pandas有强大的excel数据处理和导入处理功能，本文简单介绍pandas在csv和excel等格式方面处理的应用及绘制图表等功能。

pandas处理excel依赖xlutils, OpenPyXL, XlsxWriter等库。

本文代码地址

pandas数据读取概述

读写文本

Function	Description
read_csv	Load delimited data from a file, URL, or file-like object; use comma as default delimiter
read_table	Load delimited data from a file, URL, or file-like object; use tab ('\t') as default delimiter
read_fwf	Read data in fixed-width column format (i.e., no delimiters)
read_clipboard Version of	Read_table that	Reads data from the clipboard; useful for converting tables from web pages
read_excel	Read tabular data from an Excel XLS or XLSX file
read_hdf	Read HDF5 files written by pandas
read_html	Read all tables found in the given HTML document
read_json	Read data from a JSON (JavaScript Object Notation) string representation
read_msgpack	Read pandas data encoded using the MessagePack binary format
read_pickle	Read an arbitrary object stored in Python pickle format
read_sas	Read a SAS dataset stored in one of the SAS system’s custom storage formats
read_sql	Read the results of a SQL query (using SQLAlchemy) as a pandas DataFrame
read_stata	Read a dataset from Stata file format
read_feather	Read the Feather binary file format

参数主要涉及索引、类型推理和数据转换、日期时间处理、迭代、脏数据。

ex1.csv的内容如下：


a,b,c,d,message
1,2,3,4,hello
5,6,7,8,world
9,10,11,12,foo

读取：


In [9]: df = pd.read_csv('examples/ex1.csv')
In [10]: df
Out[10]:
a b c d message
0 1 2 3 4 hello
1 5 6 7 8 world
2 9 10 11 12 foo

还可以改用read_table读取


In [11]: pd.read_table('examples/ex1.csv', sep=',')
Out[11]:
a b c d message
0 1 2 3 4 hello
1 5 6 7 8 world
2 9 10 11 12 foo

ex2.csv的内容如下：


1,2,3,4,hello
5,6,7,8,world
9,10,11,12,foo

可以使用header=None表示没有列名，也可以用names自行指定列名，还可以使用index_col将列作为索引。


In [13]: pd.read_csv('examples/ex2.csv', header=None)
Out[13]:
0 1 2 3 4
0 1 2 3 4 hello
1 5 6 7 8 world
2 9 10 11 12 foo

In [14]: pd.read_csv('examples/ex2.csv', names=['a', 'b', 'c', 'd', 'message'])
Out[14]:
a b c d message
0 1 2 3 4 hello
1 5 6 7 8 world
2 9 10 11 12 foo
6.1

In [15]: names = ['a', 'b', 'c', 'd', 'message']
In [16]: pd.read_csv('examples/ex2.csv', names=names, index_col='message')
Out[16]:
a b c d
message
hello 1 2 3 4
world 5 6 7 8
foo 9 10 11 12

csv_mindex.csv的内容：


key1,key2,value1,value2
one,a,1,2
one,b,3,4
one,c,5,6
one,d,7,8
two,a,9,10
two,b,11,12
two,c,13,14
two,d,15,16

建立层级索引：


In [18]: parsed = pd.read_csv('examples/csv_mindex.csv',
....: index_col=['key1', 'key2'])
In [19]: parsed
Out[19]:
value1 value2
key1 key2
one a 1 2
b 3 4
c 5 6
d 7 8
two a 9 10
b 11 12
c 13 14
d 15 16

用正则表达式处理混合的分隔符：


In [20]: list(open('examples/ex3.txt'))
Out[20]:
[' A B C\n',
'aaa -0.264438 -1.026059 -0.619500\n',
'bbb 0.927272 0.302904 -0.032399\n',
'ccc -0.264273 -0.386314 -0.217601\n',
'ddd -0.871858 -0.348382 1.100491\n']

