一脸懵逼学习Hadoop中的序列化机制——流量求和统计MapReduce的程序开发案例——流量求和统计排序

 1 package com.flowSum;
 2
 3 import java.io.DataInput;
 4 import java.io.DataOutput;
 5 import java.io.IOException;
 6
 7 import org.apache.hadoop.io.Writable;
 8
 9 /***
10  *
11  * @author Administrator
12  * 1:write 是把每个对象序列化到输出流
13  * 2:readFields是把输入流字节反序列化
14  * 3:实现WritableComparable
15  *      Java值对象的比较：一般需要重写toString(),hashCode(),equals()方法
16  *
17  */
18 public class FlowBean implements Writable{
19
20     private String phoneNumber;//电话号码
21     private long upFlow;//上行流量
22     private long downFlow;//下行流量
23     private long sumFlow;//总流量
24
25
26
27     public String getPhoneNumber() {
28         return phoneNumber;
29     }
30     public void setPhoneNumber(String phoneNumber) {
31         this.phoneNumber = phoneNumber;
32     }
33     public long getUpFlow() {
34         return upFlow;
35     }
36     public void setUpFlow(long upFlow) {
37         this.upFlow = upFlow;
38     }
39     public long getDownFlow() {
40         return downFlow;
41     }
42     public void setDownFlow(long downFlow) {
43         this.downFlow = downFlow;
44     }
45     public long getSumFlow() {
46         return sumFlow;
47     }
48     public void setSumFlow(long sumFlow) {
49         this.sumFlow = sumFlow;
50     }
51
52     //为了对象数据的初始化方便，加入一个带参的构造函数
53     public FlowBean(String phoneNumber, long upFlow, long downFlow) {
54         this.phoneNumber = phoneNumber;
55         this.upFlow = upFlow;
56         this.downFlow = downFlow;
57         this.sumFlow = upFlow + downFlow;
58     }
59     //在反序列化时候，反射机制需要调用空参的构造函数，所以定义了一个空参的构造函数
60     public FlowBean() {
61     }
62
63     //重写toString()方法
64     @Override
65     public String toString() {
66         return "" + upFlow + "\t" + downFlow + "\t" + sumFlow + "";
67     }
68
69
70     //从数据流中反序列出对象的数据
71     //从数据流中读取字段时必须和序列化的顺序保持一致
72     @Override
73     public void readFields(DataInput in) throws IOException {
74         phoneNumber = in.readUTF();
75         upFlow = in.readLong();
76         downFlow = in.readLong();
77         sumFlow = in.readLong();
78
79     }
80
81     //将对象数据序列化到流中
82     @Override
83     public void write(DataOutput out) throws IOException {
84         out.writeUTF(phoneNumber);
85         out.writeLong(upFlow);
86         out.writeLong(downFlow);
87         out.writeLong(sumFlow);
88
89     }
90
91
92 }

 1 package com.flowSum;
 2
 3 import java.io.IOException;
 4
 5 import org.apache.commons.lang.StringUtils;
 6 import org.apache.hadoop.io.LongWritable;
 7 import org.apache.hadoop.io.Text;
 8 import org.apache.hadoop.mapreduce.Mapper;
 9 /***
10  *
11  * @author Administrator
12  * 1:FlowBean是我们自定义的一种数据类型，要在hadoop的各个节点之间进行传输，应该遵循hadoop的序列化
13  *      所以就必须实现hadoop的相应的序列化接口
14  * 2:Text一般认为它等价于java.lang.String的Writable。针对UTF-8序列。
15  */
16 public class FlowSumMapper extends Mapper<LongWritable, Text, Text, FlowBean>{
17
18     //拿到日志中的一行数据，切分各个字段，抽取出我们需要的字段：手机号，上行流量，下行流量
19     //封装成key-value发送出去
20
21     @Override
22     protected void map(LongWritable key, Text value, Context context)
23             throws IOException, InterruptedException {
24         //拿到一行数据
25         String line = value.toString();
26         //切分成各个字段
27         String[] fields = StringUtils.split(line,"/t");
28         //拿到手机号的字段
29         String phoneNumber = fields[1];
30         //拿到上行流量字段
31         long up_flow = Long.parseLong(fields[7]);
32         //拿到下行流量字段
33         long down_flow = Long.parseLong(fields[8]);
34
35         //最后一步，封装数据为key-value进行输出
36         context.write(new Text(phoneNumber), new FlowBean(phoneNumber, up_flow, down_flow));
37
38     }
39
40 }

