1. 前言

本文面向读者：有java基础并对zk源码实现感兴趣的同学。

用过zookeeper的同学都知道watch是一个非常好用的机制，今天我们就来看看它的实现原理。

在正文开始前，我们先来简单回忆一下watch是什么？

zk提供了分布式数据的发布/订阅功能——即典型的发布订阅模型，其定义了一种一对多的订阅关系，能够让多个订阅者同时监听某个主题对象，当这个主题对象自身状态变化时，则会通知所有订阅者。具体来说，则是zk允许一个客户端向服务端注册一个watch监听，当服务端的一些指定事件触发了这个watch，那么就会向该客户端发送事件通知。

2. 实现剖析

在剖析其实现前，我们不妨来想一想，如果自己动手实现一个watch机制，该怎么做呢？

最简单的方法是在client保存当前节点的版本，并去轮询这个节点的状态。如果发现版本变化，则client触发watch。不过比起轮询，不是有更多的好方法，不是吗？

轮询会给服务器带来不小的压力，或许我们可以考虑采用类似webhook的方式，让server保存和client约定好的地址，当watch的数据节点发生变化时，便通知client。

想到这儿，其实已经和zk自己的watch实现有点像了。沿着这个思路，我们开始剖析：

一般我们在使用client时，getData、getChildren、exist都可以用来向zk注册watcher。其原理都是一样的，我们以exist方法为例子进行剖析——即当关注的节点被创建or删除时，client会收到通知。

2.1 客户端的实现

先从客户端部分开始解析——即以我们调用的原生API为入口。

2.1.1 Zookeeper.exists

    /**
     * The asynchronous version of exists.
     *
     * @see #exists(String, Watcher)
     */
    public void exists(final String path, Watcher watcher,
            StatCallback cb, Object ctx)
    {


        final String clientPath = path;
        PathUtils.validatePath(clientPath);

        // the watch contains the un-chroot path
        WatchRegistration wcb = null;  //1.
        if (watcher != null) {


            wcb = new ExistsWatchRegistration(watcher, clientPath);
        }

        final String serverPath = prependChroot(clientPath);

        RequestHeader h = new RequestHeader();
        h.setType(ZooDefs.OpCode.exists);
        ExistsRequest request = new ExistsRequest();
        request.setPath(serverPath);
        request.setWatch(watcher != null);//3.
        SetDataResponse response = new SetDataResponse();
        cnxn.queuePacket(h, new ReplyHeader(), request, response, cb,
                clientPath, serverPath, ctx, wcb); //2.
    }

和watch相关的地方有两处，一个是其被转换成WatchRegistration中的一个属性（见注释标记1），最后变成一个Packet——即client与server的最小通信单元（见注释标记2）。

另外一处则是request.setWatch(watcher != null)，是个布尔变量。（见注释标记3）

2.1.2 ClientCnxn.queuePacket

在上文中的最后一段代码是 cnxn.queuePacket(h, new ReplyHeader(), request, response, cb,clientPath, serverPath, ctx, wcb);，我们继续看下去。

   public Packet queuePacket(RequestHeader h, ReplyHeader r, Record request,
            Record response, AsyncCallback cb, String clientPath,
            String serverPath, Object ctx, WatchRegistration watchRegistration) {


        return queuePacket(h, r, request, response, cb, clientPath, serverPath,
                ctx, watchRegistration, null);
    }

    public Packet queuePacket(RequestHeader h, ReplyHeader r, Record request,
            Record response, AsyncCallback cb, String clientPath,
            String serverPath, Object ctx, WatchRegistration watchRegistration,
            WatchDeregistration watchDeregistration) {


        Packet packet = null;

