简介: ssm整合

4.2、准备工作

①创建Maven Module

②导入依赖

<properties</properties>只能有一个,整合即可

`

<packaging>war</packaging>
<properties>
    <spring.version>5.3.1</spring.version>
</properties>
<dependencies>
    <dependency>
        <groupId>org.springframework</groupId>
        <artifactId>spring-context</artifactId>
        <version>${spring.version}</version>
    </dependency>
    <dependency>
        <groupId>org.springframework</groupId>
        <artifactId>spring-beans</artifactId>
        <version>${spring.version}</version>
    </dependency>
    <!--springmvc-->
    <dependency>
        <groupId>org.springframework</groupId>
        <artifactId>spring-web</artifactId>
        <version>${spring.version}</version>
    </dependency>
    <dependency>
        <groupId>org.springframework</groupId>
        <artifactId>spring-webmvc</artifactId>
        <version>${spring.version}</version>
    </dependency>
    <dependency>
        <groupId>org.springframework</groupId>
        <artifactId>spring-jdbc</artifactId>
        <version>${spring.version}</version>
    </dependency>
    <dependency>
        <groupId>org.springframework</groupId>
        <artifactId>spring-aspects</artifactId>
        <version>${spring.version}</version>
    </dependency>
    <dependency>
        <groupId>org.springframework</groupId>
        <artifactId>spring-test</artifactId>
        <version>${spring.version}</version>
    </dependency>
    <!-- Mybatis核心 -->
    <dependency>
        <groupId>org.mybatis</groupId>
        <artifactId>mybatis</artifactId>
        <version>3.5.7</version>
    </dependency>
    <!--mybatis和spring的整合包-->
    <dependency>
        <groupId>org.mybatis</groupId>
        <artifactId>mybatis-spring</artifactId>
        <version>2.0.6</version>
    </dependency>
    <!-- 连接池 -->
    <dependency>
        <groupId>com.alibaba</groupId>
        <artifactId>druid</artifactId>
        <version>1.0.9</version>
    </dependency>
    <!-- junit测试 -->
    <dependency>
        <groupId>junit</groupId>
        <artifactId>junit</artifactId>
        <version>4.12</version>
        <scope>test</scope>
    </dependency>
    <!-- MySQL驱动 -->
    <dependency>
        <groupId>mysql</groupId>
        <artifactId>mysql-connector-java</artifactId>
        <version>8.0.16</version>
    </dependency>
    <!-- log4j日志 -->
    <dependency>
        <groupId>log4j</groupId>
        <artifactId>log4j</artifactId>
        <version>1.2.17</version>
    </dependency>
    <!-- https://mvnrepository.com/artifact/com.github.pagehelper/pagehelper -->
    <dependency>
    <groupId>com.github.pagehelper</groupId>
    <artifactId>pagehelper</artifactId>
    <version>5.2.0</version>
    </dependency>
    <!-- 日志 -->
    <dependency>
        <groupId>ch.qos.logback</groupId>
        <artifactId>logback-classic</artifactId>
        <version>1.2.3</version>
    </dependency>
    <!-- ServletAPI -->
    <dependency>
        <groupId>javax.servlet</groupId>
        <artifactId>javax.servlet-api</artifactId>
        <version>3.1.0</version>
        <scope>provided</scope>
    </dependency>
    <dependency>
        <groupId>com.fasterxml.jackson.core</groupId>
        <artifactId>jackson-databind</artifactId>
        <version>2.12.1</version>
    </dependency>
    <dependency>
        <groupId>commons-fileupload</groupId>
        <artifactId>commons-fileupload</artifactId>
        <version>1.3.1</version>
    </dependency>
    <!-- Spring5和Thymeleaf整合包 -->
    <dependency>
        <groupId>org.thymeleaf</groupId>
        <artifactId>thymeleaf-spring5</artifactId>
        <version>3.0.12.RELEASE</version>
    </dependency>
</dependencies>

③创建表

CREATE TABLE `t_emp` (
    `emp_id` int(11) NOT NULL AUTO_INCREMENT,
    `emp_name` varchar(20) DEFAULT NULL,
    `age` int(11) DEFAULT NULL,
    `sex` char(1) DEFAULT NULL,
    `email` varchar(50) DEFAULT NULL,
    PRIMARY KEY (`emp_id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8

