grpc vs2015编译

简介: 获取gRPC源码 gRPC是开源框架,项目代码在github上,所以首先要安装github。github安装后,在指定文件夹中,执行git命令就可以获取gRPC的所有源码。 git clone  https://github.com/grpc/grpc.git cd grpc git submodule update --init   step1. 编译protobuf 参考readme用CMAKE生成工程文件,编译即可。

获取gRPC源码

gRPC是开源框架,项目代码在github上,所以首先要安装github。
github安装后,在指定文件夹中,执行git命令就可以获取gRPC的所有源码。
git clone  https://github.com/grpc/grpc.git
cd grpc
git submodule update --init

step1. 编译protobuf

参考readme用CMAKE生成工程文件,编译即可。首先打开vs2015开发人员命令提示符窗口,切换到对应的protobuf目录

具体步骤:

1:cd protobuf

2: Git clone -b release-1.7.0 https://github.com/google/googlemock.git gmock

3:cd gmock

4:git clone -b release-1.7.0 https://github.com/google/googletest.git gtest

5:cd ..\cmake

6:mkdir build & cd build & mkdir install

7:mkdir debug & cd debug

8:cmake -G "NMake Makefiles" -DCMAKE_BUILD_TYPE=Debug -DCMAKE_INSTALL_PREFIX=../install ../..

9:nmake && nmake install

10:生成完成,在install目录下面有对应的Lib文件。在cmake目录下面mkdir debug,然后把install/lib目录下的所有库文件拷贝的debug路径,并把后缀d去掉。例如protobuf生成的库名称为libprotocd.lib,应该改名成libprotoc.lib。其他的依次类推。后面编译grpc会用到这些库。



step2. 编译grpc,grpc_protoc_plugin:在vsprojects里有建好的工程文件,下载nuget.exe,用于依赖包的网络下载。主要是依赖于openssl和zlib库。在编译grpc时,出现编译boringssl,出现很多错误,可以把工程移除

具体步骤:

1:cd vsprojects

2:nuget restore grpc.sln

3:msbuild grpc.sln /p:Configuration=Debug

grpc库生成成功。

4:编译grpc_cpp_plugin,执行命令:msbuild grpc_protoc_plugins.sln /p:Configuration=Debug

grpc_cpp_plugin.exe插件编译成功


用vs2015编译基本不会遇到什么问题,除了:grpc_cpp_plugin依赖libprotoc.lib,而protobuf生成的库名称为libprotocd.lib,这块需要手动改一下

step3. zlib 参考readme

step4编译helloworld

1: cd grpc/example/protos

2: 把proto.exe(protobuf工程生成,在install/bin目录下)、helloworld.proto拷贝到vsprojects\debug路径下面。此时在vsprojects\debug路径下面执行命令



[cpp]  view plain  copy

  1. protoc.exe -I=. --grpc_out=. --plugin=protoc-gen-grpc=.\grpc_cpp_plugin.exe helloworld.proto
  2. protoc.exe -I=. --cpp_out=. helloworld.proto
生成了两套文件





[cpp]  view plain  copy

  1. hellowworld.pb.h
  2. hellowworld.pb.cc
  3. hellowworld.grpc.pb.h
  4. hellowworld.grpc.pb.cc
其中前两个是protoc生成的,后两个是插件生成的



3:在vsprojects目录创建空的WIN32 C++工程grpc_helloworld.sln,在目录grpc_helloworld下面有两个文件夹。目录结构如下图






工程配置:
头文件包含路径:
[cpp]  view plain  copy

  1. $(SolutionDir)..\..\grpc\third_party\protobuf\src;$(SolutionDir)..\..\grpc\include;$(ProjectDir)..\protobuf;%(AdditionalIncludeDirectories)
预处理器设定
[cpp]  view plain  copy

  1. _DEBUG;_WIN32_WINNT=0x600;_SCL_SECURE_NO_WARNINGS;_CRT_SECURE_NO_WARNINGS;%(PreprocessorDefinitions)

