使用阿里云消息队列

控制台地址:http://ons.console.aliyun.com/#/home/topic

(1)生成Producer ID

点击"申请发布"

示例代码:

Java代码
package com.alibaba.ons.demo;

import java.util.Properties;

import com.aliyun.openservices.ons.api.Message;
import com.aliyun.openservices.ons.api.ONSFactory;
import com.aliyun.openservices.ons.api.Producer;
import com.aliyun.openservices.ons.api.PropertyKeyConst;
import com.aliyun.openservices.ons.api.SendResult;

public class ProducerClient {

    public static void main(String[] args) {
       Properties properties = new Properties();
       properties.put(PropertyKeyConst.ProducerId, "PID_whuang");
       properties.put(PropertyKeyConst.AccessKey, "请输入AccessKey");
       properties.put(PropertyKeyConst.SecretKey, "请输入SecretKey");
       Producer producer = ONSFactory.createProducer(properties);

       //在发送消息前，必须调用start方法来启动Producer，只需调用一次即可。
       producer.start();
       Message msg = new Message(
            //Message Topic
            "com_hbjltv",
            //Message Tag,
            //可理解为Gmail中的标签，对消息进行再归类，方便Consumer指定过滤条件在ONS服务器过滤
            "TagA",
            //Message Body
            //任何二进制形式的数据，ONS不做任何干预，需要Producer与Consumer协商好一致的序列化和反序列化方式
            "Hello ONS".getBytes()
        );

        // 设置代表消息的业务关键属性，请尽可能全局唯一。
        // 以方便您在无法正常收到消息情况下，可通过ONS Console查询消息并补发。
        // 注意：不设置也不会影响消息正常收发
        msg.setKey("ORDERID_100");

        //发送消息，只要不抛异常就是成功
        SendResult sendResult = producer.send(msg);
        System.out.println(sendResult);

        // 在应用退出前，销毁Producer对象
        // 注意：如果不销毁也没有问题
        producer.shutdown();
    }
}

(2)生成Consumer ID

点击"申请订阅"

示例代码:

Java代码
public class ConsumerTest {
    public static void main(String[] args) {
        Properties properties = new Properties();
        properties.put(PropertyKeyConst.ConsumerId, "CID_tv_mobile");
        properties.put(PropertyKeyConst.AccessKey, "请输入AccessKey");
        properties.put(PropertyKeyConst.SecretKey, "请输入SecretKey");
        Consumer consumer = ONSFactory.createConsumer(properties);
        consumer.subscribe("com_hbjltv", "*", new MessageListener() {
            public Action consume(Message message, ConsumeContext context) {
                System.out.println("Receive: " + message);
                return Action.CommitMessage;
            }
        });
        consumer.start();
        System.out.println("Consumer Started");
    }
}

(3) clientId 的限制

阿里云消息队列对clientId的名称有严格限制:

(a)必须以申请的Consumer ID 开头,后面跟@@@,接着跟用于区分客户端的标志,

例如:

CID_tv_mobile@@@86458fd 是合法的

CID_tv_mobile@@86458fd 是非法的,因为只有两个@

(b)总长度不能超过23个字符

例如

CID_tv_mobile@@@86458_A是合法的

CID_tv_mobile@@@86458_Ab是非法的,因为超过了23个字符

(4)在手机端(客户端)增加订阅逻辑

Java代码
package com.service;

import java.security.InvalidKeyException;
import java.security.NoSuchAlgorithmException;

import org.eclipse.paho.client.mqttv3.MqttClient;
import org.eclipse.paho.client.mqttv3.MqttConnectOptions;
import org.eclipse.paho.client.mqttv3.MqttException;
import org.eclipse.paho.client.mqttv3.internal.MemoryPersistence;

import android.app.Service;
import android.content.Context;
import android.content.Intent;
import android.content.SharedPreferences;
import android.os.IBinder;

import com.common.util.SystemHWUtil;
import com.dict.Constants3;
import com.jianli.R;
import com.push.PushCallback;
import com.string.widget.util.ValueWidget;
import com.util.MacSignature;
import com.util.ShopUtil;

