配置
首先需要注意的是：要想适用 jpgraph ，你的 PHP 必须开启了 GD2 扩展。
在 jpgraph.php 中有以下这样一段代码是设置字体文件路径的
if (!defined('TTF_DIR')) {

if (strstr( PHP_OS, 'WIN') ) {

$sroot = getenv('SystemRoot');

if( empty($sroot) ) {

$t = new ErrMsgText();

$msg = $t->Get(12,$file,$lineno);

die($msg);

}

else {

define('TTF_DIR', $sroot.'/fonts/');

}

} else {

define('TTF_DIR','/usr/share/fonts/truetype/'); ç ( 我的作法是将 windows 下的 fonts 文件夹下的字体全部 COPY 到 /usr/local/fonts/truetype)

}

要支持中文需要用到 simhei.ttf 和 simsun.ttc 这两个字体 , 在使用中文的时候需要使用 SetFont(FF_SIMSUN,FS_BOLD) 设置字体。

如果你的文件编码为 utf-8, 修改方法如下：
代码：
方法一，在程序中修改
$title=" 流量图 ";
$title = iconv("UTF-8", "gb2312", $title);
$graph->title->Set($title);
方法二，修改源文件 jpgraph_ttf.inc.php
在第 99-106 行，改成下面这样子
   elseif( $aFF === FF_SIMSUN ) {
        // Do Chinese conversion
        /*
        if( $this->g2312 == null ) {
       include_once 'jpgraph_gb2312.php' ;
       $this->g2312 = new GB2312toUTF8();
        }
        return $this->g2312->gb2utf8($aTxt);
        */
       return $aTxt;
   }

jpgraph 默认显示汉字时是把汉字编码认为 gb2312, 转化为 utf-8 以后再显示。
这样的话，如果你的文件编码是 gb2312,SetFont 方法的第一个参数为 FF_SIMSUN 即可。
如果你是 utf-8 编码你还需要先把汉字编码转化为 gb2312 ，这样你的汉字才可以正常显示。

使用
可以参照 jpgraph-2.3.4\src\Examples 中的例子。下面是一些常用的：
$graph->title->Set(‘ 设置图表的标题 ’);
$graph->xaxis->title->Set(" 设置 X 轴的标题 ");
$graph->yaxis->title->Set(" 设置 Y 轴的标题 ");

// 设置字体如果是中文，第一个参数一般设置为 FF_SIMSUN
SetFont(FF_SIMSUN,FS_BOLD,14);
// 如设置图表标题的字体
$graph->title->SetFont(FF_SIMSUN,FS_BOLD,14);

// 设置颜色
SetColor('red');

Example:

<?php

include ("../jpgraph.php");

include ("../jpgraph_line.php");

// 将要用于图表创建的数据存放在数组中

$data = array(19,23,34,38,45,67,71,78,85,90,96,145);

$graph = new Graph(500,300); // 创建新的 Graph 对象

$graph->SetScale("textlin"); // 设置刻度样式

$graph->img->SetMargin(30,30,80,30); // 设置图表边界

$graph->title->Set("CDN Traffic Total"); // 设置图表标题

$graph->title->SetColor("blue");

$graph->title->SetMargin(20);

// Create the linear plot

$lineplot=new LinePlot($data); // 创建新的 LinePlot 对象

$lineplot->SetLegend("Line(Mbits)"); // 设置图例文字

$lineplot->SetColor("red"); // 设置曲线的颜色

// Add the plot to the graph

$graph->Add($lineplot); // 在统计图上绘制曲线

// Display the graph

$graph->Stroke(); // 输出图像

?>

<?php

include ("../jpgraph.php");

include ("../jpgraph_line.php");

$data1 = array(523,634,371,278,685,587,490,256,398,545,367,577); // 第一条曲线的数组

$data2 = array(19,23,34,38,45,67,71,78,85,87,90,96); // 第二条曲线的数组

$graph = new Graph(500,300,auto); // 创建新的 Graph 对象

$graph->SetScale("textlin");

$graph->SetShadow(); // 设置图像的阴影样式

$graph->img->SetMargin(60,30,30,70); // 设置图像边距

$graph->title->Set("CDN 流量图 "); // 设置图像标题

$graph->title->SetMargin(10);

$lineplot1=new LinePlot($data1); // 创建设置两条曲线对象

$lineplot2=new LinePlot($data2);

$lineplot1->value->Show();