        // Note that we do not generate the Xid for the packet yet. It is
        // generated later at send-time, by an implementation of ClientCnxnSocket::doIO(),
        // where the packet is actually sent.
        packet = new Packet(h, r, request, response, watchRegistration);
        packet.cb = cb;
        packet.ctx = ctx;
        packet.clientPath = clientPath;
        packet.serverPath = serverPath;
        packet.watchDeregistration = watchDeregistration;
        // The synchronized block here is for two purpose:
        // 1. synchronize with the final cleanup() in SendThread.run() to avoid race
        // 2. synchronized against each packet. So if a closeSession packet is added,
        // later packet will be notified.
        synchronized (state) {


            if (!state.isAlive() || closing) {


                conLossPacket(packet);
            } else {


                // If the client is asking to close the session then
                // mark as closing
                if (h.getType() == OpCode.closeSession) {


                    closing = true;
                }
                outgoingQueue.add(packet);
            }
        }
        sendThread.getClientCnxnSocket().packetAdded();
        return packet;
    }

这段代码看起来很多，不过仅仅在做一件事——即拼装Packet，并将其加入发送队列。该队列由ClientCnxn中的一个SendThread消费（见SendThread.run）。该方法有较多的条件分支，且不够clean code，故在此不再贴代码，避免扰乱视听。

从下面的代码可以得知，在Zk的client中，会维护发送队列和等待回复的队列，里面都是一个个Packet。

    /**
     * These are the packets that have been sent and are waiting for a response.
     */
    private final LinkedList<Packet> pendingQueue = new LinkedList<Packet>();

    /**
     * These are the packets that need to be sent.
     */
    private final LinkedBlockingDeque<Packet> outgoingQueue = new LinkedBlockingDeque<Packet>();

接下来，我们查看SendThread.readReponse，即消费client队列中Packet的逻辑：

        void readResponse(ByteBuffer incomingBuffer) throws IOException {


            ByteBufferInputStream bbis = new ByteBufferInputStream(
                    incomingBuffer);
            BinaryInputArchive bbia = BinaryInputArchive.getArchive(bbis);
            ReplyHeader replyHdr = new ReplyHeader();

            replyHdr.deserialize(bbia, "header");
            if (replyHdr.getXid() == -2) {


                // -2 is the xid for pings
                if (LOG.isDebugEnabled()) {


                    LOG.debug("Got ping response for sessionid: 0x"
                            + Long.toHexString(sessionId)
                            + " after "
                            + ((System.nanoTime() - lastPingSentNs) / 1000000)
                            + "ms");
                }
                return;
            }
            if (replyHdr.getXid() == -4) {


                // -4 is the xid for AuthPacket
                if(replyHdr.getErr() == KeeperException.Code.AUTHFAILED.intValue()) {


                    state = States.AUTH_FAILED;
                    eventThread.queueEvent( new WatchedEvent(Watcher.Event.EventType.None,
                            Watcher.Event.KeeperState.AuthFailed, null) );
                    eventThread.queueEventOfDeath();
                }
                if (LOG.isDebugEnabled()) {


                    LOG.debug("Got auth sessionid:0x"
                            + Long.toHexString(sessionId));
                }
                return;
            }
            if (replyHdr.getXid() == -1) {


                // -1 means notification
                if (LOG.isDebugEnabled()) {


                    LOG.debug("Got notification sessionid:0x"
                        + Long.toHexString(sessionId));
                }
                WatcherEvent event = new WatcherEvent();
                event.deserialize(bbia, "response");

                // convert from a server path to a client path
                if (chrootPath != null) {


                    String serverPath = event.getPath();
                    if(serverPath.compareTo(chrootPath)==0)
                        event.setPath("/");
                    else if (serverPath.length() > chrootPath.length())
                        event.setPath(serverPath.substring(chrootPath.length()));
                    else {


                        LOG.warn("Got server path " + event.getPath()
                                + " which is too short for chroot path "
                                + chrootPath);
                    }
                }

                WatchedEvent we = new WatchedEvent(event);
                if (LOG.isDebugEnabled()) {


