9-51单片机ESP8266学习-AT指令(测试TCP服务器--51单片机程序配置8266,C#TCP客户端发信息给单片机控制小灯的亮灭)-阿里云开发者社区

http://www.cnblogs.com/yangfengwu/p/8780182.html

自己都是现做现写,如果想知道最终实现的功能,请看最后

先把源码和资料链接放到这里

链接：https://pan.baidu.com/s/10MxI8-Q33-M_R2WEHqEi1A 密码：j1sz

先说一下哈,不要嫌界面不好看,自己是为了程序尽量的简单,可以通过调整颜色或者通过重绘来使使界面好看,,,,,,,,咱先学会走.....

因为咱们会用到图片所以先把图片资源加载上来,为了

调整的好看一点

现在设置,切换图片

其实呢导入图片应该先建一个资源文件更合理,后期再说

现在是让按钮状态改变了

也修改一下灯的

private void pictureBox2_Click(object sender, EventArgs e)
        {
            if (LedFlage == false)
            {
                LedFlage = true;
                pictureBox2.BackgroundImage = Properties.Resources.switchon;
                pictureBox3.BackgroundImage = Properties.Resources.ledon;
            }
            else
            {
                LedFlage = false;
                pictureBox2.BackgroundImage = Properties.Resources.switchoff;
                pictureBox3.BackgroundImage = Properties.Resources.ledoff;
            }
        }

现在做连接服务器

先说一下很多初学者会遇到的问题

这种情况是你添加了控件的事件函数,然后你又删除了,,,因为我也是经常删.................

我刚才在考虑要不要用委托和回调.....后来想了想这篇就不用了,

大家记得自己试一下这个(反正给大家说了,下次自己肯定用委托和回调写,记住不要偷懒,如果你偷懒了,后期的文章你就会无从下手,因为你连基础的都不知道)

http://www.cnblogs.com/yangfengwu/p/5761841.html

因为和android 一样只有主线程才允许操作控件,咱们就

现在做连接服务器和断开连接

先在电脑上测试

先给现在的程序

using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Linq;
using System.Net;
using System.Net.Sockets;
using System.Text;
using System.Threading;
using System.Threading.Tasks;
using System.Windows.Forms;

namespace TCPClient
{
    public partial class Form1 : Form
    {
        bool LedFlage = false;
        bool ConncetFlage = false;
        private Thread ThreadConnectService;//连接服务器线程
        private IPAddress ipAddress;//ip地址
        int Port = 0;//端口号
        private TcpClient myTcpClient = null;// TcpClient
        private NetworkStream networkstrem = null;//网络数据流

        public Form1()
        {
            InitializeComponent();
        }

        private void Form1_Load(object sender, EventArgs e)
        {
            System.Windows.Forms.Control.CheckForIllegalCrossThreadCalls = false;//加了这一句


        }

        /*连接按钮点击事件*/
        private void button1_Click(object sender, EventArgs e)
        {
            if (ConncetFlage == false)
            {
                try{ThreadConnectService.Abort();}//先清除一下以前的
                catch (Exception){}
                ThreadConnectService = new Thread(ConncetService);//把连接服务器的函数加入任务
                ThreadConnectService.Start();//启动任务
            }
            else
            {
                ConncetFlage = false;
                button1.Text = "连接";
                pictureBox1.BackgroundImage = Properties.Resources.lightoff;
                try{  myTcpClient.Close(); }catch (Exception){}//关闭通道
            }
        }

        /*LED灯控制按钮(图片)*/
        private void pictureBox2_Click(object sender, EventArgs e)
        {
            if (LedFlage == false)
            {
                LedFlage = true;
                pictureBox2.BackgroundImage = Properties.Resources.switchon;
                pictureBox3.BackgroundImage = Properties.Resources.ledon;
            }
            else
            {
                LedFlage = false;
                pictureBox2.BackgroundImage = Properties.Resources.switchoff;
                pictureBox3.BackgroundImage = Properties.Resources.ledoff;
            }
        }

        /*连接服务器函数*/
        private void ConncetService()
        {
            ipAddress = IPAddress.Parse(textBox1.Text);//获取IP地址
            Port = Convert.ToInt32(textBox2.Text);     //获取端口号

            try
            {
                myTcpClient = new TcpClient(); //实例化myTcpClient
                myTcpClient.Connect(ipAddress, Port);//连接服务器
                ConncetFlage = true;
                button1.Text = "断开";
                pictureBox1.BackgroundImage = Properties.Resources.lighton;
            }
            catch (Exception)
            {
                ConncetFlage = false;
                button1.Text = "连接";
                pictureBox1.BackgroundImage = Properties.Resources.lightoff;
                try { myTcpClient.Close(); }
                catch (Exception) { }
            }
        }