 1 package com.flowSum;
 2
 3 import java.io.IOException;
 4
 5 import org.apache.hadoop.io.Text;
 6 import org.apache.hadoop.mapreduce.Reducer;
 7
 8 public class FlowSumReducer extends Reducer<Text, FlowBean, Text, FlowBean>{
 9
10     //框架每传递一组数据<手机号,{flowbean,flowbean,flowbean...}>调用一次我们的reduce方法
11     //reduce中的业务逻辑就是遍历values，然后累加求和再输出
12     @Override
13     protected void reduce(Text key, Iterable<FlowBean> values, Context context)
14             throws IOException, InterruptedException {
15         //上行流量计数器和下行流量计数器
16         long up_flow_counter = 0;
17         long down_flow_counter = 0;
18
19         //上行流量和下行流量累加求和
20         for(FlowBean bean : values){
21             up_flow_counter += bean.getUpFlow();
22             down_flow_counter += bean.getDownFlow();
23         }
24
25         //将结果输出
26         context.write(key, new FlowBean(key.toString(), up_flow_counter, down_flow_counter));
27
28     }
29
30 }

 1 package com.flowSum;
 2
 3 import org.apache.hadoop.conf.Configuration;
 4 import org.apache.hadoop.conf.Configured;
 5 import org.apache.hadoop.fs.Path;
 6 import org.apache.hadoop.mapreduce.Job;
 7 import org.apache.hadoop.mapreduce.lib.input.FileInputFormat;
 8 import org.apache.hadoop.mapreduce.lib.output.FileOutputFormat;
 9 import org.apache.hadoop.util.Tool;
10 import org.apache.hadoop.util.ToolRunner;
11
12 import com.sun.jersey.core.impl.provider.entity.XMLJAXBElementProvider.Text;
13 /***
14  *
15  * @author Administrator
16  * 1:Job描述和提交类的规范写法
17  */
18 public class FlowSumRunner extends Configured implements Tool{
19
20
21     @Override
22     public int run(String[] args) throws Exception {
23         //创建配置文件
24         Configuration conf = new Configuration();
25         //获取一个作业
26         Job job = Job.getInstance(conf);
27
28         //设置整个job所用的那些类在哪个jar包
29         job.setJarByClass(FlowSumRunner.class);
30
31         //本job使用的mapper和reducer的类
32         job.setMapperClass(FlowSumMapper.class);
33         job.setReducerClass(FlowSumReducer.class);
34
35         //指定mapper的输出数据key-value类型
36         job.setMapOutputKeyClass(Text.class);
37         job.setMapOutputValueClass(FlowBean.class);
38
39         //指定reduce的输出数据key-value类型
40         job.setOutputKeyClass(Text.class);
41         job.setOutputValueClass(FlowBean.class);
42
43         //指定要处理的输入数据存放路径
44         //FileInputFormat是所有以文件作为数据源的InputFormat实现的基类，
45         //FileInputFormat保存作为job输入的所有文件，并实现了对输入文件计算splits的方法。
46         //至于获得记录的方法是有不同的子类——TextInputFormat进行实现的。
47         FileInputFormat.setInputPaths(job, new Path(args[0]));
48
49         //指定处理结果的输出数据存放路径
50         FileOutputFormat.setOutputPath(job, new Path(args[1]));
51
52         //将job提交给集群运行
53         //job.waitForCompletion(true);
54         //正常执行成功返回0，否则返回1
55         return job.waitForCompletion(true) ? 0 : 1;
56     }
57
58     public static void main(String[] args) throws Exception {
59         //规范性调用
60         int res = ToolRunner.run(new Configuration(), new FlowSumRunner(), args);
61         //执行结束退出
62         System.exit(res);
63     }
64
65 }

