一、U8g2

u8g2_Setup_ssd1306_i2c_128x64_noname_f

描述：设置 SSD1306 驱动的 128x64 I2C OLED 显示屏，不使用名称。

用法：u8g2_Setup_ssd1306_i2c_128x64_noname_f(&u8g2, rotation, u8x8_byte_sw_i2c, u8x8_gpio_and_delay_arduino);

u8g2_InitDisplay

描述：初始化显示。
用法：u8g2_InitDisplay(&u8g2);

u8g2_SetFont

描述：设置字体。
用法：u8g2_SetFont(&u8g2, u8g2_font_ncenB08_tr);

u8g2_DrawStr

描述：在屏幕上绘制字符串。
用法：u8g2_DrawStr(&u8g2, x, y, "Hello World!");

u8g2_SendBuffer

描述：将缓冲区的内容发送到显示屏。
用法：u8g2_SendBuffer(&u8g2);

u8g2_ClearBuffer

描述：清除缓冲区的内容。
用法：u8g2_ClearBuffer(&u8g2);

u8g2_DrawFrame

描述：在屏幕上绘制矩形框架。
用法：u8g2_DrawFrame(&u8g2, x, y, width, height);

u8g2_DrawBitmap

描述：在屏幕上绘制位图。
用法：u8g2_DrawBitmap(&u8g2, x, y, width, height, bitmap);

u8g2_SetContrast

描述：设置显示屏对比度。
用法：u8g2_SetContrast(&u8g2, contrast_value);

u8g2_SetPowerSave

描述：设置屏幕的电源保存模式。
用法：u8g2_SetPowerSave(&u8g2, is_enable);

u8g2_FirstPage和u8g2_NextPage

描述：在多页屏幕上使用，u8g2_FirstPage 开始一个新页面，u8g2_NextPage 切换到下一个页面。

二、CubeMX配置

时钟配置

时钟树配置

板子led配置

IIC配置

rtos配置

生成工程

三、移植u8g2

下载源码地址https://github.com/olikraus/u8g2

链接: https://pan.baidu.com/s/1Uu2T2-k3lRe_FgVjWbnl8A?pwd=t3n8 提取码: t3n8

解压后将下载的csrc拷贝到工程中，并新建oled和delay两个文件

在oled文件中添加空的oled.c oled.h文件

并在代码中添加路径

添加oled路径

保存，新建组

添加oled和csrc两个组

然后添加函数

全部导进来，看缺什么在添加

找到u8g2_d_setup注释其他函数

void u8g2_Setup_ssd1306_i2c_128x64_noname_f(u8g2_t *u8g2, const u8g2_cb_t *rotation, u8x8_msg_cb byte_cb, u8x8_msg_cb gpio_and_delay_cb)
{
  uint8_t tile_buf_height;
  uint8_t *buf;
  u8g2_SetupDisplay(u8g2, u8x8_d_ssd1306_128x64_noname, u8x8_cad_ssd13xx_fast_i2c, byte_cb, gpio_and_delay_cb);
  buf = u8g2_m_16_8_f(&tile_buf_height);
  u8g2_SetupBuffer(u8g2, buf, tile_buf_height, u8g2_ll_hvline_vertical_top_lsb, rotation);
}

找到u8g2_d_memory注释其他函数

uint8_t *u8g2_m_16_8_f(uint8_t *page_cnt)
{
  #ifdef U8G2_USE_DYNAMIC_ALLOC
  *page_cnt = 8;
  return 0;
  #else
  static uint8_t buf[1024];
  *page_cnt = 8;
  return buf;
  #endif
}

oled.h

#ifndef __oled_H
#define __oled_H
#ifdef __cplusplus
 extern "C" {
#endif

/* Includes ------------------------------------------------------------------*/
#include "main.h"
#include "u8g2.h"
/* USER CODE BEGIN Includes */

/* USER CODE END Includes */



/* USER CODE BEGIN Private defines */

/* USER CODE END Private defines */
#define u8         unsigned char  // ?unsigned char ????
#define MAX_LEN    128  //
#define OLED_ADDRESS  0x78 // oled??????
#define OLED_CMD   0x00  // ???
#define OLED_DATA  0x40  // ???

/* USER CODE BEGIN Prototypes */
 uint8_t u8x8_byte_hw_i2c(u8x8_t *u8x8, uint8_t msg, uint8_t arg_int, void *arg_ptr);
 uint8_t u8x8_gpio_and_delay(u8x8_t *u8x8, uint8_t msg, uint8_t arg_int, void *arg_ptr);
 void u8g2Init(u8g2_t *u8g2);
 #ifdef __cplusplus
}
#endif
#endif /*__ i2c_H */
/* USER CODE END Prototypes */

oled.c

#include "stm32f1xx_hal.h"
#include "u8g2.h"
#include "oled.h"
#include "main.h"
#include "oled.h"
#include "i2c.h"