In [21]: result = pd.read_table('examples/ex3.txt', sep='\s+')
In [22]: result
Out[22]:
A B C
aaa -0.264438 -1.026059 -0.619500
bbb 0.927272 0.302904 -0.032399
ccc -0.264273 -0.386314 -0.217601
ddd -0.871858 -0.348382 1.100491

ex4.csv的内容：


# hey!
a,b,c,d,message
# just wanted to make things more difficult for you
# who reads CSV files with computers, anyway?
1,2,3,4,hello
5,6,7,8,world
9,10,11,12,foo

skiprows可以忽略行


In [24]: pd.read_csv('examples/ex4.csv', skiprows=[0, 2, 3])
Out[24]:
a b c d message
0 1 2 3 4 hello
1 5 6 7 8 world
2 9 10 11 12 foo

ex5.csv的内容：


something,a,b,c,d,message
one,1,2,3,4,NA
two,5,6,,8,world
three,9,10,11,12,foo

可以指定哪些值为缺失值，甚至可以针对行指定缺失值。


In [26]: result = pd.read_csv('examples/ex5.csv')
In [27]: result
Out[27]:
something a b c d message
0 one 1 2 3.0 4 NaN
1 two 5 6 NaN 8 world
2 three 9 10 11.0 12 foo
In [28]: pd.isnull(result)
Out[28]:
something a b c d message
0 False False False False False True
1 False False False True False False
2 False False False False False False

In [29]: result = pd.read_csv('examples/ex5.csv', na_values=['NULL'])
In [30]: result
Out[30]:
something a b c d message
0 one 1 2 3.0 4 NaN
1 two 5 6 NaN 8 world
2 three 9 10 11.0 12 foo

In [31]: sentinels = {'message': ['foo', 'NA'], 'something': ['two']}
In [32]: pd.read_csv('examples/ex5.csv', na_values=sentinels)
Out[32]:
something a b c d message
0 one 1 2 3.0 4 NaN
1 NaN 5 6 NaN 8 world
2 three 9 10 11.0 12 NaN

pandas.read_csv和pandas.read_table的常用参数如下：

Argument	Description
path	String indicating filesystem location, URL, or file-like object
sep or delimiter	Character sequence or regular expression to use to split fields in each row
header	Row number to use as column names; defaults to 0 (first row), but should be None if there is no header row。
index_col	Column numbers or names to use as the row index in the result; can be a single name/number or alist of them for a hierarchical index
names	List of column names for result, combine with header=None
skiprows	Number of rows at beginning of file to ignore or list of row numbers (starting from 0) to skip.
na_values	Sequence of values to replace with NA.
comment	Character(s) to split comments off the end of lines.
parse_dates	Attempt to parse data to datetime; False by default. If True, will attempt to parse all columns.Otherwise can specify a list of column numbers or name to parse. If element of list is tuple or list, willcombine multiple columns together and parse to date (e.g., if date/time split across two columns).
keep_date_col	If joining columns to parse date, keep the joined columns; False by default.
converters	Dict containing column number of name mapping to functions (e.g., {'foo': f} would apply the function f to all values in the 'foo' column).
dayfirst	When parsing potentially ambiguous dates, treat as international format (e.g., 7/6/2012 -> June 7,2012); False by default.
date_parser	Function to use to parse dates.
nrows	Number of rows to read from beginning of file.
iterator	Return a TextParser object for reading file piecemeal.
chunksize	For iteration, size of file chunks.
skip_footer	Number of lines to ignore at end of file.
verbose	Print various parser output information, like the number of missing values placed in non-numericcolumns.
encoding	Text encoding for Unicode (e.g., 'utf-8' for UTF-8 encoded text).
squeeze	If the parsed data only contains one column, return a Series.
thousands	Separator for thousands (e.g., ',' or '.').

参考资料：

https://www.dataquest.io/blog/excel-and-pandas/
Using Pandas to Read Large Excel Files in Python 中文
Foundations for Analytics with Python From Non-Programmer to Hacker - 2016.pdf
Python for Data Analysis, 2nd Edition - 2017.pdf 数据分析书籍下载
本文最新版本
本文涉及的python测试开发库谢谢点赞！
本文相关海量书籍下载

CSV

使用pandas读写csv

pandas_parsing_and_write.py


import pandas as pd

input_file = r"supplier_data.csv"
output_file = r"output_files\1output.csv"

data_frame = pd.read_csv(input_file)
print(data_frame)
data_frame.to_csv(output_file, index=False)