                    LOG.debug("Got " + we + " for sessionid 0x"
                            + Long.toHexString(sessionId));
                }

                eventThread.queueEvent( we );
                return;
            }

            // If SASL authentication is currently in progress, construct and
            // send a response packet immediately, rather than queuing a
            // response as with other packets.
            if (tunnelAuthInProgress()) {


                GetSASLRequest request = new GetSASLRequest();
                request.deserialize(bbia,"token");
                zooKeeperSaslClient.respondToServer(request.getToken(),
                  ClientCnxn.this);
                return;
            }

            Packet packet;
            synchronized (pendingQueue) {


                if (pendingQueue.size() == 0) {


                    throw new IOException("Nothing in the queue, but got "
                            + replyHdr.getXid());
                }
                packet = pendingQueue.remove();
            }
            /*
             * Since requests are processed in order, we better get a response
             * to the first request!
             */
            try {


                if (packet.requestHeader.getXid() != replyHdr.getXid()) {


                    packet.replyHeader.setErr(
                            KeeperException.Code.CONNECTIONLOSS.intValue());
                    throw new IOException("Xid out of order. Got Xid "
                            + replyHdr.getXid() + " with err " +
                            + replyHdr.getErr() +
                            " expected Xid "
                            + packet.requestHeader.getXid()
                            + " for a packet with details: "
                            + packet );
                }

                packet.replyHeader.setXid(replyHdr.getXid());
                packet.replyHeader.setErr(replyHdr.getErr());
                packet.replyHeader.setZxid(replyHdr.getZxid());
                if (replyHdr.getZxid() > 0) {


                    lastZxid = replyHdr.getZxid();
                }
                if (packet.response != null && replyHdr.getErr() == 0) {


                    packet.response.deserialize(bbia, "response");
                }

                if (LOG.isDebugEnabled()) {


                    LOG.debug("Reading reply sessionid:0x"
                            + Long.toHexString(sessionId) + ", packet:: " + packet);
                }
            } finally {


                finishPacket(packet);
            }
        }

synchronized (pendingQueue)中，我们可以看到从队列中拿出了Packet，并最后将其丢入了finishPacket。

    protected void finishPacket(Packet p) {


        int err = p.replyHeader.getErr();
        if (p.watchRegistration != null) {


            p.watchRegistration.register(err);
        }
        // Add all the removed watch events to the event queue, so that the
        // clients will be notified with 'Data/Child WatchRemoved' event type.
        if (p.watchDeregistration != null) {


            Map<EventType, Set<Watcher>> materializedWatchers = null;
            try {


                materializedWatchers = p.watchDeregistration.unregister(err);
                for (Entry<EventType, Set<Watcher>> entry : materializedWatchers
                        .entrySet()) {


                    Set<Watcher> watchers = entry.getValue();
                    if (watchers.size() > 0) {


                        queueEvent(p.watchDeregistration.getClientPath(), err,
                                watchers, entry.getKey());
                        // ignore connectionloss when removing from local
                        // session
                        p.replyHeader.setErr(Code.OK.intValue());
                    }
                }
            } catch (KeeperException.NoWatcherException nwe) {


                p.replyHeader.setErr(nwe.code().intValue());
            } catch (KeeperException ke) {


                p.replyHeader.setErr(ke.code().intValue());
            }
        }

        if (p.cb == null) {


            synchronized (p) {


                p.finished = true;
                p.notifyAll();
            }
        } else {


            p.finished = true;
            eventThread.queuePacket(p);
        }
    }

这段方法中，我们会分析这两段逻辑：

• p.watchRegistration.register
• queueEvent

2.1.3 watchRegistration

需要注意的是，WatchRegistration在Packet发送前并不会被序列化发送过去，避免发送不必要的信息，毕竟已经在request中标记为watch了。那么这个WatchRegistration有什么用呢？还好register的逻辑很简单，我们来看一下：

