Java EE WEB工程师培训——JDBC+Servlet+JSP整合开发之21.Servlet_资源访问(访问数据库)

本文涉及的产品
云数据库 RDS MySQL,集群版 2核4GB 100GB
推荐场景:
搭建个人博客
RDS MySQL Serverless 基础系列,0.5-2RCU 50GB
RDS MySQL Serverless 高可用系列,价值2615元额度,1个月
简介:
? B/S结构程序、B/A/S结构程序简介
? Servlet 资源访问
–Servlet 和 JDBC
? 实例
–维护客户列表
#######################################
? B/S结构程序、B/A/S结构程序简介
–B/S结构程序是指:Browser(客户端)/Server(服务器)两层结构
–B/A/S结构程序是指:Browser(客户端)/Application Server(应用程序服务器)/DB Server 三层结构
? Servlet 资源访问
–Servlet 和 JDBC
? Servlet作为控制器
–响应用户请求
? 获得表单数据
–调用后台逻辑
? 业务逻辑
? 数据逻辑
–页面导航
? JDBC
–使用DAO模式封装数据逻辑(封装持久层)

? 实例
–维护客户列表
DBServlet.java
package com.michael.servlet;

import java.io.IOException;
import java.io.PrintWriter;
import java.sql.Connection;
import java.sql.DriverManager;
import java.sql.ResultSet;
import java.sql.SQLException;
import java.sql.Statement;

import javax.servlet.ServletException;
import javax.servlet.http.HttpServlet;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

public  class DBServlet  extends HttpServlet {

         /**
         * Constructor of the object.
         */

         public DBServlet() {
                 super();
        }

         /**
         * Destruction of the servlet. <br>
         */

         public  void destroy() {
                 super.destroy();  // Just puts "destroy" string in log
                 // Put your code here
        }

         /**
         * The doGet method of the servlet. <br>
         *
         * This method is called when a form has its tag value method equals to get.
         *
         * @param request
         *                        the request send by the client to the server
         * @param response
         *                        the response send by the server to the client
         * @throws ServletException
         *                         if an error occurred
         * @throws IOException
         *                         if an error occurred
         */

         public  void doGet(HttpServletRequest request, HttpServletResponse response)
                         throws ServletException, IOException {

                doPost(request, response);
        }

         /**
         * The doPost method of the servlet. <br>
         *
         * This method is called when a form has its tag value method equals to
         * post.
         *
         * @param request
         *                        the request send by the client to the server
         * @param response
         *                        the response send by the server to the client
         * @throws ServletException
         *                         if an error occurred
         * @throws IOException
         *                         if an error occurred
         */

         public  void doPost(HttpServletRequest request, HttpServletResponse response)
                         throws ServletException, IOException {

                 // jdbc
                 // get Connection
                Connection conn =  null;
                 // 加载驱动
                 try {
                        Class.forName( "com.mysql.jdbc.Driver");
                        conn = DriverManager.getConnection( "jdbc:mysql://localhost:3306/Servlet_db", "root", "963963");
                } catch (Exception e) {
                        e.printStackTrace();
                }
                // get Statement
                ResultSet rs = null;
                try {
                        Statement stmt = conn.createStatement();
                        String sql = "select * from customertbl";
                        rs = stmt.executeQuery(sql);
                } catch (SQLException e) {
                        e.printStackTrace();
                }

                response.setContentType("text/html");
                PrintWriter out = response.getWriter();
                out
                                .println("<!DOCTYPE HTML PUBLIC \"-//W3C//DTD HTML 4.01 Transitional//EN\">");
                out.println("<HTML>");
                out.println("    <HEAD><TITLE>A Servlet</TITLE></HEAD>");
                out.println("    <BODY>");
                out.println("    <table>");
                out.println("    <tr>");

                out.println("    <th>");
                out.println("ID");
                out.println("    </th>");

                out.println("    <th>");
                out.println("Name");
                out.println("    </th>");

                out.println("    <th>");
                out.println("Email");
                out.println("    </th>");

                try {
                        while (rs.next()) {
                                int id = rs.getInt(1);
                                String name = rs.getString(2);
                                String email = rs.getString(3);
                                out.println("    <tr>");
                                out.println("    <td>");
                                out.println(id);
                                out.println("    </td>");
                                out.println("    <td>");
                                out.println(name);
                                out.println("    </td>");
                                out.println("    <td>");
                                out.println(email);
                                out.println("    </td>");
                                out.println("    </tr>");
                        }
                } catch (SQLException e) {
                        e.printStackTrace();
                } finally {
                        try {
                                conn.close();
                        } catch (SQLException e) {
                                e.printStackTrace();
                        }
                }

                out.println("    </tr>");
                out.println("    </table>");
                out.println("    </BODY>");
                out.println("</HTML>");
                out.flush();
                out.close();
        }

