需要添加的framework:CoreMedia,CoreVideo,QuartzCore,AVFoundation
MyAVController.h:
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
|
#import <UIKit/UIKit.h>
#import <AVFoundation/AVFoundation.h>
#import <CoreGraphics/CoreGraphics.h>
#import <CoreVideo/CoreVideo.h>
#import <CoreMedia/CoreMedia.h>
@interface MyAVController : UIViewController <
AVCaptureVideoDataOutputSampleBufferDelegate> {
AVCaptureSession *_captureSession;
UIImageView *_imageView;
CALayer *_customLayer;
AVCaptureVideoPreviewLayer *_prevLayer;
}
@property (nonatomic, retain) AVCaptureSession *captureSession;
@property (nonatomic, retain) UIImageView *imageView;
@property (nonatomic, retain) CALayer *customLayer;
@property (nonatomic, retain) AVCaptureVideoPreviewLayer *prevLayer;
- (void)initCapture;
@end
MyAVController.m:
#import "MyAVController.h"
@implementation MyAVController
@synthesize captureSession = _captureSession;
@synthesize imageView = _imageView;
@synthesize customLayer = _customLayer;
@synthesize prevLayer = _prevLayer;
#pragma mark -
#pragma mark Initialization
- (id)init {
self = [
super
init];
if
(self) {
self.imageView = nil;
self.prevLayer = nil;
self.customLayer = nil;
}
return
self;
}
- (void)viewDidLoad {
[self initCapture];
}
- (void)initCapture {
AVCaptureDeviceInput *captureInput = [AVCaptureDeviceInput
deviceInputWithDevice:[AVCaptureDevice
defaultDeviceWithMediaType:AVMediaTypeVideo] error:nil];
AVCaptureVideoDataOutput *captureOutput = [[AVCaptureVideoDataOutput alloc]
init];
captureOutput.alwaysDiscardsLateVideoFrames = YES;
//captureOutput.minFrameDuration = CMTimeMake(1, 10);
dispatch_queue_t queue;
queue = dispatch_queue_create(
"cameraQueue"
, NULL);
[captureOutput setSampleBufferDelegate:self queue:queue];
dispatch_release(queue);
NSString* key = (NSString*)kCVPixelBufferPixelFormatTypeKey;
NSNumber* value = [NSNumber
numberWithUnsignedInt:kCVPixelFormatType_32BGRA];
NSDictionary* videoSettings = [NSDictionary
dictionaryWithObject:value forKey:key];
[captureOutput setVideoSettings:videoSettings];
self.captureSession = [[AVCaptureSession alloc] init];
[self.captureSession addInput:captureInput];
[self.captureSession addOutput:captureOutput];
[self.captureSession startRunning];
self.customLayer = [CALayer layer];
self.customLayer.frame = self.view.bounds;
self.customLayer.transform = CATransform3DRotate(
CATransform3DIdentity, M_PI/2.0f, 0, 0, 1);
self.customLayer.contentsGravity = kCAGravityResizeAspectFill;
[self.view.layer addSublayer:self.customLayer];
self.imageView = [[UIImageView alloc] init];
self.imageView.frame = CGRectMake(0, 0, 100, 100);
[self.view addSubview:self.imageView];
self.prevLayer = [AVCaptureVideoPreviewLayer
layerWithSession: self.captureSession];
self.prevLayer.frame = CGRectMake(100, 0, 100, 100);
self.prevLayer.videoGravity = AVLayerVideoGravityResizeAspectFill;
[self.view.layer addSublayer: self.prevLayer];
}
#pragma mark -
#pragma mark AVCaptureSession delegate
- (void)captureOutput:(AVCaptureOutput *)captureOutput
didOutputSampleBuffer:(CMSampleBufferRef)sampleBuffer
fromConnection:(AVCaptureConnection *)connection
{
NSAutoreleasePool * pool = [[NSAutoreleasePool alloc] init];
CVImageBufferRef imageBuffer = CMSampleBufferGetImageBuffer(sampleBuffer);
CVPixelBufferLockBaseAddress(imageBuffer,0);
uint8_t *baseAddress = (uint8_t *)CVPixelBufferGetBaseAddress(imageBuffer);
size_t bytesPerRow = CVPixelBufferGetBytesPerRow(imageBuffer);
size_t width = CVPixelBufferGetWidth(imageBuffer);
size_t height = CVPixelBufferGetHeight(imageBuffer);
CGColorSpaceRef colorSpace = CGColorSpaceCreateDeviceRGB();
CGContextRef newContext = CGBitmapContextCreate(baseAddress,
width, height, 8, bytesPerRow, colorSpace,
kCGBitmapByteOrder32Little | kCGImageAlphaPremultipliedFirst);
CGImageRef newImage = CGBitmapContextCreateImage(newContext);
CGContextRelease(newContext);
CGColorSpaceRelease(colorSpace);
[self.customLayer performSelectorOnMainThread:@selector(setContents:)
withObject: (id) newImage waitUntilDone:YES];
UIImage *image= [UIImage imageWithCGImage:newImage scale:1.0
orientation:UIImageOrientationRight];
CGImageRelease(newImage);
[self.imageView performSelectorOnMainThread:@selector(setImage:)
withObject:image waitUntilDone:YES];
CVPixelBufferUnlockBaseAddress(imageBuffer,0);
[pool drain];
}
#pragma mark -
#pragma mark Memory management
- (void)viewDidUnload {
self.imageView = nil;
self.customLayer = nil;
self.prevLayer = nil;
}
- (void)dealloc {
[self.captureSession release];
[
super
dealloc];
}
@end
|
