Iperf介绍
iperf是一个基于TCP/IP和UDP/IP的网络性能测试工具,用于检测网络带宽使用率和网络质量,能测试最大TCP和UDP带宽性能,可以报告带宽、网络延迟抖动、数据包丢失率和最大传输单元等统计信息等。如测试服务器和网络设备如路由器,交换机,防火墙等的网络性能。
Iperf的主要功能
1、TCP方面
-
测试网络带宽
-
支持多线程,在客户端与服务端支持多重连接
-
报告MSS/MTU值大小
-
支持TCP窗口值自定义并可通过套接字缓冲
2、UDP方面
-
可以设置指定带宽的UDP数据流
-
可以测试网络抖动值、丢包数
-
支持多播测试
-
支持多线程,在客户端与服务器端支持多重连接
Iperf的安装
1、下载源码包,官方地址:https://iperf.fr/iperf-download.php
2、安装
1
2
3
4
|
[root@web1 ~]
# tar zxf iperf-3.1.2-source.tar.gz
[root@web1 ~]
# cd iperf-3.1.2
[root@web1 iperf-3.1.2]
# ./configure
[root@web1 iperf-3.1.2]
# make && make install
|
3、参数(iperf3 -h)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
|
[root@web1 ~]
# iperf3 -h
Usage: iperf [-s|-c host] [options]
iperf [-h|--help] [-
v
|--version]
Server or Client:
-p, --port
# server port to listen on/connect to
-f, --
format
[kmgKMG]
format
to report: Kbits, Mbits, KBytes, MBytes
-i, --interval
# seconds between periodic bandwidth reports
-F, --
file
name xmit
/recv
the specified
file
-A, --affinity n
/n
,m
set
CPU affinity
-B, --bind <host> bind to a specific interface
-V, --verbose
more
detailed output
-J, --json output
in
JSON
format
--logfile f send output to a log
file
-d, --debug emit debugging output
-
v
, --version show version information and quit
-h, --help show this message and quit
Server specific:
-s, --server run
in
server mode
-D, --daemon run the server as a daemon
-I, --pidfile
file
write PID
file
-1, --one-off handle one client connection
then
exit
Client specific:
-c, --client <host> run
in
client mode, connecting to <host>
-u, --udp use UDP rather than TCP
-b, --bandwidth
#[KMG][/#] target bandwidth in bits/sec (0 for unlimited)
(default 1 Mbit
/sec
for
UDP, unlimited
for
TCP)
(optional slash and packet count
for
burst mode)
-t, --
time
# time in seconds to transmit for (default 10 secs)
-n, --bytes
#[KMG] number of bytes to transmit (instead of -t)
-k, --blockcount
#[KMG] number of blocks (packets) to transmit (instead of -t or -n)
-l, --len
#[KMG] length of buffer to read or write
(default 128 KB
for
TCP, 8 KB
for
UDP)
--cport <port> bind to a specific client port (TCP and UDP, default: ephemeral port)
-P, --parallel
# number of parallel client streams to run
-R, --reverse run
in
reverse mode (server sends, client receives)
-w, --window
#[KMG] set window size / socket buffer size
-C, --congestion <algo>
set
TCP congestion control algorithm (Linux and FreeBSD only)
-M, --
set
-mss
# set TCP/SCTP maximum segment size (MTU - 40 bytes)
-N, --no-delay
set
TCP
/SCTP
no delay, disabling Nagle's Algorithm
-4, --version4 only use IPv4
-6, --version6 only use IPv6
-S, --tos N
set
the IP
'type of service'
-L, --flowlabel N
set
the IPv6 flow label (only supported on Linux)
-Z, --zerocopy use a
'zero copy'
method of sending data
-O, --omit N omit the first n seconds
-T, --title str prefix every output line with this string
--get-server-output get results from server
