镜像 安装过系统的虚拟硬盘
管理是用glance来完成。
镜像的状态：
active 镜像已经上传完成，并且是可用的
saving 正在被上传，还没有完成
killed 上传出错
queued 并没有真的上传完成，但是被标记有这个镜像
安装glance
在 keystone注册
glance所需要的账户
创建glance服务
指定glance服务的endpoint
安装
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
|
[root@h4 ~]
# yum -y install openstack-glance.noarch
[root@h4 ~]
# openstack-db --init --service glance --password 123456 -rootpw 123456
[root@h4 ~(keystone_admin)]
# keystone user-create --name glance --pass 123456
[root@h4 ~(keystone_admin)]
# keystone user-role-add --user glance --tenant services --role admin
[root@h4 ~(keystone_admin)]
# keystone service-create --name glance --type image --description "glance jingxiang"
[root@h4 ~(keystone_admin)]
# keystone endpoint-create --service-id 3d0969b633044029a895da1ca2855464 --publicurl 'http://192.168.1.204:9292' --internalurl 'http://192.168.1.204:9292' --adminurl 'http://192.168.1.204:9292'
+-------------+----------------------------------+
| Property | Value |
+-------------+----------------------------------+
| adminurl | http:
//192
.168.1.204:9292 |
|
id
| e0f7718b18444f71a43762ca3336ef06 |
| internalurl | http:
//192
.168.1.204:9292 |
| publicurl | http:
//192
.168.1.204:9292 |
| region | regionOne |
| service_id | 3d0969b633044029a895da1ca2855464 |
+-------------+----------------------------------+
|
修改配置文件
|
1
2
3
4
5
6
7
8
9
10
11
12
13
|
[root@h4 glance(keystone_admin)]
# systemctl list-unit-files | grep glanc
openstack-glance-api.service disabled 接受用户的请求
openstack-glance-registry.service disabled 和数据库进行交互
openstack-glance-scrubber.service disabled 和其他接口进行交互
[root@h4 glance(keystone_admin)]
# ls
glance-api.conf glance-registry.conf metadefs schema-image.json
glance-cache.conf glance-scrubber.conf policy.json
[root@h4 glance(keystone_admin)]
# cd /usr/share/glance/模板
[root@h4 glance(keystone_admin)]
# ls
glance-api-dist.conf glance-registry-dist.conf
glance-api-dist-
paste
.ini glance-registry-dist-
paste
.ini
glance-cache-dist.conf glance-scrubber-dist.conf
[root@h4 glance(keystone_admin)]
# cp glance-api-dist.conf /etc/glance/glance-api.conf ##拷贝模板
|
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
|
[root@h4 glance(keystone_admin)]
# vim glance-api.conf
[DEFAULT]
debug = False
verbose = True
use_stderr = False
log_file =
/var/log/glance/api
.log
filesystem_store_datadir =
/var/lib/glance/images/
scrubber_datadir =
/var/lib/glance/scrubber
image_cache_dir =
/var/lib/glance/image-cache/
rabbit_host = 192.168.1.204
rabbit_port = 5672
rabbit_hosts = $rabbit_host:$rabbit_port
rabbit_use_ssl =
false
rabbit_userid = guest
rabbit_password = guest
rabbit_login_method = AMQPLAIN
[database]
connection = mysql:
//glance
:123456@192.168.1.204
/glance
[keystone_authtoken]
admin_tenant_name = services
admin_user = glance
admin_password = 123456
auth_host = 192.168.1.204
auth_port = 35357
auth_protocol = http
auth_uri = http:
//192
.168.1.204:5000/
[paste_deploy]
config_file =
/usr/share/glance/glance-api-dist-paste
.ini
flavor = keystone
|
|
1
2
3
|
[root@h4 glance]
# chown root.glance glance-api.conf
[root@h4 glance]
# systemctl start openstack-glance-api.service openstack-glance-registry.service openstack-glance-scrubber.service
[root@h4 glance]
# systemctl enable openstack-glance-api.service openstack-glance-registry.service openstack-glance-scrubber.service
|
管理
|
1
2
3
4
5
6
7
8
9
10
11
|
[root@h4 ~(keystone_admin)]
# glance image-list
+----+------+
| ID | Name |
+----+------+
+----+------+
[root@h4 ~(keystone_admin)]
# glance help image-create
##########################先上传一个镜像再创建
[root@h4 ~(keystone_admin)]
# glance image-create --name hequan --file hequan.img --disk-format qcow2 --visibility publice --container-format bare ##创建
[root@h4 ~(keystone_admin)]
# glance image-create --name hequan --os-distro http://mirrors.163.com/centos/7.2.1511/isos/x86_64/CentOS-7-x86_64-Minimal-1511.iso --disk-format iso --container-format bare
filesystem_store_datadir =
