matplotlib

简介: 【6月更文挑战第9天】

matplotlib.pyplot 是 Python 中一个用于创建静态、动画和交互式可视化的库,特别适合用于科学计算。它提供了一个类似于 MATLAB 的绘图框架,简化了图表的创建和自定义。以下是对 matplotlib.pyplot 库的详细介绍。

基本概念

  1. pyplotmatplotlib.pyplot 是 Matplotlib 库的一个子库,提供了一个类似 MATLAB 的绘图 API。通过这个 API,可以方便地创建各种类型的图表。
  2. Figure:图形的容器,可以包含一个或多个子图(Axes)。
  3. Axes:图的实际区域,一个 Figure 可以包含多个 Axes。
  4. Axis:指的是 x 轴和 y 轴,每个 Axes 对象有两个 Axis 对象(一个用于 x 轴,一个用于 y 轴)。

安装

如果尚未安装 Matplotlib,可以通过以下命令安装:

pip install matplotlib

基本用法

以下是一些常用的 matplotlib.pyplot 操作。

导入库

import matplotlib.pyplot as plt

创建简单的折线图

# 准备数据
x = [1, 2, 3, 4]
y = [10, 20, 25, 30]

# 创建图形
plt.figure()

# 绘制图形
plt.plot(x, y)

# 添加标题和标签
plt.title("Simple Line Plot")
plt.xlabel("X-axis")
plt.ylabel("Y-axis")

# 显示图形
plt.show()

创建多个子图

# 准备数据
x = [1, 2, 3, 4]
y1 = [10, 20, 25, 30]
y2 = [30, 25, 20, 10]

# 创建图形和子图
fig, axs = plt.subplots(2)

# 绘制第一个子图
axs[0].plot(x, y1)
axs[0].set_title('First Subplot')

# 绘制第二个子图
axs[1].plot(x, y2)
axs[1].set_title('Second Subplot')

# 显示图形
plt.tight_layout()
plt.show()

添加图例

# 准备数据
x = [1, 2, 3, 4]
y1 = [10, 20, 25, 30]
y2 = [30, 25, 20, 10]

# 创建图形
plt.figure()

# 绘制图形
plt.plot(x, y1, label='Line 1')
plt.plot(x, y2, label='Line 2')

# 添加标题和标签
plt.title("Line Plot with Legend")
plt.xlabel("X-axis")
plt.ylabel("Y-axis")

# 添加图例
plt.legend()

# 显示图形
plt.show()

常见图表类型

折线图(Line Plot)

x = [1, 2, 3, 4]
y = [10, 20, 25, 30]

plt.plot(x, y)
plt.title("Line Plot")
plt.xlabel("X-axis")
plt.ylabel("Y-axis")
plt.show()

散点图(Scatter Plot)

x = [1, 2, 3, 4]
y = [10, 20, 25, 30]

plt.scatter(x, y)
plt.title("Scatter Plot")
plt.xlabel("X-axis")
plt.ylabel("Y-axis")
plt.show()

条形图(Bar Plot)

x = ['A', 'B', 'C', 'D']
y = [10, 20, 25, 30]

plt.bar(x, y)
plt.title("Bar Plot")
plt.xlabel("Categories")
plt.ylabel("Values")
plt.show()

直方图(Histogram)

data = [1, 2, 2, 3, 3, 3, 4, 4, 4, 4]

plt.hist(data, bins=4)
plt.title("Histogram")
plt.xlabel("Value")
plt.ylabel("Frequency")
plt.show()

饼图(Pie Chart)

labels = ['A', 'B', 'C', 'D']
sizes = [10, 20, 30, 40]

plt.pie(sizes, labels=labels, autopct='%1.1f%%')
plt.title("Pie Chart")
plt.show()

自定义图表

Matplotlib 提供了丰富的自定义选项,可以对图表进行详细的调整和美化。

自定义颜色和样式

x = [1, 2, 3, 4]
y = [10, 20, 25, 30]

plt.plot(x, y, color='green', linestyle='--', marker='o')
plt.title("Custom Line Plot")
plt.xlabel("X-axis")
plt.ylabel("Y-axis")
plt.show()

添加注释

x = [1, 2, 3, 4]
y = [10, 20, 25, 30]

plt.plot(x, y)
plt.title("Annotated Line Plot")
plt.xlabel("X-axis")
plt.ylabel("Y-axis")

# 添加注释
plt.annotate('Highest Point', xy=(4, 30), xytext=(3, 25),
             arrowprops=dict(facecolor='black', shrink=0.05))

plt.show()

设置坐标轴范围和刻度

x = [1, 2, 3, 4]
y = [10, 20, 25, 30]

plt.plot(x, y)
plt.title("Custom Axis Range and Ticks")
plt.xlabel("X-axis")
plt.ylabel("Y-axis")

# 设置坐标轴范围
plt.xlim(0, 5)
plt.ylim(0, 35)

# 设置刻度
plt.xticks([0, 1, 2, 3, 4, 5])
plt.yticks([0, 10, 20, 30, 40])

plt.show()

保存图表

x = [1, 2, 3, 4]
y = [10, 20, 25, 30]

plt.plot(x, y)
plt.title("Save Plot Example")
plt.xlabel("X-axis")
plt.ylabel("Y-axis")

# 保存图表为 PNG 文件
plt.savefig('plot.png')

# 显示图表
plt.show()