--udp-counters-64bit use 64-bit counters
in
UDP
test
packets
[KMG] indicates options that support a K
/M/G
suffix
for
kilo-, mega-, or giga-
iperf3 homepage at: http:
//software
.es.net
/iperf/
Report bugs to: https:
//github
.com
/esnet/iperf
|
Iperf应用实例
iperf是以C/S模式工作,运行于服务端和客户端下。服务端主要用于监听到达的测试请求,而客户端主要用于发起连接会话。因此要使用iperf,需要两台服务器,一台运行在服务器模式下,一台运行在客户端模式下。
1、测试TCP吞吐量
启动一个服务器端,使用iperf -s命令,默认监听5201端口,在客户端使用iperf -c +服务端ip,运行测试(这里使用web1作为服务端,web2作为客户端)
由输出结果看出,iperf默认输出10s的状态,Transfer列输出每秒的数量量在370MB左右,Bandwidth列显示网卡的速率
2、指定iperf的运行时间(-t参数)和输出速率(-i参数)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
|
##指定20秒内每隔5秒输出一次结果
[root@web2 ~]
# iperf3 -c 192.168.1.250 -t 20 -i 5
Connecting to host 192.168.1.250, port 5201
[ 4]
local
192.168.1.209 port 55780 connected to 192.168.1.250 port 5201
[ ID] Interval Transfer Bandwidth Retr Cwnd
[ 4] 0.00-5.00 sec 1.79 GBytes 3.07 Gbits
/sec
0 1.07 MBytes
[ 4] 5.00-10.00 sec 1.85 GBytes 3.18 Gbits
/sec
0 1.16 MBytes
[ 4] 10.00-15.00 sec 1.83 GBytes 3.14 Gbits
/sec
0 1.20 MBytes
[ 4] 15.00-20.00 sec 1.78 GBytes 3.06 Gbits
/sec
0 1.24 MBytes
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bandwidth Retr
[ 4] 0.00-20.00 sec 7.25 GBytes 3.11 Gbits
/sec
0 sender
[ 4] 0.00-20.00 sec 7.24 GBytes 3.11 Gbits
/sec
receiver
iperf Done.
|
3、指定发送数据量(-n参数)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
|
#指定发送一个5GB左右的数据包,并且每隔2秒输出状态结果
[root@web2 ~]
# iperf3 -c 192.168.1.250 -i 2 -n 5000000000
Connecting to host 192.168.1.250, port 5201
[ 4]
local
192.168.1.209 port 56432 connected to 192.168.1.250 port 5201
[ ID] Interval Transfer Bandwidth Retr Cwnd
[ 4] 0.00-2.00 sec 758 MBytes 3.18 Gbits
/sec
0 952 KBytes
[ 4] 2.00-4.00 sec 769 MBytes 3.23 Gbits
/sec
0 984 KBytes
[ 4] 4.00-6.00 sec 757 MBytes 3.17 Gbits
/sec
0 1.01 MBytes
[ 4] 6.00-8.00 sec 684 MBytes 2.87 Gbits
/sec
0 1.05 MBytes
[ 4] 8.00-10.00 sec 734 MBytes 3.08 Gbits
/sec
0 1.08 MBytes
[ 4] 10.00-12.00 sec 754 MBytes 3.16 Gbits
/sec
0 1.11 MBytes
[ 4] 12.00-12.88 sec 313 MBytes 2.99 Gbits
/sec
0 1.12 MBytes
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bandwidth Retr
[ 4] 0.00-12.88 sec 4.66 GBytes 3.11 Gbits
/sec
0 sender
[ 4] 0.00-12.88 sec 4.65 GBytes 3.10 Gbits
/sec
receiver
iperf Done.
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
|
##指定一个文件传输(-F)
[root@web2 ~]
# du -sh ntopng-2.2.tar.gz
88M ntopng-2.2.
tar
.gz
[root@web2 ~]
# iperf3 -c 192.168.1.250 -F ntopng-2.2.tar.gz -t 20-i 2
Connecting to host 192.168.1.250, port 5201
[ 4]
local
192.168.1.209 port 56948 connected to 192.168.1.250 port 5201
[ ID] Interval Transfer Bandwidth Retr Cwnd
[ 4] 0.00-0.12 sec 36.7 MBytes 2.47 Gbits
/sec
0 420 KBytes
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bandwidth Retr
[ 4] 0.00-0.12 sec 36.7 MBytes 2.47 Gbits
/sec
0 sender
Sent 36.7 MByte / 87.1 MByte (42%) of ntopng-2.2.
tar
.gz
[ 4] 0.00-0.12 sec 34.9 MBytes 2.36 Gbits
/sec
receiver
iperf Done.