    }
}

断开

忘了加一个功能,,,判断服务器是不是断开了

using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Linq;
using System.Net;
using System.Net.Sockets;
using System.Text;
using System.Threading;
using System.Threading.Tasks;
using System.Windows.Forms;

namespace TCPClient
{
    public partial class Form1 : Form
    {
        bool LedFlage = false;
        bool ConncetFlage = false;
        private Thread ThreadConnectService;//连接服务器线程
        private IPAddress ipAddress;//ip地址
        int Port = 0;//端口号
        private TcpClient myTcpClient = null;// TcpClient
        private NetworkStream networkstrem = null;//网络数据流

        private Thread ThreadReadData;//接收消息线程
        private bool ThreadReadDataFlage = false;//接收数据任务循环用

        byte[] ReadBuffer = new byte[1024];//设置缓冲区1024个字节
        int ReadCnt = 0;//获取接收到了几个字节

        public Form1()
        {
            InitializeComponent();
        }

        private void Form1_Load(object sender, EventArgs e)
        {
            System.Windows.Forms.Control.CheckForIllegalCrossThreadCalls = false;//加了这一句


        }

        /*连接按钮点击事件*/
        private void button1_Click(object sender, EventArgs e)
        {
            if (ConncetFlage == false)
            {
                try{ThreadConnectService.Abort();}//先清除一下以前的
                catch (Exception){}
                ThreadConnectService = new Thread(ConncetService);//把连接服务器的函数加入任务
                ThreadConnectService.Start();//启动任务
            }
            else
            {
                ConncetFlage = false;
                ThreadReadDataFlage = false;
                button1.Text = "连接";
                pictureBox1.BackgroundImage = Properties.Resources.lightoff;
                try{  myTcpClient.Close(); }catch (Exception){}//关闭通道
            }
        }

        /*LED灯控制按钮(图片)*/
        private void pictureBox2_Click(object sender, EventArgs e)
        {
            if (LedFlage == false)
            {
                LedFlage = true;
                pictureBox2.BackgroundImage = Properties.Resources.switchon;
                pictureBox3.BackgroundImage = Properties.Resources.ledon;
            }
            else
            {
                LedFlage = false;
                pictureBox2.BackgroundImage = Properties.Resources.switchoff;
                pictureBox3.BackgroundImage = Properties.Resources.ledoff;
            }
        }

        /*连接服务器函数*/
        private void ConncetService()
        {
            ipAddress = IPAddress.Parse(textBox1.Text);//获取IP地址
            Port = Convert.ToInt32(textBox2.Text);     //获取端口号

            try
            {
                myTcpClient = new TcpClient(); //实例化myTcpClient
                myTcpClient.Connect(ipAddress, Port);//连接服务器
                ConncetFlage = true;
                button1.Text = "断开";
                pictureBox1.BackgroundImage = Properties.Resources.lighton;

                networkstrem = myTcpClient.GetStream();//获取数据流

                ThreadReadDataFlage = true;
                try { ThreadReadData.Abort(); }//先清除一下以前的
                catch (Exception) { }
                ThreadReadData = new Thread(ReadData);//把接收数据的函数加入任务
                ThreadReadData.Start();
            }
            catch (Exception)
            {
                ConncetFlage = false;
                ThreadReadDataFlage = false;
                button1.Text = "连接";
                pictureBox1.BackgroundImage = Properties.Resources.lightoff;
                try { myTcpClient.Close(); }
                catch (Exception) { }
            }
        }

        /*接收消息函数*/
        private void ReadData()
        {
            while (ThreadReadDataFlage)
            {
                try
                {
                    ReadCnt = networkstrem.Read(ReadBuffer, 0, ReadBuffer.Length);//读取数据
                    if (ReadCnt != 0)//有数据
                    {

                    }
                    else//异常断开
                    {
                        ConncetFlage = false;
                        ThreadReadDataFlage = false;
                        button1.Text = "连接";
                        pictureBox1.BackgroundImage = Properties.Resources.lightoff;
                        try { myTcpClient.Close(); }
                        catch (Exception) { }
                    }
                }
                catch (Exception)
                {
                    ThreadReadDataFlage = false;
                }
            }
        }
    }
}

现在做数据发送部分,和APP那块几乎是一个模子刻出来的

using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Linq;
using System.Net;
using System.Net.Sockets;
using System.Text;
using System.Threading;
using System.Threading.Tasks;
using System.Windows.Forms;

namespace TCPClient
{
    public partial class Form1 : Form
    {
        bool LedFlage = false;
        bool ConncetFlage = false;
        private Thread ThreadConnectService;//连接服务器线程
        private IPAddress ipAddress;//ip地址
        int Port = 0;//端口号
        private TcpClient myTcpClient = null;// TcpClient
        private NetworkStream networkstrem = null;//网络数据流

        private Thread ThreadReadData;//接收消息线程
        private bool ThreadReadDataFlage = false;//接收数据任务循环用

        private Thread ThreadSendData;//发送消息线程
        private bool ThreadSendDataFlage = false;//发送数据任务循环用

        byte[] ReadBuffer = new byte[1024];//设置缓冲区1024个字节
        int ReadCnt = 0;//获取接收到了几个字节

        byte[] SendBuffer = new byte[1024];//设置发送缓冲区1024个字节
        int SendCnt = 0;//发送的个数

        public Form1()
        {
            InitializeComponent();
        }

        private void Form1_Load(object sender, EventArgs e)
        {
            System.Windows.Forms.Control.CheckForIllegalCrossThreadCalls = false;//加了这一句