1363157985066     13726230503    00-FD-07-A4-72-B8:CMCC    120.196.100.82    i02.c.aliimg.com        24    27    2481    24681    200
1363157995052     13826544101    5C-0E-8B-C7-F1-E0:CMCC    120.197.40.4            4    0    264    0    200
1363157991076     13926435656    20-10-7A-28-CC-0A:CMCC    120.196.100.99            2    4    132    1512    200
1363154400022     13926251106    5C-0E-8B-8B-B1-50:CMCC    120.197.40.4            4    0    240    0    200
1363157993044     18211575961    94-71-AC-CD-E6-18:CMCC-EASY    120.196.100.99    iface.qiyi.com    视频网站    15    12    1527    2106    200
1363157995074     84138413    5C-0E-8B-8C-E8-20:7DaysInn    120.197.40.4    122.72.52.12        20    16    4116    1432    200
1363157993055     13560439658    C4-17-FE-BA-DE-D9:CMCC    120.196.100.99            18    15    1116    954    200
1363157995033     15920133257    5C-0E-8B-C7-BA-20:CMCC    120.197.40.4    sug.so.360.cn    信息安全    20    20    3156    2936    200
1363157983019     13719199419    68-A1-B7-03-07-B1:CMCC-EASY    120.196.100.82            4    0    240    0    200
1363157984041     13660577991    5C-0E-8B-92-5C-20:CMCC-EASY    120.197.40.4    s19.cnzz.com    站点统计    24    9    6960    690    200
1363157973098     15013685858    5C-0E-8B-C7-F7-90:CMCC    120.197.40.4    rank.ie.sogou.com    搜索引擎    28    27    3659    3538    200
1363157986029     15989002119    E8-99-C4-4E-93-E0:CMCC-EASY    120.196.100.99    www.umeng.com    站点统计    3    3    1938    180    200
1363157992093     13560439658    C4-17-FE-BA-DE-D9:CMCC    120.196.100.99            15    9    918    4938    200
1363157986041     13480253104    5C-0E-8B-C7-FC-80:CMCC-EASY    120.197.40.4            3    3    180    180    200
1363157984040     13602846565    5C-0E-8B-8B-B6-00:CMCC    120.197.40.4    2052.flash2-http.qq.com    综合门户    15    12    1938    2910    200
1363157995093     13922314466    00-FD-07-A2-EC-BA:CMCC    120.196.100.82    img.qfc.cn        12    12    3008    3720    200
1363157982040     13502468823    5C-0A-5B-6A-0B-D4:CMCC-EASY    120.196.100.99    y0.ifengimg.com    综合门户    57    102    7335    110349    200
1363157986072     18320173382    84-25-DB-4F-10-1A:CMCC-EASY    120.196.100.99    input.shouji.sogou.com    搜索引擎    21    18    9531    2412    200
1363157990043     13925057413    00-1F-64-E1-E6-9A:CMCC    120.196.100.55    t3.baidu.com    搜索引擎    69    63    11058    48243    200
1363157988072     13760778710    00-FD-07-A4-7B-08:CMCC    120.196.100.82            2    2    120    120    200
1363157985066     13726238888    00-FD-07-A4-72-B8:CMCC    120.196.100.82    i02.c.aliimg.com        24    27    2481    24681    200
1363157993055     13560436666    C4-17-FE-BA-DE-D9:CMCC    120.196.100.99            18    15    1116    954    200

1363157985066      13726230501      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      2481      241      200
1363157985061      13726230502      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      1481      681      200
1363157985062      13726230502      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      3481     681      200
1363157985063      13726230503      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      4481     4681      200
1363157985064      13726230504      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      5481     4681      200
1363157985065      13726230505      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      6481     2681      200
1363157985066      13726230506      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      7481     2481      200
1363157985067      13726230507      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      8481     2461      200
1363157985067      13726230507      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      1481     281      200
1363157985068      13726230508      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      2481     2681     200
1363157985068      13726230508      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      3481     24681     200
1363157985069      13726230509      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      4481     681     200
1363157985060      13726230500      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      1481     24681     200
1363157985061      13726230501      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      1481     681     200
1363157985066      13726230502      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      1481     81         200
1363157985063      13726230503      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      1481     681     200
1363157985063      13726230504      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      1481     681     200
1363157985064      13726230505      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      1481     2681     200
1363157985065      13726230506      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      1481     681     200
1363157985066      13726230507      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      81      24681     200
1363157985067      13726230508      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      481     241     200
1363157985068      13726230508      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      481     681     200
1363157985068      13726230503      00-FD-07-A4-72-B8:CMCC      120.196.100.82      i02.c.aliimg.com      24      27      241     681     200