|
4、指定多线程网络传输测试(-P),同时可以使用-f M参数将结果通过MBytes/sec来显示
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
|
#使用单线程传输,传输10GB的数据一共消耗了27.36秒,平均速率为350 MBytes/sec
[root@web2 ~]
# iperf3 -c 192.168.1.250 -n 10000000000 -i 5 -f M
Connecting to host 192.168.1.250, port 5201
[ 4]
local
192.168.1.209 port 57348 connected to 192.168.1.250 port 5201
[ ID] Interval Transfer Bandwidth Retr Cwnd
[ 4] 0.00-5.00 sec 1.58 GBytes 324 MBytes
/sec
0 1.11 MBytes
[ 4] 5.00-10.00 sec 1.62 GBytes 333 MBytes
/sec
0 1.21 MBytes
[ 4] 10.00-15.00 sec 1.65 GBytes 339 MBytes
/sec
0 1.27 MBytes
[ 4] 15.00-20.00 sec 1.76 GBytes 361 MBytes
/sec
0 1.31 MBytes
[ 4] 20.00-25.00 sec 1.82 GBytes 373 MBytes
/sec
37 1.32 MBytes
[ 4] 25.00-27.36 sec 886 MBytes 376 MBytes
/sec
0 1.35 MBytes
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bandwidth Retr
[ 4] 0.00-27.36 sec 9.31 GBytes 349 MBytes
/sec
37 sender
[ 4] 0.00-27.36 sec 9.31 GBytes 348 MBytes
/sec
receiver
iperf Done.
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
|
[root@web2 ~]
# iperf3 -c 192.168.1.250 -n 10000000000 -i 5
Connecting to host 192.168.1.250, port 5201
[ 4]
local
192.168.1.209 port 57585 connected to 192.168.1.250 port 5201
[ ID] Interval Transfer Bandwidth Retr Cwnd
[ 4] 0.00-5.00 sec 1.87 GBytes 3.21 Gbits
/sec
0 990 KBytes
[ 4] 5.00-10.00 sec 1.87 GBytes 3.22 Gbits
/sec
0 1.04 MBytes
[ 4] 10.00-15.00 sec 1.81 GBytes 3.12 Gbits
/sec
0 1.12 MBytes
[ 4] 15.00-20.00 sec 1.75 GBytes 3.01 Gbits
/sec
0 1.20 MBytes
[ 4] 20.00-25.00 sec 1.76 GBytes 3.03 Gbits
/sec
14 1.37 MBytes
[ 4] 25.00-25.81 sec 245 MBytes 2.53 Gbits
/sec
0 1.38 MBytes
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bandwidth Retr
[ 4] 0.00-25.81 sec 9.31 GBytes 3.10 Gbits
/sec
14 sender
[ 4] 0.00-25.81 sec 9.31 GBytes 3.10 Gbits
/sec
receiver
iperf Done.
|
5、指定多线程传输
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
|
[root@web2 ~]
# iperf3 -c 192.168.1.250 -n 10000000000 -i 5 -P 2 -f M
Connecting to host 192.168.1.250, port 5201
[ 4]
local
192.168.1.209 port 57751 connected to 192.168.1.250 port 5201
[ 6]
local
192.168.1.209 port 57752 connected to 192.168.1.250 port 5201
[ ID] Interval Transfer Bandwidth Retr Cwnd
[ 4] 0.00-5.00 sec 905 MBytes 181 MBytes
/sec
0 585 KBytes
[ 6] 0.00-5.00 sec 903 MBytes 181 MBytes
/sec
0 602 KBytes
[SUM] 0.00-5.00 sec 1.77 GBytes 362 MBytes
/sec
0
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 4] 5.00-10.00 sec 917 MBytes 183 MBytes
/sec
0 687 KBytes
[ 6] 5.00-10.00 sec 917 MBytes 183 MBytes
/sec
0 704 KBytes
[SUM] 5.00-10.00 sec 1.79 GBytes 367 MBytes
/sec
0
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 4] 10.00-15.00 sec 929 MBytes 186 MBytes
/sec
0 723 KBytes
[ 6] 10.00-15.00 sec 929 MBytes 186 MBytes
/sec
0 735 KBytes
[SUM] 10.00-15.00 sec 1.81 GBytes 372 MBytes
/sec
0
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 4] 15.00-20.00 sec 921 MBytes 184 MBytes
/sec
0 745 KBytes
[ 6] 15.00-20.00 sec 920 MBytes 184 MBytes
/sec
0 759 KBytes
[SUM] 15.00-20.00 sec 1.80 GBytes 368 MBytes
/sec
0
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 4] 20.00-25.00 sec 919 MBytes 184 MBytes
/sec
0 782 KBytes
[ 6] 20.00-25.00 sec 919 MBytes 184 MBytes
/sec
0 802 KBytes
[SUM] 20.00-25.00 sec 1.79 GBytes 368 MBytes
/sec
0
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 4] 25.00-25.97 sec 179 MBytes 184 MBytes
/sec
0 785 KBytes
[ 6] 25.00-25.97 sec 180 MBytes 185 MBytes
/sec
0 803 KBytes
[SUM] 25.00-25.97 sec 359 MBytes 369 MBytes
/sec
0
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bandwidth Retr
[ 4] 0.00-25.97 sec 4.66 GBytes 184 MBytes
/sec
0 sender
[ 4] 0.00-25.97 sec 4.65 GBytes 183 MBytes
/sec
receiver
[ 6] 0.00-25.97 sec 4.66 GBytes 184 MBytes
/sec
0 sender
[ 6] 0.00-25.97 sec 4.65 GBytes 183 MBytes
/sec
receiver
[SUM] 0.00-25.97 sec 9.31 GBytes 367 MBytes
/sec
0 sender
[SUM] 0.00-25.97 sec 9.30 GBytes 367 MBytes
/sec
receiver
iperf Done.
