8.5Gbps850nm SFP+ Transceiver,100m Reach
StoageModule 8.5G 100M
- Applications
Ø Tri-Rate 8.5 Gb/s Fibre Channel
Ø Other optical links
2.Features
Ø Up to 8.5Gb/s bi-directional data links
Ø Hot-pluggable SFP+ footprint
Ø Built-in digital diagnosticfunctions
Ø Built-in CDR with shut offcontrol
Ø 850nm Oxide VCSEL lasertransmitter
Ø Duplex LC connector
Ø RoHS compliant and Lead Free
Ø 35m on 50/125um MMF
Ø 150m on high-bandwidth 50/125um(OM3)
Ø Metal enclosure, for lower EMI
Ø Single 3.3V power supply
Ø Operating temperature range:0°C to 70°C
- Description
100G.SHOP’s 8.5GSW SFP+ transceivers are designed for use in FibreChannel links up to 8.5
Gb/s data rateover multimode fiber. They are compliantwith FC-PI-5 Rev. 6.00a, SFF-8472 Rev 11.0c and SFF-8081h, andcompatible with SFF-8432b and applicable portions of SFF-8431 Rev. 4.1d.The opticaltransceiver is compliant per the RoHS.
4.standard
Ø Electrical interface compliant toSFF-8431
Ø Compliant with SFF-8472 Rev 10.2
Ø Compliant with IEEE 802.3ae10GBASE-LR and 10GBASE-LW
Ø RoHS Compliant
5.Performance Specifications
5.1.Absolute Maximum Ratings
These values represent the damage threshold of the module. Stress inexcess of any of the individual Absolute Maximum Ratings can cause immediatecatastrophic damage to the module even if all other parameters are withinRecommended Operating Conditions.
Table.1 Absolute maximumratings
Parameter
Symbol
Min
Max
Unit
Maximum Supply Voltage
Vcc
-0.5
4.0
V
Storage Temperature
Ts
0
70
°C
RX Input Average Power
Pmax
0
dBm
Relative Humidity
RH
5
85
%
5.2.Recommended Operating Conditions
Table.2 RecommendedOperating Conditions
Parameter
Symbol
Min
Typical
Max
Unit
Operating Case Temperature
Standard Tc
0
25
70
°C
Power Supply Voltage
Vcc
3.15
3.3
3.46
V
Power Supply Current
Icc
290
mA
Power Dissipation
PD
90
800
mW
Data Rate
DR
8.5
Gbps
Transmission Distance
TD
150
m
5.3. Transmitter Specification
Table.3 TransmitterSpecification (Optical)
Parameter
Symbol
Min.
Typ.
Max.
Unit
Note
Average Output Power
Po
-6
-1
dBm
Disable Power
Poff
-40
dBm
Extinction Ratio
ER
3.5
dB
Output Centre Wavelength
λc
840
860
nm
Spectral Width (RMS) @ 8.5Gb/s
Δλ
0.59
nm
Optical Modulation Amplitude @ 8.5 Gb/s
OMA
-5.2
dBm
Optical Return Loss
ORL
-12
dB
Transmitter Waveform and Dispersion Penalty
DP
4.3
dB
Optical Rise/Fall Time
(20%~80%)
tr/tf
0.09
ns
Optical Eye Mask
MM
Compliant to IEEE802.3ae
1
Relative Intensity Noise
Rin
-128(12dB reflection)
dB/Hz
Note: 1. Measured at 8.5Gbps, PRBS2^7-1, NRZ
Table.4 TransmitterSpecification (Electrical)
Parameter
Symbol
Min
Typical
Max
Unit
Data Input Swing Differential
VIN
90
800
mV
Input Differential Impedance
ZIN
90
100
110
Ω
Transmit Disable Input
High
VIH
2.0
Vcc+0.3
V
Low
VIL
0
0.8
V
Transmit Enable Output
High
VOH
Vee
Vee+0.8
V
Low
VOL
0
0.4
V
5.4. Receiver Specification
Table.5 ReceiverSpecification (Optical)
Parameter
Symbol
Min
Typical
Max
Unit
note
Centre Wavelength
λc
840
850
860
nm
Receiver Sensitivity
Sen
-11.2
dBm
2
Receiver Overload
Psat
0
dBm
2
LOS De-Assert
LOSD
-13
dBm
LOS Assert
LOSA
-30
dBm
LOS Hysteresis
0.5
dB
Receiver Reflectance
Rrx
-12
dB
Note :2. Measured at BER10-12, 8.5Gbps, PRBS2^7-1, NRZ
Table.6 ReceiverSpecification (Electrical)
Parameter
Symbol
Min
Typical
Max
Unit
note
Data Output Swing Differential
Vout
185
425
mV
Deterministic Jitter @ 8.5 Gb/s
RX DJ
0.22
UI
LOS Output
High
VOH
2
Vcc+0.3
V
Low
VOL
Vee
Vee+0.8
V
5.5. Diagnostics Specification