当然也可以用python实现：

1csv_simple_parsing_and_write.py


input_file = r"supplier_data.csv"
output_file = r"output_files\1output.csv"

with open(input_file, newline='') as filereader:
    with open(output_file, 'w', newline='') as filewriter:
        for row in filereader:
            filewriter.write(row)

2csv_reader_parsing_and_write.py


import csv

input_file = r"supplier_data.csv"
output_file = r"output_files\2output.csv"

with open(input_file, 'r', newline='') as csv_in_file:
    with open(output_file, 'w', newline='') as csv_out_file:
        filereader = csv.reader(csv_in_file, delimiter=',')
        filewriter = csv.writer(csv_out_file, delimiter=',')
        for row_list in filereader:
            filewriter.writerow(row_list)

过滤特定行

选择供应商名字包含Z或者Cost大于600的行

pandas_value_meets_condition.py


import pandas as pd

input_file = r"supplier_data.csv"
output_file = r"output_files\3output.csv"

data_frame = pd.read_csv(input_file)

data_frame['Cost'] = data_frame['Cost'].str.strip('$').astype(float)
data_frame_value_meets_condition = data_frame.loc[(data_frame['Supplier Name']\
.str.contains('Z')) | (data_frame['Cost'] > 600.0), :]

data_frame_value_meets_condition.to_csv(output_file, index=False)

注意pandas的strip连里面的内容都可以清除, 有点类似replace的功能。

选择符合一个集合的数据：

选择日期为'1/20/14', '1/30/14'的行


import pandas as pd

input_file = r"supplier_data.csv"
output_file = r"output_files\4output.csv"

data_frame = pd.read_csv(input_file)

important_dates = ['1/20/14', '1/30/14']
data_frame_value_in_set = data_frame.loc[data_frame['Purchase Date']\
.isin(important_dates), :]

data_frame_value_in_set.to_csv(output_file, index=False)

用正则表达式选择数据

pandas_value_matches_pattern.py


import pandas as pd

input_file = r"supplier_data.csv"
output_file = r"output_files\4output.csv"

data_frame = pd.read_csv(input_file)
data_frame_value_matches_pattern = data_frame.ix[data_frame['Invoice Number']\
.str.startswith("001-"), :]

data_frame_value_matches_pattern.to_csv(output_file, index=False)

过滤特定列

选择0,3列

pandas_column_by_index.py


import pandas as pd
import sys

input_file = r"supplier_data.csv"
output_file = r"output_files\6output.csv"

data_frame = pd.read_csv(input_file)
data_frame_column_by_index = data_frame.iloc[:, [0, 3]]
data_frame_column_by_index.to_csv(output_file, index=False)

pandas_column_by_index.py


import pandas as pd

input_file = r"supplier_data.csv"
output_file = r"output_files\7output.csv"

data_frame = pd.read_csv(input_file)
data_frame_column_by_name = data_frame.loc[
    :, ['Invoice Number', 'Purchase Date']]
data_frame_column_by_name.to_csv(output_file, index=False)

pandas_select_contiguous_rows.py


import pandas as pd

input_file = r"supplier_data_unnecessary_header_footer.csv"
output_file = r"output_files\11output.csv"

data_frame = pd.read_csv(input_file, header=None)
data_frame = data_frame.drop([0,1,2,16,17,18])
data_frame.columns = data_frame.iloc[0]
data_frame = data_frame.reindex(data_frame.index.drop(3))
data_frame.to_csv(output_file, index=False)

添加行头

pandas_add_header_row.py


import pandas as pd

input_file = r"supplier_data_no_header_row.csv"
output_file = r"output_files\11output.csv"
header_list = ['Supplier Name', 'Invoice Number', \
'Part Number', 'Cost', 'Purchase Date']
data_frame = pd.read_csv(input_file, header=None, names=header_list)
data_frame.to_csv(output_file, index=False)

合并多个文件

pandas_concat_rows_from_multiple_files.py


import pandas as pd
import glob
import os

input_path = r"D:\code\foundations-for-analytics-with-python\csv"
output_file = r"output_files\12output.csv"

all_files = glob.glob(os.path.join(input_path,'sales_*'))
all_data_frames = []
for file in all_files:
    data_frame = pd.read_csv(file, index_col=None)
    all_data_frames.append(data_frame)
data_frame_concat = pd.concat(all_data_frames, axis=0, ignore_index=True)
data_frame_concat.to_csv(output_file, index = False)

