Java观察者模式例子

简介:

被观察者的接口类

import java.util.Observer;
/**
 * 气温预报(观察者模式)
 * @author Administrator
 *被观察者接口即subject目标接口气温
 */
public interface Temperature{
	//增加观察者
	public void addObs(Observer o);
	//删除观察者
	public void deleteObs(Observer o);
	//通知观察者
	public void notifyObs(int t);
}

被观察者实现类

/**
 * 具体主题被观察者
 * @author Administrator
 *
 */
public class TemperatureImpl extends Observable implements Temperature {

	@Override
	public synchronized void addObserver(Observer o) {
		super.addObserver(o);
	}

	@Override
	public synchronized void deleteObserver(Observer o) {
		super.deleteObserver(o);
	}

	@Override
	public void notifyObservers(Object arg) {
		super.setChanged();
		super.notifyObservers(arg);
	}
/**
 * 当具体被观察者类集成Observable时这些其实时不需要的,因为在Observable类中其实已经有定义,
 * 上面的重写这些方法已经足够(也可不重写直接调用父类的方法)
 * 如果采用下面的方法就相当于自己实现观察者模式,不用api中提供的类
 * 必须加上相应的Vector obs观察者数组用于存放观察者列表
 */
	@Override
	public void addObs(Observer o) {

	}

	@Override
	public void deleteObs(Observer o) {

	}

	@Override
	public void notifyObs(int t) {

	}

}

观察者接口类

import java.util.Observer;

/**
 * 气温显示(根据气温的实时变化来实时显示)
 * @author Administrator
 *
 */
public interface TemperatureShow extends Observer {

}

观察者实现类

import java.util.Observable;


public class TemperatureShowImpl implements TemperatureShow {
public String tname;

	public String getTname() {
	return tname;
}

public void setTname(String tname) {
	this.tname = tname;
}

	@Override
	public void update(Observable o, Object arg) {
		System.out.println(tname+":"+arg);
	}

}

测试类

public class TestMain{
public static double i=0;
public static void main(String[] args) {
	//创建被观察者
	TemperatureImpl t = new TemperatureImpl();
	//创建观察者1
	TemperatureShowImpl s = new TemperatureShowImpl();
	s.setTname("高温预报");
	t.addObserver(s);
	//创建观察者2
	TemperatureShowImpl s1 = new TemperatureShowImpl();
	s1.setTname("低温预报");
	t.addObserver(s1);
	t.notifyObservers(Math.random());

}
}

这里附上Observable类

/*
 * @(#)Observable.java	1.39 05/11/17
 *
 * Copyright 2006 Sun Microsystems, Inc. All rights reserved.
 * SUN PROPRIETARY/CONFIDENTIAL. Use is subject to license terms.
 */

package java.util;

/**
 * This class represents an observable object, or "data"
 * in the model-view paradigm. It can be subclassed to represent an
 * object that the application wants to have observed.
 * <p>
 * An observable object can have one or more observers. An observer
 * may be any object that implements interface <tt>Observer</tt>. After an
 * observable instance changes, an application calling the
 * <code>Observable</code>'s <code>notifyObservers</code> method
 * causes all of its observers to be notified of the change by a call
 * to their <code>update</code> method.
 * <p>
 * The order in which notifications will be delivered is unspecified.
 * The default implementation provided in the Observable class will
 * notify Observers in the order in which they registered interest, but
 * subclasses may change this order, use no guaranteed order, deliver
 * notifications on separate threads, or may guarantee that their
 * subclass follows this order, as they choose.
 * <p>
 * Note that this notification mechanism is has nothing to do with threads
 * and is completely separate from the <tt>wait</tt> and <tt>notify</tt>
 * mechanism of class <tt>Object</tt>.
 * <p>
 * When an observable object is newly created, its set of observers is
 * empty. Two observers are considered the same if and only if the
 * <tt>equals</tt> method returns true for them.
 *
 * @author  Chris Warth
 * @version 1.39, 11/17/05
 * @see     java.util.Observable#notifyObservers()
 * @see     java.util.Observable#notifyObservers(java.lang.Object)
 * @see     java.util.Observer
 * @see     java.util.Observer#update(java.util.Observable, java.lang.Object)
 * @since   JDK1.0
 */
public class Observable {
    private boolean changed = false;
    private Vector obs;