        }

        /*连接按钮点击事件*/
        private void button1_Click(object sender, EventArgs e)
        {
            if (ConncetFlage == false)
            {
                try{ThreadConnectService.Abort();}//先清除一下以前的
                catch (Exception){}
                ThreadConnectService = new Thread(ConncetService);//把连接服务器的函数加入任务
                ThreadConnectService.Start();//启动任务
            }
            else
            {
                ConncetFlage = false;
                ThreadReadDataFlage = false;
                ThreadSendDataFlage = false;
                button1.Text = "连接";
                pictureBox1.BackgroundImage = Properties.Resources.lightoff;
                try{  myTcpClient.Close(); }catch (Exception){}//关闭通道
            }
        }

        /*LED灯控制按钮(图片)*/
        private void pictureBox2_Click(object sender, EventArgs e)
        {
            if (LedFlage == false)
            {
                SendBuffer[0] = 0xaa;
                SendBuffer[1] = 0x55;
                SendBuffer[2] = 0x02;
                SendBuffer[3] = 0xff;
                SendCnt = 4;

                LedFlage = true;
                pictureBox2.BackgroundImage = Properties.Resources.switchon;
                pictureBox3.BackgroundImage = Properties.Resources.ledon;
            }
            else
            {
                SendBuffer[0] = 0xaa;
                SendBuffer[1] = 0x55;
                SendBuffer[2] = 0x02;
                SendBuffer[3] = 0x00;
                SendCnt = 4;

                LedFlage = false;
                pictureBox2.BackgroundImage = Properties.Resources.switchoff;
                pictureBox3.BackgroundImage = Properties.Resources.ledoff;
            }
        }

        /*连接服务器函数*/
        private void ConncetService()
        {
            ipAddress = IPAddress.Parse(textBox1.Text);//获取IP地址
            Port = Convert.ToInt32(textBox2.Text);     //获取端口号

            try
            {
                myTcpClient = new TcpClient(); //实例化myTcpClient
                myTcpClient.Connect(ipAddress, Port);//连接服务器
                ConncetFlage = true;
                button1.Text = "断开";
                pictureBox1.BackgroundImage = Properties.Resources.lighton;

                networkstrem = myTcpClient.GetStream();//获取数据流

                /*接收消息任务*/
                ThreadReadDataFlage = true;
                try { ThreadReadData.Abort(); }//先清除一下以前的
                catch (Exception) { }
                ThreadReadData = new Thread(ReadData);//把接收数据的函数加入任务
                ThreadReadData.Start();

                /*发送消息任务*/
                ThreadSendDataFlage = true;
                try { ThreadSendData.Abort(); }//先清除一下以前的
                catch (Exception) { }
                ThreadSendData = new Thread(SendData);
                ThreadSendData.Start();
            }
            catch (Exception)
            {
                ConncetFlage = false;
                ThreadReadDataFlage = false;
                ThreadSendDataFlage = false;
                button1.Text = "连接";
                pictureBox1.BackgroundImage = Properties.Resources.lightoff;
                try { myTcpClient.Close(); }
                catch (Exception) { }
            }
        }

        /*接收消息函数*/
        private void ReadData()
        {
            while (ThreadReadDataFlage)
            {
                try
                {
                    ReadCnt = networkstrem.Read(ReadBuffer, 0, ReadBuffer.Length);//读取数据
                    if (ReadCnt != 0)//有数据
                    {

                    }
                    else//异常断开
                    {
                        ConncetFlage = false;
                        ThreadReadDataFlage = false;
                        ThreadSendDataFlage = false;
                        button1.Text = "连接";
                        pictureBox1.BackgroundImage = Properties.Resources.lightoff;
                        try { myTcpClient.Close(); }
                        catch (Exception) { }
                    }
                }
                catch (Exception)
                {
                    ThreadReadDataFlage = false;
                }
            }
        }

         /*发送消息函数*/
        private void SendData()
        {
            while (ThreadSendDataFlage)
            {
                try
                {
                    if (SendCnt>0)
                    {
                        networkstrem.Write(SendBuffer, 0, SendCnt);
                        SendCnt = 0;
                    }
                }
                catch (Exception)
                {
                    ConncetFlage = false;
                    ThreadReadDataFlage = false;
                    ThreadSendDataFlage = false;
                    button1.Text = "连接";
                    pictureBox1.BackgroundImage = Properties.Resources.lightoff;
                    try { myTcpClient.Close(); }
                    catch (Exception) { }
                }
            }
        }

    }
}