uint8_t u8x8_byte_hw_i2c(u8x8_t *u8x8, uint8_t msg, uint8_t arg_int, void *arg_ptr)
{
    /* u8g2/u8x8 will never send more than 32 bytes between START_TRANSFER and END_TRANSFER */
    static uint8_t buffer[128];
    static uint8_t buf_idx;
    uint8_t *data;

    switch (msg)
    {
    case U8X8_MSG_BYTE_INIT:
    {
        /* add your custom code to init i2c subsystem */
        MX_I2C1_Init(); //I2C???
    }
    break;

    case U8X8_MSG_BYTE_START_TRANSFER:
    {
        buf_idx = 0;
    }
    break;

    case U8X8_MSG_BYTE_SEND:
    {
        data = (uint8_t *)arg_ptr;

        while (arg_int > 0)
        {
            buffer[buf_idx++] = *data;
            data++;
            arg_int--;
        }
    }
    break;

    case U8X8_MSG_BYTE_END_TRANSFER:
    {
        if (HAL_I2C_Master_Transmit(&hi2c1, (OLED_ADDRESS), buffer, buf_idx, 1000) != HAL_OK)
            return 0;
    }
    break;

    case U8X8_MSG_BYTE_SET_DC:
        break;

    default:
        return 0;
    }

    return 1;
}

void delay_us(uint32_t time)
{
    uint32_t i = 8 * time;
    while (i--)
        ;
}

uint8_t u8x8_gpio_and_delay(u8x8_t *u8x8, uint8_t msg, uint8_t arg_int, void *arg_ptr)
{
    switch (msg)
    {
    case U8X8_MSG_DELAY_100NANO: // delay arg_int * 100 nano seconds
        __NOP();
        break;
    case U8X8_MSG_DELAY_10MICRO: // delay arg_int * 10 micro seconds
        for (uint16_t n = 0; n < 320; n++)
        {
            __NOP();
        }
        break;
    case U8X8_MSG_DELAY_MILLI: // delay arg_int * 1 milli second
        HAL_Delay(1);
        break;
    case U8X8_MSG_DELAY_I2C: // arg_int is the I2C speed in 100KHz, e.g. 4 = 400 KHz
        delay_us(5);
        break;                    // arg_int=1: delay by 5us, arg_int = 4: delay by 1.25us
    case U8X8_MSG_GPIO_I2C_CLOCK: // arg_int=0: Output low at I2C clock pin
        break;                    // arg_int=1: Input dir with pullup high for I2C clock pin
    case U8X8_MSG_GPIO_I2C_DATA:  // arg_int=0: Output low at I2C data pin
        break;                    // arg_int=1: Input dir with pullup high for I2C data pin
    case U8X8_MSG_GPIO_MENU_SELECT:
        u8x8_SetGPIOResult(u8x8, /* get menu select pin state */ 0);
        break;
    case U8X8_MSG_GPIO_MENU_NEXT:
        u8x8_SetGPIOResult(u8x8, /* get menu next pin state */ 0);
        break;
    case U8X8_MSG_GPIO_MENU_PREV:
        u8x8_SetGPIOResult(u8x8, /* get menu prev pin state */ 0);
        break;
    case U8X8_MSG_GPIO_MENU_HOME:
        u8x8_SetGPIOResult(u8x8, /* get menu home pin state */ 0);
        break;
    default:
        u8x8_SetGPIOResult(u8x8, 1); // default return value
        break;
    }
    return 1;
}
void u8g2Init(u8g2_t *u8g2)
{
  u8g2_Setup_ssd1306_i2c_128x64_noname_f(u8g2, U8G2_R0, u8x8_byte_hw_i2c, u8x8_gpio_and_delay); // ??? u8g2 ???
  u8g2_InitDisplay(u8g2);                                                                       // ??????????????,??????,?????????
  u8g2_SetPowerSave(u8g2, 0);                                                                   // ?????
  u8g2_ClearBuffer(u8g2);
}

主函数中freertos.c

/* USER CODE BEGIN Header */
/**
  ******************************************************************************
  * File Name          : freertos.c
  * Description        : Code for freertos applications
  ******************************************************************************
  * @attention
  *
  * Copyright (c) 2023 STMicroelectronics.
  * All rights reserved.
  *
  * This software is licensed under terms that can be found in the LICENSE file
  * in the root directory of this software component.
  * If no LICENSE file comes with this software, it is provided AS-IS.
  *
  ******************************************************************************
  */
/* USER CODE END Header */

/* Includes ------------------------------------------------------------------*/
#include "FreeRTOS.h"
#include "task.h"
#include "main.h"
#include "cmsis_os.h"

/* Private includes ----------------------------------------------------------*/
/* USER CODE BEGIN Includes */
#include "u8g2.h"
#include "oled.h"
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
/* USER CODE END Includes */

/* Private typedef -----------------------------------------------------------*/
/* USER CODE BEGIN PTD */
// 当前湿度和设定湿度
int current_humidity = 50;  // 当前湿度
int target_humidity = 60;   // 设定湿度

