结合之前所说的自定义流程的思路，分别是后台、前台、整合，之前的内容也分别进行了相关的练习和尝试，现在就该到了最后的整合了，依旧是以实现功能为目的，细节暂且不去管他。

因为我们实际项目后端用的是spring、spring mvc、mysql、mybatis，前台用的angular js，因此在整合时我也自己搭建使用了这样的环境。

1、所使用的环境基础：eclipse4.4、mysql5.6、angularjs1.4、tomcat7、jdk1.7、maven3.2、spring4.0.9、activiit5.16、activiti-modeler5.16

2、后端maven导包pom.xml文件如下：

 <project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
   xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd">
  <modelVersion>4.0.0</modelVersion>
  <groupId>activitiTest1</groupId>
  <artifactId>activitiTest1</artifactId>
  <packaging>war</packaging>
  <version>0.0.1-SNAPSHOT</version>
  <name>activitiTest1 Maven Webapp</name>
  <url>http://maven.apache.org</url>
  <dependencies>
    <dependency>
      <groupId>junit</groupId>
      <artifactId>junit</artifactId>
      <version>4.11</version>
    </dependency>
    <dependency>
    	<groupId>org.springframework</groupId>
    	<artifactId>spring-beans</artifactId>
    	<version>4.0.9.RELEASE</version>
    </dependency>
    <dependency>
    	<groupId>org.springframework</groupId>
    	<artifactId>spring-core</artifactId>
    	<version>4.0.9.RELEASE</version>
    </dependency>
    <dependency>
    	<groupId>org.springframework</groupId>
    	<artifactId>spring-aop</artifactId>
    	<version>4.0.9.RELEASE</version>
    </dependency>
    <dependency>
    	<groupId>org.springframework</groupId>
    	<artifactId>spring-context</artifactId>
    	<version>4.0.9.RELEASE</version>
    </dependency>
    <dependency>
    	<groupId>org.springframework</groupId>
    	<artifactId>spring-webmvc</artifactId>
    	<version>4.0.9.RELEASE</version>
    </dependency>
    <dependency>
    	<groupId>org.springframework</groupId>
    	<artifactId>spring-web</artifactId>
    	<version>4.0.9.RELEASE</version>
    </dependency>
    <dependency>
    	<groupId>org.springframework</groupId>
    	<artifactId>spring-aspects</artifactId>
    	<version>4.0.9.RELEASE</version>
    </dependency>
    <dependency>
    	<groupId>org.springframework</groupId>
    	<artifactId>spring-expression</artifactId>
    	<version>4.0.9.RELEASE</version>
    </dependency>
    <dependency>
    	<groupId>org.springframework</groupId>
    	<artifactId>spring-tx</artifactId>
    	<version>4.0.9.RELEASE</version>
    </dependency>
    <dependency>
    	<groupId>javax.servlet</groupId>
    	<artifactId>javax.servlet-api</artifactId>
    	<version>3.1.0</version>
    </dependency>
    <dependency>
    	<groupId>com.fasterxml.jackson.core</groupId>
    	<artifactId>jackson-annotations</artifactId>
    	<version>2.2.3</version>
    </dependency>
    <dependency>
    	<groupId>com.fasterxml.jackson.core</groupId>
    	<artifactId>jackson-core</artifactId>
    	<version>2.2.3</version>
    </dependency>
    <dependency>
    	<groupId>com.fasterxml.jackson.core</groupId>
    	<artifactId>jackson-databind</artifactId>
    	<version>2.2.3</version>
    </dependency>
    <dependency>
    	<groupId>org.activiti</groupId>
    	<artifactId>activiti-modeler</artifactId>
    	<version>5.16</version>
    </dependency>
    <dependency>
    	<groupId>org.activiti</groupId>
    	<artifactId>activiti-engine</artifactId>
    	<version>5.16</version>
    </dependency>
    <dependency>
    	<groupId>org.activiti</groupId>
    	<artifactId>activiti-explorer</artifactId>
    	<version>5.16</version>
    </dependency>
    <dependency>
    	<groupId>org.activiti</groupId>
    	<artifactId>activiti-rest</artifactId>
    	<version>5.16</version>
    </dependency>
    <dependency>
    	<groupId>org.springframework</groupId>
    	<artifactId>spring-context-support</artifactId>
    	<version>4.0.9.RELEASE</version>
    </dependency>
    <dependency>
    	<groupId>mysql</groupId>
    	<artifactId>mysql-connector-java</artifactId>
    	<version>5.1.34</version>
    </dependency>