/**
 * @author Dominik Obermaier
 */
public class MQTTService extends Service {

    // public static final String BROKER_URL =
    // "tcp://broker.mqttdashboard.com:1883";
    // public static String BROKER_URL = "tcp://172.16.15.50:1883";
    public static String BROKER_URL_FORMAT = "tcp://%s:%s";
    // public static final String BROKER_URL = "tcp://test.mosquitto.org:1883";

    /*
     * In a real application, you should get an Unique Client ID of the device
     * and use this, see
     * http://android-developers.blogspot.de/2011/03/identifying
     * -app-installations.html
     */
    public static String clientId = null;

    /**
     * 不能含有英文句点,可以包含下划线
     */
    public static final String TOPIC = "com_hbjltv";
    private MqttClient mqttClient;
//  private String ip="182.92.80.122";
    /***
     * 是否连接上activeMQ
     */
    private boolean online = false;
    boolean isAliyun=false;

    public IBinder onBind(Intent intent) {
        return null;
    }

    @Override
    public void onCreate() {
        super.onCreate();
    }

    private MqttClient createMqttClient(String serverURL, String clientId) throws MqttException{
        return new MqttClient(serverURL, clientId,
                new MemoryPersistence());
    }
    /***
     *
     * @param serverURL
     * @param clientId
     *            : 最大长度:23
     * @param isAllowOffline
     * @param username
     * @param password
     * @throws MqttException
     */
    private void connectAndSubscribe(String serverURL, String clientId,
    /* String topicFilter, */boolean isAllowOffline, String username,
            String password) throws MqttException {

        if(isAliyun){
            if(!ShopUtil.validateClientId(getApplicationContext(), clientId)){
                return;
            }
        }
        mqttClient = createMqttClient(serverURL, clientId);
        MqttConnectOptions options = new MqttConnectOptions();
        options.setCleanSession(!isAllowOffline);// mqtt receive offline message
        if (ValueWidget.isNullOrEmpty(username)) {
            username = null;
        }
        String sign=null;
        if(isAliyun){
            try {
                sign = MacSignature.macSignature(Constants3.CONSUMER_ID_TV, password);
                password=sign;
            } catch (InvalidKeyException e) {
                e.printStackTrace();
            } catch (NoSuchAlgorithmException e) {
                e.printStackTrace();
            }

        }
        if (ValueWidget.isNullOrEmpty(password)) {
            password = null;
        } else {
            options.setPassword(password.toCharArray());
        }
        options.setUserName(username);
        options.setConnectionTimeout(10);
        options.setKeepAliveInterval(10);
        if(null==mqttClient){//点击HOME键,过很长时间,再点击应用时,mqttClient为null
            mqttClient = createMqttClient(serverURL, clientId);
        }
        mqttClient.setCallback(new PushCallback(this));
        boolean isSuccess=false;
        mqttClient.connect(options);
        isSuccess=true;
        // Subscribe to all subtopics of homeautomation
        // mqttClient.subscribe(topicFilter);
        if(null==mqttClient){//点击HOME键,过很长时间,再点击应用时,mqttClient为null
            mqttClient = createMqttClient(serverURL, clientId);
        }
        if(isAliyun){
            final String p2ptopic = TOPIC+"/p2p/";
            //同时订阅两个topic，一个是基于标准mqtt协议的发布订阅模式，一个是扩展的点对点推送模式
            final String[] topicFilters=new String[]{TOPIC,p2ptopic};
            mqttClient.subscribe(topicFilters);
        }else{
            mqttClient.subscribe(new String[] { TOPIC, clientId });
        }
    }

    @Override
    public void onStart(Intent intent, int startId) {
        final boolean isRestart=intent.getBooleanExtra("isRestart", false);
        ShopUtil.logger2("restart MQTT service:"+isRestart);
        // super.onStart(intent, startId);
//      if (intent == null) {//重启服务时intent 确实为空