4.3、配置web.xml

<!-- 配置Spring的编码过滤器 -->
<filter>
    <filter-name>CharacterEncodingFilter</filter-name>
    <filter-class>org.springframework.web.filter.CharacterEncodingFilter</filter-class>
    <init-param>
        <param-name>encoding</param-name>
        <param-value>UTF-8</param-value>
    </init-param>
    <init-param>
        <param-name>forceEncoding</param-name>
        <param-value>true</param-value>
    </init-param>
</filter>
<filter-mapping>
    <filter-name>CharacterEncodingFilter</filter-name>
    <url-pattern>/*</url-pattern>
</filter-mapping>
<!-- 配置处理请求方式PUT和DELETE的过滤器 -->
<filter>
    <filter-name>HiddenHttpMethodFilter</filter-name>
    <filter-class>org.springframework.web.filter.HiddenHttpMethodFilter</filter-class>
</filter>
<filter-mapping>
    <filter-name>HiddenHttpMethodFilter</filter-name>
    <url-pattern>/*</url-pattern>
</filter-mapping>
<!-- 配置SpringMVC的前端控制器 -->
<servlet>
    <servlet-name>DispatcherServlet</servlet-name>
    <servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
    <!-- 设置SpringMVC的配置文件的位置和名称 -->
    <init-param>
        <param-name>contextConfigLocation</param-name>
        <param-value>classpath:SpringMVC.xml</param-value>
    </init-param>
    <load-on-startup>1</load-on-startup>
</servlet>
<servlet-mapping>
    <servlet-name>DispatcherServlet</servlet-name>
    <url-pattern>/</url-pattern>
</servlet-mapping>
<!-- 设置Spring的配置文件的位置和名称 -->
<context-param>
    <param-name>contextConfigLocation</param-name>
    <param-value>classpath:Spring.xml</param-value>
</context-param>
<!-- 配置Spring的监听器 -->
<listener>
    <listener-class>org.springframework.web.context.ContextLoaderListener</listener-class>
</listener>

4.4、创建SpringMVC的配置文件并配置

<!--扫描组件-->
<context:component-scan base-package="com.atguigu.ssm.controller">
</context:component-scan>
<!--配置视图解析器-->
<bean id="viewResolver"
      class="org.thymeleaf.spring5.view.ThymeleafViewResolver">
    <property name="order" value="1"/>
    <property name="characterEncoding" value="UTF-8"/>
    <property name="templateEngine">
        <bean class="org.thymeleaf.spring5.SpringTemplateEngine">
            <property name="templateResolver">
                <bean
                      class="org.thymeleaf.spring5.templateresolver.SpringResourceTemplateResolver">
                    <!-- 视图前缀 -->
                    <property name="prefix" value="/WEB-INF/templates/"/>
                    <!-- 视图后缀 -->
                    <property name="suffix" value=".html"/>
                    <property name="templateMode" value="HTML5"/>
                    <property name="characterEncoding" value="UTF-8" />
                </bean>
            </property>
        </bean>
    </property>
</bean>
<!-- 配置访问首页的视图控制 -->
<mvc:view-controller path="/" view-name="index"></mvc:view-controller>
<!-- 配置默认的servlet处理静态资源 -->
<mvc:default-servlet-handler />
<!-- 开启MVC的注解驱动 -->
<mvc:annotation-driven />

4.5、搭建MyBatis环境

4.5、搭建MyBatis环境

①创建属性文件jdbc.properties

jdbc.username=root
jdbc.password=789632145
jdbc.url=jdbc:mysql://localhost:3306/ssm?serverTimezone=UTC
jdbc.driver=com.mysql.cj.jdbc.Driver

②创建MyBatis的核心配置文件mybatis-config.xml

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE configuration
PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
"http://mybatis.org/dtd/mybatis-3-config.dtd">
<configuration>
    <settings>
        <!--将下划线映射为驼峰-->
        <setting name="mapUnderscoreToCamelCase" value="true"/>
    </settings>
    <plugins>
        <!--配置分页插件-->
        <plugin interceptor="com.github.pagehelper.PageInterceptor"></plugin>
    </plugins>
</configuration>

③创建Mapper接口和映射文件

注意:映射文件的路径用/别用.