// 加湿器工作状态
int humidifier_status = 0;  // 0表示关闭，1表示打开

/* USER CODE END PTD */

/* Private define ------------------------------------------------------------*/
/* USER CODE BEGIN PD */

/* USER CODE END PD */

/* Private macro -------------------------------------------------------------*/
/* USER CODE BEGIN PM */

/* USER CODE END PM */

/* Private variables ---------------------------------------------------------*/
/* USER CODE BEGIN Variables */

/* USER CODE END Variables */
osThreadId defaultTaskHandle;

/* Private function prototypes -----------------------------------------------*/
/* USER CODE BEGIN FunctionPrototypes */

/* USER CODE END FunctionPrototypes */

void StartDefaultTask(void const * argument);

void MX_FREERTOS_Init(void); /* (MISRA C 2004 rule 8.1) */

/* GetIdleTaskMemory prototype (linked to static allocation support) */
void vApplicationGetIdleTaskMemory( StaticTask_t **ppxIdleTaskTCBBuffer, StackType_t **ppxIdleTaskStackBuffer, uint32_t *pulIdleTaskStackSize );

/* USER CODE BEGIN GET_IDLE_TASK_MEMORY */
static StaticTask_t xIdleTaskTCBBuffer;
static StackType_t xIdleStack[configMINIMAL_STACK_SIZE];

void vApplicationGetIdleTaskMemory( StaticTask_t **ppxIdleTaskTCBBuffer, StackType_t **ppxIdleTaskStackBuffer, uint32_t *pulIdleTaskStackSize )
{
  *ppxIdleTaskTCBBuffer = &xIdleTaskTCBBuffer;
  *ppxIdleTaskStackBuffer = &xIdleStack[0];
  *pulIdleTaskStackSize = configMINIMAL_STACK_SIZE;
  /* place for user code */
}
/* USER CODE END GET_IDLE_TASK_MEMORY */

/**
  * @brief  FreeRTOS initialization
  * @param  None
  * @retval None
  */
void MX_FREERTOS_Init(void) {
  /* USER CODE BEGIN Init */

  /* USER CODE END Init */

  /* USER CODE BEGIN RTOS_MUTEX */
  /* add mutexes, ... */
  /* USER CODE END RTOS_MUTEX */

  /* USER CODE BEGIN RTOS_SEMAPHORES */
  /* add semaphores, ... */
  /* USER CODE END RTOS_SEMAPHORES */

  /* USER CODE BEGIN RTOS_TIMERS */
  /* start timers, add new ones, ... */
  /* USER CODE END RTOS_TIMERS */

  /* USER CODE BEGIN RTOS_QUEUES */
  /* add queues, ... */
  /* USER CODE END RTOS_QUEUES */

  /* Create the thread(s) */
  /* definition and creation of defaultTask */
  osThreadDef(defaultTask, StartDefaultTask, osPriorityNormal, 0, 128);
  defaultTaskHandle = osThreadCreate(osThread(defaultTask), NULL);

  /* USER CODE BEGIN RTOS_THREADS */
  /* add threads, ... */
  /* USER CODE END RTOS_THREADS */

}

/* USER CODE BEGIN Header_StartDefaultTask */
/**
  * @brief  Function implementing the defaultTask thread.
  * @param  argument: Not used
  * @retval None
  */
/* USER CODE END Header_StartDefaultTask */
void StartDefaultTask(void const * argument)
{
  /* USER CODE BEGIN StartDefaultTask */
  /* Infinite loop */

  u8g2_t u8g2; // a structure which will contain all the data for one display
  u8g2Init(&u8g2);


  // 清空缓冲区
  //u8g2_ClearBuffer(&u8g2);
  for(;;)
  {

  // 在这里添加你的OLED显示代码
    u8g2_ClearBuffer(&u8g2);

     u8g2_ClearBuffer(&u8g2);

    // 选择一个字体
    u8g2_SetFont(&u8g2, u8g2_font_ncenB08_tr);

    // 显示当前湿度
    char current_humidity_str[20];
    sprintf(current_humidity_str, "Humidity: %d%%", current_humidity);
    u8g2_DrawStr(&u8g2, 10, 20, current_humidity_str);

    // 显示设定湿度
    char target_humidity_str[20];
    sprintf(target_humidity_str, "Set Humidity: %d%%", target_humidity);
    u8g2_DrawStr(&u8g2, 10, 35, target_humidity_str);

    // 显示加湿器状态
    char status_str[20];
    if (humidifier_status == 0) {
        strcpy(status_str, "Status: OFF");
    } else {
        strcpy(status_str, "Status: ON");
    }
    u8g2_DrawStr(&u8g2, 10, 50, status_str);

    // 发送缓冲区内容到显示屏
    u8g2_SendBuffer(&u8g2);
    osDelay(100);
  }
  /* USER CODE END StartDefaultTask */
}

/* Private application code --------------------------------------------------*/
/* USER CODE BEGIN Application */

/* USER CODE END Application */

链接:https://pan.baidu.com/s/1TjmONSX5vamA5MHYUQP0Mw 密码:24ml