        /**
         * Register the watcher with the set of watches on path.
         * @param rc the result code of the operation that attempted to
         * add the watch on the path.
         */
        public void register(int rc) {


            if (shouldAddWatch(rc)) {


                Map<String, Set<Watcher>> watches = getWatches(rc);
                synchronized(watches) {


                    Set<Watcher> watchers = watches.get(clientPath);
                    if (watchers == null) {


                        watchers = new HashSet<Watcher>();
                        watches.put(clientPath, watchers);
                    }
                    watchers.add(watcher);
                }
            }
        }

2.1.4 queueEvent

代码比较少，可以看到client维护了一个path-watchers的字典，到这里，相信大多数读者都能猜到实现了——即收到回复时根据相应的path去找对应wacher。接下来来看queueEvent：

    void queueEvent(String clientPath, int err,
            Set<Watcher> materializedWatchers, EventType eventType) {


        KeeperState sessionState = KeeperState.SyncConnected;
        if (KeeperException.Code.SESSIONEXPIRED.intValue() == err
                || KeeperException.Code.CONNECTIONLOSS.intValue() == err) {


            sessionState = Event.KeeperState.Disconnected;
        }
        WatchedEvent event = new WatchedEvent(eventType, sessionState,
                clientPath);
        eventThread.queueEvent(event, materializedWatchers);
    }

逻辑很简单，判断状态，然后组装event，交给eventThread去做通知。

        private void queueEvent(WatchedEvent event,
                Set<Watcher> materializedWatchers) {


            if (event.getType() == EventType.None
                    && sessionState == event.getState()) {


                return;
            }
            sessionState = event.getState();
            final Set<Watcher> watchers;
            if (materializedWatchers == null) {


                // materialize the watchers based on the event
                watchers = watcher.materialize(event.getState(),
                        event.getType(), event.getPath());
            } else {


                watchers = new HashSet<Watcher>();
                watchers.addAll(materializedWatchers);
            }
            WatcherSetEventPair pair = new WatcherSetEventPair(watchers, event);
            // queue the pair (watch set & event) for later processing
            waitingEvents.add(pair);
        }

ClientWatchManager.materialize不再展示源码，我们只要知道，在这段逻辑中
，当watch被触发后，即会被移除，而状态正是保存在ZkWatchManager里：

   static class ZKWatchManager implements ClientWatchManager {


        private final Map<String, Set<Watcher>> dataWatches =
            new HashMap<String, Set<Watcher>>();
        private final Map<String, Set<Watcher>> existWatches =
            new HashMap<String, Set<Watcher>>();
        private final Map<String, Set<Watcher>> childWatches =
            new HashMap<String, Set<Watcher>>();
//......
}

再说回来eventThread.run最后做的事情——即入队。那么我们来看看这个线程的核心方法：

@Override
@SuppressFBWarnings("JLM_JSR166_UTILCONCURRENT_MONITORENTER")
        public void run() {


           try {


              isRunning = true;
              while (true) {


                 Object event = waitingEvents.take();
                 if (event == eventOfDeath) {


                    wasKilled = true;
                 } else {


                    processEvent(event);
                 }
                 if (wasKilled)
                    synchronized (waitingEvents) {


                       if (waitingEvents.isEmpty()) {


                          isRunning = false;
                          break;
                       }
                    }
              }
           } catch (InterruptedException e) {


              LOG.error("Event thread exiting due to interruption", e);
           }

            LOG.info("EventThread shut down for session: 0x{}",
                     Long.toHexString(getSessionId()));
        }

又是熟悉的配方熟悉的味道——就是一个死循环去消费队列里的元素，然后我们来看看processEvent：

       private void processEvent(Object event) {


          try {


              if (event instanceof WatcherSetEventPair) {


                  // each watcher will process the event
                  WatcherSetEventPair pair = (WatcherSetEventPair) event;
                  for (Watcher watcher : pair.watchers) {


                      try {


                          watcher.process(pair.event);
                      } catch (Throwable t) {


                          LOG.error("Error while calling watcher ", t);
                      }
                  }
                } else if (event instanceof LocalCallback) {