public interface EmployeeMapper {
List<Employee> getEmployeeList();
}
<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE mapper
PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
"http://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="com.atguigu.ssm.mapper.EmployeeMapper">
    <select id="getEmployeeList" resultType="Employee">
        select * from t_emp
    </select>
</mapper>

④创建日志文件log4j.xml

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE log4j:configuration SYSTEM "log4j.dtd">
<log4j:configuration xmlns:log4j="http://jakarta.apache.org/log4j/">
    <appender name="STDOUT" class="org.apache.log4j.ConsoleAppender">
        <param name="Encoding" value="UTF-8" />
        <layout class="org.apache.log4j.PatternLayout">
            <param name="ConversionPattern" value="%-5p %d{MM-dd HH:mm:ss,SSS} %m (%F:%L) \n" />
        </layout>
    </appender>
    <logger name="java.sql">
        <level value="debug" />
    </logger>
    <logger name="org.apache.ibatis">
        <level value="info" />
    </logger>
    <root>
        <level value="debug" />
        <appender-ref ref="STDOUT" />
    </root>
</log4j:configuration>

4.6、创建Spring的配置文件并配置

ioc管理的是sqlsessionfactoryBean 这个是sqlsessionFactory的实现类,当自动装配是接口的时候,能够匹配到当前类或者当前接口的实现类

数据源和事务管理在spring中配置了,就可以在mybatis中删去了

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
       xmlns:context="http://www.springframework.org/schema/context" xmlns:tx="http://www.springframework.org/schema/tx"
       xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd http://www.springframework.org/schema/context https://www.springframework.org/schema/context/spring-context.xsd http://www.springframework.org/schema/mvc https://www.springframework.org/schema/mvc/spring-mvc.xsd http://www.springframework.org/schema/tx http://www.springframework.org/schema/tx/spring-tx.xsd">
<!--扫描除控制层以外的组件-->
    <context:component-scan base-package="com.atguigu.ssm">
    <context:exclude-filter type="annotation" expression="org.springframework.stereotype.Controller"/>
</context:component-scan>
    <context:property-placeholder location="classpath:jdbc.properties"></context:property-placeholder>
    <!-- 配置Druid数据源 -->
    <bean id="dataSource" class="com.alibaba.druid.pool.DruidDataSource">
        <property name="driverClassName" value="${jdbc.driver}"></property>
        <property name="url" value="${jdbc.url}"></property>
        <property name="username" value="${jdbc.username}"></property>
        <property name="password" value="${jdbc.password}"></property>
    </bean>
    <!-- 配置用于创建SqlSessionFactory的工厂bean ,提供的对象就是SqlSessionFactory,和普通工厂的区别:
    普通工厂:先获取ioc,再获取工厂的bean,再通过工厂获得工厂所提供的对象,工厂bean就不用获取工厂了可以直接获取工厂所提供的对象-->
    <bean class="org.mybatis.spring.SqlSessionFactoryBean">
        <!-- 设置MyBatis配置文件的路径(可以不设置) -->
        <property name="configLocation" value="classpath:mybatis-config.xml">
        </property>
        <!-- 设置数据源 -->
        <property name="dataSource" ref="dataSource"></property>
        <!-- 设置类型别名所对应的包 -->
        <property name="typeAliasesPackage" value="com.atguigu.ssm.pojo">
        </property>
        <!--
            设置映射文件的路径
            若映射文件所在路径和mapper接口所在路径一致,则不需要设置
        -->
        <!--
            <property name="mapperLocations" value="classpath:mapper/*.xml">
            </property>
        -->
    </bean>
    <!--
       配置mapper接口的扫描配置
       由mybatis-spring提供,可以将指定包下所有的mapper接口创建动态代理
       并将这些动态代理作为IOC容器的bean管理
       省略了  SqlSession sqlSession = factory.openSession();
        BrandMapper mapper = sqlSession.getMapper(BrandMapper.class);
        这个过程
   -->
    <bean class="org.mybatis.spring.mapper.MapperScannerConfigurer">
        <property name="basePackage" value="com.atguigu.ssm.mapper"></property>
    </bean>
<!--开启事务的注解驱动
将使用注解@Transactional标识的方法或类中所有的方法进行事务管理
-->
    <tx:annotation-driven transaction-manager="transactionManager"></tx:annotation-driven>
<!--配置事务管理器-->
    <bean id="transactionManager" class="org.springframework.jdbc.datasource.DataSourceTransactionManager">
        <property name="dataSource" ref="dataSource">   </property>
    </bean>
</beans>