        /**
         * Initialization of the servlet. <br>
         *
         * @throws ServletException
         *                         if an error occurs
         */

        public void init() throws ServletException {
                // Put your code here
        }


web.xml
测试
以上代码实现了读取数据库数据功能,但是没有实现分层结构哈~下面我们实现分层结构来实现代码共用。
DBServlet.java
package com.michael.servlet;

import java.io.IOException;
import java.io.PrintWriter;
import java.sql.Connection;
import java.sql.DriverManager;
import java.sql.ResultSet;
import java.sql.SQLException;
import java.sql.Statement;
import java.util.List;

import javax.servlet.ServletException;
import javax.servlet.http.HttpServlet;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

import com.michael.dao.CustomerDao;
import com.michael.dao.impl.CustomerDaoImpl;
import com.michael.vo.Customer;

public  class DBServlet  extends HttpServlet {

         /**
         * Constructor of the object.
         */

         public DBServlet() {
                 super();
        }

         /**
         * Destruction of the servlet. <br>
         */

         public  void destroy() {
                 super.destroy();  // Just puts "destroy" string in log
                 // Put your code here
        }

         /**
         * The doGet method of the servlet. <br>
         *
         * This method is called when a form has its tag value method equals to get.
         *
         * @param request
         *                        the request send by the client to the server
         * @param response
         *                        the response send by the server to the client
         * @throws ServletException
         *                         if an error occurred
         * @throws IOException
         *                         if an error occurred
         */

         public  void doGet(HttpServletRequest request, HttpServletResponse response)
                         throws ServletException, IOException {

                doPost(request, response);
        }

         /**
         * The doPost method of the servlet. <br>
         *
         * This method is called when a form has its tag value method equals to
         * post.
         *
         * @param request
         *                        the request send by the client to the server
         * @param response
         *                        the response send by the server to the client
         * @throws ServletException
         *                         if an error occurred
         * @throws IOException
         *                         if an error occurred
         */

         public  void doPost(HttpServletRequest request, HttpServletResponse response)
                         throws ServletException, IOException {
                 /*
                // jdbc
                // get Connection
                Connection conn = null;
                // 加载驱动
                try {
                        Class.forName("com.mysql.jdbc.Driver");
                        conn = DriverManager.getConnection("jdbc:mysql://localhost:3306/Servlet_db", "root", "963963");
                } catch (Exception e) {
                        e.printStackTrace();
                }
                // get Statement
                ResultSet rs = null;
                try {
                        Statement stmt = conn.createStatement();
                        String sql = "select * from customertbl";
                        rs = stmt.executeQuery(sql);
                } catch (SQLException e) {
                        e.printStackTrace();
                }
                */

                CustomerDao dao =  new CustomerDaoImpl();
                List list = dao.getCustomerList();

                response.setContentType( "text/html");
                PrintWriter out = response.getWriter();
                out
                                .println( "<!DOCTYPE HTML PUBLIC \"-//W3C//DTD HTML 4.01 Transitional//EN\">");
                out.println("<HTML>");
                out.println("    <HEAD><TITLE>A Servlet</TITLE></HEAD>");
                out.println("    <BODY>");
                out.println("    <table>");
                out.println("    <tr>");

                out.println("    <th>");
                out.println("ID");
                out.println("    </th>");

                out.println("    <th>");
                out.println("Name");
                out.println("    </th>");

                out.println("    <th>");
                out.println("Email");
                out.println("    </th>");
                /*
                try {
                        while (rs.next()) {
                                int id = rs.getInt(1);
                                String name = rs.getString(2);
                                String email = rs.getString(3);
                                out.println("    <tr>");
                                out.println("    <td>");
                                out.println(id);
                                out.println("    </td>");
                                out.println("    <td>");
                                out.println(name);
                                out.println("    </td>");
                                out.println("    <td>");
                                out.println(email);
                                out.println("    </td>");
                                out.println("    </tr>");
                        }
                } catch (SQLException e) {
                        e.printStackTrace();
                } finally {
                        try {
                                conn.close();
                        } catch (SQLException e) {
                                e.printStackTrace();
                        }
                }
                */

                for (int i=0;i<list.size();i++){
                        Customer c = (Customer) list.get(i);
                        out.println("    <tr>");
                        out.println("    <td>");
                        out.println(c.getId());
                        out.println("    </td>");
                        out.println("    <td>");
                        out.println(c.getName());
                        out.println("    </td>");
                        out.println("    <td>");
                        out.println(c.getEmail());
                        out.println("    </td>");
                        out.println("    </tr>");
                }
                out.println("    </tr>");
                out.println("    </table>");
                out.println("    </BODY>");
                out.println("</HTML>");
                out.flush();
                out.close();
        }

        /**
         * Initialization of the servlet. <br>
         *
         * @throws ServletException
         *                         if an error occurs
         */

        public void init() throws ServletException {
                // Put your code here
        }


