~ # esxcfg-scsidevs -a (Check RAID Controller and HBA Card Driver Name)
vmhba0 hpsa link-n/a sas.50014380356b0930 (0:2:0.0) Hewlett-Packard Company Smart Array P830i
vmhba1 qla2xxx link-up fc.500143803315dc4d:500143803315dc4c (0:4:0.0) QLogic Corp ISP2532-based 8Gb Fibre Channel to PCI Express HBA
vmhba2 qla2xxx link-up fc.500143803315dc4f:500143803315dc4e (0:4:0.1) QLogic Corp ISP2532-based 8Gb Fibre Channel to PCI Express HBA
vmhba3 qla2xxx link-up fc.500143803315dc85:500143803315dc84 (0:196:0.0) QLogic Corp ISP2532-based 8Gb Fibre Channel to PCI Express HBA
vmhba4 qla2xxx link-up fc.500143803315dc87:500143803315dc86 (0:196:0.1) QLogic Corp ISP2532-based 8Gb Fibre Channel to PCI Express HBA
~ # vmkchdev -l |grep vmhba0
00:02:00.0 103c:323c 103c:1921 vmkernel vmhba0
~ # vmkchdev -l |grep vmhba1
00:04:00.0 1077:2532 103c:3263 vmkernel vmhba1
~ # vmkload_mod -s hpsa | grep Version (Check RAID Controller Driver Version / RAID Controller Firmware Version check from iLO)
Version: Version 5.0.0.114-1OEM, Build: 472560, Interface: 9.2 Built on: Oct 2 2015
~ # vmkload_mod -s qla2xxx | grep Version (Check HBA Card Driver Version)
Version: Version 934.5.45.0-1vmw, Build: 472560, Interface: 9.2 Built on: Sep 26 2014
/proc/scsi/qla2xxx # head -4 3 (Check HBA Card Firmware Version)
QLogic PCI to Fibre Channel Host Adapter for HPAJ764A:
FC Firmware version 7.04.00 (90d5), Driver version 934.5.45.0-1vmw
/proc/scsi/qla2xxx # esxcfg-nics -l (Check Network Card Driver Name)
Name PCI Driver Link Speed Duplex MAC Address MTU Description
vmnic0 0000:03:00.00 tg3 Up 1000Mbps Full 28:80:23:a5:b4:a8 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic1 0000:03:00.01 tg3 Up 1000Mbps Full 28:80:23:a5:b4:a9 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic10 0000:81:00.02 tg3 Up 1000Mbps Full 28:80:23:ac:95:de 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic11 0000:81:00.03 tg3 Up 1000Mbps Full 28:80:23:ac:95:df 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic12 0000:c1:00.00 tg3 Up 1000Mbps Full 28:80:23:ac:d3:54 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic13 0000:c1:00.01 tg3 Up 1000Mbps Full 28:80:23:ac:d3:55 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic14 0000:c1:00.02 tg3 Up 1000Mbps Full 28:80:23:ac:d3:56 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic15 0000:c1:00.03 tg3 Down 0Mbps Full 28:80:23:ac:d3:57 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic2 0000:03:00.02 tg3 Up 1000Mbps Full 28:80:23:a5:b4:aa 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic3 0000:03:00.03 tg3 Up 1000Mbps Full 28:80:23:a5:b4:ab 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic4 0000:41:00.00 tg3 Up 1000Mbps Full 28:80:23:ac:d1:14 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic5 0000:41:00.01 tg3 Down 0Mbps Full 28:80:23:ac:d1:15 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic6 0000:41:00.02 tg3 Up 1000Mbps Full 28:80:23:ac:d1:16 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic7 0000:41:00.03 tg3 Up 1000Mbps Full 28:80:23:ac:d1:17 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic8 0000:81:00.00 tg3 Up 1000Mbps Full 28:80:23:ac:95:dc 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
vmnic9 0000:81:00.01 tg3 Up 1000Mbps Full 28:80:23:ac:95:dd 1500 Broadcom Corporation NetXtreme BCM5719 Gigabit Ethernet
/proc/scsi/qla2xxx # ethtool -i vmnic0 (Check Network Card Driver and Firmware Version)
driver: tg3
version: 3.136h.v50.1
firmware-version: 5719-v1.41 NCSI v1.3.7.0
bus-info: 0000:03:00.0
/proc/scsi/qla2xxx # vmkchdev -l |grep vmnic0
00:03:00.0 14e4:1657 103c:169d vmkernel vmnic0
/proc/scsi/qla2xxx # esxcli network nic get -n vmnic0
Advertised Auto Negotiation: true
Advertised Link Modes: 10baseT/Half, 10baseT/Full, 100baseT/Half, 100baseT/Full, 1000baseT/Half, 1000baseT/Full
Auto Negotiation: true
Cable Type: Twisted Pair
Current Message Level: 4260095
Driver Info:
Bus Info: 0000:03:00.0
Driver: tg3
Firmware Version: 5719-v1.41 NCSI v1.3.7.0
Version: 3.136h.v50.1
Link Detected: true
Link Status: Up
Name: vmnic0
PHYAddress: 1
Pause Autonegotiate: true
Pause RX: true
Pause TX: true
Supported Ports: TP
Supports Auto Negotiation: true
Supports Pause: true
Supports Wakeon: true
Transceiver: internal
Wakeon: MagicPacket(tm)
2016-03-02T05:19:28.596Z
~ # esxcfg-scsidevs -a
vmhba0 ata_piix link-n/a sata.vmhba0 (0:0:31.2) Intel Corporation ICH10 4 port SATA IDE Controller
vmhba1 hpsa link-n/a sas.500143802128f030 (0:3:0.0) Hewlett-Packard Company Smart Array P410i
vmhba2 qla2xxx link-up fc.50014380186bfe21:50014380186bfe20 (0:17:0.0) QLogic Corp ISP2532-based 8Gb Fibre Channel to PCI Express HBA
vmhba3 qla2xxx link-up fc.50014380186bfe23:50014380186bfe22 (0:17:0.1) QLogic Corp ISP2532-based 8Gb Fibre Channel to PCI Express HBA
vmhba4 qla2xxx link-up fc.50014380186bf4e1:50014380186bf4e0 (0:144:0.0) QLogic Corp ISP2532-based 8Gb Fibre Channel to PCI Express HBA
vmhba5 qla2xxx link-up fc.50014380186bf4e3:50014380186bf4e2 (0:144:0.1) QLogic Corp ISP2532-based 8Gb Fibre Channel to PCI Express HBA
vmhba32 ata_piix link-n/a sata.vmhba32 (0:0:31.2) Intel Corporation ICH10 4 port SATA IDE Controller
~ # vmkchdev -l |grep vmhba0
00:00:1f.2 8086:3a20 103c:330d vmkernel vmhba0
~ # vmkchdev -l |grep vmhba1
00:03:00.0 103c:323a 103c:3245 vmkernel vmhba1
~ # vmkload_mod -s hpsa | grep Version
Version: Version 5.0.0.74-1OEM, Build: 472560, Interface: 9.2 Built on: Aug 5 2014
vmkload_mod -s qla2xxx | grep Version
Version: Version 934.5.38.0-1vmw, Build: 472560, Interface: 9.2 Built on: Apr 15 2014
/proc/scsi/qla2xxx # head -4 3
QLogic PCI to Fibre Channel Host Adapter for HPAJ764A:
FC Firmware version 7.03.00 (90d5), Driver version 934.5.38.0-1vmw
Host Device Name vmhba2