第二个如果使用的是sqlSessionFactoryBean的默认名字就不需要配置,只有像下面这样才需要配置

<bean id="sqlSessionFactory" class="org.mybatis.spring.SqlSessionFactoryBean">
        <property name="dataSource" ref="dataSource"/>
        <!-- configLocation的属性值为MyBatis的核心配置文件 -->
        <property name="configLocation" value="classpath:mybatis-config.xml"/>
    </bean>
    ```

正因为这里配置类sqlsessionfactory和接口的路径所以如果mapper配置文件和接口文件路径一样则不需要配置
## 4.7、测试功能
### ①创建组件
实体类Employee
```java
package com.atguigu.ssm.pojo;
/**
 * Date:2022/7/11
 * Author:ybc
 * Description:
 */
public class Employee {
    private Integer empId;
    private String empName;
    private Integer age;
    private String gender;
    private String email;
    public Employee() {
    }
    public Employee(Integer empId, String empName, Integer age, String gender, String email) {
        this.empId = empId;
        this.empName = empName;
        this.age = age;
        this.gender = gender;
        this.email = email;
    }
    public Integer getEmpId() {
        return empId;
    }
    public void setEmpId(Integer empId) {
        this.empId = empId;
    }
    public String getEmpName() {
        return empName;
    }
    public void setEmpName(String empName) {
        this.empName = empName;
    }
    public Integer getAge() {
        return age;
    }
    public void setAge(Integer age) {
        this.age = age;
    }
    public String getGender() {
        return gender;
    }
    public void setGender(String gender) {
        this.gender = gender;
    }
    public String getEmail() {
        return email;
    }
    public void setEmail(String email) {
        this.email = email;
    }
    @Override
    public String toString() {
        return "Employee{" +
                "empId=" + empId +
                ", empName='" + empName + '\'' +
                ", age=" + age +
                ", gender='" + gender + '\'' +
                ", email='" + email + '\'' +
                '}';
    }
}

创建控制层组件EmployeeController

@Controller
public class EmployeeController {
    @Autowired
    private EmployeeService employeeService;
    @RequestMapping(value = "/employee/page/{pageNum}", method = RequestMethod.GET)
    public String getEmployeeList(Model model, @PathVariable("pageNum") Integer pageNum){
        PageInfo<Employee> page = employeeService.getEmployeeList(pageNum);
        model.addAttribute("page", page);
        return "employee_list";
    }
}

创建接口EmployeeService

public interface EmployeeService {
  PageInfo<Employee> getEmployeeList(Integer pageNum);
}

创建实现类EmployeeServiceImpl

@Service
public class EmployeeServiceImpl implements EmployeeService {
    @Autowired
    private EmployeeMapper employeeMapper;
    @Override
    public PageInfo<Employee> getEmployeeList(Integer pageNum) {
        PageHelper.startPage(pageNum, 4);
        List<Employee> list = employeeMapper.getEmployeeList();
        PageInfo<Employee> page = new PageInfo<>(list, 5);
        return page;
    }
}

②创建页面

<!DOCTYPE html>
    <html lang="en" xmlns:th="http://www.thymeleaf.org">