求和和求平均值

pandas_sum_average_from_multiple_files.py


import pandas as pd
import glob
import os

input_path = r"D:\code\foundations-for-analytics-with-python\csv"
output_file = r"output_files\12output.csv"

all_files = glob.glob(os.path.join(input_path,'sales_*'))
all_data_frames = []
for input_file in all_files:
    print(input_file)
    data_frame = pd.read_csv(input_file, index_col=None)

    print(data_frame)

    sales = pd.DataFrame([float(str(value).strip('$').replace(',',''))
      for value in data_frame.loc[:, 'Sale Amount']])

    total_cost = sales.sum()
    average_cost = sales.mean()

    data = {'file_name': os.path.basename(input_file),
            'total_sales': total_cost,
            'average_sales': average_cost}

    all_data_frames.append(pd.DataFrame(
        data, columns=['file_name', 'total_sales', 'average_sales']))

data_frames_concat = pd.concat(all_data_frames, axis=0, ignore_index=True)
data_frames_concat.to_csv(output_file, index = False)

XLS

使用pandas读写xls

pandas_parsing_and_write_keep_dates.py


import pandas as pd

input_file = "sales_2013.xlsx"
output_file = "pandas_output.xls"
data_frame = pd.read_excel(input_file, sheetname='january_2013')

writer = pd.ExcelWriter(output_file)
data_frame.to_excel(writer, sheet_name='jan_13_output', index=False)
writer.save()

过滤特定行

销售额大于1400的记录

pandas_value_meets_condition.py


import pandas as pd

input_file = "sales_2013.xlsx"
output_file = "pandas_output.xls"

data_frame = pd.read_excel(input_file, 'january_2013', index_col=None)
data_frame_value_meets_condition = \
    data_frame[data_frame['Sale Amount'].astype(float) > 1400.0]

writer = pd.ExcelWriter(output_file)
data_frame_value_meets_condition.to_excel(
    writer, sheet_name='jan_13_output', index=False)
writer.save()

指定日期的

pandas_value_in_set.py


import string

input_file = "sales_2013.xlsx"
output_file = "pandas_output.xls"

data_frame = pd.read_excel(input_file, 'january_2013', index_col=None)

important_dates = ['01/24/2013','01/31/2013']
data_frame_value_in_set = data_frame[data_frame['Purchase Date'].isin(important_dates)]

writer = pd.ExcelWriter(output_file)
data_frame_value_in_set.to_excel(writer, sheet_name='jan_13_output', index=False)
writer.save()

其他条件

startswith , endswith , match和search等。

pandas_value_matches_pattern.py


import pandas as pd

input_file = "sales_2013.xlsx"
output_file = "pandas_output.xls"

data_frame = pd.read_excel(input_file, 'january_2013', index_col=None)

data_frame_value_matches_pattern = data_frame[
    data_frame['Customer Name'].str.startswith("J")]

writer = pd.ExcelWriter(output_file)
data_frame_value_matches_pattern.to_excel(
    writer, sheet_name='jan_13_output', index=False)
writer.save()

选取特定列

iloc基于ｉｎｄｅｘ选取第２和第５列


import pandas as pd

input_file = "sales_2013.xlsx"
output_file = "pandas_output.xls"

data_frame = pd.read_excel(input_file, 'january_2013', index_col=None)

data_frame_column_by_index = data_frame.iloc[:, [1, 4]]

writer = pd.ExcelWriter(output_file)
data_frame_column_by_index.to_excel(
    writer, sheet_name='jan_13_output', index=False)
writer.save()

loc基于列名选取第２和第５列

pandas_column_by_name.py


import pandas as pd

input_file = "sales_2013.xlsx"
output_file = "pandas_output.xls"

data_frame = pd.read_excel(input_file, 'january_2013', index_col=None)

data_frame_column_by_name = data_frame.loc[:, ['Customer ID', 'Purchase Date']]

writer = pd.ExcelWriter(output_file)
data_frame_column_by_name.to_excel(
    writer, sheet_name='jan_13_output', index=False)
writer.save()

