(object sender, RoutedEventArgs e) 28  { 29 this.Close(); 30  } 31 32 private void maxButton_Click(object sender, RoutedEventArgs e) 33  { 34 if (WindowState == WindowState.Normal) 35 WindowState = WindowState.Maximized; 36 else 37 WindowState = WindowState.Normal; 38  } 39 40 private void mniButton_Click(object sender, RoutedEventArgs e) 41  { 42 this.WindowState = WindowState.Minimized; 43  } 44 45 private void menuButton_Click(object sender, RoutedEventArgs e) 46  { 47 Menu.IsOpen = true; 48  } 49 50 private void Window_MouseLeftButtonDown(object sender, MouseButtonEventArgs e) 51  { 52 //拖动 53 this.DragMove(); 54  } 55 56 private void TabControl_SelectionChanged(object sender, SelectionChangedEventArgs e) 57  { 58 int index = this.tab360.SelectedIndex; 59 if (index == 0) 60  { 61 //可以设置TransitionType WpfPage 来更改界面出入的动画效果 62 //this.pTransitionControl_1.TransitionType = WpfPageTransitions.PageTransitionType.SpinAndFade; 63 pages.index newPage = new pages.index(); 64 this.pTransitionControl_1.ShowPage(newPage); 65 66  } 67 68 else if (index == 1) 69  { 70 pages.scan newPage = new pages.scan(); 71 this.pTransitionControl_2.ShowPage(newPage); 72  } 73 else if (index == 2) 74  { 75 pages.scan newPage = new pages.scan(); 76 this.pTransitionControl_3.ShowPage(newPage); 77  } 78 else 79  { 80 pages.index newPage = new pages.index(); 81 this.pTransitionControl_1.ShowPage(newPage); 82  } 83  } 84  } 85 }

当用户单击Tab页签时（切换事件），程序用pages.index newPage = new pages.index();先实例化一个page子页面（实际继承UserControl)，然后调用 this.pTransitionControl_1.ShowPage(newPage);将子页面进行加载(本质上是pTransitionControl_1.Content=newpage）。

4、运行代码，界面如下：

下面是360安全卫士界面截图，可对比一下，还是比较相似的。

源码下载地址：

仿360界面UI

WPF如何实现一款类似360安全卫士界面的程序？(共享源码!)

源码下载地址：

热门文章

最新文章

相关电子书

热门

活动广场

任务中心

开发者评测

高校计划

乘风者计划

训练营

阿里云MVP

话题

直播

下载

镜像站

技术资料

插件

WPF如何实现一款类似360安全卫士界面的程序？(共享源码!)

源码下载地址：

热门文章

最新文章

相关电子书