    <dependency>
    	<groupId>org.activiti</groupId>
    	<artifactId>activiti-spring</artifactId>
    	<version>5.16</version>
    </dependency>
    <dependency>
    	<groupId>org.springframework</groupId>
    	<artifactId>spring-jdbc</artifactId>
    	<version>4.0.9.RELEASE</version>
    </dependency>
    <dependency>
    	<groupId>org.springframework</groupId>
    	<artifactId>spring-test</artifactId>
    	<version>4.0.9.RELEASE</version>
    </dependency>
    <dependency>
    	<groupId>org.activiti</groupId>
    	<artifactId>activiti-bpmn-converter</artifactId>
    	<version>5.16</version>
    </dependency>
    <dependency>
    	<groupId>org.codehaus.jackson</groupId>
    	<artifactId>jackson-core-asl</artifactId>
    	<version>1.9.11</version>
    </dependency>
    <dependency>
    	<groupId>org.codehaus.jackson</groupId>
    	<artifactId>jackson-mapper-asl</artifactId>
    	<version>1.9.11</version>
    </dependency>
  </dependencies>
  <build>
    <finalName>activitiTest1</finalName>
  </build>
</project>

3、 web项目基础配置web.xml如下：

 <?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
	xmlns="http://java.sun.com/xml/ns/javaee" xmlns:web="http://java.sun.com/xml/ns/javaee/web-app_2_5.xsd"
	xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/web-app_2_5.xsd"
	id="WebApp_ID" version="2.5">
	<filter>
		<description>字符集过滤器</description>
		<filter-name>encodingFilter</filter-name>
		<filter-class>org.springframework.web.filter.CharacterEncodingFilter</filter-class>
		<init-param>
			<description>字符集编码</description>
			<param-name>encoding</param-name>
			<param-value>UTF-8</param-value>
		</init-param>
	</filter>
	<filter-mapping>
		<filter-name>encodingFilter</filter-name>
		<url-pattern>/*</url-pattern>
	</filter-mapping>


	<servlet>
    <servlet-name>RestletServlet</servlet-name>
    <servlet-class>org.restlet.ext.servlet.ServerServlet</servlet-class>
    <init-param>
      <param-name>org.restlet.application</param-name>
      <param-value>org.activiti.rest.editor.application.ModelerRestApplication</param-value>
    </init-param>
  </servlet>
  <servlet-mapping>
    <servlet-name>RestletServlet</servlet-name>
    <url-pattern>/service/*</url-pattern>
  </servlet-mapping>


    <servlet>
        <servlet-name>springMVC</servlet-name>
        <servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
        <init-param>
            <param-name>contextConfigLocation</param-name>
            <param-value>classpath:spring.xml</param-value>
        </init-param>
    </servlet>
    <servlet-mapping>
        <servlet-name>springMVC</servlet-name>
        <url-pattern>*.do</url-pattern>
    </servlet-mapping>
    <welcome-file-list>
    	<welcome-file>activiti.html</welcome-file>
    	<welcome-file>activiti.htm</welcome-file>
    	<welcome-file>activiti.jsp</welcome-file>
    	<welcome-file>default.html</welcome-file>
    	<welcome-file>default.htm</welcome-file>
    	<welcome-file>default.jsp</welcome-file>
    </welcome-file-list>
</web-app>