|
6、测试UDP丢包和延迟,使用-u参数指定UDP协议,-b(K|M|G)参数指定UD式使用的带宽模式
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
|
[root@web2 ~]
# iperf3 -c 192.168.1.250 -u -b 1G -f M -i 2
Connecting to host 192.168.1.250, port 5201
[ 4]
local
192.168.1.209 port 45424 connected to 192.168.1.250 port 5201
[ ID] Interval Transfer Bandwidth Total Datagrams
[ 4] 0.00-2.00 sec 81.1 MBytes 40.5 MBytes
/sec
10377
[ 4] 2.00-4.00 sec 94.5 MBytes 47.3 MBytes
/sec
12102
[ 4] 4.00-6.00 sec 94.6 MBytes 47.3 MBytes
/sec
12107
[ 4] 6.00-8.00 sec 103 MBytes 51.5 MBytes
/sec
13192
[ 4] 8.00-10.00 sec 93.6 MBytes 46.8 MBytes
/sec
11983
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bandwidth Jitter Lost
/Total
Datagrams
[ 4] 0.00-10.00 sec 467 MBytes 46.7 MBytes
/sec
0.037 ms 435
/59760
(0.73%)
[ 4] Sent 59760 datagrams
iperf Done.
|
由输出结果显示,Jitter表示抖动时间,或者称为传输延迟,Lost/Total表示丢失的数据包和总的数据包数量,Datagrams表示总共传输数据包的数量
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
|
#在服务端的输出
Accepted connection from 192.168.1.209, port 58179
[ 5]
local
192.168.1.250 port 5201 connected to 192.168.1.209 port 45424
[ ID] Interval Transfer Bandwidth Jitter Lost
/Total
Datagrams
[ 5] 0.00-1.00 sec 35.6 MBytes 299 Mbits
/sec
0.054 ms 29
/4590
(0.63%)
[ 5] 1.00-2.00 sec 43.0 MBytes 361 Mbits
/sec
0.071 ms 30
/5533
(0.54%)
[ 5] 2.00-3.00 sec 48.4 MBytes 406 Mbits
/sec
0.154 ms 29
/6225
(0.47%)
[ 5] 3.00-4.00 sec 45.6 MBytes 382 Mbits
/sec
0.026 ms 6
/5837
(0.1%)
[ 5] 4.00-5.00 sec 47.3 MBytes 397 Mbits
/sec
0.168 ms 124
/6183
(2%)
[ 5] 5.00-6.00 sec 46.1 MBytes 387 Mbits
/sec
0.023 ms 40
/5941
(0.67%)
[ 5] 6.00-7.00 sec 49.0 MBytes 411 Mbits
/sec
0.022 ms 48
/6322
(0.76%)
[ 5] 7.00-8.00 sec 53.1 MBytes 446 Mbits
/sec
0.037 ms 67
/6867
(0.98%)
[ 5] 8.00-9.00 sec 44.9 MBytes 376 Mbits
/sec
0.163 ms 26
/5769
(0.45%)
[ 5] 9.00-10.00 sec 48.4 MBytes 406 Mbits
/sec
0.015 ms 36
/6232
(0.58%)
[ 5] 10.00-10.04 sec 2.04 MBytes 426 Mbits
/sec
0.037 ms 0
/261
(0%)
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bandwidth Jitter Lost
/Total
Datagrams
[ 5] 0.00-10.04 sec 0.00 Bytes 0.00 bits
/sec
0.037 ms 435
/59760
(0.73%)
-----------------------------------------------------------
Server listening on 5201
-----------------------------------------------------------
|