    /** Construct an Observable with zero Observers. */

    public Observable() {
	obs = new Vector();
    }

    /**
     * Adds an observer to the set of observers for this object, provided
     * that it is not the same as some observer already in the set.
     * The order in which notifications will be delivered to multiple
     * observers is not specified. See the class comment.
     *
     * @param   o   an observer to be added.
     * @throws NullPointerException   if the parameter o is null.
     */
    public synchronized void addObserver(Observer o) {
        if (o == null)
            throw new NullPointerException();
	if (!obs.contains(o)) {
	    obs.addElement(o);
	}
    }

    /**
     * Deletes an observer from the set of observers of this object.
     * Passing <CODE>null</CODE> to this method will have no effect.
     * @param   o   the observer to be deleted.
     */
    public synchronized void deleteObserver(Observer o) {
        obs.removeElement(o);
    }

    /**
     * If this object has changed, as indicated by the
     * <code>hasChanged</code> method, then notify all of its observers
     * and then call the <code>clearChanged</code> method to
     * indicate that this object has no longer changed.
     * <p>
     * Each observer has its <code>update</code> method called with two
     * arguments: this observable object and <code>null</code>. In other
     * words, this method is equivalent to:
     * <blockquote><tt>
     * notifyObservers(null)</tt></blockquote>
     *
     * @see     java.util.Observable#clearChanged()
     * @see     java.util.Observable#hasChanged()
     * @see     java.util.Observer#update(java.util.Observable, java.lang.Object)
     */
    public void notifyObservers() {
	notifyObservers(null);
    }

    /**
     * If this object has changed, as indicated by the
     * <code>hasChanged</code> method, then notify all of its observers
     * and then call the <code>clearChanged</code> method to indicate
     * that this object has no longer changed.
     * <p>
     * Each observer has its <code>update</code> method called with two
     * arguments: this observable object and the <code>arg</code> argument.
     *
     * @param   arg   any object.
     * @see     java.util.Observable#clearChanged()
     * @see     java.util.Observable#hasChanged()
     * @see     java.util.Observer#update(java.util.Observable, java.lang.Object)
     */
    public void notifyObservers(Object arg) {
	/*
         * a temporary array buffer, used as a snapshot of the state of
         * current Observers.
         */
        Object[] arrLocal;

	synchronized (this) {
	    /* We don't want the Observer doing callbacks into
	     * arbitrary code while holding its own Monitor.
	     * The code where we extract each Observable from
	     * the Vector and store the state of the Observer
	     * needs synchronization, but notifying observers
	     * does not (should not).  The worst result of any
	     * potential race-condition here is that:
	     * 1) a newly-added Observer will miss a
	     *   notification in progress
	     * 2) a recently unregistered Observer will be
	     *   wrongly notified when it doesn't care
	     */
	    if (!changed)
                return;
            arrLocal = obs.toArray();
            clearChanged();
        }

        for (int i = arrLocal.length-1; i>=0; i--)
            ((Observer)arrLocal[i]).update(this, arg);
    }

    /**
     * Clears the observer list so that this object no longer has any observers.
     */
    public synchronized void deleteObservers() {
	obs.removeAllElements();
    }

    /**
     * Marks this <tt>Observable</tt> object as having been changed; the
     * <tt>hasChanged</tt> method will now return <tt>true</tt>.
     */
    protected synchronized void setChanged() {
	changed = true;
    }

    /**
     * Indicates that this object has no longer changed, or that it has
     * already notified all of its observers of its most recent change,
     * so that the <tt>hasChanged</tt> method will now return <tt>false</tt>.
     * This method is called automatically by the
     * <code>notifyObservers</code> methods.
     *
     * @see     java.util.Observable#notifyObservers()
     * @see     java.util.Observable#notifyObservers(java.lang.Object)
     */
    protected synchronized void clearChanged() {
	changed = false;
    }

    /**
     * Tests if this object has changed.
     *
     * @return  <code>true</code> if and only if the <code>setChanged</code>
     *          method has been called more recently than the
     *          <code>clearChanged</code> method on this object;
     *          <code>false</code> otherwise.
     * @see     java.util.Observable#clearChanged()
     * @see     java.util.Observable#setChanged()
     */
    public synchronized boolean hasChanged() {
	return changed;
    }

    /**
     * Returns the number of observers of this <tt>Observable</tt> object.
     *
     * @return  the number of observers of this object.
     */
    public synchronized int countObservers() {
	return obs.size();
    }
}