/var/lib/glance/images/
###镜像保存的位置
#default_store=file
|
修改镜像存储位置
swift 做后端存储
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
|
6
#filesystem_store_datadir = /var/lib/glance/images/ ##先禁用
[glance_store]
default_store = swift 默认为
file
改为swift
stores =
file
, http 默认不用动
swift_store_auth_version = 2 默认版本为2
stores=glance.store.swift.Store,glance.store.filesystem.Store 此项一定要加上，不然无法上传
swift_store_auth_address = http:
//192
.168.1.204:5000
/v2
.0/ controller的keystone认证
swift_store_user = service:swift 使用swift用户
swift_store_key = hequan 密码
swift_store_container = glance 将要被创建的容器
swift_store_create_container_on_put = True 上传开
swift_store_large_object_size = 5120 最大5G限制，但与glance结合后限制无效
swift_store_large_object_chunk_size = 200 最大200个容器
swift_enable_snet = False
[root@h4 glance(keystone_admin)]
# systemctl restart openstack-glance-api.service openstack-glance-registry.service openstack-glance-scrubber.service
|
ceph 共享存储
安装epel仓库
|
1
2
3
4
5
6
7
8
9
10
11
12
|
rpm -vih http:
//mirrors
.sohu.com
/fedora-epel/7/x86_64/e/epel-release-7-2
.noarch.rpm
添加yum ceph仓库
vim
/etc/yum
.repos.d
/ceph
.repo
[ceph]
name=Ceph noarch packages
baseurl=http:
//mirrors
.163.com
/ceph/rpm-hammer/el7/x86_64/
enabled=1
gpgcheck=1
type
=rpm-md
gpgkey=http:
//mirrors
.163.com
/ceph/keys/release
.asc
安装ceph-deploy,ceph（ceph所有节点都安装，ceph-deploy只需admin节点安装）
yum -y update && yum -y
install
--release hammer ceph ceph-deploy
|
1 生成相关的MOD信息 监控服务器 h5
|
1
2
3
|
[root@h5 xx]
# ceph-deploy new h5
[root@h5 xx]
# ls
ceph.conf ceph-deploy-ceph.log ceph.mon.keyring
|
2 要根据自己的情况修改配置文件ceph.conf
|
1
2
|
osd_pool_default_size = 2
##几个节点组成，默认是3
osd_pool_defaults_min_size = 1
##最小值是1
|
3 生成key 当客户端要链接到ceph服务器，需要用户名和密码
|
1
2
3
4
5
|
[root@h5 xx]
# ceph-deploy mon create-initial
[root@h5 myceph]
# ls
ceph.bootstrap-mds.keyring ceph.client.admin.keyring ceph.mon.keyring
ceph.bootstrap-osd.keyring ceph.conf
ceph.bootstrap-rgw.keyring ceph.log
|
4 开始准备配置OSD
|
1
2
3
4
|
mkdir
path1 path2
[root@h5 xx]
# ceph-deploy osd prepare h5:/path1 h6:/path2
[root@h5 xx]
# ceph-deploy osd activate h5:/path1 h6:/path2 ##激活
[ceph_deploy.osd][DEBUG ] Host h5 is now ready
for
osd use.
|
5 把key复制到各个节点上去
|
1
2
|
[root@h5 ceph]
# ceph-deploy admin h5 h6
[root@h5 ceph]
# ceph health ##健康性检查
|
6 生成元数据
|
1
2
3
4
|
[root@h5 ceph]
# ceph-deploy mds create h5
[root@h5 ceph]
# rados lspools
[root@h5 ceph]
# rados mkpool glance
[root@h5 ceph]
# rados rmpool glance glance --yes-i-really-really-mean-it ##删除
|
glance配置成ceph的客户端
安装ceph
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
|
[root@h4 ceph(keystone_admin)]
# ls
rbdmap
[root@h5 myceph]
# ceph-deploy admin h4
[root@h4 ceph(keystone_admin)]
# ls
ceph.client.admin.keyring ceph.conf rbdmap tmp6BxOoY
vim glance-api.conf
[glance_store]
default_store = rbd
stores = rbd
rbd_store_pool = glance
rbd_store_user = admin
rbd_store_ceph_conf =
/etc/ceph/ceph
.conf
rbd_store_chunk_size = 8
systemctl restart openstack-glance-api.service openstack-glance-registry.service openstack-glance-scrubber.service
-rw------- 1 root root 63 7月 21 16:43 ceph.client.admin.keyring
setfacl -m u:glance:r-- ceph.client.admin.keyring
##设置权限 能读
|
制作镜像
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
|
yum -y groupinstall
"Server with GUI"
yum
install
virt-manager python-virtinst qemu-kvm-tools qemu-kvm libvirt
KVM
创建存储卷 centos.qcow2
基本安装
配置网卡 删除MAC
安装基本组件openssh-clients
cloud-init
##云包
[root@h4 ~]
# vim /etc/default/grub
GRUB_CMDLINE_LINUX=
"net.ifnames=0 biosdevname=0 console=tty0 console=ttyS0,115200n8 rhgb quiet"
##指定串口的参数
[root@h4 ~]
# grub2-mkconfig -o /boot/grub2/grub.cfg
封装
[root@h5 ~]
# yum whatprovides */virt-sysprep
[root@h5 ~]
# yum -y install libguestfs-bash-completion-1.28.1-1.55.el7.centos.noarch
[root@h4 ~]
# virt-sysprep -d centos
[root@h4 ~]
# cd /openstack-image/
[root@h4 openstack-image]
# qemu-img info centos.qcow2
qemu-img conver -c -o qcow2 centos.qcow2 newcentos.qcow2
###3 压缩命令
|