CustomerDaoImpl
ConnectionUtil
package com.michael.dao.impl;

import java.sql.Connection;
import java.sql.DriverManager;
import java.util.Properties;

public  class ConnectionUtil {

         /**
         * @param args
         */

         public  static  void main(String[] args) {
                ConnectionUtil cu =  new ConnectionUtil();
                System.out.println(cu.openConnection());
        }
         public Connection openConnection() {
                String url = "";
                String driver = "";
                String user = "";
                String password = "";
                Properties prop =  new Properties();
                 try {
                        prop.load( this.getClass().getClassLoader().getResourceAsStream( "DBConfig.properties"));
                        driver = prop.getProperty( "driver");
                        url = prop.getProperty( "url");
                        user = prop.getProperty( "user");
                        password = prop.getProperty( "password");
                        Class.forName(driver);
                        Connection conn = DriverManager.getConnection(
                                        url, user, password);
                         return conn;
                }  catch (Exception e) {
                        e.printStackTrace();
                }
                 return  null;
        }
         public Connection getConnection(String driver, String url, String user,
                        String password) {
                 // Class.forName()
                 try {
                        Class.forName(driver);
                         // DriverManager get connection
                        Connection conn = DriverManager.getConnection(url, user, password);
                         return conn;
                }  catch (Exception e) {
                        e.printStackTrace();
                }
                 return  null;
        }

         public Connection getConnection() {
                 // Class.forName()
                 try {
                        Class.forName( "com.mysql.jdbc.Driver");
                         // DriverManager get connection
                        Connection conn = DriverManager.getConnection(
                                         "jdbc:mysql://localhost:3306/Servlet_db", "root", "963963");
                        return conn;
                } catch (Exception e) {
                        e.printStackTrace();
                }
                return null;
        }


DBConfig.properties
Customer
测试
############################################





本文转自redking51CTO博客,原文链接:http://blog.51cto.com/redking/289971 ,如需转载请自行联系原作者
相关实践学习
基于CentOS快速搭建LAMP环境
本教程介绍如何搭建LAMP环境,其中LAMP分别代表Linux、Apache、MySQL和PHP。
全面了解阿里云能为你做什么
阿里云在全球各地部署高效节能的绿色数据中心,利用清洁计算为万物互联的新世界提供源源不断的能源动力,目前开服的区域包括中国(华北、华东、华南、香港)、新加坡、美国(美东、美西)、欧洲、中东、澳大利亚、日本。目前阿里云的产品涵盖弹性计算、数据库、存储与CDN、分析与搜索、云通信、网络、管理与监控、应用服务、互联网中间件、移动服务、视频服务等。通过本课程,来了解阿里云能够为你的业务带来哪些帮助 &nbsp; &nbsp; 相关的阿里云产品:云服务器ECS 云服务器 ECS(Elastic Compute Service)是一种弹性可伸缩的计算服务,助您降低 IT 成本,提升运维效率,使您更专注于核心业务创新。产品详情: https://www.aliyun.com/product/ecs
相关文章
|
15天前
|
Java 程序员
【Java探索之旅】继承概念_语法_父类的成员访问
【Java探索之旅】继承概念_语法_父类的成员访问
28 10
|
19天前
|
安全 Java API
Java中的Servlet编程详解
Java中的Servlet编程详解
|
19天前
|
Java 数据库连接 开发者
Java中的Servlet生命周期详解
Java中的Servlet生命周期详解
|
23天前
|
Java 关系型数据库 MySQL
使用MySQL JDBC连接数据库
使用MySQL JDBC连接数据库
|
23天前
|
SQL 存储 Java
优化Java应用的数据库访问性能
优化Java应用的数据库访问性能
|
24天前
|
存储 NoSQL Java
探索Java分布式锁:在高并发环境下的同步访问实现与优化
【6月更文挑战第30天】Java分布式锁在高并发下确保数据一致性,通过Redis的SETNX、ZooKeeper的临时节点、数据库操作等方式实现。优化策略包括锁超时重试、续期、公平性及性能提升,关键在于平衡同步与效率,适应大规模分布式系统的需求。
30 1
|
13天前
|
SQL 安全 Java
Java面试题:什么是JDBC以及如何在Java中使用它进行数据库操作?
Java面试题:什么是JDBC以及如何在Java中使用它进行数据库操作?
17 0
|
14天前
|
SQL Java 关系型数据库
Java面试题:描述JDBC的工作原理,包括连接数据库、执行SQL语句等步骤。
Java面试题:描述JDBC的工作原理,包括连接数据库、执行SQL语句等步骤。
24 0
|
19天前
|
Java 应用服务中间件 Linux
Tomcat安装部署[单机软件],可以让用户开发的WEB应用程序,变成可以被访问的网页,Tomcat的使用需要jdk环境
Tomcat安装部署[单机软件],可以让用户开发的WEB应用程序,变成可以被访问的网页,Tomcat的使用需要jdk环境
|
19天前
|
Java 关系型数据库 MySQL
使用MySQL JDBC连接数据库
使用MySQL JDBC连接数据库