$lineplot1->value->SetColor("black");

$graph->Add($lineplot1); // 将曲线放置到图像上

$graph->Add($lineplot2);

$graph->xaxis->title->Set(" 月份 "); // 设置坐标轴名称

$graph->yaxis->title->Set(" 流量 (Gbits)");

$graph->xaxis->title->SetMargin(10);

$graph->yaxis->title->SetMargin(10);

$graph->title->SetFont(FF_SIMSUN,FS_BOLD); // 设置字体

$graph->yaxis->title->SetFont(FF_SIMSUN,FS_BOLD);

$graph->xaxis->title->SetFont(FF_SIMSUN,FS_BOLD);

$graph->xaxis->SetTickLabels($gDateLocale->GetShortMonth());

$lineplot1->SetColor("red"); // 设置颜色

$lineplot2->SetColor("blue");

$lineplot1->SetLegend("Max"); // 设置图例名称

$lineplot2->SetLegend("Min");

$graph->legend->SetLayout(LEGEND_HOR); // 设置图例样式和位置

$graph->legend->Pos(0.5,0.96,"center","bottom");

$graph->Stroke(); // 输出图像

?>

<?php

include ("../jpgraph.php");

include ("../jpgraph_bar.php");

$data = array(19,23,34,38,45,67,71,78,85,87,96,145); // 定义数组

$ydata = array(" 一 "," 二 "," 三 "," 四 "," 五 "," 六 "," 七 "," 八 "," 九 "," 十 "," 十一 "," 十二 ");

$graph = new Graph(500,300); // 创建新的 Graph 对象

$graph->SetScale("textlin");

$graph->SetShadow(); // 设置阴影

$graph->img->SetMargin(40,30,40,50); // 设置边距

$barplot = new BarPlot($data); // 创建 BarPlot 对象

$barplot->SetFillColor('blue'); // 设置颜色

$barplot->value->Show(); // 设置显示数字

$graph->Add($barplot); // 将柱形图添加到图像中

$graph->title->Set("CDN 流量图 "); // 设置标题和 X-Y 轴标题

$graph->title->SetColor("red");

$graph->title->SetMargin(10);

$graph->xaxis->title->Set(" 月份 ");

$graph->xaxis->title->SetMargin(5);

$graph->xaxis->SetTickLabels($ydata);

$graph->yaxis->title->Set(" 流量 (Mbits)");

$graph->title->SetFont(FF_SIMSUN,FS_BOLD); // 设置字体

$graph->yaxis->title->SetFont(FF_SIMSUN,FS_BOLD);

$graph->xaxis->title->SetFont(FF_SIMSUN,FS_BOLD);

$graph->xaxis->SetFont(FF_SIMSUN,FS_BOLD);

$graph->Stroke();

?>

<?php

include ("../jpgraph.php");

include ("../jpgraph_pie.php");

$data = array(19,23,34,38,45,67,71,78,85,87,90,96);

$lable_data = range(1,12);

$graph = new PieGraph(400,300);

$graph->SetShadow();

$graph->title->Set("CDN 流量比例 ");

$graph->title->SetFont(FF_SIMSUN,FS_BOLD);

$pieplot = new PiePlot($data);

$pieplot->SetLegends($lable_data);

$pieplot->SetCenter(0.4);

$graph->Add($pieplot);

$graph->Stroke();

?>

<?php

include ("../jpgraph.php");

include ("../jpgraph_pie.php");

include ("../jpgraph_pie3d.php");

$data = array(19,23,34,38,45,67,71,78,85,87,90,96);

$graph = new PieGraph(550,400);

$graph->SetShadow();

$graph->title->Set("CDN 流量比例 ");

$graph->title->SetFont(FF_SIMSUN,FS_BOLD);

$pieplot = new PiePlot3D($data); // 创建 PiePlot3D 对象

$pieplot->SetCenter(0.4); // 设

置饼图中心的位置

$pieplot->SetLegends($gDateLocale->GetShortMonth()); // 设置图例

$graph->Add($pieplot);

$graph->Stroke();

?>

index.html

<html>

<head>

<title>CDN 流量查询系统统计 </title>

<mce:style type="text/css"><!--

.style1 {

font-size: 16px;

font-weight: bold;

}

--></mce:style><style type="text/css" mce_bogus="1">.style1 {

font-size: 16px;

font-weight: bold;