操作所有sheet

选取销售额大于2000的行

pandas_value_meets_condition_all_worksheets.py


import pandas as pd

input_file = "sales_2013.xlsx"
output_file = "pandas_output.xls"

data_frame = pd.read_excel(input_file, sheetname=None, index_col=None)

row_output = []
for worksheet_name, data in data_frame.items():
    row_output.append(data[data['Sale Amount'].replace('$', '').
                           replace(',', '').astype(float) > 2000.0])
filtered_rows = pd.concat(row_output, axis=0, ignore_index=True)

writer = pd.ExcelWriter(output_file)
filtered_rows.to_excel(writer, sheet_name='sale_amount_gt2000', index=False)
writer.save()

loc基于列名选取所有sheet的第2和第5列

pandas_value_meets_condition_all_worksheets.py


import pandas as pd

input_file = "sales_2013.xlsx"
output_file = "pandas_output.xls"

data_frame = pd.read_excel(input_file, sheet_name=None, index_col=None)

column_output = []
for worksheet_name, data in data_frame.items():
    column_output.append(data.loc[:, ['Customer Name', 'Sale Amount']])
selected_columns = pd.concat(column_output, axis=0, ignore_index=True)

writer = pd.ExcelWriter(output_file)
selected_columns.to_excel(
        writer, sheet_name='selected_columns_all_worksheets', index=False)
writer.save()

操作部分sheet

选取销售额大于２０００的行

pandas_value_meets_condition_set_of_worksheets.py


import pandas as pd

input_file = "sales_2013.xlsx"
output_file = "pandas_output.xls"

my_sheets = [0,1]
threshold = 1900.0

data_frame = pd.read_excel(input_file, sheetname=my_sheets, index_col=None)

row_list = []
for worksheet_name, data in data_frame.items():
    row_list.append(data[data['Sale Amount'].replace('$', '').
                         replace(',', '').astype(float) > threshold])
filtered_rows = pd.concat(row_list, axis=0, ignore_index=True)

writer = pd.ExcelWriter(output_file)
filtered_rows.to_excel(writer, sheet_name='set_of_worksheets', index=False)
writer.save()

处理多个excel

连接concat

pandas_concat_data_from_multiple_workbooks.py


import pandas as pd
import glob
import os

input_path = "/media/andrew/6446FA2346F9F5A0/code/foundations-for-analytics-\
with-python/excel"
output_file = "pandas_output.xls"

all_workbooks = glob.glob(os.path.join(input_path,'*.xls*'))
data_frames = []
for workbook in all_workbooks:
    all_worksheets = pd.read_excel(
            workbook, sheet_name=None, index_col=None)
    for worksheet_name, data in all_worksheets.items():
        data_frames.append(data)
all_data_concatenated = pd.concat(data_frames, axis=0, ignore_index=True)

writer = pd.ExcelWriter(output_file)
all_data_concatenated.to_excel(
        writer, sheet_name='all_data_all_workbooks', index=False)
writer.save()

求和

pandas_sum_average_multiple_workbooks.py


import pandas as pd
import glob
import os

input_path = "/media/andrew/6446FA2346F9F5A0/code/foundations-for-analytics-\
with-python/excel"
output_file = "pandas_output.xls"

all_workbooks = glob.glob(os.path.join(input_path,'*.xls*'))
data_frames = []
for workbook in all_workbooks:
    all_worksheets = pd.read_excel(workbook, sheetname=None, index_col=None)
    workbook_total_sales = []
    workbook_number_of_sales = []
    worksheet_data_frames = []
    worksheets_data_frame = None
    workbook_data_frame = None
    for worksheet_name, data in all_worksheets.items():
        total_sales = pd.DataFrame(
            [float(str(value).strip('$').replace(',','')) for value in
             data.ix[:, 'Sale Amount']]).sum()
        number_of_sales = len(data.loc[:, 'Sale Amount'])
        average_sales = pd.DataFrame(total_sales / number_of_sales)

        workbook_total_sales.append(total_sales)
        workbook_number_of_sales.append(number_of_sales)

        data = {'workbook': os.path.basename(workbook),
                'worksheet': worksheet_name,
                'worksheet_total': total_sales,
                'worksheet_average': average_sales}