4、其他依赖环境，如下图中红线框起来的部分：其中包括使用angularjs依赖的js，整合activiti-modeler依赖的文件和使用ueditor插件所需的文件。（具体的文件可参考之前的博客内容）

5、后台spring基础配置文件spring.xml如下：

 <?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
    xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:p="http://www.springframework.org/schema/p"
    xmlns:context="http://www.springframework.org/schema/context"
    xmlns:mvc="http://www.springframework.org/schema/mvc"
    xsi:schemaLocation="
        http://www.springframework.org/schema/beans
        http://www.springframework.org/schema/beans/spring-beans-3.0.xsd
        http://www.springframework.org/schema/context
        http://www.springframework.org/schema/context/spring-context-3.0.xsd
        http://www.springframework.org/schema/mvc
        http://www.springframework.org/schema/mvc/spring-mvc.xsd">


    <context:annotation-config />
    <mvc:annotation-driven />
    <context:component-scan base-package="controllers" />
    <context:component-scan base-package="serviceImp" />
	<bean id="dataSource" class="org.springframework.jdbc.datasource.SimpleDriverDataSource">

	   <property name="driverClass" value="com.mysql.jdbc.Driver"></property>
	   <property name="url" value="jdbc:mysql://127.0.0.1:3306/testtu?useUnicode=true&characterEncoding=utf8" ></property>
	   <property name="username" value="root" ></property>
	   <property name="password" value="123456" ></property>
	</bean>

	<bean id="transactionManager" class="org.springframework.jdbc.datasource.DataSourceTransactionManager">
	   <property name="dataSource" ref="dataSource"></property>
	</bean>

	<bean id="processEngineConfiguration" class="org.activiti.spring.SpringProcessEngineConfiguration">
        <property name="dataSource" ref="dataSource" />
		<property name="databaseSchemaUpdate" value="true" />
	    <property name="jobExecutorActivate" value="false"/>
	    <property name="history" value="full"/>
	    <property name="transactionManager" ref="transactionManager" />
		<!-- 配置事务管理器，统一事务 -->

		<!-- 设置建表策略，如果没有表，自动创建表 -->
	</bean>
	<!-- 创建流程引擎对象 -->
	<bean id="processEngine" class="org.activiti.spring.ProcessEngineFactoryBean">
		<property name="processEngineConfiguration" ref="processEngineConfiguration" />
	</bean>


	<!-- 由流程引擎对象，提供的方法，创建项目中使用的Activiti工作流的Service -->
	<bean id="repositoryService" factory-bean="processEngine" factory-method="getRepositoryService" />
	<bean id="runtimeService" factory-bean="processEngine" factory-method="getRuntimeService" />
	<bean id="taskService" factory-bean="processEngine" factory-method="getTaskService" />
	<bean id="historyService" factory-bean="processEngine" factory-method="getHistoryService" />
	<bean id="formService" factory-bean="processEngine" factory-method="getFormService" />
     <bean id="IdentityService" factory-bean="processEngine" factory-method="getIdentityService" />
    <!-- 避免IE执行AJAX时,返回JSON出现下载文件 -->
	<bean id="mappingJacksonHttpMessageConverter"
		class="org.springframework.http.converter.json.MappingJackson2HttpMessageConverter">
		<property name="supportedMediaTypes">
			<list>
				<value>text/html;charset=utf-8</value>
			</list>
		</property>
	</bean>


	<!-- 启动Spring MVC的注解功能，完成请求和注解POJO的映射 -->
	<bean
		class="org.springframework.web.servlet.mvc.annotation.AnnotationMethodHandlerAdapter">
		<property name="messageConverters">
			<list>
				<ref bean="mappingJacksonHttpMessageConverter" /><!-- json转换器 -->
			</list>
		</property>
	</bean>

</beans>

5、整个项目结构如图：

activiti自定义流程之整合（一）：整体环境配置