}</style>

</head>

<body>

<p align="center" class="style1"> CDN 流量查询系统统计 </p>

<tr>

</select></td>

</tr>

<tr>

</select></td>

</tr>

<tr>

</select></td>

</tr>

<tr>

<td><strong> 统计图类别 </strong></td>

</select></td>

</tr>

</table>

</p>

</form>

</body>

</html>

result.php

<?php

include ("../jpgraph.php");

include ("../jpgraph_line.php");

include ("../jpgraph_bar.php");

include ("../jpgraph_pie.php");

include ("../jpgraph_pie3d.php");

$conn = mysql_connect("localhost", "root", "woxiangnileyali"); // 连接数据库

$acct_yr = $_GET['acct_yr']; // 获取年份

$start_mth = $_GET['start_mth']; // 获取超始月份

$end_mth = $_GET['end_mth']; // 获取结束月份

$choose = $_GET['graph']; // 获取图形类型

mysql_select_db("test", $conn); // 执行 SQL, 获得销量值

$query_rs_prod = "SELECT acct_mth, amount FROM traffic WHERE acct_yr = '$acct_yr' and acct_mth between '$start_mth' and '$end_mth'";

$rs_prod = mysql_query($query_rs_prod, $conn) or die(mysql_error());

$row_rs_prod = mysql_fetch_assoc($rs_prod);

$totalRows_rs_prod = mysql_num_rows($rs_prod);

$data = array(0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0); // 初始化数组

do // 循环设置各月份数值

{

$i = (int)$row_rs_prod['acct_mth']-1;

$data[$i] = $row_rs_prod['amount'];

} while($row_rs_prod = mysql_fetch_assoc($rs_prod));

switch($choose)

{

case 1:

$graph = new Graph(400,300); // 创建新的 Graph 对象

$graph->SetScale("textlin"); // 设置刻度样式

$graph->img->SetMargin(30,30,80,30); // 设置图表边界

$graph->title->SetFont(FF_SIMSUN,FS_BOLD); // 设置字体

$graph->title->Set("CDN 流量查询 "); // 设置图表标题

$lineplot=new LinePlot($data);

$lineplot->SetLegend("Line");

$lineplot->SetColor("red");

$graph->Add($lineplot);

break;

case 2:

$graph = new Graph(400,300);

$graph->SetScale("textlin");

$graph->SetShadow();

$graph->img->SetMargin(40,30,20,40);

$barplot = new BarPlot($data); // 创建 BarPlot 对象

$barplot->SetFillColor('blue'); // 设置颜色

$barplot->value->Show(); // 设置显示数字

$graph->Add($barplot); // 将柱形图添加到图像中

$graph->title->Set("CDN 流量查询 "); // 设置标题和 X-Y 轴标题

$graph->xaxis->title->Set(" 月份 ");

$graph->yaxis->title->Set(" 流量 (Gbits)");

$graph->title->SetFont(FF_SIMSUN,FS_BOLD); // 设置字体

$graph->yaxis->title->SetFont(FF_SIMSUN,FS_BOLD);

$graph->xaxis->title->SetFont(FF_SIMSUN,FS_BOLD);

break;

case 3:

$graph = new PieGraph(400,300);

$graph->SetShadow();

$graph->title->Set("CDN 流量查询 ");

$graph->title->SetFont(FF_SIMSUN,FS_BOLD);

$pieplot = new PiePlot($data);

$pieplot->SetLegends($gDateLocale->GetShortMonth()); // 设置图例

$graph->Add($pieplot);

break;

case 4:

$graph = new PieGraph(400,300);

$graph->SetShadow();

$graph->title->Set("CDN 流量查询 ");

$graph->title->SetFont(FF_SIMSUN,FS_BOLD);

$pieplot = new PiePlot3D($data); // 创建 PiePlot3D 对象

$pieplot->SetCenter(0.4); // 设置饼图中心的位置

$pieplot->SetLegends($gDateLocale->GetShortMonth()); // 设置图例

$graph->Add($pieplot);

break;

default:

echo "graph 参数错误 ";

exit;

}

$graph->Stroke();

?>

jpgraph 实例文档

例1. php Jpgraph绘制简单的X-Y坐标图

例2. php Jpgraph绘制复杂的X-Y坐标图

例3. php Jpgraph绘制柱形图

例4. php Jpgraph绘制饼图

例5. php Jpgraph绘制3D饼图

例6.