                    //在本文中这些逻辑不重要，skip
                  }

当process被调用后，我们自己编写的逻辑就会被触发。

看完客户端部分的代码，大家不妨可以思考思考，将一个上层的机制（watch）与底层的通信代码（如finishPacket）显示的写在一起真的好吗？如果让你来写，你会怎么做呢？

2.2 服务端实现

在上文，我们了解了client的watch相关实现，接下来，我们就来捋一捋服务端的watch实现。

我们直接到ZkServer handle request的地方——FinalRequestProcessor的processRequest中的相关部分：

            case OpCode.exists: {


                lastOp = "EXIS";
                // TODO we need to figure out the security requirement for this!
                ExistsRequest existsRequest = new ExistsRequest();
                ByteBufferInputStream.byteBuffer2Record(request.request,
                        existsRequest);
                String path = existsRequest.getPath();
                if (path.indexOf('\0') != -1) {


                    throw new KeeperException.BadArgumentsException();
                }
                Stat stat = zks.getZKDatabase().statNode(path, existsRequest
                        .getWatch() ? cnxn : null);
                rsp = new ExistsResponse(stat);
                break;
            }

可以看到，如果request是要求watch的，那么会将ServerCnxn传递下去，ServerCnxn代表了客户端和服务器之间的连接。这样当数据事件发生时，可以通过连接触发client的watch。

跳转DataTree.statNode：

    public Stat statNode(String path, Watcher watcher)
            throws KeeperException.NoNodeException {


        Stat stat = new Stat();
        DataNode n = nodes.get(path);
        if (watcher != null) {


            dataWatches.addWatch(path, watcher);
        }
        if (n == null) {


            throw new KeeperException.NoNodeException();
        }
        synchronized (n) {


            n.copyStat(stat);
            return stat;
        }
    }

当watcher != null时，则会添加一个watcher当服务端的dataWatches中。接下来，我们来看一下服务端的watch核心类——WatchManager:

/**
 * This class manages watches. It allows watches to be associated with a string
 * and removes watchers and their watches in addition to managing triggers.
 */
class WatchManager {


    private static final Logger LOG = LoggerFactory.getLogger(WatchManager.class);

    private final HashMap<String, HashSet<Watcher>> watchTable =
        new HashMap<String, HashSet<Watcher>>();

    private final HashMap<Watcher, HashSet<String>> watch2Paths =
        new HashMap<Watcher, HashSet<String>>();

    synchronized int size(){


        int result = 0;
        for(Set<Watcher> watches : watchTable.values()) {


            result += watches.size();
        }
        return result;
    }

    synchronized void addWatch(String path, Watcher watcher) {


        HashSet<Watcher> list = watchTable.get(path);
        if (list == null) {


            // don't waste memory if there are few watches on a node
            // rehash when the 4th entry is added, doubling size thereafter
            // seems like a good compromise
            list = new HashSet<Watcher>(4);
            watchTable.put(path, list);
        }
        list.add(watcher);

        HashSet<String> paths = watch2Paths.get(watcher);
        if (paths == null) {


            // cnxns typically have many watches, so use default cap here
            paths = new HashSet<String>();
            watch2Paths.put(watcher, paths);
        }
        paths.add(path);
    }

    synchronized void removeWatcher(Watcher watcher) {


        HashSet<String> paths = watch2Paths.remove(watcher);
        if (paths == null) {


            return;
        }
        for (String p : paths) {


            HashSet<Watcher> list = watchTable.get(p);
            if (list != null) {


                list.remove(watcher);
                if (list.size() == 0) {


                    watchTable.remove(p);
                }
            }
        }
    }

    Set<Watcher> triggerWatch(String path, EventType type) {


        return triggerWatch(path, type, null);
    }

    Set<Watcher> triggerWatch(String path, EventType type, Set<Watcher> supress) {


        WatchedEvent e = new WatchedEvent(type,
                KeeperState.SyncConnected, path);
        HashSet<Watcher> watchers;
        synchronized (this) {


