1.拓扑图：
2.接口配置：
R1(config)#int f0/0
R1(config-if)#ip add 10.1.1.11 255.255.255.0
R1(config-if)#no sh
R2(config)#int f0/0
R2(config-if)#ip add 10.1.1.12 255.255.255.0
R2(config-if)#no sh
R3#vlan database
R3(vlan)#vlan 10
VLAN 10 added:
Name: VLAN0010
R3(vlan)#exit
APPLY completed.
Exiting....
R3(config)#int f0/0
R3(config-if)#switchport mode access
R3(config-if)#switchport access vlan 10
R3(config-if)#int f0/15
R3(config-if)#swi mo acc
R3(config-if)#swi acc vlan 10
R4#vlan data
R4(vlan)#vlan 20
VLAN 20 added:
Name: VLAN0020
R4(vlan)#exit
APPLY completed.
Exiting....
R4#
R4#config t
Enter configuration commands, one per line. End with CNTL/Z.
R4(config)#int f0/0
R4(config-if)#swi mo acc
R4(config-if)#swi acc vlan 20
R4(config-if)#int f0/15
R4(config-if)#swi mo acc
R4(config-if)#swi acc vlan 20
3.IPS配置：
A.确认g0/1和g/2接口都已经enabled
B.创建接口对，将g0/1和g/2接口加入接口对
C.将接口对关联到virtual sensor
4.测试：
A.在R1上连续ping R2
R1#ping 10.1.1.12 repeat 100
Type escape sequence to abort.
Sending 100, 100-byte ICMP Echos to 10.1.1.12, timeout is 2 seconds:
.!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
Success rate is 99 percent (99/100), round-trip min/avg/max = 12/27/108 ms
B.在IPS上能看到攻击事件