Table.7Diagnostics Specification
Parameter
Range
Unit
Accuracy
Calibration
Temperature
0 to 70
℃
±3℃
Internal / External
Voltage
3.0 to 3.6
V
±3%
Internal / External
Bias Current
0 to 100
mA
±10%
Internal / External
TX Power
-7.8 to 0
dBm
±3dB
Internal / External
RX Power
-30 to 0
dBm
±3dB
Internal / External
5.6. Pin Definitions
Table.8Pin Definitions
PIN
Symbol
Description
Remarks
1
VEET
Transmitter ground (common with receiver ground)
Circuit ground is isolated from chassis ground
2
Tx_Fault
Transmitter Fault. Not supported
3
Tx_Disable
Transmitter Disable. Laser output disable on high or open
Disabled: TDIS>2V or open
Enabled: TDIS<0.8V
4
SDA
2-wire Serial Interface Data Line
Should Be pulled up with 4.7k – 10k ohm on host board to a voltage between 2V and 3.6V
5
SCL
2-wire Serial Interface Clock Line
6
MOD_ABS
Module Absent. Grounded within the module.
7
RS0
No connection required
8
RX_LOS
Loss of Signal indication. Logic 0 indicates normal operation
LOS is open collector output
9
RS1
No connection required
10
VEER
Receiver ground (common with transmitter ground)
Circuit ground is isolated from chassis ground
11
VEER
Receiver ground (common with transmitter ground)
12
RD–
Receiver Inverted DATA out. AC coupled
13
RD+
Receiver Non-inverted DATA out. AC coupled
14
VEER
Receiver ground (common with transmitter ground)
Circuit ground is isolated from chassis ground
15
VCCR
Receiver power supply
16
VCCT
Transmitter power supply
17
VEET
Transmitter ground (common with receiver ground)
Circuit ground is isolated from chassis ground
18
TD+
Transmitter Non-Inverted DATA in. AC coupled
19
TD–
Transmitter Inverted DATA in. AC coupled
20
VEET
Transmitter ground (common with receiver ground)
Circuit ground is isolated from chassis ground
5.7. Timing Electrical Interface
Table.9 Timing ElectricalInterface
Parameter
Symbol
Min
Max
Units
Conditions
Tx_Disable Assert Time
t_off
100
us
Rising edge of Tx_Disable to fall of output signal below 10% of nominal
Tx_Disable Negate Time
t_on
2
ms
Tx_Disable negate time. Falling edge of Tx_Disable to rise of output signal above 90% of nominal. This only applies in normal operation, not during start up or fault recovery.
Time to initialize
t_start_up
300
ms
From power supplies or hot plug or Tx disable negated during power up, or Tx_Fault recovery, until non-cooled power level I is fully operational.
Tx_Fault Assert Time
Tx_Fault
1
ms
From occurrence of fault to assertion of Tx_Fault
Tx_Fault to Reset
t_reset
10
us
Time Tx_Disable must be held high to reset Tx_Fault
Rx_LOS Assert Time
t_los_on
100
us
From occurrence of loss of signal to assertion of Rx_LOS
Rx_LOS De-Assert Time
t_los_off
100
us
From occurrence of presence of signal to negation of Rx_LOS
5.8. Mechanical Dimensions
Diagram of Mechanical Dimensions
6.Aplication Cautions
6.1.ESD
This 100G.SHOPtransceiver is specified as ESD threshold 1kV for high speed pins and 2kV forall other electrical input pins, tested per MIL-STD-883, Method 3015.4/JESD22-A114-A (HBM). However, normalESD precautions are still required during the handling of this module. Thistransceiver is shipped in ESD protective packaging. It should be removed fromthe packaging and handled only in an ESD protected environment.
6.2. LASER SAFTY
This is aClass 1 Laser Product according to IEC 60825-1:1993:+A1:1997+A2:2001. This product complies with 21 CFR 1040.10 and1040.11 except for deviations pursuant to Laser Notice No. 50, dated (July 26,2001)