            watchers = watchTable.remove(path);
            if (watchers == null || watchers.isEmpty()) {


                if (LOG.isTraceEnabled()) {


                    ZooTrace.logTraceMessage(LOG,
                            ZooTrace.EVENT_DELIVERY_TRACE_MASK,
                            "No watchers for " + path);
                }
                return null;
            }
            for (Watcher w : watchers) {


                HashSet<String> paths = watch2Paths.get(w);
                if (paths != null) {


                    paths.remove(path);
                }
            }
        }
        for (Watcher w : watchers) {


            if (supress != null && supress.contains(w)) {


                continue;
            }
            w.process(e);
        }
        return watchers;
    }

    /**
     * Brief description of this object.
     */
    @Override
    public synchronized String toString() {


        StringBuilder sb = new StringBuilder();

        sb.append(watch2Paths.size()).append(" connections watching ")
            .append(watchTable.size()).append(" paths\n");

        int total = 0;
        for (HashSet<String> paths : watch2Paths.values()) {


            total += paths.size();
        }
        sb.append("Total watches:").append(total);

        return sb.toString();
    }

    /**
     * String representation of watches. Warning, may be large!
     * @param byPath iff true output watches by paths, otw output
     * watches by connection
     * @return string representation of watches
     */
    synchronized void dumpWatches(PrintWriter pwriter, boolean byPath) {


        if (byPath) {


            for (Entry<String, HashSet<Watcher>> e : watchTable.entrySet()) {


                pwriter.println(e.getKey());
                for (Watcher w : e.getValue()) {


                    pwriter.print("\t0x");
                    pwriter.print(Long.toHexString(((ServerCnxn)w).getSessionId()));
                    pwriter.print("\n");
                }
            }
        } else {


            for (Entry<Watcher, HashSet<String>> e : watch2Paths.entrySet()) {


                pwriter.print("0x");
                pwriter.println(Long.toHexString(((ServerCnxn)e.getKey()).getSessionId()));
                for (String path : e.getValue()) {


                    pwriter.print("\t");
                    pwriter.println(path);
                }
            }
        }
    }

    /**
     * Checks the specified watcher exists for the given path
     *
     * @param path
     *            znode path
     * @param watcher
     *            watcher object reference
     * @return true if the watcher exists, false otherwise
     */
    synchronized boolean containsWatcher(String path, Watcher watcher) {


        HashSet<String> paths = watch2Paths.get(watcher);
        if (paths == null || !paths.contains(path)) {


            return false;
        }
        return true;
    }

    /**
     * Removes the specified watcher for the given path
     *
     * @param path
     *            znode path
     * @param watcher
     *            watcher object reference
     * @return true if the watcher successfully removed, false otherwise
     */
    synchronized boolean removeWatcher(String path, Watcher watcher) {


        HashSet<String> paths = watch2Paths.get(watcher);
        if (paths == null || !paths.remove(path)) {


            return false;
        }

        HashSet<Watcher> list = watchTable.get(path);
        if (list == null || !list.remove(watcher)) {


            return false;
        }

        if (list.size() == 0) {


            watchTable.remove(path);
        }

        return true;
    }

    /**
     * Returns a watch report.
     *
     * @return watch report
     * @see WatchesReport
     */
    synchronized WatchesReport getWatches() {


        Map<Long, Set<String>> id2paths = new HashMap<Long, Set<String>>();
        for (Entry<Watcher, HashSet<String>> e: watch2Paths.entrySet()) {