 1 package com.flowSum;
 2
 3 import java.io.IOException;
 4
 5 import org.apache.commons.lang.StringUtils;
 6 import org.apache.hadoop.io.LongWritable;
 7 import org.apache.hadoop.io.Text;
 8 import org.apache.hadoop.mapreduce.Mapper;
 9 /***
10  *
11  * @author Administrator
12  * 1:FlowBean是我们自定义的一种数据类型，要在hadoop的各个节点之间进行传输，应该遵循hadoop的序列化
13  *      所以就必须实现hadoop的相应的序列化接口
14  * 2:Text一般认为它等价于java.lang.String的Writable。针对UTF-8序列。
15  */
16 public class FlowSumMapper extends Mapper<LongWritable, Text, Text, FlowBean>{
17
18     //拿到日志中的一行数据，切分各个字段，抽取出我们需要的字段：手机号，上行流量，下行流量
19     //封装成key-value发送出去
20
21     @Override
22     protected void map(LongWritable key, Text value, Context context)
23             throws IOException, InterruptedException {
24         //拿到一行数据
25         String line = value.toString();
26         //切分成各个字段
27         String[] fields = StringUtils.split(line, "      ");
28         //拿到手机号的字段
29         String phoneNumber = fields[1];
30         //拿到上行流量字段
31         long up_flow = Long.parseLong(fields[7]);
32         //拿到下行流量字段
33         long down_flow = Long.parseLong(fields[8]);
34
35         //最后一步，封装数据为key-value进行输出
36         context.write(new Text(phoneNumber), new FlowBean(phoneNumber, up_flow, down_flow));
37
38     }
39
40 }

  1 package com.flowSort;
  2
  3 import java.io.IOException;
  4
  5 import org.apache.commons.lang.StringUtils;
  6 import org.apache.hadoop.conf.Configuration;
  7 import org.apache.hadoop.fs.Path;
  8 import org.apache.hadoop.io.LongWritable;
  9 import org.apache.hadoop.io.NullWritable;
 10 import org.apache.hadoop.io.Text;
 11 import org.apache.hadoop.mapreduce.Job;
 12 import org.apache.hadoop.mapreduce.Mapper;
 13 import org.apache.hadoop.mapreduce.Reducer;
 14 import org.apache.hadoop.mapreduce.lib.input.FileInputFormat;
 15 import org.apache.hadoop.mapreduce.lib.output.FileOutputFormat;
 16
 17
 18 public class FlowSortMapReduce {
 19
 20     /***
 21      * mapper静态内部类
 22      * @author Administrator
 23      *
 24      */
 25     public static class FlowSortMapper extends Mapper<LongWritable, Text, FlowBean, NullWritable>{
 26
 27         //拿到一行数据，切分出各字段，封装为一个flowbean，作为key输出
 28         @Override
 29         protected void map(LongWritable key, Text value,Context context)
 30                 throws IOException, InterruptedException {
 31             //获取到一行数据
 32             String line = value.toString();
 33             //对这一行数据进行截取
 34             String[] fields = StringUtils.split(line, "");
 35
 36             //获取数据里面的数据
 37             String phoneNumber = fields[0];
 38             long up_flow = Long.parseLong(fields[1]);
 39             long down_flow = Long.parseLong(fields[2]);
 40
 41             //将数据进行封装传递给reduce
 42             context.write(new FlowBean(phoneNumber, up_flow, down_flow), NullWritable.get());
 43         }
 44
 45     }
 46
 47     /***
 48      * reducer的静态内部类
 49      * @author Administrator
 50      *
 51      */
 52     public static class FlowSortReducer extends Reducer<FlowBean, NullWritable, Text, FlowBean>{
 53
 54         @Override
 55         protected void reduce(FlowBean key, Iterable<NullWritable> values,Context context)
 56                 throws IOException, InterruptedException {
 57
 58             String phoneNumber = key.getPhoneNumber();
 59             context.write(new Text(phoneNumber), key);
 60         }
 61     }
 62
 63
 64     /***
 65      * 主方法
 66      * @param args
 67      * @throws InterruptedException
 68      * @throws IOException
 69      * @throws ClassNotFoundException
 70      */
 71     public static void main(String[] args) throws ClassNotFoundException, IOException, InterruptedException {
 72         //创建配置文件
 73         Configuration conf = new Configuration();
 74         //获取一个作业
 75         Job job = Job.getInstance(conf);
 76
 77         //设置整个job所用的那些类在哪个jar包
 78         job.setJarByClass(FlowSortMapReduce.class);
 79
 80         //本job使用的mapper和reducer的类
 81         job.setMapperClass(FlowSortMapper.class);
 82         job.setReducerClass(FlowSortReducer.class);
 83
 84         //指定mapper的输出数据key-value类型
 85         job.setMapOutputKeyClass(FlowBean.class);
 86         job.setMapOutputValueClass(NullWritable.class);
 87
 88         //指定reduce的输出数据key-value类型Text
 89         job.setOutputKeyClass(Text.class);
 90         job.setOutputValueClass(FlowBean.class);
 91
 92         //指定要处理的输入数据存放路径
 93         //FileInputFormat是所有以文件作为数据源的InputFormat实现的基类，
 94         //FileInputFormat保存作为job输入的所有文件，并实现了对输入文件计算splits的方法。
 95         //至于获得记录的方法是有不同的子类——TextInputFormat进行实现的。
 96         FileInputFormat.setInputPaths(job, new Path(args[0]));
 97
 98         //指定处理结果的输出数据存放路径
 99         FileOutputFormat.setOutputPath(job, new Path(args[1]));
100
101         //将job提交给集群运行
102         //job.waitForCompletion(true);
103         //正常执行成功返回0，否则返回1
104         System.exit(job.waitForCompletion(true) ? 0 : 1);
105     }
106
107 }