<head>
    <meta charset="UTF-8">
    <title>员工列表</title>
    <link rel="stylesheet" th:href="@{/static/css/index_work.css}">
</head>
<body>
<table>
    <tr>
        <th colspan="6">员工列表</th>
    </tr>
    <tr>
        <th>流水号</th>
        <th>员工姓名</th>
        <th>年龄</th>
        <th>性别</th>
        <th>邮箱</th>
        <th>操作</th>
    </tr>
    <tr th:each="employee,status : ${page.list}">
<!--        status.count获取循环的次数 -->
        <td th:text="${status.count}"></td>
        <td th:text="${employee.empName}"></td>
        <td th:text="${employee.age}"></td>
        <td th:text="${employee.gender}"></td>
        <td th:text="${employee.email}"></td>
        <td>
            <a href="">删除</a>
            <a href="">修改</a>
        </td>
    </tr>
</table>
<div style="text-align: center;">
    <a th:if="${page.hasPreviousPage}" th:href="@{/employee/page/1}">首页</a>
    <a th:if="${page.hasPreviousPage}" th:href="@{'/employee/page/'+${page.prePage}}">上一页</a>
    <span th:each="num : ${page.navigatepageNums}">
        <a th:if="${page.pageNum == num}" style="color: red;" th:href="@{'/employee/page/'+${num}}" th:text="'['+${num}+']'"></a>
        <a th:if="${page.pageNum != num}" th:href="@{'/employee/page/'+${num}}" th:text="${num}"></a>
    </span>
    <a th:if="${page.hasNextPage}" th:href="@{'/employee/page/'+${page.nextPage}}">下一页</a>
    <a th:if="${page.hasNextPage}" th:href="@{'/employee/page/'+${page.pages}}">末页</a>
</div>
</body>
</html>

③访问测试分页功能

localhost:8080/employee/page/1

相关实践学习
如何在云端创建MySQL数据库
开始实验后,系统会自动创建一台自建MySQL的 源数据库 ECS 实例和一台 目标数据库 RDS。
全面了解阿里云能为你做什么
阿里云在全球各地部署高效节能的绿色数据中心,利用清洁计算为万物互联的新世界提供源源不断的能源动力,目前开服的区域包括中国(华北、华东、华南、香港)、新加坡、美国(美东、美西)、欧洲、中东、澳大利亚、日本。目前阿里云的产品涵盖弹性计算、数据库、存储与CDN、分析与搜索、云通信、网络、管理与监控、应用服务、互联网中间件、移动服务、视频服务等。通过本课程,来了解阿里云能够为你的业务带来哪些帮助 &nbsp; &nbsp; 相关的阿里云产品:云服务器ECS 云服务器 ECS(Elastic Compute Service)是一种弹性可伸缩的计算服务,助您降低 IT 成本,提升运维效率,使您更专注于核心业务创新。产品详情: https://www.aliyun.com/product/ecs
相关文章
|
6月前
|
前端开发 Java 应用服务中间件
SSM相关
SSM相关
|
前端开发 Java 数据库连接
SSM整合~
SSM整合~
|
1月前
|
JSON 前端开发 Java
SSM:SpringMVC
本文介绍了SpringMVC的依赖配置、请求参数处理、注解开发、JSON处理、拦截器、文件上传下载以及相关注意事项。首先,需要在`pom.xml`中添加必要的依赖,包括Servlet、JSTL、Spring Web MVC等。接着,在`web.xml`中配置DispatcherServlet,并设置Spring MVC的相关配置,如组件扫描、默认Servlet处理器等。然后,通过`@RequestMapping`等注解处理请求参数,使用`@ResponseBody`返回JSON数据。此外,还介绍了如何创建和配置拦截器、文件上传下载的功能,并强调了JSP文件的放置位置,避免404错误。
|
5月前
|
前端开发 JavaScript Java
SSM
【6月更文挑战第6天】
28 1
|
6月前
|
XML Java 关系型数据库
springboot整合ssm详细讲解
springboot整合ssm详细讲解
171 1
|
6月前
|
Java 数据库连接 Spring
SSM整合
SSM整合
|
XML 存储 JSON
SSM 之 SpringMVC(下)
SSM 之 SpringMVC(下)
67 0
SSM 之 SpringMVC(下)
|
JSON 前端开发 JavaScript
SSM 之 SpringMVC(上)
SSM 之 SpringMVC(上)
71 0
|
Java 数据库连接 Spring
SSM整合(超详细)
新建一个excepition包包下创建所需各个异常类记得继承相应的异常父类,原因:程序运行时遇到相应异常后可以不处理向上抛不继承坏处:以后每个方法都要加上这个类//继承RuntimeException类 public class TestExcepition extends RuntimeException {//区别自定义异常类的编码 public TestExcepition(Integer code) {} }
134 1
SSM整合(超详细)
|
数据安全/隐私保护
基于SSM的教学质量系统
本系统为2020年4月做的项目,基于SSM整合开发。主要包括系部教学工作质量评价、日常教学质量检查、教学检查评价结果分析、学生评教,教师教学信息等,主要分为四个角色。
基于SSM的教学质量系统