            Long id = ((ServerCnxn) e.getKey()).getSessionId();
            HashSet<String> paths = new HashSet<String>(e.getValue());
            id2paths.put(id, paths);
        }
        return new WatchesReport(id2paths);
    }

    /**
     * Returns a watch report by path.
     *
     * @return watch report
     * @see WatchesPathReport
     */
    synchronized WatchesPathReport getWatchesByPath() {


        Map<String, Set<Long>> path2ids = new HashMap<String, Set<Long>>();
        for (Entry<String, HashSet<Watcher>> e : watchTable.entrySet()) {


            Set<Long> ids = new HashSet<Long>(e.getValue().size());
            path2ids.put(e.getKey(), ids);
            for (Watcher watcher : e.getValue()) {


                ids.add(((ServerCnxn) watcher).getSessionId());
            }
        }
        return new WatchesPathReport(path2ids);
    }

    /**
     * Returns a watch summary.
     *
     * @return watch summary
     * @see WatchesSummary
     */
    synchronized WatchesSummary getWatchesSummary() {


        int totalWatches = 0;
        for (HashSet<String> paths : watch2Paths.values()) {


            totalWatches += paths.size();
        }
        return new WatchesSummary (watch2Paths.size(), watchTable.size(),
                                   totalWatches);
    }
}

整个类非常好理解，先看两个核心成员变量：

• watchTable:path-watchs
• watch2Paths:watcher-paths

addWatch就是往两个map中添加数据，而触发便是根据path遍历出那些watcher，并从内存中删除它们，然后调用它们的process——这时ServerCnxn就会发送一个Packet到client。

那么什么时候触发呢？也很简单。就在DataTree的代码里，对相应数据进行操作时，就会触发watcher。我们以DataTree.setData为例：

    public Stat setData(String path, byte data[], int version, long zxid,
            long time) throws KeeperException.NoNodeException {


        Stat s = new Stat();
        DataNode n = nodes.get(path);
        if (n == null) {


            throw new KeeperException.NoNodeException();
        }
        byte lastdata[] = null;
        synchronized (n) {


            lastdata = n.data;
            n.data = data;
            n.stat.setMtime(time);
            n.stat.setMzxid(zxid);
            n.stat.setVersion(version);
            n.copyStat(s);
        }
        // now update if the path is in a quota subtree.
        String lastPrefix = getMaxPrefixWithQuota(path);
        if(lastPrefix != null) {


          this.updateBytes(lastPrefix, (data == null ? 0 : data.length)
              - (lastdata == null ? 0 : lastdata.length));
        }
        // 触发处
        dataWatches.triggerWatch(path, EventType.NodeDataChanged);
        return s;
    }

至此，我们就理清watch在Zk里到底是怎么一回事了。同时，我们也了解watcher的几个特性：

1. 一次性：无论是client还是server，一旦watcher被触发，zk都会将其移除。这意味着开发者需要反复注册，但是好处也很明显——降低了服务器压力，避免频繁更新的节点一直触发watcher。
2. 客户端串行执行：客户端回调是一个串行同步的过程，这使得回调是有序的。同样，开发者要注意不要因为一个watcher的逻辑影响整个client回调。
3. 轻量：client的request是否要watch其实仅仅通过一个boolean来决定，同样的，server的response的watch回调——WatchedEvent也仅仅只有三个属性：
   • 通知状态
   • 事件类型
   • 节点路径

这种轻量化的设计使得网络开销和服务端内存开销上都是很廉价的。

3. 小结

在本文中，我们一起了解了watch的实现机理。简单总结如下：

1. client在发送请求时候，会将watch的具体状态保存在client中，即存在于等待回复队列中
2. 标记watch的request到达服务端后，服务端会将这个watcher（包含client的连接属性）以字典的形式保存在内存中
3. 当watch的数据发生相应变化时，去字典里找出注册的watch，并拿到对应client连接
4. 根据连接，发送一个通知到client
5. client从等待回复队列中取出元素，watch的回调被触发