        worksheet_data_frames.append(
            pd.DataFrame(data,
                         columns=['workbook', 'worksheet', 'worksheet_total',
                                  'worksheet_average']))
    worksheets_data_frame = pd.concat(
        worksheet_data_frames, axis=0, ignore_index=True)

    workbook_total = pd.DataFrame(workbook_total_sales).sum()
    workbook_total_number_of_sales = pd.DataFrame(
        workbook_number_of_sales).sum()
    workbook_average = pd.DataFrame(
        workbook_total / workbook_total_number_of_sales)

    workbook_stats = {'workbook': os.path.basename(workbook),
                      'workbook_total': workbook_total,
                      'workbook_average': workbook_average}

    workbook_stats = pd.DataFrame(workbook_stats,
                                  columns=['workbook', 'workbook_total',
                                           'workbook_average'])
    workbook_data_frame = pd.merge(
        worksheets_data_frame, workbook_stats, on='workbook', how='left')
    data_frames.append(workbook_data_frame)

all_data_concatenated = pd.concat(data_frames, axis=0, ignore_index=True)

writer = pd.ExcelWriter(output_file)
all_data_concatenated.to_excel(
    writer, sheet_name='sums_and_averages', index=False)
writer.save()

使用excel绘制图表


import pandas as pd
import random

# Some sample data to plot.
cat_1 = ['y1', 'y2', 'y3', 'y4']
index_1 = range(0, 21, 1)
multi_iter1 = {'index': index_1}
for cat in cat_1:
    multi_iter1[cat] = [random.randint(10, 100) for x in index_1]

# Create a Pandas dataframe from the data.
index_2 = multi_iter1.pop('index')
df = pd.DataFrame(multi_iter1, index=index_2)
df = df.reindex(columns=sorted(df.columns))

# Create a Pandas Excel writer using XlsxWriter as the engine.
excel_file = 'legend.xlsx'
sheet_name = 'Sheet1'

writer = pd.ExcelWriter(excel_file, engine='xlsxwriter')
df.to_excel(writer, sheet_name=sheet_name)

# Access the XlsxWriter workbook and worksheet objects from the dataframe.
workbook = writer.book
worksheet = writer.sheets[sheet_name]

# Create a chart object.
chart = workbook.add_chart({'type': 'line'})

# Configure the series of the chart from the dataframe data.
for i in range(len(cat_1)):
    col = i + 1
    chart.add_series({
        'name':       ['Sheet1', 0, col],
        'categories': ['Sheet1', 1, 0, 21, 0],
        'values':     ['Sheet1', 1, col, 21, col],
    })

# Configure the chart axes.
chart.set_x_axis({'name': 'Index'})
chart.set_y_axis({'name': 'Value', 'major_gridlines': {'visible': False}})

# Insert the chart into the worksheet.
worksheet.insert_chart('G2', chart)

# Close the Pandas Excel writer and output the Excel file.
writer.save()

讨论钉钉免费群21745728 qq群144081101 567351477

参考资料：http://pandas-xlsxwriter-charts.readthedocs.io/

[雪峰磁针石博客]使用pandas数据分析工具处理excel

pandas数据读取概述

读写文本

参考资料：

CSV

使用pandas读写csv

过滤特定行

过滤特定列

添加行头

合并多个文件

求和和求平均值

XLS

使用pandas读写xls

过滤特定行

选取特定列

操作所有sheet

操作部分sheet

处理多个excel

使用excel绘制图表

热门文章

最新文章

相关课程

相关电子书

相关实验场景

热门

活动广场

任务中心

开发者评测

高校计划

乘风者计划

训练营

阿里云MVP

话题

直播

下载

镜像站

技术资料

插件

[雪峰磁针石博客]使用pandas数据分析工具处理excel

pandas数据读取概述

读写文本

参考资料：

CSV

使用pandas读写csv

过滤特定行

过滤特定列

添加行头

合并多个文件

求和和求平均值

XLS

使用pandas读写xls

过滤特定行

选取特定列

操作所有sheet

操作部分sheet

处理多个excel

使用excel绘制图表

热门文章

最新文章

相关课程

相关电子书

相关实验场景