  1 package com.flowSort;
  2
  3 import java.io.DataInput;
  4 import java.io.DataOutput;
  5 import java.io.IOException;
  6
  7 import org.apache.hadoop.io.Writable;
  8 import org.apache.hadoop.io.WritableComparable;
  9
 10 /***
 11  *
 12  * @author Administrator
 13  * 1:write 是把每个对象序列化到输出流
 14  * 2:readFields是把输入流字节反序列化
 15  * 3:实现WritableComparable
 16  *      Java值对象的比较：一般需要重写toString(),hashCode(),equals()方法
 17  *
 18  */
 19 public class FlowBean implements WritableComparable<FlowBean>{
 20
 21
 22     private String phoneNumber;//电话号码
 23     private long upFlow;//上行流量
 24     private long downFlow;//下行流量
 25     private long sumFlow;//总流量
 26
 27
 28
 29     public String getPhoneNumber() {
 30         return phoneNumber;
 31     }
 32     public void setPhoneNumber(String phoneNumber) {
 33         this.phoneNumber = phoneNumber;
 34     }
 35     public long getUpFlow() {
 36         return upFlow;
 37     }
 38     public void setUpFlow(long upFlow) {
 39         this.upFlow = upFlow;
 40     }
 41     public long getDownFlow() {
 42         return downFlow;
 43     }
 44     public void setDownFlow(long downFlow) {
 45         this.downFlow = downFlow;
 46     }
 47     public long getSumFlow() {
 48         return sumFlow;
 49     }
 50     public void setSumFlow(long sumFlow) {
 51         this.sumFlow = sumFlow;
 52     }
 53
 54     //为了对象数据的初始化方便，加入一个带参的构造函数
 55     public FlowBean(String phoneNumber, long upFlow, long downFlow) {
 56         this.phoneNumber = phoneNumber;
 57         this.upFlow = upFlow;
 58         this.downFlow = downFlow;
 59         this.sumFlow = upFlow + downFlow;
 60     }
 61     //在反序列化时候，反射机制需要调用空参的构造函数，所以定义了一个空参的构造函数
 62     public FlowBean() {
 63     }
 64
 65     //重写toString()方法
 66     @Override
 67     public String toString() {
 68         return "" + upFlow + "\t" + downFlow + "\t" + sumFlow + "";
 69     }
 70
 71
 72     //从数据流中反序列出对象的数据
 73     //从数据流中读取字段时必须和序列化的顺序保持一致
 74     @Override
 75     public void readFields(DataInput in) throws IOException {
 76         phoneNumber = in.readUTF();
 77         upFlow = in.readLong();
 78         downFlow = in.readLong();
 79         sumFlow = in.readLong();
 80
 81     }
 82
 83     //将对象数据序列化到流中
 84     @Override
 85     public void write(DataOutput out) throws IOException {
 86         out.writeUTF(phoneNumber);
 87         out.writeLong(upFlow);
 88         out.writeLong(downFlow);
 89         out.writeLong(sumFlow);
 90
 91     }
 92
 93     //流量比较的实现方法
 94     @Override
 95     public int compareTo(FlowBean o) {
 96
 97         //大就返回-1，小于等于返回1，进行倒序排序
 98         return sumFlow > o.sumFlow ? -1 : 1;
 99     }
100
101
102
103 }
