基于若依的ruoyi-nbcio流程管理系统增加读取节点扩展属性的方法

/**
     * 完成任务
     *
     * @param taskBo 请求实体参数
     */
    @Transactional(rollbackFor = Exception.class)
    @Override
    public void complete(WfTaskBo taskBo) {
        Task task = taskService.createTaskQuery().taskId(taskBo.getTaskId()).singleResult();
        if (Objects.isNull(task)) {
            throw new ServiceException("任务不存在");
        }
        //获取流程当前节点设置的扩展属性值,需要的时候可以使用
        //Map<String, Object> flowProperties = getFlowProperties(taskBo.getProcInsId());

@Override
  public Map<String, Object> getFlowProperties(String procInsId) {
    try {
            Task task = taskService.createTaskQuery().processInstanceId(procInsId).active().singleResult();
            ProcessDefinition processDefinition = repositoryService.createProcessDefinitionQuery().processDefinitionId(task.getProcessDefinitionId()).singleResult();
            BpmnModel bpmnModel = repositoryService.getBpmnModel(processDefinition.getId());
            List<FlowViewerDto> flowViewerList = (List<FlowViewerDto>) getFlowViewer(task.getProcessInstanceId()).getData();
            FlowViewerDto dto = flowViewerList.stream().filter(flowViewerDto -> !flowViewerDto.isCompleted()).findFirst().orElse(null);
            String actId;
            if (ObjectUtils.isNotEmpty(dto)) {
                actId = dto.getKey();
            } else {
                return null;
            }
            FlowElement element = bpmnModel.getFlowElement(actId);
            List<ExtensionElement> extensionElements = element
                    .getExtensionElements().get("properties");
            List<ExtensionElement> child = null;
            for (ExtensionElement extensionElement : extensionElements) {
                child = extensionElement.getChildElements().get("property");
            }
            List<Map<String, List<ExtensionAttribute>>> list = new ArrayList<>();
            child.stream().forEach(o -> {
                Map<String, List<ExtensionAttribute>> attributeMap = o.getAttributes();
                list.add(attributeMap);
            });
            Map<String, Object> result = new HashMap();
            list.stream().forEach(a -> {
                result.put(a.get("name").get(0).getValue(), a.get("value").get(0).getValue());
            });
            return result;
        } catch (NullPointerException nullExcption) {
            return null;
        }
  }
    /**
     * 获取流程执行过程
     *
     * @param procInsId
     * @return
     */
    @Override
    public R getFlowViewer(String procInsId) {
        List<FlowViewerDto> flowViewerList = new ArrayList<>();
        FlowViewerDto flowViewerDto;
        // 获得活动的节点
        List<HistoricActivityInstance> hisActIns = historyService.createHistoricActivityInstanceQuery()
                .processInstanceId(procInsId)
                .orderByHistoricActivityInstanceStartTime()
                .asc().list();
        for (HistoricActivityInstance activityInstance : hisActIns) {
            if (!"sequenceFlow".equals(activityInstance.getActivityType())) {
                flowViewerDto = new FlowViewerDto();
                flowViewerDto.setKey(activityInstance.getActivityId());
                flowViewerDto.setCompleted(!Objects.isNull(activityInstance.getEndTime()));
                flowViewerList.add(flowViewerDto);
            }
        }
        return R.ok(flowViewerList);
    }

/**
 */
@Data
public class FlowViewerDto implements Serializable {
    private String key;
    private boolean completed;
}