代码生成-->运行库设置为 "多线程调试 (/MTd)"

附件库目录设定
[cpp]  view plain  copy

  1. $(OutDir);$(SolutionDir)packages\grpc.dependencies.openssl.1.0.204.1\build\native\lib\v140\Win32\Debug\dynamic;$(SolutionDir)packages\grpc.dependencies.zlib.1.2.8.10\build\native\lib\v140\Win32\Debug\dynamic\cdecl;%(AdditionalLibraryDirectories)

附加依赖项设定
libprotobuf.lib;grpc.lib;gpr.lib;grpc++.lib;Ws2_32.lib;libeay32.lib;ssleay32.lib;zlib.lib;%(AdditionalDependencies)

编译工程文件,顺利的话就可以生成对应的exe了。
将gRPC的C++ example的代码拷贝到我们刚创建的项目中,编译,出现一些error:

错误A:

Error 2 error C1189:#error :"Please compile grpc with _WIN32_WINNT of at least 0x600 (aka Windows Vista)" d:\projects_framework\grpc\include\grpc\impl\codegen\port_platform.h 59 1 Server_Cpp

解决:在项目属性中的Preprocessor Definitions中添加_WIN32_WINNT=0x600

错误B:

Error    1    error C4996: 'std::_Copy_impl': Function call with parameters that may be unsafe - this call relies on the caller to check that the passed values are correct. To disable this warning, use -D_SCL_SECURE_NO_WARNINGS. See documentation on how to use Visual C++ 'Checked Iterators' c:\program files (x86)\microsoft visual studio 12.0\vc\include\xutility 2132 1 Server_Cpp

解决:在项目属性中的Preprocessor Definitions中添加

_SCL_SECURE_NO_WARNINGS
_CRT_SECURE_NO_WARNINGS

错误C:

error LNK2038: mismatch detected for 'RuntimeLibrary': value

解决:只需要主程序和静态库都采用同一种Runtime Libray编译即可。
在项目属性C/C++中的Code Generation的Runtime Library选择Multi-threaded(/MT)

错误D:

Error    2    error LNK2038: mismatch detected for 'RuntimeLibrary': value 'MT_StaticRelease' doesn't match value 'MTd_StaticDebug' in greeter_server.obj D:\Projects_My\gRPC\gRPC_cpp\Server_Cpp\libprotobuf.lib(generated_message_util.obj) Server_Cpp

解决:原因是将debug的配置拷贝到release时,将Preprocessor Definitions的_DEBUG也考到release中了,去掉_DEBUG即可

错误E:

Error    113    error LNK2001: unresolved external symbol _SSL_state    D:\Projects_My\gRPC\gRPC_cpp\Server_Cpp\grpc.lib(ssl_transport_security.obj)    Server_Cpp

解决:添加openssl的lib(用v120,可能是vs的版本号),具体用v1xx可以根据自己的vs版本来对应



D:\XXXX\grpc\vsprojects\packages\grpc.dependencies.openssl.1.0.204.1\build\native\lib\v120\Win32\Release\static



库文件:

libeay32.lib
ssleay32.lib

错误F:

Error    2    error LNK2005: "private: __thiscall type_info::type_info(class type_info const &)" (??0type_info@@AAE@ABV0@@Z) already defined in LIBCMT.lib(typinfo.obj) D:\Projects_My\gRPC\gRPC_cpp\Server_Cpp\msvcrt.lib(ti_inst.obj) Server_Cpp

解决:
Project Settings:
-> Configration Properties -> Linker -> Input -> Ignore Specific Library: LIBCMT.lib

在编译的时候,有可以还会遇到找不到Grpc内的某个符号,比如Channel、Complete_quque等, 以下以channel为例说明解决方法:

GRPC编译grpc++.lib时,生成的Channel.obj会被覆盖(原因没查出来,大概是因为grpc.lib编译时同样会生成channel.obj)

 删掉obj目录中C:\path\to\grpc\vsprojects\IntDir\grpc++中的channel.obj,然后在工程里“生成”(不要重新生成)