//          Log.d(Constants.LOG_TAG, "intent is null");
//          return;
//      }
        Context context = getApplicationContext();
        clientId = ShopUtil.getIMEI(context);
        // Bundle bundle=intent.getExtras();
        // String ip=bundle.getString(Constants.ACTIVEMQ_IP);
//      final String ip = context.getString(R.string.pushserver_ip);
        SharedPreferences preferences = getApplicationContext()
                .getSharedPreferences(Constants3.SHAREDPREFERENCES_NAME,
                        Context.MODE_PRIVATE);
        final String ip ="mqtt.ons.aliyun.com";// preferences.getString("pushserver_ip", context.getString(R.string.pushserver_ip));
        final String port = preferences.getString("pushserver_port", "1883");
        isAliyun=SystemHWUtil.parse2Boolean(preferences.getString("is_aliyun_mq_ONS", "false"));
        // String topic=bundle.getString(Constants.ACTIVEMQ_TOPIC);
         System.out.println("push ip:"+ip);
        new Thread(new Runnable() {
            /****
             * 尝试连接的次数,为什么要尝试连接几次那?
             * (1)无wifi时启动,则肯定连接失败,所以尝试连接三次,只要在这个期间启动wifi就可以连接上activeMQ;<br />
             * (2)之前连接上,然后断开wifi,然后又启动wifi,<br />
             * 这时容易报 "Broker unavailable"异常,暂时不清楚原因,所以也需要继续尝试连接;<br />
             *
             */
            private int tryTime = 5;

            @Override
            public void run() {
                System.out.println(tryTime+","+mqttClient+","+isOnline() );
                while (tryTime > 0
                        && (!isOnline() || mqttClient == null || (!mqttClient
                                .isConnected())||isRestart)) {
                    try {
                        ShopUtil.logger2("start push service");
                        ShopUtil.logger2("push server:"+ip);
                        String prefix=Constants3.CONSUMER_ID_TV+"@@@";
                        int remainingLength=23-prefix.length();
                        String suffix=null;
                        if(clientId.length()>remainingLength){
                            suffix=clientId.substring(0,remainingLength);
                        }else{
                            suffix=clientId;
                        }
                        String clientId2=prefix+suffix;
                        connectAndSubscribe(String.format(
                                MQTTService.BROKER_URL_FORMAT, ip, port),
                                clientId2, /* topic, */true, ""/*自己申请的access key*/, ""/*secret*/);
                         ShopUtil.logger2("clientId:" + clientId2);
                        ShopUtil.logger2("succeed to connect to activeMQ");
                        setOnline(true);
                    } catch (MqttException e) {
                        setOnline(false);
                        mqttClient=null;
                         e.printStackTrace();
                        ShopUtil.logger2("抛异常:"+e.getMessage());
                        ShopUtil.logger2("ip:" + ip + " ,port:" + port);
                        try {
                            Thread.sleep(10000);
                        } catch (InterruptedException e1) {
                            e1.printStackTrace();
                        }
                    }
                    tryTime--;
                }

            }
        }).start();
//      new Thread(new Runnable() {
//          @Override
//          public void run() {
//              System.out.println("start:"+System.currentTimeMillis());
//              try {
//                  Thread.sleep(10000);
//              } catch (InterruptedException e) {
//                  e.printStackTrace();
//              }
//              while(true){
//                  try {
//                      Thread.sleep(10000);
//                      if(mqttClient!=null&& !mqttClient.isConnected()){
//                          System.out.println("disConnected:"+System.currentTimeMillis());
//                      }
//                  } catch (InterruptedException e) {
//                      e.printStackTrace();
//                  }
//              }
//          }
//      }).start();
    }

    @Override
    public void onDestroy() {
        setOnline(false);

        try {
            ShopUtil.logger2("MQTTService destory");
            mqttClient.disconnect(0);
        } catch (MqttException e) {
//          Toast.makeText(getApplicationContext(),
//                  "Something went wrong!" + e.getMessage(), Toast.LENGTH_LONG)
//                  .show();
            e.printStackTrace();

        }
        mqttClient = null;
        stopForeground(true);
        Intent intent = new Intent("com.dbjtech.waiqin.destroy");
        sendBroadcast(intent);
    }



    public boolean isOnline() {
        return online;
    }

    public void setOnline(boolean online) {
        this.online = online;
    }
    @Override
    public int onStartCommand(Intent intent, int flags, int startId) {
        flags = START_STICKY;
        return super.onStartCommand(intent, flags, startId);
    }
}
